air conditioning MERCEDES-BENZ S500 2005 W220 Owner's Manual

Contents
Automatic transmission ..................... 173
One-touch gearshifting................. 175
Gear ranges ................................. 176
Gear selector lever position ......... 177
Automatic shift program .............. 179
Driving tips ................................... 180
Steering wheel gearshift control
(Speedshift) S 55 AMG................. 181
Manual shift program S 55 AMG .. 183
Emergency operation
(Limp Home Mode) ...................... 185
Good visibility .................................... 186
Headlamp cleaning system*
(Standard on S 500, S 600,
S 55 AMG).................................... 186
Rear view mirrors ......................... 186
Electrically folding exterior
rear view mirrors .......................... 188
Windshield wipers ........................ 189
Sun visors .................................... 190
Rear window sunshade* .............. 191
Rear door window sunshade* ...... 191Automatic climate control .................. 192
Setting the temperature................ 195
Adjusting air distribution............... 196
Adjusting air volume ..................... 198
Maximum cooling MAXCOOL ........ 198
Defrosting ..................................... 199
Air recirculation mode .................. 199
Charcoal filter ............................... 200
Rear window defroster .................. 201
Deactivating the climate
control system .............................. 202
Air conditioning............................. 202
Residual heat and ventilation ........ 203
Ventilated storage compartment .. 204
Rear passenger compartment
adjustable air vents....................... 204
Rear passenger compartment
climate control* ............................ 205
Power windows .................................. 207
Opening and closing the power
windows........................................ 207
Synchronizing the power
windows........................................ 209
Summer opening feature .............. 209
Convenience closing feature......... 210Power tilt/sliding sunroof .................. 211
Opening and closing the power
tilt/sliding sunroof........................ 211
Synchronizing the power
tilt/sliding sunroof........................ 213
Driving systems .................................. 214
Cruise control ............................... 214
Distronic* ..................................... 217
Airmatic ........................................ 229
Active Body Control (ABC)* .......... 231
Parktronic system*
(Parking assist) ............................. 235
Loading .............................................. 240
Roof rack* .................................... 240
Loading instructions ..................... 241
Cargo tie-down hooks ................... 241
Useful features ................................... 242
Vanity mirrors ............................... 242
Storage compartments ................. 243
Ashtrays........................................ 251
Cigarette lighters .......................... 252
Heated steering wheel* ................ 253
Telephone* ................................... 254
Tele Aid ......................................... 255
Garage door opener ...................... 264
Infrared reflecting windshield ....... 270

ContentsFuels, coolants, lubricants, etc. ......... 429
Capacities .................................... 429
Engine oils .................................... 431
Engine oil additives ...................... 431
Air conditioning refrigerant .......... 431
Brake fluid .................................... 431
Premium unleaded gasoline ......... 432
Fuel requirements ........................ 432
Gasoline additives ........................ 432
Coolants ....................................... 433
Windshield and headlamp
washer system ............................. 436
Technical terms............................... 437Index................................................. 443

195 Controls in detail
Automatic climate control
Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.
The air conditioning will not engage (no
cooling) if the ± mode is selected
(page 202).
Setting the temperature
Use temperature controls aand8
(page 194) to separately adjust the air
temperature on each side of the passenger
compartment. You should raise or lower
the temperature setting in small incre-
ments, preferably starting at 72°F (22°C).
Increasing/decreasing

Press button a or 8 repeatedly until
the display shows the desired tempera-
ture.
The automatic climate control system
will correspondingly adjust the interior
air temperature.
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iThe current climate control settings
(ON/OFF, temperature, air volume, ac-
tivated charcoal filter, etc.) are stored
for each SmartKey before it is removed
from the starter switch or when the ve-
hicle is locked using the SmartKey with
KEYLESS-GO* (
page 108).
If the vehicle interior is hot, ventilate
the interior before driving off.
Keep the air intake grille in front of the
windshield free of snow, leaves, sticks,
and any other debris.
Do not obstruct air volume by placing
objects on the air volume-through ex-
haust slots below the rear window.
iWhen operating the climate control
system in automatic mode, you will
only rarely need to adjust the tempera-
ture, air volume and air distribution.

197 Controls in detail
Automatic climate control
Adjusting manually
Press left or right buttonU.
The button emerges and theh,
», d and csymbols become
visible.

Turn the marking on the regulator to
the desired symbol.
The air will be directed to the vents cor-
responding to this symbol.
Adjusting automatically

Press left or right buttonU until it
clicks in.
Theh, », d and
csymbols are no longer visible.
The air distribution is adjusted auto-
matically.Windows fogged on the inside

Press button± to switch on the air
conditioning (
page 194).
The indicator lamp in the button goes
out.

Press button, to switch off the air
recirculation (
page 194).
The indicator lamp on the button goes
out.

Make sure left and right buttonU
emerges.
Theh, », d and
csymbols become visible.

Press left and rightd button.

Set blower to the maximum speed.

Adjust left and right air vents1
and6 upwards (
page 192).

Increase temperature setting.

Open side air vents9 and direct them
onto the side windows (
page 192).
Windshield fogged on the outside

Switch the windshield wipers on
(page 52).

Press on both U buttons until they
click in.
Theh, », d and c sym-
bols are no longer visible.

200 Controls in detailAutomatic climate controlDeactivating
Press button, (
page 194).
The indicator lamp on the button goes
out.The air recirculation mode is deactivated
automatically:


after five minutes if the outside temper-
ature is below approximately 41°F
(5°C)


after five minutes if the air conditioning
is turned off


after 30 minutes if the outside temper-
ature is above approximately 41°F
(5°C)
At outside temperatures above 79°F
(26°C) the system will not automatically
switch back to outside air. A quantity of
outside air is added after approximately
30 minutes.
Charcoal filter
An activated charcoal filter markedly re-
duces bad odors and removes pollutants
from air entering the passenger compart-
ment.
Activating
Press buttone (
page 194).
The indicator lamp on the button
comes on.
iThe air recirculation mode is activated
automatically:

at high outside temperatures


if the concentration of carbon mon-
oxide and nitrogen oxide in the out-
side air increases beyond a
predetermined level, for example in
a tunnel.
Please note that the charcoal filter
must be activated (
page 200) for the
air recirculation mode to be activated
automatically.
If you have turned off the air condition-
ing (
page 202) or the outside tem-
perature is below 41°F (5°C), the air
recirculation mode will not switch on
automatically.
iIf you keep button, pressed, the
side windows and the tilt/sliding sun-
roof will return to their previous posi-
tion.
iIf you keep buttone pressed, the
side windows and the tilt/sliding sun-
roof will close.

202 Controls in detailAutomatic climate control
Deactivating the climate control sys-tem
Deactivating
It is possible to completely deactivate the
automatic climate control system.
Press button M (
page 194).
The display shows “0”.
Reactivating
There are several ways to reactivate the
automatic climate control system:

Press one of the following buttons,
M, P, U, a temperature con-
trol switch (
page 194) or air volume
switch 9 on the automatic climate
control panel.
Air conditioning
The air conditioning is operational while
the engine is running and cools the interior
air to the temperature set by the operator.
Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the automatic
climate control system. The air in the vehi-
cle will then no longer be cooled or dehu-
midified.
Press button± (
page 194).
The indicator lamp on the button±
comes on.
Warning!
G
Any accumulation of snow and ice should be
removed from the rear window before driv-
ing. Visibility could otherwise be impaired,
endangering you and others.!If the rear window defroster switches
off too soon and the indicator lamp
starts flashing, this means that too
many electrical consumers are operat-
ing simultaneously and there is insuffi-
cient voltage in the battery. The system
responds automatically by deactivating
the rear window defroster.
As soon as the battery has sufficient
voltage, the rear window defroster au-
tomatically turns itself back on.
iCondensation may drip out from under-
neath the vehicle. This is normal and
not an indication of a malfunction.

203 Controls in detail
Automatic climate control
Activating
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.
Press± again (
page 194).
The indicator lamp on the ± button
goes out.
The air conditioning uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer.
Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.
Activating
Turn the SmartKey in the starter switch
to position1 or 0, or remove it from the
starter switch.

Press buttonT (
page 194).
The indicator lamp on buttonT
comes on.Deactivating

Press buttonT (
page 194).
The indicator lamp on buttonT
goes out.
The residual heat is automatically turned
off:


when the ignition is switched on


after about 30 minutes


if the battery voltage drops
!If the± button on the automatic cli-
mate control panel starts to flash, this
indicates that the air conditioning is
losing refrigerant. The compressor has
turned itself off. The air conditioning
cannot be turned on again.
Have the air conditioning checked at
the nearest authorized Mercedes-Benz
Center.
iHow long the system will provide heat-
ing depends on the coolant tempera-
ture and the temperature set by the
operator. The blower will run at speed
setting 1 regardless of the air distribu-
tion control setting.

204 Controls in detailAutomatic climate controlVentilated storage compartment
Depending on vehicle model and configu-
ration, your vehicle is equipped with a stor-
age compartment under the front armrest
(page 245) which can be ventilated
when the automatic air conditioning is
switched on. If so equipped, the switch is
located inside the storage compartment in
the front. The air temperature is about the
same as that of the center air vents.
The air volume is dependent on the setting
of:


Air distribution control


Air volume control


Air vents in the dashboard
The air temperature is about the same as
that of the dashboard air vents. It cannot
be regulated separately.Switching ventilation on

Open the storage compartment in front
of the armrest, see “Storage compart-
ment in front of armrest” (
page 245).

Push upper portion of switch.
Switching ventilation off

Open the storage compartment in front
of the armrest, see “Storage compart-
ment in front of armrest” (
page 245).

Push lower portion of switch. Rear passenger compartment adjust-
able air vents
Rear center console air vents
1Left center air vent, adjustable
2Right center air vent, adjustable
3Thumbwheel for center air vents with
adjustable booster blower
!Do not obstruct the air vent in the stor-
age compartment.iThe compartment can get very warm
due to its confined space. When storing
heat sensitive objects in the compart-
ment, close the air vent while heating
the passenger compartment.

322 OperationTires and wheelsTire and loading terminology
Accessory weight
The combined weight (in excess of those
standard items which may be replaced) of
automatic transmission, power steering,
power brakes, power windows, power
seats, radio, and heater, to the extent that
these items are available as
factory-installed equipment (whether
installed or not).
Air pressure
The amount of air inside the tire pressing
outward on each square inch of the tire.
Air pressure is expressed in pounds per
square inch (psi), or kilopascal (kPa) or
bars.
Aspect ratio
Dimensional relationship between tire
section height and section width
expressed in percentage.Bar
Another metric unit for air pressure. There
are 14.5038 pounds per square inch (psi)
to 1 bar; there are 100 kilopascals (kPa)
to 1 bar.
Bead
The tire bead contains steel wires wrapped
by steel cords that hold the tire onto the
rim.
Cold tire inflation pressure
Tire inflation pressure when your vehicle
has been sitting for at least three hours or
driven no more than one mile (1.6 km).
Curb weight
The weight of a motor vehicle with stan-
dard equipment including the maximum
capacity of fuel, oil, and coolant, and, if so
equipped, air conditioning and additional
optional equipment, but without passen-
gers and cargo.DOT (D
epartment o
f T
ransportation)
A tire branding symbol which denotes the
tire meets requirements of the
U.S. Department of Transportation.
GAWR (G
ross A
xle W
eight R
ating)
The GAWR is the maximum permissible
axle weight. The gross vehicle weight on
each axle must never exceed the GAWR for
the front and rear axle indicated on the
Certification label located on the driver's
door B-pillar.
GVW (G
ross V
ehicle W
eight)
The GVW comprises the weight of the
vehicle including fuel, tools, spare wheel,
installed accessories, passengers and
cargo and, if applicable, trailer tongue
load. The GWV must never exceed the
GWVR indicated on the Certification label
located on the driver's door B-pillar.

419 Technical data
Layout of poly-V-belt drive
Layout of poly-V-belt drive
S 430/S 500 (all models)
1Automatic belt tensioner
2ABC tandem pump (pump for
power-steering assistance and ABC
chassis)
3Air conditioning compressor
4Crankshaft
5Coolant pump
6Generator (alternator)
7Idler pulley
S55AMGThe S 55 AMG has two poly-V-belts (belt one
shown in purple/belt two shown in black). 1Idler pulley
2Automatic belt tensioner
3ABC tandem pump (pump for
power-steering assistance and ABC
chassis)
4Air conditioning compressor
5Crankshaft
6Coolant pump
7Generator (alternator)
8Idler pulley
9Automatic belt tensioner
aSupercharger
S600
1Automatic belt tensioner
2ABC tandem pump (pump for
power-steering assistance and ABC
chassis)
3Air conditioning compressor
4Crankshaft
5Coolant pump
6Generator (alternator)
7Idler pulley
8Idler pulley
9Idler pulley
