MERCEDES-BENZ S550 2007 W221 Owner's Manual

650 Technical dataThe “Technical data” section provides the
necessary technical data for your vehicle.Parts service
All authorized Mercedes-Benz Centers
maintain a stock of Genuine
Mercedes-Benz parts required for mainte-
nance and repair work. In addition, strate-
gically located parts distribution centers
provide quick and reliable parts service.
More than 300 000 different parts for
Mercedes-Benz models are available.
Genuine Mercedes-Benz parts are subject-
ed to stringent quality inspections. Each
part has been specifically developed, man-
ufactured or selected for and adapted to
Mercedes-Benz vehicles.
Therefore, Genuine Mercedes-Benz parts
should be installed.
!
The use of non-genuine Mercedes-Benz
parts and accessories not authorized by
Mercedes-Benz could damage the vehicle, which
is not covered by the Mercedes-Benz Limited
Warranty, or could compromise the vehicle’s du-
rability or safety.

651 Technical data
Warranty coverage
Warranty coverage
Your vehicle is covered under the terms of
the warranties printed in the Service and
Warranty Information booklet. Your autho-
rized Mercedes-Benz Center will exchange
or repair any defective parts originally in-
stalled on the vehicle in accordance with
the terms of the following warranties:

New Vehicle Limited Warranty


Emission System Warranty


Emission Performance Warranty


California, Maine, Massachusetts, and
Vermont Emission Control Systems
WarrantyReplacement parts and accessories are
covered by the Mercedes-Benz Parts and
Accessories warranties, copies of which
are available at any authorized
Mercedes-Benz Center.Loss of Service and Warranty
Information Booklet
Should you lose your Service and Warranty
Information booklet, have an authorized
Mercedes-Benz Center arrange for a re-
placement. It will be mailed to you.

652 Technical dataIdentification labels1Certification label, includes Paintwork
code (on driver’s B-pillar) 2Vehicle Identification Number (VIN)

Fold down rear center armrest.
Vehicle Identification Number 2 is un-
derneath a cover in the center armrest.
Example illustration from S 5503Engine number (engraved on engine)
4VIN, visible (lower edge of windshield)
5Emission control information label,
includes both federal and California
certification exhaust emission
standards
Vacuum line routing diagram labeli
When ordering parts, please specify vehicle
identification and engine numbers.

653 Technical data
Layout of poly-V-belt drive
Layout of poly-V-belt drive
S 550
1Idler pulley
2Idler pulley
3Automatic belt tensioner
4ABC* tandem pump (pump for
power-steering assistance and ABC*
chassis)
5Air conditioning compressor
6Crankshaft
7Coolant pump
8Generator (alternator)
S 600
1Automatic belt tensioner
2ABC tandem pump (pump for
power-steering assistance and ABC
chassis)
3Air conditioning compressor
4Crankshaft
5Coolant pump
6Generator (alternator)
7Idler pulley
8Idler pulley
9Idler pulley

654 Technical dataEngineModel
S 550 (221.171)
1
1The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special
bodies and special equipment.
S 600 (221.176)
1
Engine
273
275
Mode of operation
4-stroke engine, gasoline injection
4-stroke engine, gasoline injection
No. of cylinders
8
12
Bore
3.86 in (98.00 mm)
3.23 in (82.00 mm)
Stroke
3.56 in (90.50 mm)
3.43 in (87.00 mm)
Total piston displacement
333.3 cu in (5461 cm
3)
336.4 cu in (5513 cm
3)
Compression ratio
10.7:1
9:1
Output acc. to SAE J 1349
2
2Premium fuel required. Performance may vary with fuel octane rating.
382 hp/6000 rpm
(285 kW/6000 rpm)
510 hp/5000 rpm
(380 kW/5000 rpm)
Maximum torque
acc. to SAE J 1349
384 lb-ft/3000 rpm
(520 Nm/3000 rpm)
612 lb-ft/1800 - 3500 rpm
(830 Nm/1800 - 3500 rpm)
Maximum engine speed
6500 rpm
5950 rpm
Firing order
1-5-4-2-6-3-7-8
1-12-5-8-3-10-6-7-2-11-4-9
Poly-V-belt
2404 mm
2370 mm

655 Technical data
Rims and tires
Rims and tires
!
Only use tires which have been tested and
approved for your vehicle by Mercedes-Benz.
Tires approved by Mercedes-Benz are developed
to provide best possible performance in conjunc-
tion with the driving safety systems on your vehi-
cle such as ABS or ESP
®. Tires specially
developed for your vehicle and tested and ap-
proved by Mercedes-Benz can be identified by
finding the following on the tire’s sidewall:


MO = M
ercedes-Benz O
riginal equipment
tires
Using tires other than those approved by
Mercedes-Benz may result in damage that is not
covered by the Mercedes-Benz Limited
Warranty.
!
Using tires other than those approved by
Mercedes-Benz can have detrimental effects,
such as


poor handling characteristics


increased noise


increased fuel consumption
Moreover, tires and rims not approved by
Mercedes-Benz may, under load, exhibit dimen-
sional variations and different tire deformation
characteristics that could cause them to come
into contact with the vehicle body or axle parts. Damage to the tires or the vehicle may be the re-
sult.
i
Further information on tires and rims is
available at any authorized Mercedes-Benz
Center. A placard with the recommended tire in-
flation pressures is located on the driver’s door
B-pillar (
page 503). Some vehicles may have
supplemental tire inflation pressure information
for driving at high speeds (
page 510) or for ve-
hicle loads less than the maximum loaded
vehicle condition (
page 518). If such informa-
tion is provided, it can be found on the placard lo-
cated on the inside of the fuel filler flap.
The tire inflation pressure should be checked
regularly and should only be adjusted on cold
tires. Follow tire manufacturer’s maintenance
recommendation included with vehicle.
i
The following pages also list the approved
wheel rim and tire sizes for equipping your vehi-
cles with winter tires. Winter tires are not avail-
able as standard or optional factory equipment,
but can be purchased from an authorized
Mercedes-Benz Center.
Depending on vehicle model and the standard or
optional factory-equipped wheel rim/tire config-
uration on your vehicle (Appearance Package,
Sport Package etc.), equipping your vehicle with
winter tires approved for your vehicle model may
also require the purchase of two or four wheel
rims of the recommended size for use with these
winter tires. See an authorized Mercedes-Benz
Center for more information.

656 Technical dataRims and tiresSame size tires
S 550
S 600
S 550 (Sport Package*)
S 600 (Sport Package*)
Rims (light alloy)
8.5 J x18 H2
8.5 J x18 H2
Wheel offset
1.69 in (43 mm)
1.69 in (43 mm)
Summer tires
1
1Radial-ply tires
–
–
All-season tires
1
255/45 R18 99H M+S
–
Winter tires
1, 2, 3
2For use with snow chains contact an authorized Mercedes-Benz Center.3Not available as factory equipment.
255/45 R18 99H M+S.
255/45 R18 99H M+S.

657 Technical data
Rims and tires
Mixed size tires
S 600
S 550*
S 600*
S 550 (Sport Package*)
S 600 (Sport Package*)
Front axle:
Rims (light alloy)
8.5 J x 18 H2
8.5 J x 19 H2
–
AMG rims (light alloy)
–
–
8.5 J x 19 H2
Wheel offset
1.69 in (43 mm)
1.69 in (43 mm)
1.69 in (43 mm)
Summer tires
1
1Radial-ply tires
255/45 R18 99V
255/40 R19 96Y
255/40 R19 96Y
Rear axle:
Rims (light alloy)
9.5 J x 18 H2
9.5 J x 19 H2
–
AMG rims (light alloy)
–
–
9.5 J x 19 H2
Wheel offset
1.69 in (43 mm)
1.69 in (43 mm)
1.69 in (43 mm)
Summer tires
1
275/45 R18 103V
275/40 R19 101Y
275/40 R19 101Y

658 Technical dataRims and tiresMinispare wheelRim
4.5 B x 19
Wheel offset
1.38 in (35 mm)
Tire
T 155/70 R19 113M
1
1Must not be used with snow chains.!
Please compare the recommended tire in-
flation pressure for your vehicle with the tire in-
flation pressure on the yellow label located on
the Minispare wheel rim.
If the tire inflation pressure on the yellow label
on the Minispare wheel rim differs from the val-
ues given in this Operator’s Manual, inflate the
spare wheel tire to the recommended tire infla-
tion pressure given on the yellow label on the
Minispare wheel rim.
i
Please note that the tire inflation pressure of
the Minispare differs from the tire inflation pres-
sure of the road tires.
Make sure the Minispare tire is inflated to ap-
proximately 61 psi (4.2 bar).

659 Technical data
Electrical system
Electrical system
Model
S 550
S 600
Generator (alternator)
14 V/180 A
14 V/220 A
Starter motor
12 V/1.7 kW
12 V/1.7 kW
Starter battery
12 V/35 Ah
12 V/35 Ah
Electrical consumer battery
12 V/95 Ah
12 V/95 Ah
Spark plugs
NGK PLKR 6A
Bosch Y 7 MPP 33
NGK IFR 6Q-G
Electrode gap
0.031 in (0.8 mm)
0.028 in (0.7 mm)
Tightening torque
15 – 18 lb-ft (20 – 25 Nm)
18 – 22 lb-ft (25 – 30 Nm)
