51 Audio
Single CD operation
The following options are available:
Selecting via track skip
Selecting via track list (page 51)
Selecting via manual entry of the track
number (
page 52)
Selecting via scan search (page 52)
Selecting via track skipOn the COMAND control unit
Open the Single CD main menu
(
page 50).
Press+7for forward skipping;
or
Press, for backward skipping.
The tracks skip immediately after
pressing one of the buttons.
On the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Single CD dis-
play (
page 27).
Pressj for forward skipping;
or
Pressk for backward skipping.
The tracks skip immediately after
pressing one of the buttons.Selecting via track list
The track list contains all tracks of the cur-
rent CD. Only one list entry is visible at a
time, it is the number of the track currently
playing.
Use% or & to select another track
from the list.
The current track remains playing while
selecting.
Press' or wait approx. 3 seconds
without changing the selection.
The newly selected track is played.
Selecting a track
i
Forward skipping:
The next track is played.
Backward skipping:
If the track has been playing longer
than approx. 10 seconds, the system
skips back to the beginning of the
track.
If less than 10 seconds have played,
the system skips back to the beginning
of the previous track.

60 Audio
MP3 operation
Press'.
COMAND changes the folder and loads
the data from the new folder.
It may take a while to load the data, de-
pending on the number of folders and
tracks.
The following options are available:
Selecting via track skip (page 60)
Selecting via track list (page 60)
Selecting via direct entry of the track
number (
page 61)
Selecting via scan search (page 61)Selecting via track skip
On the COMAND control unitOpen the MP3 main menu (page 58).
For forward skipping press+;
or
For backward skipping press,.
The tracks skip immediately after
pressing one of the buttons.
On the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the MP3 display
(
page 27).
For forward skipping pressj;
or
For backward skipping pressk.
The tracks skip immediately after
pressing one of the buttons.
Selecting via track list
The track list contains all tracks in the cur-
rent folder. Only one track can be viewed
at a time.
Selecting a track
i
Forward skipping:
The next track is played.
Backward skipping:
If the track has been playing longer
than approx. 10 seconds, the system
skips back to the beginning of the
track.
If less than 10 seconds have played,
the system skips back to the beginning
of the previous track.

66 Audio
CD changer* operation
In order to load CDs, you will need to open
the glove box.
1CD slot
2Magazine compartment buttonsThe CD changer has a built-in magazine
which can hold up to six CDs.
The CD changer has six magazine compart-
ment buttons 2 for controlling the loading
procedure.
LEDs in the buttons indicate the status of
the corresponding magazine compart-
ment.
Button LED OFF:
Magazine compartment empty
Button LED flashes green:
CD changer requesting CD to be load-
ed
Button LED continuously red:
Magazine compartment loaded with a
CD
The status of a magazine compartment can
also be seen when selecting a CD in the CD
Selection menu (
page 71).
The CD slot 1 for loading CDs into the CD
changer is located above the buttons 2.
!
Do not attach labels of any type to the
CD. They may become detached and
damage the drive.
Your CD drive has been designed to
play CDs which correspond to the IEC
60908 standard. Therefore only CDs
not exceeding a thickness of 1.3 mm
can be used.
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they will become stuck and
damage the drive.
Data carriers which contain data on
both sides can cause play-back prob-
lems because the storage layers are
thinner than one-sided data carriers.
!
Do not play single CDs (80mm) with an
adapter. An adapter could become
stuck and damage the drive. Only use
12 cm diameter CDs.
i
The CD changer may not be able to play
audio CDs with copy protection.

67 Audio
CD changer* operation
Loading options:
Loading a single magazine compart-
ment
Loading all six magazine compart-
ments
Loading a single magazine compart-
ment
Open the glove box
(
Vehicle owner's manual).
Briefly press the button 2 of the emp-
ty magazine compartment to be load-
ed.
Wait until the LED in the button 2
flashes green.
This indicates that the CD changer re-
quests a CD.
Insert an audio CD into the CD slot 1
within approx. 15 seconds. Insert the
CD face up.
The CD is pulled in. The red LED in the
corresponding magazine compartment
button 2 lights up continuously. The
system starts playing the CD.
The loading procedure is completed.
Loading all six magazine compart-
ments
Initial situation: all magazine compart-
ments are empty.
The CD changer loads all magazine com-
partments beginning with compartment 1.
Open the glove box
(
Vehicle owner's manual).1CD slot
2Magazine compartment buttons
Press and hold the button of an empty
magazine compartment 2 for more
than 2 seconds.
The LEDs of all magazine compartment
buttons 2 briefly light up green sever-
al times.
Wait until the LED in the first magazine
compartment button 2 flashes green.
This indicates that the CD changer re-
quests a CD.
i
Loading a magazine slot will stop the
playback of a CD in the changer.


68 Audio
CD changer* operation
Insert an audio CD into the CD slot 1
within approx. 15 seconds. Insert the
CD face up.
The CD is pulled in; the magazine com-
partment is loaded.
The red LED in the corresponding mag-
azine compartment button 2 lights up
continuously.
The CD changer then requests inser-
tion of the next CD. The LED in the cor-
responding magazine compartment
button 2 flashes green.
Repeat the last step until all six maga-
zine compartments are loaded.
The system plays the sixth CD. The
LEDs in all magazine compartment but-
tons 2 light up red continuously.
The loading procedure is completed.The following options are available:Ejecting one CD
Ejecting all CDs (page 69)Ejecting one CD
1CD slot
2Magazine compartment buttons
Open the glove box
(
Vehicle owner's manual).
Briefly press the appropriate magazine
compartment button 2.
The button LED 2 flashes red. The CD
changer ejects the CD.
Within 15 seconds, remove the CD
from the slot 1.
i
If, for example, only compartments 1
through 4 are to be loaded instead of
all six compartments, simply do not in-
sert the a fifth CD into the slot 1. The
CD changer attempts to load the fifth
CD, yet aborts the loading procedure.
The system automatically plays the last
(fourth) CD.
Ejecting CDs

72 Audio
CD changer* operation
Press'.
The newly selected CD is played.
The following options are available:
Selecting via track skip
Selecting via track list (page 72)
Selecting via manual entry of the track
number (
page 73)
Selecting via scan search (page 73)
Selecting via track skip On the COMAND control unitOpen the CD changer main menu
(
page 69).
Press+7for forward skipping;
or
Press, for backward skipping.
The tracks skip immediately after
pressing one of the buttons. On the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the CD changer
display (
page 27).
Pressj for forward skipping;
or
Pressk for backward skipping.
The tracks skip immediately after
pressing one of the buttons.
Selecting via track list
The track list contains all tracks of the cur-
rent CD. Only one list entry is visible at a
time, it is the number of the track currently
playing.
Selecting a track
i
Forward skipping:
The next track is played.
i
Backward skipping:
If the track has been playing longer
than approx. 10 seconds, the system
skips back to the beginning of the
track.
If less than 10 seconds have played,
the system skips back to the beginning
of the previous track.

102 Telephone*
Phone book
The following options are now available:
Switching between number and name
display
Selecting a phone book entry and es-
tablishing a connection (
page 102)
Deleting a phone book entry
(
page 103)
Switching between number and name
display
Open the phone book from COMAND
(
page 101).
Press the 123 soft key.
The phone book switches to number
display. The status bar shows the name
of the highlighted entry;
or
Press the ABC soft key.
The phone book switches to name dis-
play. The status bar shows the number
of the highlighted entry.
On the COMAND control unit
Open the phone book (page 101).
The list of phone book entries stored
on your cell phone appears.
Changing initials:
Press# or $ once or repeatedly.
Each time you press the button, the
display changes to the next letter up or
down. At the end of the list of letters is the
category
Other. This category combines
all entries without a name, or entries
whose names start with a special char-
acter (e.g.
* or #).
Selecting an entry:
If necessary, change the initial.
Select an entry using % or &.
If you press and hold either one of the
buttons, the scrolling up or down accel-
erates.
Establishing a connection:
Press2.
The telephone initiates the connection
with the selected number.
Selecting a phone book entry and es-
tablishing a connection

108 Navigation*
Important notes
Safety instructions
WarningG
For safety reasons, you should only enter a
destination when the vehicle is stationary.
When the vehicle is in motion, a passenger
should enter the destination. Study manual
and select route before driving.
Do not watch display screen or operate but-
tons while the vehicle is in motion - let navi-
gation announcements guide you. Stop at a
safe location before using buttons or mak-
ing corrections.
Traffic regulations always have priority over
any route recommendations given.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
WarningG
The route calculated by COMAND is a rec-
ommendation on how to best reach your se-
lected destination.
During route guidance, you will not receive
any information on
Traffic lights
Stop and yield signs
Parking or stopping zones
One-way streets
Narrow bridges
Similar traffic regulation data
You should therefore always strictly observe
traffic regulations while driving. Drive care-
fully and always obey traffic laws and road
signs even if they contradict COMAND in-
structions.
WarningG
The Navigation DVD module contains a
Class 1 laser product. There is a danger of
invisible laser radiation if the cover is
opened or damaged.
Do not remove the cover. The Navigation
DVD module does not contain any parts
which can be serviced by the user. For safe-
ty reasons, have any service work which
may be necessary performed only by quali-
fied personnel.

127 Navigation*
Destination entry
Press5;
or
Press the Map soft key if it appears in a
menu.
The map appears in full-screen display.
1Symbol = current position
If the soft key displays are hidden,
press any soft key.
The soft key displays appear.Selectable soft keys
Coord. soft key
Allows entering a destination via geo
coordinates (
page 128),
Memory soft key
The current location is stored
(
page 130),
Display soft key
You can select which POIs will appear
as symbols on the map (
page 147).
 soft key
The map scale will change to display a
more detailed map,
 soft key
The map scale will change to display a
map that shows a wider area.
Moving the map and selecting a desti-
nation
Move the cursor using#, $, %,
&, 6 or 8 to select the desired
destination.
Release the buttons.
If the system finds a street name at the
location the cursor is pointing to, the
corresponding street name is shown in
the status bar.
In this example:
WATER ST
Entering a destin ation using th e mapi
If no soft key is selected within
approx. 8 seconds, the soft key dis-
plays will disappear.
i
The Coord., Memory and Display soft key
are visible only if the map has been
called up using5.
