80 Audio
CD changer* operation
Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterized as follows:
Scan search plays each track on the
current CD for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
track listened to before the scan
search was started.Starting scan search
Press the Scan soft key.
Ending scan search manually
Press the Scan soft key.
The track playing at the time the scan
is terminated remains playing.
Open the CD changer main menu
(
page 75).
Press and hold or .
To stop release or .
The following options are available:
Normal sequence
Repeat track
Repeat CD
Track Random
CD Random
i
Entries beyond the number of available
tracks on the CD are not possible.
i
When you start scan search, playback
option
Normal sequence (page 81) is
activated automatically.
Therein scan search is restricted to the
current CD.
Fast forward/reverse
Playback options

81 Audio
CD changer* operation
Explanation of the playback options
Normal sequence
The tracks are played in the normal se-
quence (e.g. track 1, 2, 3 etc.).
If only one CD is loaded, the last track
is followed by the first track.
If several CDs are loaded in the CD
changer, the last track on a CD will be
followed by the first track of the next
CD in the changer.
The CDs are changed in their normal
sequence (e.g. CD 1, 2, 3 etc.).
The last track of the last CD in the
changer will be followed by the first
track of the first CD.
Repeat track
The current track will be repeated until
this function is deactivated.
Repeat CD
The current CD will be repeated until
this function is deactivated.
Track Random
The tracks are played in random order
(e.g. track 3, 8, 5 etc.).
If several CDs are loaded in the CD
changer, the last track on a CD will be
followed by the first track of the next
CD in the changer.
The CDs are changed in their normal
sequence (e.g. CD 1, 2, 3, etc.).
CD Random
At least 4 tracks on one CD are played
in random order (e.g. track 5, 7, 3, 9)
before the next CD is played.
The CDs are changed in random
order (e.g. CD 4, 1, 5, etc.).
Changing the playback option
In the CD changer main menu
(
page 75) press the Setting soft key.
The Settings menu is displayed.
The solid circle indicates which op-
tion is currently selected.
i
It is only possible to select this function
if at least two audio CDs are loaded in
the CD changer.
i
This selection is only possible if at least
two CDs are loaded in the CD changer.

82 Audio
CD changer* operation
Press or  to select a different
option.
Press.
The option is activated. A correspond-
ing display will appear in the status bar
for all options except
Normal sequence.
An option will remain activated even if
the COMAND is switched OFF and then
ON again.

83 Audio
Audio AUX operation
1Socket
Open the Audio main menu
(
page 40).
Press the AUX soft key.
The AUX menu appears.
The external audio source is made au-
dible, provided it is connected and
switched to playback.In AUX mode, you can adjust the following:
Volume (page 32)
Balance (page 34)
Bass and treble (page 35)
Sound functions (page 36)
i
An external audio source can be con-
nected to COMAND via the 1/8" sock-
et located inside the glovebox.
Switching to AUX mode i
Please refer to the appropriate operat-
ing manual for the operation of the ex-
ternal audio source.

84

85
General information
Satellite radio operation
Satellite radio*

86 Satellite radio*
General information
Sirius Satellite Radio provides 100 chan-
nels, so called streams, of digital-quality
radio, among others music, sports, news,
and entertainment free of commercials.
Sirius Satellite Radio uses a fleet of high-
power satellites to broadcast 24 hours per
day, coast-to-coast, in the contiguous US.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service availabil-
ity, call the Sirius Service Center
(
page 94), or contact
www.siriusradio.comProgram categories
The channels are categorized. Categories
allow you to tune to stations broadcasting
a certain type of program (category mode)
(
page 90).
Category selection
ALL contains the station
list of all receivable channels (channel
mode) (
page 90).
Introduction to satellite radio
i
Additional optional satellite radio
equipment and a subscription to satel-
lite radio service provider are required
for the satellite radio operation de-
scribed in this chapter.
Contact your authorized Mercedes-
Benz Center for details and availability
for your vehicle.
i
Note that categories and channels
shown in illustrations are dependent on
programming content delivered by the
service provider. Programming content
is subject to change. Therefore, chan-
nel and categories shown in illustra-
tions and descriptions contained in this
manual may differ from the channels
and categories delivered by the service
provider.
Satellite radio service may be unavail-
able or interrupted from time to time
for a variety of reasons, such as envi-
ronmental or topographic conditions
and other things we can't control. Ser-
vice might also not be available in cer-
tain places (e.g., in tunnels, parking
garages, or within or next to buildings)
or near other technologies.

87 Satellite radio*
Satellite radio operation

Satellite radio operation
Press.
Different menus appear depending on
Satellite radio service activation.
Prior to activation of the Satellite
radio service,
After Satellite radio service was ac-
tivated.
Prior to activation of the Satellite radio
service
The telephone number of the Sirius Service
Center and the twelve-digit electronic seri-
al number (ESN) of the particular receiver
are displayed.
This information is required to call the Siri-
us Service Center for an activation re-
quest.After activation of the Satellite radio
service
The SAT main menu appears.
The radio station selected last is audible,
provided it can be received.
Switching to Satellite radio modei
Credit card information is also required
for your application.
The activation process takes approxi-
mately 5 to 10 minutes after calling the
Sirius Service Center.
i
The system will tune to a default sta-
tion if no station had been selected
previously.

88 Satellite radio*
Satellite radio operation
Station information is displayed on the
main area and in the center of the status
bar.
Main area, in this example:
ROCK = selected category (page 90)
Vault = name of the selected stationStatus bar, in this example:
SAT (on the left) = the selected mode
SAT5 = location in the program
memory, if the current channel is pre-
stored
Ch16 = number of the current channel
Selectable soft keys
Presets
shows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 93) and re-
quest stored stations (
page 89).
Info
shows additional text information relat-
ed to the current channel.
Scan
is used to start and stop the scan
search (
page 92).
Service
displays a screen showing the tele-
phone number of the Sirius Service
Center and electronic serial number
(ESN) of the receiver in your vehicle.
SAT main menu

89 Satellite radio*
Satellite radio operation
You can also adjust the following:
Balance (page 34)
Bass and treble (page 35)
Sound functions (page 36)
Volume (not on soft keys)
(
page 32)
The following options are available:
Tuning via station presets
Tuning via manual channel input
(
page 90)
Tuning via the program category list
(
page 90)
Tuning a station within the selected
category (
page 91)
Tuning via scan search (page 92)
Tuning via station presets
Ten satellite radio station presets are avail-
able.
You can access the presets via number
keys or via the Presets menu.
Accessing via number keys
Press one of the number keys
 - .The system will tune to the station
stored under this number.
Accessing via Presets menu.
Press the Presets soft key.
The Presets list appears.
Selecting a station
i
The Presets memory is empty at first-
time activation of the system.
