MERCEDES-BENZ R350 2008 W251 Owner's Manual

180 Controls in detail
Control system
Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain on for
10 seconds during darkness after you have
removed the SmartKey from the starter
switch.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Interior Lighting
Delayed Shut-off
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the interior lighting delayed shut-off
feature
On or Off.Vehicle submenu
Access the
Vehicle submenu via the
Settings menu. Use the Vehicle submenu
to make general vehicle settings.
The following functions are available:Compass adjustment
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Determine your location on the basis of the
following zone maps.
Zone map North America
FunctionPage
Compass adjustment180
Compass calibration181
Audio search function182
Setting automatic locking183
Limiting opening height of
tailgate*183

181 Controls in detail
Control system
Zone map South America
Press buttonæ orç to move
the selection marker to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Compass Setting
Zone
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to set the
respective compass zone.
For information on how to call up the
compass, see “Compass” (
page 334).Compass calibration
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
In order to calibrate the compass properly,
mind the following:

Calibrate the compass in open terrain.
Nearby buildings, bridges, power lines
and large antenna masts, for example,
could impair compass calibration.

Switch off electrical consumers (e.g.
climate control, windshield wipers, or
rear window defroster).

Close all doors and the tailgate.
Start the engine (page 53).
Press buttonæ orç to move
the selection marker to the
Vehicle
submenu.
iMake sure you are in an area where you can
drive a full circle with your vehicle without dis-
turbing traffic in order to calibrate your compass.


182 Controls in detail
Control system
Press buttonj ork repeatedly
until the message
Compass Calibra-
tion
appears in the multifunction
display.
The selection marker is on setting
Off.
Press buttonæ to set the selection
marker to
Start.
The following message appears in the
multifunction display:
Compass Calibration Active
Please drive in a full circle
.
Drive a full circle at a vehicle speed
of between 3 mph and 6 mph
(5 km/h and 10 km/h).
When calibration was successful, the
following message appears in the
multifunction display:
Compass Calibration
Completed Successfully
Audio search function
Use of the Audio search function to
select a radio station (
page 166) will
enable you to start a frequency scan
(
Frequency) or select a radio station stored
in memory (
Memory).
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Audio Search
Function
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
Frequency or Memory.
iIf the message Compass Calibration
Completed Successfully
does not appear in
the multifunction display, drive another full
circle.
If calibration does not succeed within 3 minutes,
the message
Compass Calibration appears
in the multifunction display again. Calibrating the
compass has failed due to outside influences.
Repeat compass calibration in a different
location.


183 Controls in detail
Control system
Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked
at vehicle speeds of approximately
9mph(15km/h).
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Automatic Door
Locking
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the automatic central locking
On or Off.Limiting opening height of tailgate*
Use this function to activate or deactivate
the limiting opening height of the tailgate.
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Opening Limiter
Tailgate
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the limiting opening height of the
tailgate
On or Off.Comfort submenu*
Access the
Comfort submenu via the
Settings menu. Use the Comfort submenu
to change the settings for a number of con-
venience features.
The following functions are available:
FunctionPage
Activating easy-entry/exit
feature*184
Setting fold-in function for
exterior rear view mirrors*184

184 Controls in detail
Control system
Activating easy-entry/exit feature*
Use this function to activate and
deactivate the easy-entry/exit feature
(
page 128).
Move the selection marker with
buttonæ orç to the
Comfort
submenu.
Press buttonj ork repeatedly
until the message
Easy-entry
Function
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the easy-entry/exit feature
On or Off.Setting fold-in function for exterior rear
view mirrors*
Using this function, you can set the
exterior rear view mirrors to be automati-
cally folded in when you lock your vehicle.
Warning!G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To stop steering wheel movement, do one of
the following:

Move steering wheel adjustment stalk*
(
page 47).

Press one of the stored position
buttons* or memory button M*
(
page 141).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
iWith this function set to On and the exterior
rear view mirrors folded in using the button on
the door control panel (
page 205), the exterior
rear view mirrors will not fold out when you
switch on the ignition. You will then have to fold
out the exterior rear view mirrors using the
button on the door control panel (
page 205).
Make sure both exterior rear view mirrors are
folded out completely before driving off.

185 Controls in detail
Control system
Move the selection marker with
buttonæ orç to the
Comfort
submenu.
Press buttonj ork repeatedly
until the message
Fold In Mirrors
When Locking
appears in the multi-
function display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the function
On or Off.
Distance warning function*
In vehicles equipped with Distronic*, you
can determine whether the distance warn-
ing function* is to be enabled or disabled.
With this function set to
On, the system will
alert you when recognizing a stationary ob-
stacle or a slower vehicle moving in your
vehicle’s path and the danger of a collision
exists, even when the Distronic* is
switched off.
Press buttonè orÿ repeatedly
until the message
Distance Warning
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the distance warning function
On or
Off.
Trip computer menu
Use the trip computer menu to call up
statistical data on your vehicle.
The following information is available:
FunctionPage
Fuel consumption statistics
since start186
Fuel consumption statistics
since last reset186
Resetting fuel consumption
statistics186
Distance to empty187
iWhen you enter the trip computer menu, you
will always see the fuel consumption statistics
since start first.

186 Controls in detail
Control system
Fuel consumption statistics since start
Press buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since startFuel consumption statistics since last
resetPress buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonj ork repeatedly
until the message
From Reset appears
in the multifunction display.
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last
resetResetting fuel consumption statistics
Press buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonj ork repeatedly
until the fuel consumption statistics
which you want to reset appear in the
multifunction display.
Press and hold the reset button in the
instrument cluster (
page 154) until
the respective values are reset to
0.
iAll statistics stored since the last engine
start will be reset approximately 4 hours after
the SmartKey in the starter switch is turned to
position0 or removed from the starter switch.
Resetting will not occur if you turn the SmartKey
back to position1 or2 within this time period.
iThe fuel consumption statistics reset auto-
matically to
0 when either of the following values
is exceeded:

distance covered: 100 000 miles

time elapsed: 10 000 hours

187 Controls in detail
Control system
Distance to empty
Press buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonj ork repeatedly
until the message
Range: appears in
the multifunction display.
The calculated remaining driving range
based on the current fuel tank level
appears in the multifunction display.
TEL menu*
You can use the functions in the
TEL menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.
Switch on the telephone and COMAND
system.
Press buttonÿ orè on the
multifunction steering wheel repeat-
edly until the message
TEL appears in
the multifunction display.
iIf only very little fuel is left in the tank, a
vehicle at the fuel pump is shown instead of the
range.
Warning!G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we
recommend that you pull over to a safe
location and stop before placing or taking a
telephone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road and traffic
conditions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a
vehicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system,
possibly resulting in an accident and/or
personal injury.

188 Controls in detail
Control system
Which messages will appear in the multi-
function display depends on whether your
telephone is switched on or off:

If the telephone is off, the message
TEL off appears in the multifunction
display.

If the telephone is on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network, the message
Ready appears in
the multifunction display.
This standby message indicates that your
telephone is ready for use and you can
operate it using the control system.Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will then see
the following message or, if available, the
caller ID (name and number):Press buttons.
You have answered the call.
The duration of the call appears in the
multifunction display.Ending a call or rejecting an incoming
call
Press buttont.
Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.
Press buttonÿ orè repeatedly
until the message
TEL appears in the
multifunction display.
Press buttonj ork.
The control system reads the phone
book which is stored in the telephone.
This may take several minutes. The
message
Please wait appears in the
multifunction display.
When the message
Please wait
disappears, the phone book has been
loaded.

189 Controls in detail
Control system
Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in
ascending or descending alphabetical
order.
1Name from the phone bookPress buttons.
The system dials the selected phone
number.

If the connection is successful and
this feature is supported by your
network provider, the name of the
party you are calling (if stored in
your phone book) and the duration
of the call will appear in the multi-
function display.

If no connection is made, the
control system stores the dialed
number in the redial memory.Redialing
The control system stores the most
recently dialed phone numbers. This
eliminates the need to search through your
entire phone book.
Press buttonÿ orè repeatedly
until the message
TEL appears in the
multifunction display.
Press buttons.
The first number in the redial memory
appears in the multifunction display.
Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.
Press buttons.
The control system dials the selected
phone number.
iIf you press and holdj ork for
longer than 1 second, the system scrolls rapidly
through the list of names until you release the
button again.
Cancel the quick search mode by pressing
buttont.
