MERCEDES-BENZ S550 4MATIC 2008 W221 Owner's Manual

370 Controls in detail
Fastening the seat belts
Proper use of seat belts

Do not twist the seat belt when fasten-
ing.

Adjust seat belt so that the shoulder
portion is located as close as possible
to the middle of the shoulder (it should
not touch the neck). Never pass the
shoulder portion of the seat belt under
your arm.

Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.

Place the seat backrest in a nearly up-
right position.

Never use a seat belt for more than one
person at a time.

Do not fasten a seat belt around a per-
son and another object at the same
time. When using a seat belt to secure
infant restraints or toddler restraints or
children in booster seats, always follow
the child seat manufacturer’s instruc-
tions.

Check your seat belt during travel to
make sure that it is properly posi-
tioned.

Make sure the seat belt is always fitted
snugly. Take special care of this when
wearing loose clothing.For more information, see “Seat belts”
(
page 52).
Seat belt height adjustment
The vehicle automatically adjusts the seat
belt height for the driver’s and front pas-
senger’s seats as well as for the rear outer
seats. Comply with the instructions on how
to properly fasten a seat belt
(
page 368).
Warning!G
Do not pass seat belts over sharp edges.
They could tear.
Do not allow the seat belt to get caught in
the door or in the seat adjustment mecha-
nism. This could damage the seat belt.
Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the seat belts.
Do not bleach or dye seat belts as this may
severely weaken them. In a crash, they may
not be able to provide adequate protection.
Damaged seat belts or seat belts that were
highly stressed in an accident must be re-
placed. Contact an authorized
Mercedes-Benz Center.

371 Controls in detail
Lighting
Lighting
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.iIf you drive in countries where vehicles drive
on the other side of the road than the country in
which the vehicle is registered, you must have
the headlamps modified for symmetrical low
beams. Relevant information can be obtained at
any authorized Mercedes-Benz Center.
iThe active Bi-Xenon headlamps monitor
your steering angle and driving speed, then auto-
matically shift their beams to either side to bet-
ter follow the curvature of the road ahead,
increasing usable illumination over conventional
headlamps.
1‚Standing lamps, left (turn left two
stops)
2ˆStanding lamps, right (turn left
one stop)
3MOff
Daytime running lamp mode
(
page 373)
4*Automatic headlamp mode
Daytime running lamp mode
(
page 373)
5CParking lamps (also side marker
lamps, tail lamps, license plate
lamps, instrument panel lamps)
6BLow beam headlamps or high
beam headlamps when the com-
bination switch is pushed for-
ward. The tail lamps, license
plate lamps, side marker lamps,
parking lamps and instrument
panel lamps also come on.
7‡Front fog lamps
8†Rear fog lamp

372 Controls in detail
Lighting
Manual headlamp mode
The low beam headlamps and parking
lamps can be switched on and off with the
exterior lamp switch.
Switching on low beam headlamps
Turn the exterior lamp switch toB.
The green indicator lampC in the
exterior lamp switch comes on.Automatic headlamp mode
The following lamps switch on and off au-
tomatically depending on the brightness of
the ambient light:

Low beam headlamps

Tail and parking lamps

License plate lamps

Side marker lamps
iIf you hear a warning signal you have forgot-
ten to switch off the headlamps before opening
the driver’s door.
In addition the message “Please switch off
lights” appears in the multifunction display.
Switch off the headlamps.
!Failure to switch off the headlamps when
leaving the vehicle may result in a discharged
battery.
Warning!G
If the exterior lamp switch is set to*,

the headlamps may switch off unexpect-
edly when the system senses bright am-
bient light, for example light from
oncoming traffic.

the headlamps will not be automatically
switched on under foggy conditions.
To minimize risk to you and to others, acti-
vate headlamps by turning exterior lamp
switch to B when driving or when traffic
and/or ambient lighting conditions require
you to do so.
In low ambient lighting conditions, only
switch from position * to B with the
vehicle at a standstill in a safe location.
Switching from * to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.

373 Controls in detail
Lighting
Turn the exterior lamp switch to *.
With the SmartKey in starter switch
position1 or the KEYLESS-GO*
start/stop button pressed once, only
the parking lamps and the side marker
lamps will switch on and off automati-
cally.
When the engine is running, the low
beam headlamps, the tail and parking
lamps, the license plate lamps, and the
side marker lamps will switch on and
off automatically.Daytime running lamp mode
Turn exterior lamp switch to
positionM or*.
When the engine is running, the low
beam headlamps are switched on.
In low ambient light conditions, the fol-
lowing lamps will switch on additional-
ly:

Tail and parking lamps

License plate lamps

Side marker lamps
Canada only
The daytime running lamp mode is manda-
tory and therefore in a constant mode.When the engine is running, and you shift
from a driving position to positionN orP,
the low beam headlamps will switch off
with a 3-minute delay.
When the engine is running, and you
turn the exterior lamp switch to
positionC, the parking lamps and
the side marker lamps switch on addi-
tionally.

turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime run-
ning lamp mode.
The corresponding exterior lamps
switch on (
page 371).
The automatic headlamp feature is only an
aid to the driver. The driver is responsible for
the operation of the vehicle’s lights at all
times.
iUSA only:
With the automatic headlamp mode activated
you can switch on the high beam headlamps in
low ambient lighting conditions.
iWith the daytime running lamp mode activat-
ed and the engine running, the low beam head-
lamps cannot be switched off manually.
iWith the exterior lamp switch in position
M or *, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the exterior
lamp switch to positionB to permit activa-
tion of the high beam headlamps.

374 Controls in detail
Lighting
USA only
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Setting daytime running lamp mode
(USA only)” (
page 281).
When the engine is running, and you turn
the exterior lamp switch to position C
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 371).Locator lighting and night security illu-
mination
The locator lighting and night security illu-
mination are described in the COMAND ve-
hicle section under “Setting locator
lighting” (
page 243) and “Setting night
security illumination” (
page 242).
Fog lampsFront fog lampsSwitch on the low beam
headlampsB (
page 372).
Pull out exterior lamp switch to first
stop.
The front fog lamps are switched on.
The green indicator lamp‡ in the
exterior lamp switch comes on
(
page 371).
Push in the exterior lamp switch.
The front fog lamps are switched off.
The green indicator lamp‡ in the
exterior lamp switch goes out.
iWith the daytime running lamp mode
activated and the exterior lamp switch in
position M, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the exterior
lamp switch to positionB or * to permit
activation of the high beam headlamps.
Warning!G
In low ambient lighting or foggy conditions,
only switch from position * to B with
the vehicle at a standstill in a safe location.
Switching from * to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.
iFog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
iFog lamps cannot be switched on manually
with exterior lamp switch in position*. To
activate the fog lamps, turn exterior lamp switch
to positionB first.

375 Controls in detail
Lighting
Rear fog lamp (driver’s side only)
Switch on the low beam
headlampsB (
page 372).
Pull out exterior lamp switch to second
stop.
The front fog lamps and the rear fog
lamp switch on.
The yellow indicator lamp† in the
exterior lamp switch comes on
(
page 371).
Push in the exterior lamp switch to first
stop.
The rear fog lamp switches off.
The green indicator lamp‡ in the
exterior lamp switch goes out.
The front fog lamps remain lit.
Switching on high beams
Combination switch
1High beam
2High beam flasher
Turn the exterior lamp switch to
positionB (
page 371).
Push the combination switch in the di-
rection of arrow1.
The high beam indicatorA in the in-
strument cluster comes on
(
page 28).
High beam flasher: Pull the combina-
tion switch briefly in the direction of
arrow2.
Headlamp cleaning system
1Headlamp cleaning button
Switch on the ignition (page 344).
Press button1 up or down.
The headlamps are cleaned with a
high-pressure water jet.
iThe headlamps are automatically cleaned
when, at the same time,

the engine is running

the headlamps are switched on

the windshield wipers have wiped the wind-
shield with washer fluid fifteen times


376 Controls in detail
Lighting
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system”
(
page 548).
Corner-illuminating lamps
The corner-illuminating lamps improve illu-
mination of the area in the direction into
which you are turning.
The corner-illuminating lamps will operate
with the engine running and with:

the exterior lamp switch in
positionB or* (
page 371)
or

the daytime running lamp mode acti-
vated (
page 373).Switching on corner-illuminating lamps
Switch on the left or right turn signal
(
page 371), depending on whether
you are turning left or right.
or
Turn steering wheel in desired direc-
tion.
The corner-illuminating lamp on the
side of your steering direction comes
on.
When you switch off the ignition or press
button1, the automatic function is reset and
will start counting the next time from the begin-
ning.iWith the automatic headlamp mode activat-
ed: The corner-illuminating lamps will only come
on in low ambient lighting conditions.
iIf you are driving faster than 43 mph
(70 km/h), the corner-illuminating function is
not available.
iIf you have switched on the turn signal for
one side but turn the steering wheel in the other
direction, the corner-illuminating lamp lights up
on the side of the turn signal.
iThe corner-illuminating lamps temporarily
come on on both sides of the vehicle if you turn
the steering wheel in one direction and then in
the other direction shortly thereafter.
iThe corner-illuminating lamps will come on
automatically depending on the steering angle,
even if you did not switch on either turn signal. If
the corner-illuminating lamps came on automat-
ically, they will also go out automatically depend-
ing on the steering angle.
iWhen you shift the automatic transmission
in reverse gearR, the corner-illuminating lamp
opposite to your steering direction comes on.
The turn signal has no influence on the corner-il-
luminating lamp on the outside of the curve.


377 Controls in detail
Lighting
Switching off the corner-illuminating
lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating lamps if they were acti-
vated by switching on the left or right turn
signal.
If the turn signal should stay on after mak-
ing the turn, the turn signal and corner-illu-
minating lamp can be switched off by
returning the combination switch to its
original position.Hazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher is automatical-
ly switched on if

an air bag has been triggered

S 600/S 65 AMG and USA only: you
brake the vehicle strongly at a speed of
more than 50 mph (70 km/h) and
bring it to a complete stop
1Hazard warning flasher switch
Switching on: Press hazard warning
flasher switch.
All turn signals will flash.
Switching off: Press hazard warning
flasher switch again.
iIf you are driving faster than 25 mph
(40 km/h) when activating the turn signal indica-
tor, the corner-illuminating lamp function is
switched off.
iThe corner-illuminating lamp may remain lit
for a short time. The corner-illuminating lamp
lights up for no more than 20 seconds with the
vehicle standing still. It is then switched off even
if the turn signal is still switched on or you have
turned the steering wheel to full lock.
iWith the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the SmartKey in the
starter switch is in position
1 or2 or the
KEYLESS-GO* start/stop button (
page 346) is
pressed once or twice.
iIf the hazard warning flasher was activated
automatically, also press hazard warning flasher
switch 1 to switch off the hazard warning flash-
er.

378 Controls in detail
Lighting
Interior lighting Interior lighting in the front
The controls are located in the overhead
control panel.
1Left reading lamp on/off
2Rear interior lamps on/off
3Front interior lighting on/off
4Interior lighting control
5Right reading lamp on/offAutomatic control
Deactivating: Press button4.
The OFF indicator lamp next to the but-
ton comes on.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle

remove the SmartKey from the
starter switch

open a door
Activating: Press button4.
The interior lighting switches on in
darkness, when you:

unlock the vehicle

remove the SmartKey from the
starter switch

open a door
iEven with the SmartKey being removed from
the starter switch you can still use the lighting for
the storage compartment, glove box and vanity
mirrors, when you open a door or press one of
the interior lighting buttons. If a lamp is switched
on and you do not lock the vehicle, it will be
switched off automatically after 30 minutes.
When you lock the vehicle from the outside, the
interior lighting is switched off.iThe interior lighting is factory-set to auto-
matic mode.

379 Controls in detail
Lighting
The interior lighting switches off auto-
matically following an adjustable time
delay (
page 248).
Manual control
Switching on/off front interior light-
ing: Press button 3.
Switching on/off rear interior light-
ing: Press button 2.
The front reading lamps reading lamps are
located in the lower edge of the interior
rear view mirror.
Switching on/off front reading
lamps: Press button 1 or 5.
Ambient lighting: The brightness of
the ambient lighting is adjusted via
COMAND (
page 247).Interior lighting in the rear
1Rear interior lamp
2Button
3Reading lamp
Press button2.
You can switch the lamps on/off in
succession as follows:

reading lamp3 and rear interior
lamp1 on

only reading lamp3 on

reading lamp3 off
Door entry lamps
For better orientation in the dark, the cor-
responding door entry lamps will switch on
in darkness when you open a door and the
automatic control is activated.
The door entry lamps switch off when the
corresponding door is closed.
iIf the door remains open, the interior lighting
switches off automatically after approximately
5minutes.
iIf you turn the SmartKey in the starter
switch to position0 and switch off the exterior
headlamps, the door entry lamps will remain lit
for approximately 5 minutes.
