Page 7 of 705
ContentsCOMAND navigation system
(last destinations) .............................. 201
Saving a destination permanently
in the destination memory ........... 201
Saving the vehicle position in
the list of last destinations ........... 201
Saving the crosshair position in
the list of last destinations ........... 201
Deleting one of the last
destinations ................................. 201
COMAND address book ..................... 202
General notes ............................... 202
Address book menu overview ...... 202
Calling up the address book ......... 202
Selecting an entry in the main
address book display.................... 202
Creating a new address book
entry ............................................. 203
Deleting an entry .......................... 204
Searching for an address book
entry ............................................. 204
Displaying a complete address
book entry .................................... 206
Displaying of a complete phone
book entry in the mobile phone.... 207
Changing an entry ........................ 207Calling a number saved in
an entry ........................................ 209
Starting route guidance to
an entry ........................................ 209
Voice entries ................................ 210
Saving a phone book entry from
mobile phone in the COMAND
address book ............................... 211
Importing data from external
Bluetooth devices ........................ 212
COMAND system settings................. 213
Systems settings menu overview . 213
Display settings............................ 213
Time settings................................ 213
Voice Control* settings ................ 215
Setting the system language ........ 216
Assigning the favorite button ....... 216
Bluetooth settings ........................ 217
Reset............................................ 219
COMAND vehicle menu ..................... 220
Setting night security illumination 220
Locator lighting on/off ................. 221
Exterior mirror convenience
settings ........................................ 222
Automatic locking on/off ............. 223Activating easy-entry/exit feature 224
Setting interior ambient lighting .. 225
Setting interior lighting delayed
switch-off ..................................... 226
Extending or retracting rear
window sunshade ........................ 227
Trunk opening-height restriction
on/off .......................................... 227
Switching on/of the tow-away
alarm............................................ 228
COMAND automatic climate control . 229
Setting temperature..................... 230
Adjusting air distribution.............. 230
Adjusting air volume .................... 230
Central climate control menu via
COMAND ..................................... 231
Operating rear climate control*
from the front .............................. 234
COMAND seats ................................. 236
Operating seats via COMAND ...... 236
Lumbar support ........................... 237
Multicontour seats*, front ........... 237
Drive-dynamic multicontour
seats, front*................................. 240
Page 34 of 705
33 At a glance
Center console
Lower part
Item
Page
1
Favorite button
216
2
Rear head restraints retract
button
325
3
Program mode selector
switch for:
automatic transmission
shift program
suspension tuning of
Airmatic (only S 550) or
ABC*
engine control
374
4
Shortcut button for:
radio
CD/DVD
94
111
5
Back button
87
Item
Page
6
Hazard warning flasher
348
7
Seat operation via COMAND:
Lumbar support
Multicontour seat*
Drive-dynamic
multicontour seat*
236
237
237
240
8
Shortcut button for:
telephone*
navigation
115
148
9
COMAND controller
82
a
COMAND on/off switch
79
b
Volume adjustment
89
c
Mute function
89
d
Telephone keypad
117
Page 237 of 705
236 Control systemsCOMAND seatsWhen adjusting the seats, observe the
safety notes in the section “Seats”
(page 318).
Operating seats via COMAND
The following seat adjustments can be
made via COMAND:Selecting a seat
You must first select the seat for which you
would like to make adjustments.
1Seat menu button
Press O.
The main area is active.
Switching to the bottom menu line:
Slide qmr.
Example illustration (vehicles with Drive-dy-
namic multicontour seat*)
Selecting seat: Slide omp or
rotateymz.
Confirming selection: Press n.
Exiting menu
There are several ways to exit the multi-
contour seat menu.
Press O again.
or
Press any shortcut button.
or
i
The components and operating principles of
COMAND can be found on (
page 79).
Settings
Page
Lumbar support
237
Multicontour seat*, front
237
Drive-dynamic multicontour
seat*
240
Page 238 of 705
237 Control systems
COMAND seats
Select another main menu from the
main menu line.
Lumbar support
To support the spine, you can adjust the
curvature of the front seat backrests.
Press O.
The main area of the COMAND display
is active. A scale appears.
1Scale
2Cursor
3Current seat
4Current setting
Select seat (
page 236).
Adjusting lumbar support:
Slideomp or rotate ymz until desired
setting is reached.
Confirming selection: Press n.
Switching to the bottom menu line:
Slide omp.
Confirming selection: Press n.
Multicontour seats*, front
To support the spine, you can individually
adjust the backrest contour of the front
seats by regulating the air pressure in the
air chambers of the multicontour seat.
The settings are made on the COMAND
display.You can adjust the following air chambers:
sides of seat cushion
thigh support
sides of backrest
backrest curvature in lumbar area
backrest curvature in shoulder area
seat firmness
Adjusting sides of seat cushion
This function is used to adjust the air
chambers in the sides of the seat cushion.
Select seat (
page 236).
Selecting “Seat sides”: Slide omp or
rotate ymz.
Confirming selection: Press n.
A scale appears.
i
After you have pressed
O
, the seat last
adjusted is active.
i
If PRE-SAFE
® has been activated, the air
pressure in the air chambers (on the sides of the
seat cushion and backrest) of the front multicon-
tour seats is increased.
i
When you adjust the multicontour seat,
noises may result from pumping air into or re-
leasing air out of the air chambers.
Page 239 of 705
238 Control systemsCOMAND seats1Scale
2Cursor
3Current setting
Slide qmr or rotate ymz until desired
setting is reached.
Saving setting: Press n.
Adjusting thigh support
This function is used to adjust the air
chambers for the thighs.
Select seat (
page 236).
Selecting “Thighs”: Slide qmr or
rotateymz.
Confirming selection: Press n.
A scale appears.
Slide qmr or rotate ymz until desired
setting is reached.
Saving setting: Press n.
Adjusting backrest sides
This function is used to adjust the air
chambers in the backrest sides.
Select seat (
page 236).
Selecting “Seatback Sides”:
Slideqmr or rotate ymz.
Confirming selection: Press n.
A scale appears.
Slide qmr or rotate ymz until desired
setting is reached.
Saving setting: Press n.
Adjusting backrest curvature in lumbar
area
This function is used to adjust the air
chambers in the lumbar area of the back-
rest.
Select seat (
page 236).
Selecting “Lumbar”: Slide omp or
rotateymz.
Page 319 of 705
318 Controls in detailSeatsSeat adjustment
You can adjust the lumbar support, multi-
contour seats for driver and front passen-
ger, as well as drive-dynamic multicontour
seats using COMAND (
page 236).
Warning!
G
All seat, head restraint adjustments, as well
as fastening of seat belts, must be done be-
fore the vehicle is put into motion.Warning!
G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
back in an excessively reclined position as
this can be dangerous. You could slide un-
der the seat belt in a collision. If you slide
under it, the belt would apply force at the ab-
domen or neck. That could cause serious or
fatal injuries. The seat backrest and seat
belts provide the best restraint when the
wearer is in a nearly upright position and
belts are properly positioned on the body.
Your seat must be adjusted so that you can
correctly fasten your seat belt
(page 339).
Never place hands under the seat or near
any moving parts while a seat is being ad-
justed.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated when the respective door is
open. Therefore, do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
Warning!
G
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriate infant, or toddler restraint, or
booster seat recommended for the size and
weight of the child. For additional informa-
tion, see “Children in the vehicle”
(page 61).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
Page 328 of 705
327 Controls in detailSeats
Press switch down in the direction of
arrow3.
The rear power head restraint will fold
backward.
Press the switch forward or backward
in the direction of arrow2 or4.
The power head restraint will be tilted.
Luxury head restraints*
(rear outer seats)Adjustment
1Head restraint side cushions
2Head restraint height
You can individually adjust side
cushions1 of the luxury head restraints
Adjusting side cushions: Pull or push
side cushions1 into desired position.
Adjusting head restraint angle: Grip
head restraint at upper edge of cushion
and pull it forward or backward in di-
rection of arrow2.
Multicontour seats*, rear
You can adjust the rear outer multicontour
seats using the buttons on the center con-
sole.
1To select right rear passenger seat
2Massage setting, gentle
3Massage setting, vigorous
4To adjust position of backrest curva-
ture (lordosis)
5Lumbar region support
6Side bolster adjustment
7To select left rear passenger seat
Switch on the ignition (
page 315).
Warning!
G
When folding back the side cushions, never
reach between the side cushion and the
mounting post. You could otherwise be
trapped.
Page 329 of 705
328 Controls in detailSeats
Selecting a seat: Press rocker
switch1 or7 forward or backward.
The indicator lamp on the selected but-
ton lights up for a short while.
Gentle massage
Switching on: Press rocker switch2
forward.
Switching off: Pull rocker switch2
backward.
Vigorous massage
Switching on: Press rocker switch3
forward.
Switching off: Pull rocker switch3
backward.
Position of backrest curvature
Moving upward: Press rocker
switch4 forward.
Moving downward: Pull rocker
switch4 backward.Lumbar region support
Selecting greater curvature: Press
rocker switch5 forward.
Selecting less curvature: Pull rocker
switch5 backward.
Side bolster adjustment
Reducing width: Press rocker
switch6 forward.
Increasing width: Pull rocker
switch6 backward.
Easy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the driver’s seat is in its
maximum rearward position and the steer-
ing wheel is in its uppermost position.
The easy-entry/exit feature can be activat-
ed or deactivated in the “Vehicle” menu of
the COMAND system (
page 224).
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:
Press seat adjustment switch
(page 319).
Move steering column stalk
(page 330).
Press one of the memory position but-
tons or the memory button M
(page 337).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
Page 337 of 705
336 Controls in detailMemory functionPrior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach, and comfort. The head re-
straint should also be adjusted for proper
height. See also the section on air bags
(page 45) for proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the inside and outside
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small chil-
dren should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety Stan-
dards 213 and 225 and Canadian Motor
Vehicle Safety Standards 213 and 210.2.With the memory function you can store up
to 3 different settings.
The following settings are saved for each
stored position the driver’s door:
Seat position and lumbar support
Multicontour seat*: previously select-
ed setting
Drive-dynamic multicontour seat*: ac-
tivation/deactivation
Steering wheel position
Exterior rear view mirrors position
The following settings are stored when us-
ing the buttons on the front passenger
door:
Seat position and lumbar support
Multicontour seat*: previously select-
ed setting
Drive-dynamic multicontour seat*: ac-
tivation/deactivationThe following settings are stored when us-
ing the buttons* on the rear passenger
doors (Canada only):
Seat position
Multicontour seat*: previously select-
ed settingWarning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.
Page 338 of 705
337 Controls in detail
Memory function
The memory button and stored position
buttons are located on the door control
panel.
MMemory button
1 2 3Memory position buttons
Switch on the ignition (
page 315).
or
Open the respective door.
Storing positions into memory
Adjust the seat (
page 318) to the de-
sired position.
On the driver’s side: adjust the steering
wheel (
page 330) and the exterior
rear view mirrors (
page 332) to the
desired position.
Press memory buttonM.
Release memory buttonM and push
one of the position buttons within
3 seconds.
All the settings are stored with the se-
lected position.
Recalling positions from memory
Press and hold one of the position
buttons until the seat, steering wheel
and exterior rear view mirrors have fully
moved to the stored positions.
!
Do not operate the power seats using the
memory button if the seat backrest is in an ex-
cessively reclined position. Doing so could cause
damage to front or rear seats.
First move seat backrest to an upright position.
i
Releasing the button immediately stops
movement to the stored positions.
The multicontour seat* and/or lumbar support
will continue to be adjusted.
