turn signal MERCEDES-BENZ S-Class 2008 W221 Comand Manual

Contents
Multicontour seats*, rear ............. 383
Easy-entry/exit feature ................ 384
Steering wheel ................................... 386
Steering wheel adjustment........... 386
Heated steering wheel* ............... 387
Mirrors ............................................... 388
Interior rear view mirror ............... 388
Exterior rear view mirrors ............. 388
Power folding exterior rear
view mirrors ................................. 389
Auto-dimming rear view mirrors ... 390
Activating exterior rear
view mirror parking position ......... 391
Memory function................................ 392
Storing positions into memory ..... 393
Recalling positions from memory . 393
Storing exterior rear view
mirror parking position ................. 394
Fastening the seat belts..................... 395
Proper use of seat belts ............... 397
Seat belt height adjustment
automatically ................................ 397
Seat belt height adjustment
manually ....................................... 398
Lighting .............................................. 399
Exterior lamp switch ..................... 399High beam .................................... 403
Headlamp cleaning system .......... 403
Corner-illuminating lamps ............ 404
Hazard warning flasher ................ 405
Interior lighting............................. 406
Door entry lamps ......................... 407
Trunk lamp ................................... 407
Windshield wipers .............................. 408
Switching on/off
windshield wipers......................... 408
Intermittent wiping....................... 409
Single wipe................................... 409
Wiping with windshield
washer fluid.................................. 409
Power windows .................................. 410
Opening and closing
power windows ............................ 410
Rear side window sunshades* ..... 412
Summer opening feature.............. 412
Convenience closing feature ........ 413
Driving and parking............................ 416
Starting the engine....................... 416
Driving off .................................... 419
Turn signals .................................. 420
Problems while driving ................. 420
Parking ......................................... 421Turning off the engine .................. 424
Releasing seat belts ..................... 425
Automatic transmission ..................... 426
Gear selector lever....................... 426
Shifting procedure ....................... 429
Transmission positions ................ 430
Driving tips................................... 433
Gear ranges ................................. 435
Automatic shift program .............. 436
Steering wheel gearshift control .. 438
Manual shift program
(S 63 AMG and S 65 AMG only) ... 440
Emergency operation
(Limp-Home Mode) ...................... 443
Instrument cluster ............................. 444
Adjusting instrument cluster
display illumination ...................... 444
Coolant temperature gauge ......... 444
Tachometer .................................. 445
Outside temperature indicator ..... 445
Fuel gauge ................................... 445
Driving systems ................................. 446
Cruise control .............................. 446
DISTRONIC Plus* ......................... 451
Airmatic ....................................... 468
Active Body Control (ABC)* ......... 470

27 At a glance
Cockpit
Item
Page
1
Combination switch

High beam


Corner-illuminating lamps


Windshield wipers


Turn signals
403
404
408
420
2
Lever for

Cruise control


DISTRONIC Plus*
447
451
3
Horn
4
Multifunction steering wheel
288
5
Instrument cluster
28
6
Steering wheel gearshift con-
trol
438
7
Gear selector lever for
automatic transmission
416
Item
Page
8
Control panel with

Front passenger front
air bag indicator lamp


Vehicle level control
switch


Electronic Stability Pro-
gram (ESP
®) switch


Parktronic*/Park Assist*
deactivation switch


Swivel COMAND display


COMAND/instrument
cluster display
illumination
51
469,
471
74
475,
480
89
444
9
COMAND display
87
a
Overhead control panel
33
b
Automatic climate control
Center console, upper part
501
32
Item
Page
c
Glove box lock
526
d
Cover of compartment with

CD/DVD changer


PCMCIA card slot
120
121
e
Center console, lower part
30
f
Starter switch
KEYLESS-GO* start/stop
button
370
371
g
Steering wheel adjustment
Heated steering wheel*
386
387
h
Electronic parking brake
422
j
Door control panel
34
k
Hood lock release
573
l
Night View Assist*
491
m
Exterior lamp switch
399

29 At a glance
Instrument cluster
Item
Page
1
Coolant temperature gauge
444
2
Fuel gauge with:
Fuel tank reserve warning
lamp
AHigh beam headlamp
indicator lamp
-ABS indicator lamp
=SRS indicator lamp
683
403
628
637
3
Parktronic*/Park Assist*
warning indicator for left
front area
474,
479
4
Multifunction display with:Speedometer0
USA only
!
Canada only
Electronic
parking brake
warning or indi-
cator lamps
630
Item
Page
;
USA only
3
Canada only
Brake warning
lamp
629
635
HCombination low tire
pressure/TPMS mal-
function telltale, USA
only
Low tire pressure*
telltale, Canada only
638
LLeft turn signal
indicator lamp
420
KRight turn signal
indicator lamp
420
vESP
® warning lamp
634
lDistance warning
lamp*
1
79,
454,
634
1Vehicles without DISTRONIC Plus*: Warning lamp
without function. It illuminates when the ignition is
on. It should go out when the engine is running.
Item
Page
5
Parktronic*/Park Assist*
warning indicator for right
front area
474,
479
6
Gear position/range
indicator
435
7
Tachometer with:±Engine malfunction
indicator lamp
632
8
Selected program mode indi-
cator
437
9
Main menu for control sys-
tem, multifunction display
287
a
Outside temperature
445
b
Display with:Additional speedometer
306
:PRE-SAFE
® Brake*
indicator
303

69 Safety and Security
Driving safety systems
Adaptive Brake Lights (S600andS65AMG, USAonly)
The brake lamps flash in quick intervals
while you are braking in order to signal to
cars behind you that

you are braking strongly at a speed of
more than 30 mph (50 km/h)


you are braking with the aid of BAS or
BAS Plus*
If you bring the car to a complete stop by
hard braking at a speed of more than
40 mph (70 km/h), the hazard warning
flasher automatically comes on as soon as
the vehicle is at a standstill. While the vehi-
cle is stationary, the brake lamps are con-
tinuously lit up.
Once you drive faster than 6 mph
(10 km/h) afterward, the hazard warning
flasher goes out.
BAS
The Brake Assist System (BAS) operates in
emergency situations. If you apply the
brakes very quickly, the BAS automatically
provides full brake boost, thereby poten-
tially reducing the braking distance.
Apply continuous full braking pressure
until the emergency braking situation is
over.
The ABS will prevent the wheels from
locking.
When you release the brake pedal, the
brakes function again as normal. The BAS
is then deactivated.
For more information, see “Practical hints”
section (
page 628).
Warning!
G
When the BAS is malfunctioning, the brake
system is still functioning normally, but with-
out the additional brake boost available that
BAS would normally provide in an emergen-
cy braking maneuver. Therefore, the braking
distance may increase.
Warning!
G
The BAS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking efficiency beyond that af-
forded by the condition of the vehicle brakes
and tires or the traction afforded. The BAS
cannot prevent accidents, including those
resulting from excessive speed in turns, fol-
lowing another vehicle too closely, or hydro-
planing. Only a safe, attentive, and skillful
driver can prevent accidents.
The capabilities of a BAS equipped vehicle
must never be exploited in a reckless or dan-
gerous manner which could jeopardize the
user’s safety or the safety of others.

83 Safety and Security
Anti-theft systems
1Indicator lamp
Arming: Lock your vehicle with the
SmartKey or KEYLESS-GO*.
The turn signal lamps flash three times
to indicate that the vehicle is locked.
The indicator lamp1 flashes to indi-
cate that the alarm system is armed.

Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*.
The turn signal lamps flash once to in-
dicate that the alarm system is dis-
armed.
Canceling the alarm
To cancel the alarm, do one of the follow-
ing:
Insert the SmartKey or SmartKey with
KEYLESS-GO* in the starter switch.

Press the Œ or ‹ button on the
SmartKey or SmartKey with
KEYLESS-GO*.
In vehicles with KEYLESS-GO*:

Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft (1 m) of the vehicle.

Press the KEYLESS-GO start/stop but-
ton (
page 372).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
i
If the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 542) provided Tele Aid service was sub-
scribed to and properly activated, and that nec-
essary mobile phone, power supply and GPS
coverage are available.
i
If the turn signal lamps does not flash three
times one of the following elements may not be
properly closed:


a door


the trunk
Close the respective element and lock the vehi-
cle again.
i
The alarm system will rearm automatically
again after approximately 40 seconds if no door
was opened.

197 Control systems
COMAND navigation (introduction)
1Crosshair
2Details of the crosshair position
3Map scaleAdjusting the map scale

Rotate ymz.
Rotating clockwise zooms in, rotating
counterclockwise zooms out.
Saving crosshair position as destination
in last destinations list

Showing menu system, if neces-
sary: Press n.

Saving: Select “Position”
“Save Po-
sition”.
COMAND saves the crosshair position
as a destination in the last destinations
list (
page 258).
Hiding the crosshair

Press back button L in the center
console (
page 88).
The crosshair disappears and the map
is centered on the vehicle position.
or

Set the map to the vehicle or destina-
tion position, see the explanation be-
low.
Centering the map on the vehicle or
destination position

Centering on the vehicle’s position:
Select “Navi”
“Position”
“Vehicle
Position Map”.
or

Press back button L when the
crosshair is displayed.

Centering on the destination:
Select “Navi”
“Position”
“Destina-
tion Position Map”.
i
Display 2 may be the name of a road, for
example, provided the digital map contains the
necessary data.
If no data is available, display 2 shows:


the coordinates of the crosshair if the
geo-coordinate display is switched on
(page 200) and the GPS signal is strong
enough


no display if the geo-coordinate display is
switched off (
page 200)
i
If you have moved the map, you can use this
function to rapidly return the map to the position
of the vehicle or destination. It is only possible to
center the map on the destination position when
route guidance is active.

359 Controls in detail
Locking and unlocking
Factory setting
Global unlocking: Press buttonŒ.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
i
USA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
You can also open and close the door win-
dows and tilt/sliding sunroof, or the tilt/ sliding
panel* using the SmartKey (
page 412).
!
If you cannot lock or unlock the vehicle with
the SmartKey, then either the batteries in the
SmartKey are discharged, the SmartKey is mal-
functioning or the vehicle batteries are drained.


Check the batteries in the SmartKey and re-
place them if necessary (
page 712).


Use the mechanical key to unlock the driv-
er’s door (
page 708) and the trunk
(
page 709).


Use the mechanical key to lock the driver’s
door (
page 709) and the trunk
(
page 517).


Have the vehicle batteries and their connec-
tions checked (
page 729).
If the SmartKey is malfunctioning, contact Road-
side Assistance or an authorized Mercedes-Benz
Center.
i
Your vehicle may be equipped with an
acoustic lock and unlock confirmation signal fea-
ture. If your vehicle is equipped with this feature
and the feature is activated, an acoustic signal
will sound when the vehicle is locked or unlocked
using the SmartKey.
To determine whether or not your vehicle is
equipped with this feature, contact an autho-
rized Mercedes-Benz Center. If equipped and
you wish to activate or deactivate the feature, or
adjust its signal volume, also contact an autho-
rized Mercedes-Benz Center.

360 Controls in detailLocking and unlockingThe vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:

neither a door nor the trunk is opened


the SmartKey is not inserted in the
starter switch


the central locking/unlocking switch is
not activated

Global locking: Press button‹.
With the trunk and both doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that press-
ing buttonŒ only unlocks the driver’s
door and the fuel filler flap.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 358)
flashes twice.
The SmartKey will then function as fol-
lows:

Unlocking driver’s door and fuel fill-
er flap: Press buttonΠonce.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 359).


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.

Global unlocking: Press buttonŒ
twice.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.

Global locking: Press button‹.
With the trunk and both doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.

364 Controls in detailLocking and unlocking

Remember that the engine can be
started by anyone with a SmartKey
wi th KEY LES S-GO tha t i s le ft ins id e t he
vehicle.
Possibility 1: (One SmartKey with
KEYLESS-GO in the vehicle, one
SmartKey with KEYLESS-GO outside
the vehicle):
If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, no message
appears in the multifunction display.
Possibility 2: (One SmartKey with
KEYLESS-GO in the vehicle, no
SmartKey with KEYLESS-GO outside
the vehicle):
When exiting and trying to lock the ve-
hicle, the message “Key Detected In
Vehicle” appears in the multifunction
display. The vehicle will not be locked.Factory setting
1Outside door handle

Global unlocking: Grasp an outside
door handle1.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:


neither a door nor the trunk is opened


the central locking/unlocking switch is
not activated
i
Your vehicle may be equipped with an
acoustic lock and unlock confirmation signal fea-
ture. If your vehicle is equipped with this feature
and the feature is activated, an acoustic signal
will sound when the vehicle is locked or unlocked
using the SmartKey with KEYLESS-GO.
To determine whether or not your vehicle is
equipped with this feature, contact an autho-
rized Mercedes-Benz Center. If equipped and
you wish to activate or deactivate the feature, or
adjust its signal volume, also contact an autho-
rized Mercedes-Benz Center.
i
The vehicle could inadvertently be unlocked
if the SmartKey with KEYLESS-GO is within 3 ft
(1 m) of the vehicle and:


an outside door handle is splashed with wa-
ter, or


you attempt to clean an outside door handle.

365 Controls in detail
Locking and unlocking

Global locking: Close all doors and
touch outside of door handle1. Do
not keep your hand in the door handle
recess.
With the trunk and both doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you, grasp the driv-
er’s outside door handle only the driver’s
door and the fuel filler flap unlocks.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 361)
flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:

Unlocking driver’s door and fuel fill-
er flap: Grasp the driver’s outside door
handle.


All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 364).


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.

Global unlocking: Grasp any outside
door handle other than the driver’s out-
side door handle.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
i
Vehicles with trunk opening/closing
system*:
You can also lock the vehicle using the
KEYLESS-GO locking/closing switch
(
page 514).
