150 Controls in detail
Control system
You can use the functions in the TEL menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.
Switch on the telephone and Audio or
COMAND*.
See separate operating instructions.
Press buttonèorÿ repeatedly
until the
TEL menu appears in the
multifunction display.Which messages will appear in the multi-
function display depends on whether your
telephone is switched on or off:

If the telephone is switched off, the
message in the multifunction display is:
PHONE OFF.

If the telephone is switched on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network,
Ready is indicated in the mul-
tifunction display.
This standby message indicates that your
telephone is ready for use and you can op-
erate it using the control system.Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will see the
message, or if available, the caller ID
(name and number):Audio system
COMAND*
Press buttons.
You have answered the call.
The duration of the call appears in the
multifunction display.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

151 Controls in detail
Control system
Ending a call or rejecting an incoming
call
Press buttont.
Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.
Press buttonèorÿ repeatedly
until the
TEL menu and the standby
message appear in the multifunction
display.
Press buttonjork.
The control system reads the phone
book which is stored in the telephone.
This may take up to 30 seconds. In the
multifunction display you will see the
message
Please Wait.
When the message
Please wait
disappears, the phone book has been
loaded.
Press buttonjork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in
ascending or descending alphabetical
order.
1Selected name from phone bookPress buttons.
The control system dials the selected
phone number.

If the connection is successful, the
name of the party you called and
the duration of the call will appear
in the display.

If no connection is made, the con-
trol system stores the dialed num-
ber in the redial memory.
or
Cancel the call you have intended to
make by pressing buttont.
iIf you press and hold buttonj ork
for longer than 1 second, the system scrolls
rapidly through the list of names until you
release the button again.
Cancel the quick search mode by pressing
buttont.

152 Controls in detail
Control system
Redialing
The control system stores the most recent-
ly dialed phone numbers. This eliminates
the need to search through your entire
phone book.
Press buttonèorÿ repeatedly
until the
TEL menu and the standby
message appear in the multifunction
display.
Press buttons.
In the multifunction display you will see
the first number in the redial memory.
Press buttonjork repeatedly
until the desired number or name
appears in the multifunction display.
Press buttons.
The control system dials the selected
phone number.
If the connection is successful, the
duration of the call will appear in the
multifunction display, and

the name of the party if stored in
the phone book
or

instead of it the dialed number
or
Cancel the call you have intended to
make by pressing buttont.

153 Controls in detail
Manual transmission
Manual transmission
Manual transmission is standard equip-
ment on select models and not available
on all models.
For information on driving with a manual
transmission, see “Driving off”
(
page 53).
Warning!G
For vehicles equipped with a manual trans-
mission, getting out of your vehicle with the
gearshift lever not engaged in first or
reverse gear and the parking brake not
engaged is dangerous.
Also, when parked on an incline, an engaged
first or reverse gear alone may not prevent
your vehicle from moving, possibly hitting
people or objects.
Always set the parking brake in addition to
engaging first or reverse gear (
page 59).
W h e n p a r k e d o n a n i n c line, turn front wheels
towards the road curb.
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could move the gearshift lever, which could
result in an accident and/or serious
personal injury.
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action.
This could result in drive wheel slip and
reduced vehicle control. Your vehicle’s ABS
will not prevent this type of loss of control.

154 Controls in detail
Manual transmission
Gearshift pattern for manual transmission
Shifting into reverse
Stop the vehicle completely.
Fully depress the clutch pedal.
Move the gearshift lever to the neutral
position (no gear selected).
Move the gearshift lever to the left until
you feel a certain resistance.
Push the gearshift lever past this
resistance.
Then move the gearshift lever forward
into positionR.
!When you are shifting into the5th or6th
gear, make sure that you press the gearshift
lever to the right. Otherwise, you could acciden-
tally shift into the3rd or4th gear and damage
the transmission.
Downshifting gears leading to overrevving the
engine can result in engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Never hold the vehicle stopped on a hill by using
the clutch pedal. The clutch may be damaged
which is not covered by the Mercedes-Benz
Limited Warranty.
Do not exceed the engine speed limits. Refer to
tachometer (
page 119) for engine speeds.
!Only shift into reverse gearR when the
vehicle is stationary, as the transmission could
otherwise be damaged.

155 Controls in detail
Automatic transmission*
Automatic transmission*
For more information on driving with an
automatic transmission, see “Driving off”
(
page 53).
Your vehicle’s transmission adapts its gear
shifting process to your individual driving
style by continually adjusting the shift
points up or down. These shift point adjust-
ments are performed based on current
operating and driving conditions.
If the operating conditions change, the
automatic transmission reacts by
adjusting its shift program.
Gear selector lever
The gear selector lever is located on the
lower part of the center console.
Gearshift pattern for automatic
transmission
PPark position
RReverse gear
NNeutral
DDrive position
iDuring the brief warm-up, transmission
upshifting is delayed. This allows the catalytic
converter to heat up more quickly to operating
temperature.
Warning!G
Make sure that absolutely no objects are
obstructing the pedals’ range of movement.
Keep the driver’s footwell clear of all obsta-
cles. If there are any floormats or carpets in
the footwell, make sure that the pedals still
have sufficient clearance.
During sudden driving or braking maneuvers
the objects could get caught between the
pedals. You could then no longer brake or
accelerate. This could lead to accidents and
injury.
iThe current gear selector lever positionP,
R,N orD appears in the multifunction display
(
page 157).

156 Controls in detail
Automatic transmission*
There are additional indicators on the
cover of the shifting gate showing the
current gear selector lever position.
The indicators come on when you insert
the SmartKey into the starter switch, and
go out when you remove the SmartKey
from the starter switch.
Shifting procedure
The automatic transmission selects indi-
vidual gears automatically, depending on:

gear selector lever positionD
(
page 157) with gear ranges
(
page 160)

the selected program mode:
(C/S)(
page 161)
or
(M/C/S)* (
page 165)

the position of the accelerator pedal
(
page 159)

the vehicle speedWhen the gear selector lever is in drive
positionD, you can influence transmission
shifting by:

limiting the gear range

changing gears manually
Warning!G
It is dangerous to shift the gear selector
lever out of park positionP or neutral
positionN if the engine speed is higher than
idle speed. If your foot is not firmly on the
brake pedal, the vehicle could accelerate
quickly forward or reverse. You could lose
control of the vehicle and hit someone or
something. Only shift into gear when the
engine is idling normally and when your right
foot is firmly on the brake pedal.
!Allow engine to warm up under low load use.
Do not place full load on the engine until the
operating temperature has been reached.
Shift into reverse gearR or park positionP only
when the vehicle is stopped.
Avoid spinning of a drive wheel for an extended
period when driving off on slippery road
surfaces. This may cause serious damage to the
drivetrain which is not covered by the
Mercedes-Benz Limited Warranty.

157 Controls in detail
Automatic transmission*
Gear selector lever positions
The current gear selector lever position
appears in the multifunction display.
1Current gear selector lever positionEffect
ìPark position
Gear selector lever position
when the vehicle is parked. Place
gear selector lever in park
positionP only when vehicle is
stopped. The park position is not
intended to serve as a brake
when the vehicle is parked.
Rather, the driver should always
set the parking brake in addition
to placing the gear selector lever
in park positionP to secure the
vehicle.
Effect
The SmartKey can only be
removed from the starter switch
with the gear selector lever in
park positionP. With the
SmartKey removed, the gear
selector lever is locked in park
positionP.
If the vehicle’s electrical system
is malfunctioning, the gear
selector lever could remain
locked in park positionP
(
page 396).
íReverse gear
Place gear selector lever in
positionR only when vehicle is
stopped.

158 Controls in detail
Automatic transmission*
Effect
ëNeutral
No power is transmitted from the
engine to the drive axle. When
the brakes are released, the
vehicle can be moved freely
(pushed or towed).
To avoid damage to the trans-
mission, never engage neutral
positionN while driving.
If the ESP
® is deactivated or
malfunctioning:
Move gear selector lever to neu-
tral positionN only if the vehicle
is in danger of skidding, e.g. on
icy roads.
êDrive
The transmission shifts
automatically. All forward gears
are available.
!Coasting the vehicle, or driving for any other
reason with gear selector lever in neutral
positionN can result in transmission damage
that is not covered by the Mercedes-Benz
Limited Warranty.
Warning!G
Getting out of your vehicle with the gear
selector lever not fully engaged in park
positionP is dangerous. Also, park
positionP alone is not intended to or capa-
ble of preventing your vehicle from moving,
possibly hitting people or objects.
Always set the parking brake in addition to
shifting to park positionP (
page 59).
When parked on an incline, turn the front
wheels towards the road curb.
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could move the gear selector lever from
park positionP, which could result in an
accident and/or serious personal injury.

159 Controls in detail
Automatic transmission*
Driving tips
Accelerator position
Your driving style influences the
transmission’s shifting behavior:
Less throttle Earlier upshifting
More throttle Later upshifting
Kickdown
Use kickdown when you want maximum
acceleration.
Press the accelerator past the point of
resistance.
Depending on the engine speed the
transmission shifts into a lower gear.
Ease on the accelerator when you have
reached the desired speed.
The transmission shifts up again.Stopping
When you stop briefly, e.g. at traffic lights:
Leave the transmission in gear.
Hold the vehicle with the brake.
When you stop for a longer period of time
with the engine idling and/or on a hill:
Set the parking brake.
Move the gear selector lever to park
positionP.Maneuvering
When you maneuver in tight areas,
e.g. when pulling into a parking space:
Control the vehicle speed by gradually
releasing the brakes.
Accelerate gently.
Never abruptly step on the accelerator.
Working on the vehicle
Warning!G
When working on the vehicle, set the
parking brake and move gear selector lever
to park positionP. Otherwise the vehicle
could roll away.
