light MERCEDES-BENZ SL-Class 2008 R230 Comand Manual

109
Telephone*
Telephone operation
You can use the following functions in the
telephone menu:
Entering a telephone number
(
page 110)
Use the redial function (page 111)
Displaying the dialed numbers list
(
page 112)
Displaying the received calls list
(
page 113)
Use speed-dialing (page 114)
Use quick-dialing (page 114)
Displaying the phone book
(
page 116)
Adjusting balance settings (page 36)
The system detects an incoming call, the
phone rings.
Incoming calls are indicated in a window in
any system (e.g. radio).
The window shows:
the caller’s number if it is transmitted
or
the caller’s name if her or his name and
number are saved in the phone book. Accepting a call
Press
k.
or
Press E.
The window disappears and the display
will change to the call menu
(
page 114). An active audio source
will be muted. You talk over the hands-
free set.
Muting the ringing tone
Press K.
or
Press H to highlight Reject and
than press E.
The window disappears. The last active
audio source is audible.
Incoming call

112 Telephone*
Telephone operation
Selecting an entry from the dialed
numbers list
The COMAND automatically generates a
list of the last 10 numbers dialed. The list
is sorted chronologically with the most
recently dialed number at the top of the
list.
Displaying the list
In the Telephone menu (page 108),
press the
Redial soft key.
or
In the Telephone menu (page 108),
press the
Calls soft key.
Press H to display the dialed num-
bers list.
The most recently dialed number is
highlighted. The status bar shows:
the caller’s name if her or his name and
number are stored in the phone book
the message Unknown Name if no entry
is available
You can select the following functions:
Changing the list display
Selecting an entry and begin dialing
Ending a call (page 111) Changing the list display
Press the 123 soft key.
The display changes to names.
or
Press the ABC soft key.
The display changes to numbers.
Selecting an entry and begin dialing
Use g or G to select the desired
entry.
Press k.
or
Press E.
The telephone dials the number.
i
Duplicate entries will be shown only
once. This means the list may contain
less than 10 entries.

113
Telephone*
Telephone operation
Selecting an entry from the received
calls list
The COMAND automatically generates a
list of the last 10 calls received. The list is
sorted chronologically with the most
recently received call
at the top of the list.
Displaying the list
In the Telephone menu (page 108),
press the
Calls soft key.
The list is displayed and the most
recently received number is
highlighted. The status bar shows:
the caller’s name if her or his name and
number are stored
in the phone book
the message Unknown Name if no entry
is available
the telephone number You can select the following functions:
Changing list display (page 112)
Selecting an entry and begin dialing
(
page 112)
Ending a call (page 111)
Missed calls
If there are one or more missed calls avai-
lable on the mobile phone, a correspon-
ding message will appear.
Press the Back soft key to return to the
Telephone menu.
or
Press a.
or
Press E.
i
Duplicate entries will be shown only
once. This means the list may contain
less than 10 entries.

116 Telephone*
Telephone operation
The phone book contains all entries
of the internal memory of the mobile
phone (TDMA/CDMA and GSM mobile
phone)
of the address book (page 192) if it
contains any telephone numbers
Displaying the phone book
In the Telephone menu (page 108),
press the Z soft key.
The phone book will appear. The first entry found is at the top of the list
and highlighted. All entries are marked
with symbols which
indicate the phone number category.
Entries marked with symbols have been
imported into the phone book from the in-
ternal memory of the mobile phone.
Usable phone number categories:
Symbol : Cell number
Symbol : Private number
Symbol : Business number
And additional categories:
Symbol : Fax number
Symbol : Pager number
Symbol : Main number
Phone book
i
GSM mobile phone:
COMAND also reads entries from SIM
card.
Phone book
entryStatus bar shows
A phone numberUnknown Name
A name for a
phone numberThe phone number
Several numbersSeveral Numbers
i
Address book entries with more than
one phone number are marked with the
Main number symbol.

120 Telephone*
Telephone operation
Saving the entry
In the Input menu, press the OK soft
key.
If you have not assigned a name, the
system will save the entry in the
Other
category, otherwise under the name
you have assigned.
Cell Phone
The message Transmitting Data
to Telephone is displayed.
If transmission is succesful, the
message
Data Has Been Saved will
appear and the phone book is
displayed again.
Otherwise the message
Error
Occured While Saving Data
will
appear.
Press E to confirm.
The phone book is displayed again.
Address Book
If transmission is succesful, the
message
Data Has Been Saved will
appear and the phone book is
displayed again.
Otherwise the message
Error
Occured While Saving Data
will
appear.
Press E to confirm.
The phone book is displayed again. Deleting a phone book entry
Select a phone book entry at the
COMAND (
page 116).
Press the Delete soft key.
The delete dialogue will appear.
Press E to confirm with Yes.
The message is deleted.
If you do not wish to delete the message
Press h to highlight No and then
press E.
or
Press the Back soft key.
i
If you select an address book entry, the
Delete soft key is greyed out. The
selected entry must be deleted from
within the address book (
page 202).

124 Telephone*
Telephone operation
Use g or G to select the phone
number type.
Press E.
Phone number type available:
The message
Data Has Been Saved
will appear. After around three se-
conds, the list from where you started
the saving process will appear. Phone number type occupied:
The message
Do You Want to Over-
write Entry?
will appear.
Press E if you wish to overwrite the
entry.
The message
Data Has Been Saved
will appear. After around three se-
conds, the list from where you started
the saving process will appear.
If you do not wish to overwrite the entry
Press h to highlight No if you do not
wish to overwrite the entry.
Press E.
The list from where you started the sto-
rage will appear.
i
If transmission is not succesful the
message
Error Occured While
Saving Data
will appear.
Press E to confirm.
The phone book is displayed again.

126 Navigation
Important notes

Important notes
WarningG
For safety reasons, you should only enter a
destination when the vehicle is stationary.
When the vehicle is in motion, a passenger
should enter the destination. Study manual
and select route before driving.
Do not watch display screen or operate but-
tons while the vehicle is in motion - let voice
instructions guide you. Stop at a safe locati-
on before using buttons or making correc-
tions.
Traffic regulations always have priority over
any route recomm endations given.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car is co-
vering a distance of 44 feet (approximately
14 m) every second.
The route calculated by COMAND is a re-
commendation on how to best reach your
selected destination.
During route guidance, you will not receive
any information on
Traffic lights
Stop and yield signs
Parking or stopping zones
One-way streets
Narrow bridges
Similar traffic regulation data
You should therefore always strictly observe
traffic regulations while driving. Drive care-
fully and always obey tr affic laws and road
signs even if they contradict COMAND in-
structions.
WarningG
The Navigation DVD module contains a
Class 1 laser product. There is a danger of
invisible laser radiation if the cover is ope-
ned or damaged.
Do not remove the cover. The Navigation
DVD module does not contain any parts ser-
viceable by the user. For safety reasons,
have any necessary service work performed
only by qualif ied personnel.

153
Navigation
Route guidance
Important map symbols:
Current vehicle location and direction
of travel
y
If the map orientation
2D Heading Up
(page 169) is chosen, the arrow will
always point upward.
The remaining route section is
highlighted in blue color.
Display example 2: On the right side of the display, the symbol
for the next driving maneuver is indicated
(here: right turn).
On the very right side next to turn symbol
is the distance bar. It indicates the
distance to the next driving maneuver
(here: 300 ft).
The status bar shows the name of the
street after the driving maneuver, if
available, here:
PARK AVE
The destination is marked with a flag
$ on
the map, an intermediate destination is
marked with a flag showing the letter
S.
Altering the map scale
The current map scale is indicated on the
left side of the status bar.
Press any soft key.
The soft key displays appear.
i
The colored highlight only appears
when the system has completed the
route calculation.
i
Using the multifunction steering wheel
buttons, the display unit can be
changed between km or miles (see
your vehicle’s Operator’s Manual).
When the display unit is set to
miles, the COMAND will indicate
distances in miles (mi) or feet (ft).
When the display unit is set to km,
the COMAND will indicate
distances in kilometers (km) or
meters (m).
i
If no other action is taken within
approx. 8 seconds, the soft key
displays will disappear again.

156 Navigation
Route guidance
“You are about to enter an area where
turn by turn guidance cannot be
provided.”
Route guidance within a partially
digitized area
If you start route guidance in this type of
area, you will hear the following
announcements:
“You are currently in an area where
turn by turn guidance cannot be
provided.”
“Please follow the arrow on the
display.” Route guidance is provided by means of a
direction arrow showing the compass
heading to the destination. COMAND will
not generate automatic navigation
announcements.
If you try to repeat the current voice
instruction manually, (
page 151) you will
hear the announcement “You are currently
in an area where turn by turn guidance
cannot be provided.”.
During route guidance, the display is
divided. On the right-hand side you will see
the direction arrow showing the compass
heading to the destination.
On the left-hand side of the display you will
see the map with the suggested route. The
suggested route is highlighted blue.
However, it may not be possible to follow
the suggested route because, for example,
the road is closed or not open for car
traffic. 1
Current vehicle location and direction
of travel y
2 Arrow indicates the direction of the
destination and the distance to
destination
If, during route guidance, COMAND leads
you back into a fully digitalized area, route
guidance will simply continue in the usual
manner.
i
When you call up the route info to this
type of destination, (
page 160) the
following data shown there may differ
from the actual situation:
Estimated time of arrival
Distance to the destination

157
Navigation
Route guidance
Route guidance to an off-road destina-
tion
COMAND can guide you to destinations
within the area covered by the digital map,
even if a destination is not located at a
road known to the system.
These destinations are shown as off-road
destinations, which you can enter using
the map, for example.
In these cases, COMAND guides you for as
long as possible with navigation announce-
ments and displays on roads known to the
system.
Shortly before you reach the last known
point in the digitized road network, you will
hear the announcement “The destination
is nearby. Follow the arrow on the display”.
You will then see an arrow that indicates
the direction to the off-road destination.
When the off-road destination is close to
the road, “Area of dest. reached” appears
in addition below the arrow. The section of the route from the last
known point on the map to the off-road
destination is highlighted blue. It simply
shows the direction to the off-road
destination without taking into account
any type of obstacles in the way.
1 Current vehicle position, the triangle
indicates the vehicle’s direction of
travel
2 Off-road section of the route
3 Off-road destination
4 Direction arrow, shows compass
heading to destination, the distance to
destination and
OFF ROAD indication
Off-road and off-map
WarningG
The COMAND navigation system may direct
you to off-road routes that your vehicle may
not be capable of trav ersing through without
damaging your tires, wheels or vehicle. It is
the driver's sole responsibility to determine
the suitability of the ro ute. Off-road routes
may be of varying cond itions and their ap-
propriateness for use may be affected by va-
rious factors such as time of day, time of
year and immediate weather conditions that
cannot be judged or taken into considerati-
on by the COMAND system.
