MERCEDES-BENZ SLK-Class 2006 R171 Comand Manual

50 Audio
Radio operation
Storing using Autostore
The Autostore function places stations into
the Autostore memory sorted by reception
quality.
The system stores the station with the
strongest signal in preset 1.Switch to the desired waveband
(
page 42).
Press the Autost. soft key.
The Autostore preset list appears.
Use to select the
Reprogram Autostore header entry.
Press.
The Autostore search starts. After a de-
lay the new preset assignment ap-
pears. The system tunes to the station
stored on preset 1.
To tune-in another station from the
Autostore preset list (
page 45).
i
The Autostore feature stores presets in
a separate memory, not in the regular
presets seen under the
Presets soft
key. As such, the Autostore memory is
only temporary.

51 Audio
Single CD operation

Single CD operation
Only touch the CD on the edges.
Clean the CD with a dry, lint-free cloth.
Wipe the CD a straight line from the
center. Never wipe the CD in a circular
motion.
Do not use rubbing alcohol or solvents
to clean CDs.
Do not expose the CDs to heat or direct
sunlight.
Do not write or put labels on CDs
Safety instructions
WarningG
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and
operate the audio system only when road,
weather and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
Warning G
The CD drive is a Class 1 laser product.
There is a danger of invisible laser radiation
when you open or damage the cover.
Do not remove the cover. The CD drive does
not contain any parts serviceable by the us-
er. For safety reasons, have any necessary
service work performed by qualified person-
nel.
Tips on caring for your CDs

52 Audio
Single CD operation
Open the Single CD main menu
(
page 53);
or
Load an audio CD into the COMAND
CD drive.
aaSwitching to Single CD mode
Loading a CD
WarningG
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and oper-
ate the audio system only when road, weath-
er and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
!
Do not attach labels of any type to the
CD. They may become detached and
damage the drive.
Your CD drive has been designed to
play CDs which correspond to the IEC
60908 standard. Therefore only CDs
not exceeding a thickness of 1.3 mm
can be used.
!
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they will become stuck and
damage the drive.
Data carriers which contain data on
both sides can cause play-back prob-
lems because the storage layers are
thinner than one-sided data carriers.
Do not play single-CDs (80 mm) with an
adapter. An adapter could become
stuck and damage the drive. Only use
12 cm diameter CDs.
i
The COMAND CD drive may not be able
to play audio CDs with copy protection.

53 Audio
Single CD operation
The COMAND CD drive holds one CD. The
slot for inserting a CD is located above the
display (
page 15).
Insert a CD into the CD slot while
COMAND is switched ON. Insert the
CD face up.
COMAND pulls in the CD. If the CD is
an audio CD, the system switches to
Single CD mode and starts playing the
first track.
Press.
COMAND ejects the CD.
Remove the CD from the slot.
If you do not remove the CD from the
slot within approx. 7 seconds, the CD is
pulled back into the CD drive.
Open the Audio main menu
(
page 40).
Press the CD soft key.The system switches to Single CD
mode and starts playing the first track.
!
If a CD is already loaded, it must be
ejected before inserting the new CD.
Inserting a second CD in the slot with
another CD still loaded will cause dam-
age to the CD drive not covered by the
Mercedes-Benz Limited Warranty.
i
If the CD is an MP3 CD, the system
switches to MP3 mode
(page 62).
Ejecting a CD
Single CD main menu
i
The CD soft key is shaded out if no CD
is loaded. The system will not switch to
Single CD mode.
Load an audio CD into the
COMAND CD drive (
page 52)
The
MP3 soft key instead of the CD soft
key is visible when a MP3 CD has been
inserted.


54 Audio
Single CD operation
The center of the status bar shows:
The track number and total number
of tracks
The elapsed playing time of the
track
1Track title or track number
2Elapsed track playing time
3Track number/total tracks The Single CD main menu shows the track
title in the center if the CD contains corre-
sponding text data.
If the CD does not contain any CD text da-
ta, the track number is displayed instead of
the track title.
The following options are available:
Selecting via track skip
Selecting via track list (page 55)
Selecting via manual entry of the track
number (
page 55)
Selecting via scan search (page 56)Selecting via track skip
Selecting a track
i
Forward skipping:
The next track is played.
Backward skipping:
If the track has been playing longer
than approx. 10 seconds, the system
skips back to the beginning of the
track.
If less than 10 seconds have played,
the system skips back to the beginning
of the previous track.

55 Audio
Single CD operation
On the COMAND control unit
Open the Single CD main menu
(
page 53).
Pressfor forward skipping;
or
Press for backward skipping.
The tracks skip immediately after
pressing one of the buttons.
On the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Single CD dis-
play (
page 27).
Pressj for forward skipping;
or
Pressk for backward skipping.
The tracks skip immediately after
pressing one of the buttons.
Selecting via track list
The track list contains all tracks of the cur-
rent CD. Only one list entry is visible at a
time, it is the number of the track currently
playing.Use or  to select another track
from the list.
The current track remains playing while
selecting.
Press or wait approx. 3 seconds
without changing the selection.
The newly selected track is played.
Selecting via manual entry of the track
number
Open the Single CD main menu
(
page 53).
Press.
The Manual track input display ap-
pears.


56 Audio
Single CD operation
1Number of tracks on the CD (12 tracks)
Entry example: Track 1
Press.
Entry example: Track 12
Press and  in quick succession.
Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterized as follows:
Scan search plays each track on the
current CD for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
track listened to before the scan
search was started.
Starting scan search
Press the Scan soft key.
Ending scan search manually
Press the Scan soft key.
The track playing at the time the scan
is ended remains playing.
i
Entries beyond the number of available
tracks on the CD are not possible.
i
When you start the scan search, play-
back option
Normal Sequence
(page 57) is activated automatically.

57 Audio
Single CD operation
Open the Single CD main menu
(
page 53).
Press and hold or.
To stop release or.
The following options are available:
Normal sequence
Repeat track
Random track
Explanation of the playback options
Normal sequence
The tracks are played in the normal se-
quence (e.g. track 1, 2, 3 etc.).
The last track is followed by the first
track of the CD.
Repeat track
The current track will be repeated until
this function is deactivated.
Random track
The tracks are played in random order
(e.g. track 3, 8, 5 etc.).
Changing the playback option
In the Single CD main menu
(
page 53) press the Setting soft key.
The Settings menu is displayed.
The solid circle indicates which op-
tion is currently selected.
Press or  to select a different
option.
Press.
The option is activated. A correspond-
ing display will appear in the status bar
for all options except
Normal sequence.
An option will remain activated even if
COMAND is switched OFF and then ON
again.
Fast forward/reverse
Playback options

58 Audio
MP3 operation
Safety Instructions
WarningG
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and oper-
ate the audio system only when road, weath-
er and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
WarningG
The CD drive is a Class 1 laser product.
There is a danger of invisible laser radiation
when you open or damage the cover.
Do not remove the cover. The CD drive does
not contain any parts serviceable by the us-
er. For safety reasons, have any necessary
service work performed by qualified person-
nel.
Tips on data storage media
!
Do not attach labels of any type to the
CD. They may become detached and
damage the drive.
!
Your CD drive has been designed to
play CDs which correspond to the IEC
60908 standard. Therefore only CDs
not exceeding a thickness of 1.3 mm
can be used.
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they will become stuck and
damage the drive.
Data carriers which contain data on
both sides can cause play-back prob-
lems because the storage layers are
thinner than one-sided data carriers.
Do not play single CDs (80mm) with an
adapter. An adapter could become
stuck and damage the drive. Only use
12 cm diameter CDs.

59 Audio
MP3 operation
Only touch the CD on the edges.
Clean the CD with a dry, lint-free cloth.
Wipe the CD a straight line from the
center. Never wipe the CD in a circular
motion.
Do not use rubbing alcohol or solvents
to clean CDs.
Do not expose the CDs to heat or direct
sunlight.
Do not write or put labels on CDsPermissible MP3 CDs
In MP3 mode COMAND can read CD-R and
CD-RW CDs.
Permissible file systems
The permitted file system is
ISO9660/Joliet for CD-R and CD-RW.
Multi session CDs
With multi session CDs, the content of the
first session determines how COMAND
treats the CD.
Tips on caring for your MP3 CDsTips on creating MP3 CDs
i
CDs, software and hardware for writing
audio data to CDs are widely available.
Therefore, we cannot guarantee that
COMAND will be able to play every
user-written CD.
Problems may be encountered during
playback of user-written CDs with a
storage capacity of more than 700 MB.
These CDs do not meet valid standards
as of this printing.
