Index ....................................................... 4Introduction ......................................... 19At a glance ........................................... 25Safety ................................................... 35Opening and closing ...........................73Seats, steering wheel and mirrors ....97Lights and windshield wipers ..........115Climate control ................................. 131Driving and parking ..........................147On-board computer and displays ....197Loading, stowing and features ........245Maintenance and care ......................277Roadside Assistance ........................291Tires and wheels ............................... 319Technical data ................................... 347
Contents3BA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 3

Customer Relations Department ....... 22
D
Dashboard see Cockpit
Date (on-board computer) ................ 206
Daytime driving lights Display message ............................ 223
Switching on/off (on-board
computer) ...................................... 206
Delayed switch-off
Exterior lighting (on-board
computer) ...................................... 207
Interior lighting (on-board
computer) ...................................... 208
Diesel particle filter .......................... 169
Digital speedometer Displaying ...................................... 202
Setting the unit (on-board
computer) ...................................... 205
DIRECT SELECT lever
see Automatic transmission
Display (cleaning instructions) ........ 287
Display messages Brakes ........................................... 219
Calling up (on-board computer) .....213
Clearing (on-board computer) ........213
Driving systems ............................. 228
Engine ............................................ 224
Lamps ............................................ 224
Safety systems .............................. 214
Service interval display ..................282
Tires ............................................... 230
Vehicle ........................................... 233
Distance recorder ............................. 202
Distance warning function
(vehicles with DISTRONIC) ................. 70
Activating/deactivating (on-
board computer) ............................ 210
Distance warning lamp ..................... 243
DISTRONIC ......................................... 175
Display message ............................ 229
Displays in the multifunction
display ........................................... 180
Driving tips .................................... 181
Setting the specified minimum
distance ......................................... 179
Warning lamp ................................. 243
Door
Automatic locking ............................ 81
Automatic locking (on-board
computer) ...................................... 208
Display message ............................ 234
Emergency locking ........................... 82
Emergency unlocking .......................82
Opening (from inside) ......................81
Door control panel
Overview .......................................... 33
Doors
Important safety notes ....................80
Drinking and driving ......................... 169
Drinks holder see Cup holder
Drive program
Automatic ...................................... 158
Driving abroad ................................... 173
Driving on flooded roads .................. 172
Driving safety system EBD (Electronic Brake force
Distribution) ..................................... 70
ESP ®
(Electronic Stability
Program) .......................................... 68
Important safety information ...........67
Driving safety systems
4ETS (Electronic Traction System) ...69
ABS (Anti-lock Braking System) .......67
BAS (Brake Assist System) ..............68
Distance warning system
(vehicles with DISTRONIC) ...............70
Overview .......................................... 67
Driving systems
Blind Spot Assist ............................ 191
Cruise control ................................ 173
DISTRONIC .................................... 175
Level control .................................. 183
PARKTRONIC ................................. 186
Rear axle level control ...................182
Rear view camera .......................... 189
Driving tips ........................................ 157
DISTRONIC .................................... 181
Downhill gradients .........................170
Driving on flooded roads ................172Index7BA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 7

Steering wheel heating ..................110
Storing settings (memory
function) ........................................ 114
Steering wheel heating
Indicator lamp (Malfunction) ..........110
Steering wheel paddle shifters ........ 158
Stowage compartments 3rd row of seats ............................. 248
Armrest (under) ............................. 248
Center air vents (2nd row of
seats) ............................................. 248
Center console (2nd row of seats) . 248
Glove box ....................................... 247
Stowage space
Center console .............................. 247
Cup holders ................................... 260
Important safety information .........246
Submenu (on-board computer)
Convenience .................................. 209
Instrument cluster .........................205
Lighting .......................................... 206
Time/Date ..................................... 206
Vehicle ........................................... 208
Summer opening
see Convenience opening feature
Sun visor ............................................ 262
Supplemental Restraint System see SRS
Surround lighting (on-board
computer) .......................................... 207
SUV (Sport Utility Vehicle) .......................21
Switching off the alarm (ATA) ............ 71
T
Tachometer ........................................ 198
Tailgate Display message ............................ 234
Important safety guidelines .............82
Limiting the opening angle ...............86
Taillight
see Tail lamps
Tank contents
Gauge .............................................. 28
Technical data ................................... 348
R 350 ............................................. 358
R 350 BlueTEC ............................... 357
Tires/wheels ................................. 343
TELEAID
Call priority .................................... 271
Display message ............................ 215
Downloading destinations
(COMAND) ..................................... 271
Emergency call .............................. 268
Important safety notes ..................267
Locating a stolen vehicle ...............272
MB info call button ........................270
Roadside Assistance button ..........269
Self-test ......................................... 268
System .......................................... 268
Vehicle remote unlocking ..............272
Telephone
Accepting a call ............................. 211
Display message ............................ 234
Menu (on-board computer) ............211
Number from the phone book ........ 212
Redialing ........................................ 212
Rejecting/ending a call .................212
Temperature
Coolant (on-board computer) ......... 202
Displaying the outside
temperature ................................... 202
Outside temperature ...................... 198
Setting ........................................... 141
Theft deterrent locking system
Immobilizer ...................................... 71
Tilt/sliding sunroof
Opening/closing .............................. 92
Resetting ......................................... 93
Time (on-board computer) ................ 206
TIREFIT kit .......................................... 297
Tire pressure Calling up (on-board computer) .....327
Checking manually ........................325
Display message ............................ 230
Maximum ....................................... 330
Notes ............................................. 323
Not reached (TIREFIT) ....................300
Pressure loss warning ....................325
Reached (TIREFIT) ..........................300
Recommended ............................... 322
Tire pressure monitor
Warning lamp ................................. 243Index15BA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 15

Tire pressure monitoring systemFunction/notes ............................. 327
Restarting ...................................... 329
Tires
Aspect ratio (definition) .................342
Average weight of the vehicle
occupants (definition) ....................340
Bar (definition) ............................... 340
Characteristics .............................. 340
Checking ........................................ 321
Cleaning ......................................... 322
Definition of terms .........................340
Direction of rotation ......................334
Distribution of the vehicle
occupants (definition) ....................343
DOT, Tire Identification Number
(TIN) ............................................... 339
DOT (Department of
Transportation) (definition) ............340
Flat tire .......................................... 296
GAWR (Gross Axle Weight Rating)
(definition) ..................................... 341
GTW (Gross Trailer Weight)
(definition) ..................................... 341
Guidelines to be observed .............321
GVW (Gross Vehicle Weight)
(definition) ..................................... 341
GVWR (Gross Vehicle Weight
Rating) (definition) .........................341
Increased vehicle weight due to
optional equipment (definition) ......340
Kilopascal (kPa) (definition) ...........341
Labeling (overview) ........................336
Load bearing index (definition) ......342
Load index ..................................... 339
Load index (definition) ...................341
Maximum loaded vehicle weight
(definition) ..................................... 341
Maximum load on a tire
(definition) ..................................... 342
Maximum permissible tire
pressure (definition) ....................... 341
Maximum tire load .........................334
Maximum tire loading (definition) ..341
Optional equipment weight
(definition) ..................................... 342
PSI (pounds per square inch)
(definition) ..................................... 342Replacing ....................................... 336
Service life ..................................... 321
Sidewall (definition) .......................342
Speed index (definition) .................341
Storing ........................................... 322
Structure and characteristics
(definition) ..................................... 340
Temperature .................................. 335
TIN (Tire Identification Number)
(definition) ..................................... 342
Tire bead (definition) ......................342
Tire pressure (definition) ................342
Tire pressures (recommended) ......340
Tire quality classes ........................334
Tire size (data) ............................... 343
Tire size designation, load-bearing
capacity, speed index ....................337
Tire tread ....................................... 321
Tire tread (definition) .....................342
Total load limit (definition) .............343
Traction ......................................... 335
Traction (definition) .......................342
Tread wear ..................................... 335
TWR (permissible trailer drawbar
noseweight) (definition) .................342
Uniform tire quality classification
standards (definition) .....................340
Unladen weight (definition) ............341
Wear indicator (definition) .............342
Wheel rim (definition) ....................341
Tires and wheels (important safety
information) ....................................... 320
Top Tether ............................................ 63
Towing Important safety guidelines ...........313
Towing a trailer
Driving tips .................................... 193
Towing away
Installing the towing eye ................313
Removing the towing eye ...............314
Trailer
Coupling up ................................... 193
Decoupling ..................................... 195
Display message ............................ 221
Power supply ................................. 196
Towing ........................................... 194
Trailer loads and drawbar
noseweights ...................................... 19616IndexBA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 16

Contact an authorized Mercedes-Benz Center
for repairs or modifications to electronic
components.
Other improper work or modifications on the
vehicle could also have a negative impact on
the operating safety of the vehicle.
Some safety systems only function when the
engine is running. You should therefore never
turn off the engine while driving.GWarning
Heavy blows against the vehicle underbody or
tires/wheels may cause serious damage and
impair the operating safety of your vehicle.
Such blows can be caused, for example, by
running over an obstacle, road debris or a
pothole. If you feel a sudden significant
vibration or ride disturbance, or you suspect
that damage to your vehicle has occurred:
R turn on your hazard warning flashers.
R slow down carefully.
R drive with caution to an area which is a safe
distance from the road.
Inspect the vehicle underbody and tires/
wheels for possible damage. If the vehicle
appears unsafe, have it towed to the nearest
authorized Mercedes-Benz Center or other
qualified maintenance or repair facility for
further inspection or repairs.
Proper use of the vehicle
To ensure proper use of the vehicle, you must
familiarize yourself with the following
information and rules:
R safety notes in this Operator's Manual
R technical data in this Operator's Manual
R traffic rules and regulations
R laws and safety standards pertaining to
motor vehicles
GWarning!
Various warning labels are attached to your
vehicle. These warning labels are intended to
make you and others aware of various risks.
Do not remove any of these warning labels
unless explicitly instructed to do so by
information on the label itself.
Removing warning labels may cause you and
others to be unaware of certain risks which
may result in an accident and/or personal
injury.GWarning!
HYBRID vehicles: It is imperative that you read
the HYBRID Supplemental Operating
Instructions included in your vehicle literature
portfolio. You may otherwise not receive all
necessary safety information and warning for
the operation of your vehicle.
Problems with your vehicle
If you should experience a problem with your
vehicle, particularly one that you believe may
affect its safe operation, we urge you to
contact an authorized Mercedes-Benz Center
immediately to have the problem diagnosed
and rectified. If the problem is not resolved to
your satisfaction, please discuss the problem
with the Mercedes-Benz Center again or, if
necessary, contact us at one of the following
addresses.
In the USA
Customer Assistance Center
Mercedes-Benz USA, LLC
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada
Customer Relations Department
Mercedes-Benz Canada, Inc.
98 Vanderhoof Avenue
Toronto, Ontario M4G 4C9
22IntroductionBA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 22

Exterior viewFunctionPage:TailgateVehicle tool kit294;Rear window defroster143=Lights121?Fuel filler flap160AExterior mirrors112BSliding sunroof91CDefrosting the windshield142Cleaning the windows286FunctionPageDWindshield wipers126EOpening the hood278Engine oil279Coolant281FTowing313GTires and wheels320Flat tire29626Exterior viewAt a glance
BA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 26

orXPress the KEYLESS-GO Start-Stop button.
The KEYLESS-GO key must be in the
vehicle.
i USA only:
This device complies with the part 15 of the
FCC regulations. Operation is subject to
the following two conditions:
1. This device may not cause interference,
and
2. This device must withstand any
interference received, including
interference that may cause undesired
operation.
Any unauthorized modification to this
device could void the user's authority to
operate the equipment.
i Canada only:
This device complies with the RSS-210
regulations of Industry Canada. Operation
is subject to the following two conditions:
1. This device may not cause interference,
and
2. This device must withstand any
interference received, including
interference that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user's authority to
operate the equipment.
Driving safety systems
Overview of driving safety systems
In this section, you will find information about
the following driving safety systems:
R ABS ( Anti-lock Braking System)
R BAS ( Brake Assist System)
R ESP ®
(E lectronic Stability Program)
R EBD ( Electronic Brake-power Distribution)
Important safety guidelinesGWarning
The following factors increase the risk of
accidents:
R Excessive speed, especially in turns
R Wet and slippery road surfaces
R Following another vehicle too closely
The driving safety systems described in this
section cannot reduce these risks or prevent
the natural laws of physics from acting on the
vehicle. They cannot increase braking or
steering efficiency beyond that afforded by
the condition of the vehicle brakes and tires
or the traction afforded.
Only a safe, attentive, and skillful driver can
prevent accidents.
The capabilities of a vehicle equipped with the
driving safety systems described in this
section must never be exploited in a reckless
or dangerous manner which could jeopardize
the user's safety or the safety of others.
Always adjust your driving style to the
prevailing road and weather conditions and
keep a safe distance to other road users and
objects on the street.
If a driving system malfunctions, other driving
safety systems may also switch off. Observe
indicator and warning lamps that may come
on as well as messages in the multifunction
display that may appear.
i In wintry driving conditions, always use
winter tires (M+S tires) and if necessary,
snow chains. Only in this way will the
driving safety systems described in this
section work as effectively as possible.
ABS (Anti-lock Braking System)
Important safety information
GWarning
Observe "Important safety instructions"
( Y page 67).
Driving safety systems67SafetyBA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 67Z

XTo apply: depress parking brake ; firmly.
When the engine is running, the $ (USA
only) or J (Canada only) indicator lamp
lights up in the instrument cluster.XTo release: depress the brake pedal and
keep it depressed.XPull release handle :.
When the ignition is switched on or the
engine is running, the $ (USA only) or
J (Canada only) indicator lamp goes out
in the instrument cluster.
Parking up the vehicle
If you leave the vehicle parked up for longer
than four weeks, the battery may be damaged
by exhaustive discharge.
XDisconnect the battery or connect it to a
trickle charger.
i You can obtain information about trickle
chargers from a qualified specialist
workshop, e.g. an authorized Mercedes-
Benz Center.
If you leave the vehicle parked up for longer
than six weeks, the vehicle may suffer
damage as a result of lack of use.
XVisit a qualified specialist workshop and
seek advice.Driving tips
General driving tips
Important safety instructions
GWarning!
Please do not forget that your primary
responsibility is to drive the vehicle. A driver’s
attention to the road must always be his/her
primary focus when driving. For your safety
and the safety of others, we recommend that
you pull over to a safe location and stop
before placing or taking a telephone call.
If you choose to use the telephone 25
while
driving, please use the hands-free device and
only use the telephone when road, weather
and traffic conditions permit. Some
jurisdictions prohibit the driver from using a
mobile telephone while driving a vehicle.
Only operate the COMAND 25
(Cockpit
Management and Data System) if road,
weather and traffic conditions permit.
Otherwise, you may not be able to observe
traffic conditions and could endanger yourself
and others.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximately
14 m) every second.
Drive sensibly – save fuel
To save fuel, observe the following notes:
XKeep tires at the recommended inflation
pressures.XRemove unnecessary cargo.XRemove the roof carrier when not in use.XMaintain a low engine speed until the
engine is warm.XAvoid frequent acceleration and
deceleration.XHave all maintenance work performed at
the service intervals specified in the25 Observe all legal requirements.168Driving tipsDriving and parking
BA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 168

too low. Observe additional warning
messages in the multifunction display.
The brake fluid level may be too low due to
brake pad wear or leaking brake lines.
Have the brake system checked
immediately. This work should be carried
out at an authorized Mercedes-Benz
Center.
All checks and maintenance work on the
brake system must be carried out at a
qualified specialist workshop. Contact an
authorized Mercedes-Benz Center.
Only install brake pads and use brake fluid
recommended by Mercedes-Benz.GWarning
If other than recommended brake pads are
installed, or other than recommended brake
fluid is used, the braking properties of the
vehicle can be degraded to an extent that safe
braking is substantially impaired. This could
result in an accident.
! A function or performance test may only
be carried out on a two-axle dynamometer.
If you are planning to have the vehicle
tested on such a dynamometer, contact an
authorized Mercedes-Benz Center to
obtain further information first. Otherwise,
the drive train or the brake system may
suffer damage.
! As the ESP ®
system operates
automatically, the engine and the ignition
must be switched off (SmartKey in position
0 or 1 in the ignition lock or Start/Stop
button in position 0 or 1) while the parking
brake is being tested on a brake
dynamometer (maximum 10 seconds).
Braking maneuvers triggered automatically
by ESP ®
may seriously damage the brake
system.
If your brake system is only subjected to
moderate loads, you should regularly test
your brake system's function by forcefully
depressing the brake pedal when driving at
high speed. This also improves the brake
pads' friction.GWarning
Make sure that you do not endanger other
road users when you apply the brakes.
You can find a description of Brake Assist
(BAS) on ( Y page 68).
Parking brake
If you drive on wet roads or dirt-covered
surfaces, road salt and/or dirt could get into
the parking brake.
In order to prevent corrosion and a reduction
in the braking power of the parking brake,
observe the following:
R gently depress the parking brake from time
to time before beginning the journey.
R drive approximately 110 yd (100 m)
without exceeding a speed of 12 mph
(20 km/h).
GWarning!
While performing this procedure please
assure that the vehicle is stopped before
applying the parking brake. Otherwise the
rear wheels could lock up. You could lose
control of the vehicle and cause an accident.
In addition, the vehicle’s brake lights do not
light up when the parking brake is engaged.
Make sure not to endanger any other road
users when you engage the parking brake.
Driving on wet roads
Hydroplaning
If water has accumulated to a certain depth
on the road surface, there is a danger of
hydroplaning occurring, even if:
R you drive at low speeds
R the tires have adequate tread depth
Driving tips171Driving and parkingBA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 171Z

you use winter tires (M+S tires), with snow
chains if necessary.
! When testing the parking brake, operate
the vehicle only briefly (for a maximum of
ten seconds) on a brake test dynamometer.
When doing this, turn the key to position
0 or 1 in the ignition. Failure to do this can
cause damage to the drive train or the
brake system.
! Function or performance tests may only
be performed on a 2-axle dynamometer. If
you wish to operate the vehicle on such a
dynamometer, please consult an
authorized Mercedes-Benz Center
beforehand. You could otherwise damage
the drive train or the brake system.
PARKTRONIC
Important safety guidelines
GWarning!
The PARKTRONIC is a supplemental system.
It is not intended to, nor does it replace, the
need for extreme care. The responsibility
during parking and other critical maneuvers
always remains with the driver.
GWarning!
Make sure no persons or animals are in or
near the area in which you are parking/
maneuvering. Otherwise, they could be
injured.
PARKTRONIC is an electronic parking aid with
ultrasonic sensors. It indicates visually and
audibly the distance between your vehicle
and an object.
PARKTRONIC is activated automatically when
you:
R switch on the ignition.
R shift the transmission to position D, R or
N .
R release the parking brake.
PARKTRONIC is deactivated at speeds above
11 mph (18 km/h). It is reactivated at lower
speeds.
PARKTRONIC monitors the area around your
vehicle using six sensors in the front bumper
and four sensors in the rear bumper.:Sensors in the front bumper, left-hand
side (example)
Range of the sensors
The sensors must be free of dirt, ice and
slush; otherwise they may not function
correctly. Clean the sensors regularly, taking
care not to scratch or damage them
( Y page 287).
Side view
186Driving systemsDriving and parking
BA 251 USA, CA Edition A 2011; 1; 3, en-USd2sboikeVersion: 3.0.3.52010-04-16T14:31:55+02:00 - Seite 186
