320 Controls in detailSeatsRear power seat* adjustment
(rear outer seats)Example rear right door1Seat cushion tilt
2Seat backrest tilt
3Folding down and placing upright head
restraint (
page 326)
4Head restraint tilt (
page 326)
5Seat fore and aft adjustment

Switch on the ignition (
page 315).
or

Open the respective door.

Adjust desired seat using seat
switches1,2 and5.Adjusting front passenger seat from
driver’s seat/rear*
Warning!
G
The seat belt only offers its intended protec-
tion when the seat backrest is in a nearly
vertical position and the occupant is sitting
upright. Avoid sitting in positions that pre-
vent the seat belt from being properly posi-
tioned against the body (
page 339). You
should therefore adjust the backrest to a po-
sition as upright as possible.
Warning!
G
When adjusting the front passenger seat,
make sure the seat, if occupied, is as far
from the passenger front air bag as possi-
ble.
Otherwise, the passenger could be seriously
or even fatally injured in the event of an ac-
cident or braking maneuver.
Make sure no one is caught or injured while
the seat is being adjusted.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated when the respective door is
open. Therefore, do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.!
Do not move the front passenger seat com-
pletely forward if objects are stored in the parcel
net in the front passenger-side footwell. Items in
the net may be damaged.

321 Controls in detailSeats
Adjusting front passenger seat from
driver’s seat*
You can adjust the front passenger seat
using the seat switches on the driver’s
side.
1Adjusting front passenger seat
Switch on the ignition (
page 315).

Press button1.
When the indicator lamp on button1 is
on, you can operate the following features
of the front passenger seat:


seat adjustment


seat heating/ventilation*


memory function
Setting front passenger seat position
from rear*
The switch is located on the right rear pas-
senger door.
1To select front or rear passenger seat
2Seat height
3Head restraint height (
page 324)
4Backrest tilt
5Seat fore and aft adjustment

Switch on the ignition (
page 315).
or

Open the right rear passenger door.

Press button1 to adjust the front
passenger seat.
The Indicator lamp in the button1
comes on.

Adjust front passenger seat using seat
switches2,3,4 and5.

To adjust right rear passenger seat
(page 320), press button1 again.
The Indicator lamp in the button1
goes out.
i
Adjusting the passenger seat position from
the rear is not possible if you deactivate the over-
ride switch (
page 67).

322 Controls in detailSeatsSeat heating*
The buttons for seat heating are located on
the respective door. The red indicator
lamps on the button come on to show the
heating level selected.
1Seat heating button

Switch on the ignition (
page 315).

Switching on: Press button1 repeat-
edly until the desired heating level is
set.
One or more red indicator lamps on the
button show the selected heating level.

Switching off: Press button1 repeat-
edly until all indicator lamps go out.
Level3
Three indicator lamps on
(highest level)
The seat heating automatically
switches to level2 after approxi-
mately 5 minutes.
2
Two indicator lamps on
The seat heating automatically
switches to level1 after approxi-
mately 10 minutes.
1
One indicator lamp on
(lowest level)
The seat heating automatically
switches off after approximately
20 minutes.
off
No indicator lamp on
i
If one or more of the lamps on the seat heat-
ing button are flashing, there is insufficient volt-
age available since too many electrical
consumers are turned on. The seat heating
switches off automatically.
The seat heating will switch back on again auto-
matically as soon as sufficient voltage is avail-
able.

323 Controls in detailSeats
Seat ventilation*
The buttons for seat ventilation are located
on the respective door. The blue indicator
lamps on the button come on show the
ventilation level selected.
1Seat ventilation button

Switch on the ignition (
page 315).

Switching on: Press button1 repeat-
edly until the desired ventilation level is
set.
One or more blue indicator lamps on
the button show the selected ventila-
tion level.

Switching off: Press button1 repeat-
edly until all indicator lamps go out.
Level3
Three indicator lamps on
(highest level)
2
Two indicator lamps on
1
One indicator lamp on
(lowest level)
off
No indicator lamp on
i
The seat ventilation for the driver’ seat can
be activated using summer opening feature
(
page 355).
i
If one or more of the lamps on the seat ven-
tilation button are flashing, there is insufficient
voltage available since too many electrical con-
sumers are turned on. The seat ventilation
switches off automatically.
The seat ventilation will switch back on again au-
tomatically as soon as sufficient voltage is avail-
able.

324 Controls in detailSeatsHead restraints Front power head restraints
Head restraint height
1Head restraint height

Press the switch up or down in the di-
rection of arrow1.Head restraint tilt
Manually adjust the angle of the head re-
straint.

Push or pull on the upper edge of the
head restraint cushion.
Luxury active head restraints
(S 600 only) (front seats)
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that it is as close to
the head as possible and the center of the
head restraint supports the back of the head
at eye level. This will reduce the potential for
injury to the head and neck in the event of
an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.i
Adjust the head restraint in such a way that
it is as close to the head as possible.
i
Depending on the seat’s set fore and aft po-
sition, the head restraint height is automatically
pre-set.
i
The head restraint on the front passenger’s
side is automatically lowered all the way down
while the vehicle is in motion if no one is sitting
on the seat. This helps you to acquire a better
all-round view.
Warning!
G
When folding back the side cushions, never
reach between the side cushion and the
mounting post. You could otherwise be
trapped.

325 Controls in detailSeats
Adjustment
1Head restraint side cushions
2Adjusting head restraint forward and
backward
You can individually adjust side
cushions1 of the luxury head restraints.
Adjusting side cushions: Pull or push
side cushions1 into desired position.

Adjusting forward or backward: Pull
or push head restraint in direction of
arrow2.Resetting
If the luxury active head restraints have
been triggered in an accident, the luxury
active head restraints must be reset. Oth-
erwise, the luxury active head restraints
cannot offer any additional protection in
the event of another rear-end collision.
Have this work carried out by an autho-
rized Mercedes-Benz Center.
For information on luxury active head re-
straints, see “Luxury active head restraints
(S 600 only)” (
page 59).
Rear head restraintsFolding head restraints back
The rear seat head restraints and the rear
seat power head restraints* can be folded
backward for increased visibility.
1Switch in the front center console
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Otherwise, the back of the head will not be
supported in the event of a collision. As a re-
sult, rear seat occupants could be injured.
Warning!
G
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.i
You can only fold back the rear seat head re-
straints when no rear seat passenger is wearing
a seat belt.

326 Controls in detailSeats
Switch on the ignition (
page 315).

Press switch1 in the front center con-
sole briefly.
The rear head restraints will fold back-
ward.
Placing head restraints upright

Pull the rear head restraint upright until
it locks into position.Placing power head restraints* upright
(rear outer seats)

Switch on the ignition (
page 315).

Press and hold switch1 in the front
center console and hold.
The rear outer seats head restraints
will place upright.

Pull the rear center seat head restraint
upright manually until it locks into posi-
tion.Rear power head restraints*
(rear outer seats)
1Placing upright head restraint
2Folding down head restraint
3Head restraint tilt
4Head restraint tilt

Switch on the ignition (
page 315) or
open the respective door.

Press switch up in the direction of
arrow1.
The rear outer seats power head re-
straint will place upright.
!
Make sure the head restraints engage when
placing them upright manually. Otherwise their
protective function cannot be ensured.
i
When you fasten your seat belt in the rear,
the respective rear outer seat head restraint
places upright.

327 Controls in detailSeats

Press switch down in the direction of
arrow3.
The rear power head restraint will fold
backward.

Press the switch forward or backward
in the direction of arrow2 or4.
The power head restraint will be tilted.
Luxury head restraints*
(rear outer seats)Adjustment
1Head restraint side cushions
2Head restraint height
You can individually adjust side
cushions1 of the luxury head restraints

Adjusting side cushions: Pull or push
side cushions1 into desired position.

Adjusting head restraint angle: Grip
head restraint at upper edge of cushion
and pull it forward or backward in di-
rection of arrow2.
Multicontour seats*, rear
You can adjust the rear outer multicontour
seats using the buttons on the center con-
sole.
1To select right rear passenger seat
2Massage setting, gentle
3Massage setting, vigorous
4To adjust position of backrest curva-
ture (lordosis)
5Lumbar region support
6Side bolster adjustment
7To select left rear passenger seat
Switch on the ignition (
page 315).
Warning!
G
When folding back the side cushions, never
reach between the side cushion and the
mounting post. You could otherwise be
trapped.


328 Controls in detailSeats
Selecting a seat: Press rocker
switch1 or7 forward or backward.
The indicator lamp on the selected but-
ton lights up for a short while.
Gentle massage

Switching on: Press rocker switch2
forward.

Switching off: Pull rocker switch2
backward.
Vigorous massage

Switching on: Press rocker switch3
forward.

Switching off: Pull rocker switch3
backward.
Position of backrest curvature

Moving upward: Press rocker
switch4 forward.

Moving downward: Pull rocker
switch4 backward.Lumbar region support

Selecting greater curvature: Press
rocker switch5 forward.

Selecting less curvature: Pull rocker
switch5 backward.
Side bolster adjustment

Reducing width: Press rocker
switch6 forward.

Increasing width: Pull rocker
switch6 backward.
Easy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the driver’s seat is in its
maximum rearward position and the steer-
ing wheel is in its uppermost position.
The easy-entry/exit feature can be activat-
ed or deactivated in the “Vehicle” menu of
the COMAND system (
page 224).
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press seat adjustment switch
(page 319).


Move steering column stalk
(page 330).


Press one of the memory position but-
tons or the memory button M
(page 337).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.


329 Controls in detailSeats
With the easy-entry/exit feature activated,
the steering wheel and driver’s seat will re-
turn to their last set memory position or a
factory-set maximum forward position
when you:

close the driver’s door with the ignition
switched on


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 317) once
with the driver’s door closed. With the easy-entry/exit feature activated
the steering wheel tilts upwards and the
driver’s seat moves a few inches to the
rear when you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position 0
or 1 or the KEYLESS-GO* start/stop
button (
page 317) in position 1.
!
Do not activate the easy-entry/exit feature
if the seat backrest is in an excessively reclined
position. Doing so could cause damage to front
or rear seats.
First move the seat backrest to an upright posi-
tion.
i
For safety reasons, the driver’s seat will not
return to its last set position with the easy-en-
try/exit feature activated if the system recogniz-
es the last set position as an extreme forward
position. Instead, the driver’s seat will remain at
or move to a factory-set maximum forward posi-
tion. To again fully return the driver’s seat toyour last set position or to memory position, ad-
just the seat to the desired position or press and
hold the respective memory position button
(
page 337).
i
The last set driver’s seat and steering wheel
positions are stored when


the ignition is switched off


the position is stored in memory
(page 336)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
If the current seat position falls into a factory-set
position range and the system recognizes the
current seat position to be rearward enough for
easy entry and exit, the driver’s seat will not
move to the rear when the easy-entry/ exit fea-
ture is activated.
The adjustment procedure is briefly interrupted
when the engine is started.Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All driver’s seat and steering wheel ad-
justments must be completed before setting
the vehicle in motion. Driving off with the
driver’s seat/steering wheel still adjusting
could cause the driver to lose control of the
vehicle.
