MERCEDES-BENZ SL65AMG 2008 R230 Owner's Manual

150 Controls in detail
Control system
AMG menu
The main screen of the AMG menu shows
you the gear currently engaged as well as
the engine oil temperature.
Press button è or ÿ repeatedly
until you see the AMG menu.
1Engine oil temperature
2Gear indicatorUse buttons k or j to select the fol-
lowing functions in the AMG menu:Vehicle supply voltage
Press button è or ÿ repeatedly
until you see the AMG menu.
Press button j repeatedly until you
see the vehicle supply voltage.
1Vehicle supply voltage
2Gear indicator
iThis function is only available in AMG
vehicles.
iThe engine oil temperature symbol flashes if
the engine oil temperature has not yet reached
80°C. During this time, avoid driving at full
engine speed.
FunctionPage
Vehicle supply voltage150
RACETIMER151
Overall analysis153
Lap analysis153
iIf the engine reaches the overspeed range in
the manual shift program, the menu will be
shown in red. In addition, you will see UP next to
gear indicator 2 as a reminder to upshift.

151 Controls in detail
Control system
RACETIMER
The RACETIMER allows you to time and
save driving stretches in hours, minutes
and seconds.
Press button è or ÿ repeatedly
until you see the AMG menu.
Press button j repeatedly until you
see the RACETIMER.1Lap
2RACETIMER
3Gear indicatorStarting the RACETIMER
Press button æ.
The timer starts.
Displaying intermediate time
Press button ç while the timer is
running.
The intermediate time is shown for
5 seconds.
Stopping the RACETIMER
Press button æ.
The timer stops.
Warning!G
The RACETIMER feature is only for use on
roads and in conditions where high speed
driving is permitted. Racing on public roads
is prohibited under all circumstances and
the driver is and must always remain
responsible for following posted speed
limits.
iYou can start the RACETIMER when the
engine is running or the starter switch is in
position2 (
page 40).
iWhile the RACETIMER is being displayed,
you cannot adjust the volume using
buttonsæ or ç.
iWhen you stop the vehicle and turn the
SmartKey to position 1 (
page 40) or, in vehi-
cles with KEYLESS-GO*, turn off the engine and
do not open the driver’s door, the RACETIMER
stops timing. Timing is resumed when you
switch the ignition back on (
page 40) or
restart the engine (
page 53) and then press
the æbutton.

152 Controls in detail
Control system
Saving lap time and starting a new lap
Press button ç while the timer is
running.
The intermediate time will be shown for
5 seconds.
Press button ç within the next
5 seconds.
The intermediate time shown will be
saved as a lap time.
The RACETIMER begins timing the new
lap. The new lap begins to be timed as
soon as the intermediate time is called
up.1Best lap time
2Lap number
3RACETIMER
4Gear indicator
Resetting current lap
Press button æ while the timer is
running.
The timer stops.
Press button ç.
The lap time is reset to “0”.Deleting all laps
Press button æ while the timer is
running.
The timer stops.
Press the reset button twice
(
page 27).
Press button æ.
The timer starts. The saved laps are
deleted.
iYou can save up to nine laps.iIt is not possible to delete a single saved lap.
iWhen you switch off the engine, the
RACETIMER will be reset to“0” after 30 seconds.
All laps are deleted.

153 Controls in detail
Control system
Overall analysis
Press button è or ÿ repeatedly
until you see the AMG menu.
Press button j repeatedly until you
see the overall analysis.
1Overall analysis of RACETIMER
2Overall driving time
3Maximum speed
4Average speed
5Overall distance drivenLap analysis
Press button è or ÿ repeatedly
until you see the AMG menu.
Press button j repeatedly until you
see the lap analysis.
1Lap number
2Lap time
3Maximum speed
4Average speed during lap
5Lap length
Press button j or k to see other
lap analyses.
AUDIO menu
The functions in the
AUDIO menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO OFF appears in the
right multifunction display.
The following functions are available:
iThese functions are only available if you
have saved at least one lap and have stopped the
RACETIMER.iThese functions are only available if you
have saved at least two laps and have stopped
the RACETIMER.
iEach lap is shown in its own submenu. The
fastest lap is indicated by flashing symbol 1.
FunctionPage
Selecting radio station154
Selecting satellite radio station154
Operating CD player155

154 Controls in detail
Control system
Selecting radio station
Turn on COMAND and select radio. Re-
fer to the separate operating instruc-
tions.
Press button è or ÿ repeatedly
until you see the currently tuned sta-
tion in the right multifunction display.
1Waveband setting
2Station frequency
Press button k or j repeatedly
until the desired station is found.Selecting satellite radio station
The satellite radio is treated as a radio
application.
Select satellite radio with the corre-
sponding key on the COMAND control
panel (SAT).
Press button è or ÿ repeatedly
until you see the currently tuned sta-
tion in the right multifunction display.
1SAT mode
2Channel name or number
Press button k or j repeatedly
until the desired channel is found.iYou can only store new stations using the
designated feature on the radio. Refer to the
separate operating instructions.
iAdditional optional satellite radio equipment
and a subscription to satellite radio service pro-
vider are required for satellite radio operation.
Contact an authorized Mercedes-Benz Center
for details and availability for your vehicle.
For more information, refer to separate
COMAND operating instructions.

155 Controls in detail
Control system
Operating the CD player
Selecting CD track
Turn on COMAND and select CD. Refer
to the separate COMAND operating
instructions.
Press button è or ÿ repeatedly
until the settings for the CD currently
being played appear in the right multi-
function display.
1Current CD (with additional number
from 1 to 6 when running from CD
changer)
2Current track
Press button k or j repeatedly
until the desired track is selected.Selecting MP3-CD track
Turn on COMAND and select MP3-CD.
Refer to the separate COMAND
operating instructions.
Press button è or ÿ repeatedly
until the settings for the MP3-CD
currently being played appear in the
right multifunction display.
1Current track
Press button k or j repeatedly
until the desired track is selected.
NAV menu
The
NAV menu contains the functions
needed to operate your navigation system.
Press button è or ÿ repeatedly
until you see the message
NAV in the
left multifunction display.
The message shown in the multifunction
display depends on the status of the
navigation system:

With COMAND switched off, the
message
NAV OFF appears in the
multifunction display.

With COMAND switched on but route
guidance not activated, the direction of
travel and, if applicable, the name of
the street currently traveled on appear
in the multifunction display.

With COMAND switched on and route
guidance activated, the direction of
travel and maneuver instructions
appear in the multifunction display.
iTo select a CD from the magazine of the
CD changer, press a number on the COMAND
system key pad located in the upper center
console.

156 Controls in detail
Control system
Please refer to the COMAND manual for
instructions on how to activate the route
guidance system.
Distronic* menu
Use the
DISTRONIC menu (page 222) to
display the current settings for your Dis-
tronic system. The information shown in
the multifunction display depends on
whether the Distronic system is activated
or deactivated.
Please refer to the “Driving systems” sec-
tion of this manual (
page 218) for in-
structions on how to activate Distronic.
Press button è or ÿ repeatedly
to select the
DISTRONIC menu in the
multifunction display.
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the sys-
tem. Such messages appear in the multi-
function display and are based on
conditions or system status the vehicle’s
system has recorded.
The vehicle status message memory menu
only appears, if messages have been
stored.
Press button è or ÿ repeatedly
until the vehicle status message mem-
ory menu appears in the multifunction
display.
If the vehicle status message memory
menu does not appear, no messages
have been stored.
Warning!G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Center to address the malfunction and
warning messages (
page 359).

157 Controls in detail
Control system
If conditions have occurred causing status
messages to be recorded, the number of
messages appears in the right multifunc-
tion display:
1Number of recorded status messages
Press button k or j.
The stored messages will now be dis-
played in the order in which they have
occurred. For malfunction and warning
messages, see “Vehicle status messag-
es in the multifunction display”
(
page 359).Should the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display

when the SmartKey in the starter
switch is turned to position0 or
removed from the starter switch
or

when you turn off the engine by press-
ing the KEYLESS-GO* start/stop
button on the gear selector lever once
and open the driver’s door (this puts
the starter switch in position 0, same
as with the SmartKey removed from
the starter switch)
Settings menu
In the
Settings menu there are two
functions:

The function Reset, with which you can
reset most settings to those set at the
factory.

A collection of submenus with which
you can make individual settings for
your vehicle.
The following settings and submenus are
available:
iAfter you have scrolled through all recorded
status messages, the first recorded message
appears again.
iThe vehicle status message memory will be
cleared when you then turn the SmartKey in the
starter switch to position 1 or 2, or when you
press the KEYLESS-GO* start/stop button once
or twice without depressing the brake pedal. You
will then only see high priority messages in the
multifunction display (
page 359).
FunctionPage
Resetting all settings158
Submenus in the Settings menu158
Instrument cluster submenu160
Time submenu161
Lighting submenu163
Vehicle submenu166
Convenience submenu166

158 Controls in detail
Control system
Resetting all settings
You can reset the functions of most of the
submenus to the factory settings.
For safety, the
Light Circuit Headlamp
Mode
submenu in the Lighting menu can
be reset with the vehicle at standstill only.
Press button è or ÿ repeatedly
until the
Settings menu appears in the
multifunction display.
Press the reset button in the instru-
ment cluster for approximately
3 seconds.
In the right multifunction display you
will see the request to press the reset
button again to confirm.
Press the reset button again.
The functions of most submenus will
reset to factory settings.
Submenus in the Settings menu
Press button è or ÿ repeatedly
until the
Settings menu appears in the
multifunction display.
Press button j.
In the right multifunction display you
see the collection of submenus. There
are more submenus than can be simul-
taneously displayed.
Press button ç.
The selection marker moves to the next
submenu.
Scroll down with the ç button,
scroll up with the æ button.
With the selection marker on the de-
sired submenu, use the j button to
access the individual functions within
that submenu.
Once within the submenu, use
thej button to move to the next
function or the k button to move to
the previous function within that sub-
menu.
Use buttons æ or ç to change
the settings of the respective function.
iThe settings you have changed will not be
reset unless you confirm the action by pressing
the reset button a second time.

159 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus.
Detailed instructions on making individual
settings can be found on the following
pages.
Instrument clusterTimeLightingVehicleConvenience
(page 160)(page 161)(page 163)(page 166)(page 166)
Selecting speedometer
display modeSynchronizing time with
head unitSetting daytime running
lamp mode (USA only)Setting automatic lockingActivating
easy-entry/exit feature
Selecting standard
displaySetting the time (hour)Setting locator lighting
Selecting languageSetting the time
(minutes)Setting night security
illumination
Setting interior lighting
delayed switch-off
