AF01.40-P-4000AU
Oil leak out of drain opening on left side of engine (cylinder 6)
21.1.98
ENGINE
112 in MODEL 129, 163, 170, 202, 203, 208, 210, 220
ENGINE
113 in MODEL 129, 163, 202, 208, 210, 215, 220
ENGINE
112 in MODEL 463
ENGINE
113 in MODEL 463
Modification notes
23.3.99
Supersedes STIP no. 01.40-004 dated 15.1.98
Validity and cause modified
Damage code
Cause
Remedy
Threaded connection of oil duct in
front of crankcase V is installed without or
with a damaged sealing ring.
Consequently, engine oil in V of crankcase
below intake module. Engine oil flows out of
drain opening on left side of engine behind
cylinder 6 and 8 resp.
1
Remove intake module
2
Replace sealing ring
Parts ordering notes
Part no.
Designation
Quantity
023 997 70 48
Sealing ring
1
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 3722 of 4133
BT27.10-P-0006-01W
Oil pan and overflow tube modified
k
TRANSMISSION
722.901
P27.10-2139-06
To improve fluid supply to the transmission,
the transmission oil pan and the overflow tube
have been redesigned.
The characteristic sloped surface (arrow) can
be used to identify the new oil pan (1). This oil
pan configuration should be installed only
together with the white overflow tube (2).
The fluid temperatures used as references for
checking and refilling are different with the
new components.
Whenever a transmission is removed for repairs, the earlier oil pan (3) with the black overflow
tube (4) should be replaced by the new sloped-surface version (1) with the white overflow tube
(2).
P27.10-2140-03
Copyright DaimlerChrysler AG 28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 3723 of 4133
GF18.40-P-4111-02A
Oil sensor function
n
P18.40-2046-12
B40
Oil sensor (oil level, temperature and quality)
2
Temperature sensor (PT1000)
A
Capacitive measuring range
C 1
Top condenser
C L
Capacitive air
C
OIL
Capacitive engine oil
C 2
Bottom condenser
h
Fill level
Oil level and oil quality are detected on the basis of the capacitance
of the engine oil (dielectric). The oil temperature is detected by the
temperature sensor. All the signals are processed in the electronics
to form a PWM signal and transferred to the engine control unit.
The measuring principle of the oil sensor is a capacitance
measurement, whereby the capacitance is dependent upon the oil
level. The measuring system consists of two cylinder condensers
which possess a metal pipe as a common external electrode. Both
other electrodes are arranged over each other as an inner pipe.
The dielectric constant of the engine oil is determined by the lower
condenser (C
2
) which is always full of oil (
e
approximately 2.3 to 4.0).
The fill level (h) is then determined by the upper condenser (C
1
)
using the dielectric constant. The capacitance of the upper
condenser (C
1
) is calculated on the basis of a parallel connection
with two condensers which have air and engine oil as a dielectric
material.
The condensers are located in a plastic housing which serves as a
damping cup. The engine oil flows through the feed bore holes into
the housing between the condensers.
The measuring range for the oil level is 80 mm
(normal level
F
40 mm), accuracy of measurement approx.
F
3 mm.
The voltage for the oil sensor (approx. 5 V) is supplied by the engine
control unit.
P07.61-0445-05
Signal assignment oil sensor
1
On/off ratio signals
Okay
A
Oil temperature
20 to 80%
B
Oil level
20 to 80%
C
Oil quality
20 to 80%
2
On/off ratio signals
>80 %
A
Oil temperature
> +160 °C
B
Oil level
>80 mm
C
Oil quality
e
>6
3
On/off ratio signals
<20 %
A
Oil temperature
< - 40 °C
B
Oil level
<0 mm
C
Oil quality
e
< 1
T
pulse duty factor
100 %
Each information block consists of three successive square-wave
signals, This is followed by a short pause.
A measured variable is assigned to each square-wave signal (A, B,
C). The quantisizing in each case is based on the on/off ratio (T) of
approx. 20 to 80 %.
Because oil level and oil quality (capacitance of the engine oil) are
dependent of each other, this information is first compensated for in
the engine control unit, before it is transmitted via CAN databus to
instrument cluster.
The following faults at the oil sensor are detected by the engine
control unit and entered in the fault memory:
- Duty cycle of a signal less than 17 % or more than 83 %
- Dielectric constant of engine oil longer than 100 seconds greater
than 5.8 (e.g. because of a lot of water in the engine oil).
Copyright DaimlerChrysler AG 05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 3724 of 4133
GF18.40-P-4111A
Oil sensor, location/task/design/function
15.10.96
ENGINE
111.951 /955 /956 /957 /982
ENGINE
112.910 /911 /912 /913 /914 /916 /917 /920 /921 /922 /923 /940 /941 /942 /943 /944 /946 /947 /949 /9 53 /954 /955
/970 /972 /973 /975
ENGINE
113.940 /941 /942 /943 /948 /960 /961 /963 /965 /966 /967 /968 /969
ENGINE
166.940 /960 /990 /995
P18.40-2104-11
Shown on engine 112, 113 in Model 129, 163, 170, 202, 208, 210,
215, 220
1
Electronics with 3-pin plug connection
B40
Oil sensor (oil level, temperature and quality)
A
Capacitive measuring range at sensor
C
Plug connection
Pin 1: output signal
Pin 2: GND
Pin 3: voltage supply
Oil sensor position
Motor 111.951/ 955
GF18.40-P-4111-01GS
M112113 in Model 129, 163, 170, 202, 208,
210, 215, 220 and model 203, 211with 4MATIC
GF18.40-P-4111-01A
M112, 113 in Model 203, 211 without 4MATIC
and model 209
GF18.40-P-4111-01AA
M166
GF18.40-P-4111-01GC
Oil sensor task
Detecting oil level, oil temperature, oil quality
Oil sensor design
The oil sensor consists of:
D
Electronics with 3-pin connector
D
Capacitive measuring elements
(condensers)
D
Temperature sensor.
Oil sensor function
GF18.40-P-4111-02A
Copyright DaimlerChrysler AG 05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 3725 of 4133
GF18.40-P-4111-01A
Oil sensor position
n
P18.40-0247-06
Location of oil sensor, engine 112, 113 in
model 129, 163, 170, 202, 208, 210, 215, 220
Model 203 with 4MATIC
Model 211 with 4MATIC
B40
Oil sensor (oil level, temperature
and quality)
Copyright DaimlerChrysler AG 05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 3726 of 4133
BB00.40-P-0229-03AMultigrade engine oils (Sheet 229.3)
For use in vehicles/engines refer to
#
Sheet 229.3
Sheet 223.2
BB00.40-P-0223-02A
For specified viscosity grades refer to
#
Sheet 224.1 (passenger-car engines)
BB00.40-P-0224-01A
Sheet 224.2 (commercial-vehicle
engines)
BB00.40-P-0224-02A
Product name
0W-300W-405W-305W-405W-50
Company, town, country
76 Pure Synthetic Motor Oil
X
ConocoPhillips, Costa Mesa, CA, USA
Addinol Extra light MV 038
X
Addinol Lube Oil GmbH, Leuna, Germany
Addinol Super light MV 0546
X
Addinol Lube Oil GmbH, Leuna, Germany
Addinol Super power MV 0537
X
Addinol Lube Oil GmbH, Leuna, Germany
Agip Eurosport
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Agip Extra HTS
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Agip Sint 2000 Evolution
XX
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Agip Sint Turbodiesel Evolution
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Agip Synthetic PC
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Agip Tecsint SL
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Agip Tecsint SX
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Alpine topsynth
X
Mitan Mineralöl GmbH, Ankum, Germany
Antar Excellia LDX 5W40
X
Total Lubrifiants, Paris, France
AP Supreme Premium 9999 Synthetic
X
AP Oil International Ltd, Singapore, Singapore
Aral HighTronic
X
Aral Aktiengesellschaft, Hamburg, Germany
Aral SuperSynth
X
Aral Aktiengesellschaft, Hamburg, Germany
Aral SuperTronic
X
Aral Aktiengesellschaft, Hamburg, Germany
Aral SuperTronic G
X
Aral Aktiengesellschaft, Hamburg, Germany
Autol Carrera
X
Agip Schmiertechnik GmbH, Würzburg, Germany
Aviasynth
X
Avia Mineralöl-AG, Munich, Germany
Azmol Leader
X
Aot Azmol, Berdyansk, Ukraine
Blasol PSP 5W40
X
Blaser Swisslube AG, Hasle-Rüegsau, Switzerland
BP Euro Plus
X
BP p.I.c., London, England
BP Visco 5000
X
BP p.I.c., London, England
BP Visco 5000 Turbo Diesel
X
BP p.I.c., London, England
BP Visco 7000 GM
X
BP p.I.c., London, England
BP Visco 7000 Long Life
X
BP p.I.c., London, England
BP Visco 7000 Special
X
BP p.I.c., London, England
BP Visco 7000 Sport
X
BP p.I.c., London, England
Carl Motorenöl Power
X
Coparts Autoteile GmbH, Essen, Germany
Castrol Formula RS Motorsport 0W-40
X
Castrol Ltd., Swindon, England
Castrol Formula RS Road and Track
X
Castrol Ltd., Swindon, England
Castrol Formula SLX
X
Castrol Ltd., Swindon, England
Castrol Formula SLX LongTec
X
Castrol Ltd., Swindon, England
Castrol Formula SLX Turbo Diesel
X
Castrol Ltd., Swindon, England
Castrol GTX 7 Dynatec
X
Castrol Ltd., Swindon, England
Castrol Performance
X
Castrol Ltd., Swindon, England
Castrol Syntec 0W-30
X
Castrol Ltd., Swindon, England
Castrol Syntec 5W-40
X
Castrol Ltd., Swindon, England
Castrol TXT E.D.I. tec
X
Castrol Ltd., Swindon, England
Castrol TXT Softec
X
Castrol Ltd., Swindon, England
Castrol TXT Softec Plus
X
Castrol Ltd., Swindon, England
Cepsa Star Mega Synthetic
X
Cepsa Lubricantes, S.A., Madrid, Spain
Cepsa Star Mega Synthetic 0W-30
X
Cepsa Lubricantes, S.A., Madrid, Spain
CONCEP-TECH VS
X
Swd Lubricants GmbH & CO. KG, Duisburg, Germany
Consol Ultima
X
Vial Oil Ltd., Moscow, Russia
Cosmo Lio Royal
X
Cosmo Oil Lubricants Co., Ltd, Tokyo, Japan
CPC 9000 MB Motor Oil
X
Chinese Petroleum Corporation, Chia-Yi, Taiwan
DEA Ultec SYN-T
X
Shell & DEA Oil GmbH, Hamburg, Germany
Duckhams Q 5W40 Fully Synthetic
X
BP p.I.c., London, England
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 3727 of 4133
Econo Veritas XL-HC
X
Oelwerke Julius Schindler GmbH, Hamburg, Germany
Elf Excellium LDX 0W30
X
Total Lubrifiants, Paris, France
Elf Excellium LDX 5W40
X
Total Lubrifiants, Paris, France
ENOC Protec X-treme 5W-40
X
ENCO International Sales L.L.C., Dubai, U.A.E.
Esso Megatron 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Esso Ultron
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Esso Ultron (Fuel Economy)
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Esso Ultron 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Esso Ultron Turbo Diesel 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Eurol Futura
X
Eurol Produktionsges.m.b.H, Ried im Innkreis, Austria
Fina First
X
Total Lubrifiants, Paris, France
FormulaShell Ultra
X
Shell International Petroleum Co., London, England
Fuchs Titan Supersyn SL
XXX
Fuchs Petrolub AG, Mannheim, Germany
Fuchs Titan Supersyn SL MB
X
Fuchs Petrolub AG, Mannheim, Germany
Galp Energy Ultra
X
Petrogla S.A., Lisbon, Portugal
Genesis Motor SL/CF 5W40
X
Nippon Oil Corporation, Tokyo, Japan
Gold Chief
X
Shenzhen Sanjiu Fine Chemical Co., Ltd, Shenzhen, P.
R. China
Gulf Formula S (EP)
X
S.A.E.L., Madrid, Spain
Gulf Pride SLV
X
Gulf Oil International, London, England
Habot - Full Synthetic
X
Habot Marketing SA (Pty) Ltd., Krugersdorp, South
Africa
Havoline Synthetic DS
X
ChevronTexaco Technology Ghent, Ghent/Zwijnaarde,
Belgium
Havoline Ultra
X
ChevronTexaco Technology Ghent, Ghent/Zwijnaarde,
Belgium
High Star
X
Addinol Lube Oil GmbH, Leuna, Germany
Igol Process Compact P
X
Igol France, Amiens - cedex 3, France
Igol Process MB, SAE 0W-30
X
Igol France, Amiens - cedex 3, France
Igol Symbol Ceramic 5W40
X
Igol France, Amiens - cedex 3, France
IP Sintiax Motor Oil Extreme
X
ENI S.p.A. - Refining & Marketing Division, Rome, Italy
Jomo Dreamer Motor Oil
X
Japan Energy Corporation, Tokyo, Japan
Kendall GT-1 Full Synthetic Motor Oil
X
ConocoPhillips, Costa Mesa, CA, USA
Kompressol-Super Synth
X
Kompressol-Oel Verkaufs GmbH, Cologne, Germany
Labo RC
X
Fuchs Labo Auto S.A., Rueil-Malmaison, France
Liqui Moly Leichtlauf HD C7
X
Liqui Moly GmbH, Ulm, Germany
Liqui Moly Longtime High Tech
X
Liqui Moly GmbH, Ulm, Germany
Liqui Moly Synthoil Longtime
X
Liqui Moly GmbH, Ulm, Germany
Lotos Economic SL/CF
X
Grupa Lotos SA., Gdansk, Poland
Lotos Syntetic Auto Diesel CF
X
Grupa Lotos SA., Gdansk, Poland
Lotos Syntetic SL/SJ/CF/CD
X
Grupa Lotos SA., Gdansk, Poland
Lotos Trafic SL/CF
X
Grupa Lotos SA., Gdansk, Poland
Lukoil Synthetic
X
OAO Lukoil-Permnefteorgsintez, Perm/Osentsy, Russia
MANNOL Extreme
X
SCT-Vertriebs GmbH, Wedel, Germany
MANNOL Legend + Elser
X
SCT-Vertriebs GmbH, Wedel, Germany
megol Motorenoel New Generation
X
Meguin GmbH & Co. KG Mineraloelwerke, Saarlouis,
Germany
megol Motorenoel Super Leichtlauf
Multisynth
X
Meguin GmbH & Co. KG Mineraloelwerke, Saarlouis,
Germany
Midland Avanza
X
Oel-Brack AG, Hunzenschwil, Switzerland
Mobil 1 0W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil 1 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil 1 5W-50
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil 1 Turbo Diesel 0W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil 1 Turbo Diesel 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil Special X 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil Synt S 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil Synt S Turbo Diesel 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil Syst S
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Mobil Syst S 5W-40X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
Page 3728 of 4133
MOL Dynamic Star 0W-40
X
MOL-LUB Ltd., Almasfüzitö, Hungary
MOL Dynamic Star 5W-40
X
MOL-LUB Ltd., Almasfüzitö, Hungary
Morris Multilife
X
Morris & Co. Ltd., Shrewsbury, England
Motor Gold Highline
X
Mineralöl-Raffinerie Dollbergen GmbH, Uetze-
Dollbergen, Germany
Motor Gold Supertec
X
Mineralöl-Raffinerie Dollbergen GmbH, Uetze-
Dollbergen, Germany
Motor Oil Plus 5W-40
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Motorenoel Ultra Performance Longlife
X
Meguin GmbH & Co. KG Mineraloelwerke, Saarlouis,
Germany
Motorenöl, SAE 5W-40, A 000 989 82 01X
DaimlerChrysler AG, Stuttgart, Germany
Motorex Profile M-XL 0W/30
X
Bucher AG, Langenthal, Switzerland
Motorex Profile M-XL 5W/30
X
Bucher AG, Langenthal, Switzerland
Motorex Select DX
X
Bucher AG, Langenthal, Switzerland
Motorex Select SP-X 0530
X
Bucher AG, Langenthal, Switzerland
Motorex Select SP-X 5W40
X
Bucher AG, Langenthal, Switzerland
Motorex Xperience FS-X
X
Bucher AG, Langenthal, Switzerland
Motorex Xperience FS-X 0W/30
X
Bucher AG, Langenthal, Switzerland
Motul 6100 X-cess 5W-40
X
Motul, Aubervilliers Cedex, France
Motul 8100 E-Tech 0W-40
X
Motul, Aubervilliers Cedex, France
Motul 8100 X-cess 5W-40
X
Motul, Aubervilliers Cedex, France
Motul Specific MB 229.5 5W-30
X
Motul, Aubervilliers Cedex, France
Motul Synergie
X
Motul, Aubervilliers Cedex, France
Motul Synergie Ester + 0W-40
X
Motul, Aubervilliers Cedex, France
Multilub Super Synth
X
Koordination Globus-Betriebe, St. Wendel, Germany
Neste City Pro
X
Fortum Oil and Gas Oy, Fortum, Finland
New Process Fullsynth
X
New-Process AG, Tübach SG, Switzerland
Oest ETA Synthetik
X
Georg Oest Mineralölwerke, Freudenstadt, Germany
OMV full syn
X
OMV Aktiengesellschaft, Vienna, Austria
OMV full syn plus SAE 5W-30
X
OMV Aktiengesellschaft, Vienna, Austria
Opaljet 24 S
X
Unil S.A., Saumur, France
Opet Oxt Formula 5W-40
X
Opet Petrolcülük AS., Cigli/Izmir, Turkey
Optima HC Magnum
X
Oil Refinery Modrica, Modrica, Bosnia-Herzegovina
Optima HC Magnum Plus
X
Oil Refinery Modrica, Modrica, Bosnia-Herzegovina
OWS TXI Syntholube 5W-40
X
OWS, Lohfelden, Germany
Panolin Indy SV
X
Panolin AG, Madetswil, Switzerland
Panolin Racing Synth DC
X
Panolin AG, Madetswil, Switzerland
Pennzoil Performax
X
Pennzoil-Quaker State Mediteraneo, S.L., Madrid, Spain
Pennzoil Synthetic European Formula
X
Pennzoil-Quaker State, Houston, Texas, USA
Pento High Performance 5W40
X
Deutsche Pentosin-Werke GmbH, Wedel, Germany
Pentospeed
X
Deutsche Pentosin-Werke GmbH, Wedel, Germany
Pentospeed 0W-30 VS
X
Deutsche Pentosin-Werke GmbH, Wedel, Germany
Petronas Syntium 3000
X
Petroliam Nasional Berhad, Kuala Lumpur, Malaysia
Petronas Syntium 900
X
Petroliam Nasional Berhad, Kuala Lumpur, Malaysia
Platinum Synthetic SL/CF 0W/30
X
Orlen Oil Sp. z o.o., Krakow, Poland
Platinum Synthetic SL/CF 5W/40
X
Orlen Oil Sp. z o.o., Krakow, Poland
PO Ultra 5W/40
X
Petrol Ofisi Anonim Sirketi, Istanbul, Turkey
Q8 Formula Special
X
Kuwait Petroleum, Hoogvliet RT, Netherlands
Quaker State DeLuxe
X
Oel-Brack AG, Hunzenschwil, Switzerland
Quaker State Full Synthetic European
Formula
X
Pennzoil-Quaker State, Houston, Texas, USA
Quaker State Synquest
XX
Oel-Brack AG, Hunzenschwil, Switzerland
raitec t 5
X
Raiffeisen Central-Genossenschaft Nordwest eG,
Münster, Germany
Ravenol Hydrocrack Synth. HCS SAE
5W-40
X
Ravensberger Schmierstoffvertrieb GmbH, Werther,
Germany
Ravenol VSI SAE 5W-40
X
Ravensberger Schmierstoffvertrieb GmbH, Werther,
Germany
Repsol Elite Competición
X
Repsol YPF Lubricantes y Especialidades, S.A.,
Mostoles-Madrid, Spain
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 3
Page 3729 of 4133
Repsol Elite Cosmos
X
Repsol YPF Lubricantes y Especialidades, S.A.,
Mostoles-Madrid, Spain
ROWE Synth RS 5W40 i
X
ROWE Mineralölwerk GmbH, Bubenheim, Germany
S-Tronic
X
Kuttenkeuler GmbH, Cologne, Germany
Selenia Digitech
X
FL Italia s.p.a., Villastellone (Torino), Italy
Selenia Perform
X
FL Selenia s.p.a., Villastellone (Torino), Italy
Selenia WR 5W-40
X
FL Selenia s.p.a., Villastellone (Torino), Italy
Shell Helix Diesel Ultra
XX
Shell International Petroleum Co., London, England
Shell Helix Plus G-B025
X
Shell International Petroleum Co., London, England
Shell Helix Plus S
X
Shell International Petroleum Co., London, England
Shell Helix Ultra
XXX
Shell International Petroleum Co., London, England
Shell Helix Ultra AB
X
Shell International Petroleum Co., London, England
Statoil LazerWay 5W40
X
Statoil Lubricants, Stockholm, Sweden
Statoil LazerWay X
X
Statoil Lubricants, Stockholm, Sweden
swd Primus HDC
X
Swd Lubricants GmbH & Co. KG, Duisburg, Germany
swd Primus Ultra
X
Swd Lubricants GmbH & Co. KG, Duisburg, Germany
swd Primus VS
X
Swd Lubricants GmbH & Co. KG, Duisburg, Germany
Syncon High Performance Synthetic
X
ConocoPhillips International Inc., Singapore, Singapore
Synt 5W/40
X
Hunold Schmierstoffe GmbH, Eching, Germany
Synt-XL; SAE 5 W 40
X
Hubert Math. Müller Handelsgesellschaft mbH,
Eschweiler, Germany
Tamoil Sint Future Prestige (I)
X
Tamoil Petroli S.p.A., Milan, Italy
Tamoil Sint Future Racing
X
Tamoil Petroli S.p.A., Milan, Italy
Teboil Diamond Plus
X
Suomen Petrooli Oy, Hamina, Finland
Top Evolution
X
TOP OIL Products Company, Burlingame, CA, USA
Tor Hypersynth
X
De Oliebron B.V., Zwijndrecht, Netherlands
Total activa 9000
X
Total Lubrifiants, Paris, France
Total quartz 9000
X
Total Lubrifiants, Paris, France
Triathlon Sprint
X
Adolf Würth GmbH & Co. KG, Künzelsau, Germany
Ultra - Synth 4000
X
Profi-Tech chem. tech. Produkte GmbH, Gingen,
Germany
Ultrasyn Plus
X
Kuttenkeuler GmbH, Cologne, Germany
Unil Opal Opaljet 32 S
X
Unil S.A., Saumur, France
Unil Synth
X
Unil Germany GmbH, Stuttgart, Germany
Unimot Synth 9
X
GB Lubricants Limited, Gateshead, England
Unoil GX-7
X
Exxon Mobil Corporation, Fairfax, Virginia, USA
Valvoline Durablend MXL
X
The Valvoline Company, Dordrecht, Netherlands
Valvoline SynPower
X
The Valvoline Company, Dordrecht, Netherlands
Valvoline SynPower 0W-40
X
The Valvoline Company, Dordrecht, Netherlands
Valvoline SynPower 5W-40
X
The Valvoline Company, Dordrecht, Netherlands
Valvoline SynPro 5W-40
X
The Valvoline Company, Dordrecht, Netherlands
Valvoline SynPro motor oil
X
The Valvoline Company, Dordrecht, Netherlands
Veedol Powertron
X
Veedol International, Swindon, England
Veedol Syntron
X
Veedol International, Swindon, England
Wako's ex Synthe
X
Wako Chemical Co. Limited, Kanagawa / Japan
Westfalen Gigatron
X
Westfalen AG, Münster, Germany
Wintershall ViVA 1 LonglifeX
SRS Schmierstoff Vertrieb GmbH, Salzbergen, Germany
Wintershall ViVA 1 topsynth
X
SRS Schmierstoff Vertrieb GmbH, Salzbergen, Germany
Wintershall ViVA 1 topsynth alpha
X
SRS Schmierstoff Vertrieb GmbH, Salzbergen, Germany
Wolf Masterlube Synflow DC
X
Wolf Oil Corporation N.V., Hemiksem, Belgium
Wolf Masterlube Synflow Plus
X
Wolf Oil Corporation N.V., Hemiksem, Belgium
Yacco VX 1000
X
Yacco SAF, Saint-Pierre-lès-Elbeuf, France
Yacco VX 600
X
Yacco SAF, Saint-Pierre-lès-Elbeuf, France
York 748
X
Ginouves Georges S.A., La Farlède, France
ZIC XQ
X
SK Corporation, Seoul, Rep. of Korea
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 4
Page 3730 of 4133
GF77.20-P-2003GH
Opening pop-up roof, function
19.2.97
MODEL
163 with CODE (414a) Electric glass sliding/pop-up roof
Function prerequisites
D
Voltage not too low or too high
D
Switch-on conditions for convenience control fulfilled
D
Sliding/pop-up roof synchronized
Function
When
switch (SHD, S13/2)
is actuated continuously, circuit 30 is
switched through to the
sliding/pop-up roof (M12)
and the pop-up
roof opens.
The function "Open pop-up roof" is executed as long as
D
switch (SHD, S13/2)
is actuated and
D
the pop-up roof has not yet reached the end position and
D
lock-up is not recognized.
If the sliding/pop-up roof is desynchronized, it moves only in the pop-
up roof direction each time the
switch (SHD, S13/2)
is actuated. This
means that it is possible to move to the zero
position for synchronizing. After successful
synchronization
, the
sliding/pop-up roof can be controlled again without limitation.
Vehicles
up to 11.99:
The power for the
sliding/pop-up roof (M12)
is supplied via a
fuse directly to c. 30.
The power for the
switch (SR, S13/2)
is supplied via the
convenience relay (F1k14)
, which is actuated by the all-
activity module (AAM, N10).
Vehicles
as of 12.99:
The power for the
sliding/pop-up roof (M12)
is supplied via a
fuse directly to c. 30. The power for the
switch (SHD, S13/2) is
supplied via a lead to the
extended-activity module (EAM,
N10/1) , this power is switched through only when the switch-on
conditions for the convenience control are fulfilled and the EAM
is coded accordingly.
Closing sliding /pop-up roof, function
GF77.20-P-2002GH
Sliding /pop-up roof lock-up recognition,
function
GF77.20-P-3000GH
Sliding /pop-up roof position measurement,
function
GF77.20-P-3001GH
Synchronizing sliding /pop-up roof, function
GF77.20-P-3002GH
Convenience control
GF72.29-P-2002GH
All-activity module (AAM)
up to 11.99
GF54.21-P-4100GH
Extended-activity module, location/
purpose/design/function
as of 12.99
GF54.21-P-4107GK
Copyright DaimlerChrysler AG 04.08.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
