MERCEDES-BENZ SLR 2009 R199 Owner's Manual

201 Controls in detail
Open air
Closing the soft top
Switch on the ignition.

Press and hold button4, until the
electrical closing process has been
completed.
While the soft top is closing, the K
symbol and the message
Top In
Operation
appear in the multifunction
display.
An acoustic signal indicates that you
can now lock the soft top.

Pull the soft top by means of the handle
down on the windscreen frame.

Turn the handle counter-clockwise as
far as it will go.
The soft top is locked.

Fold up the handle.
Wind screen
The wind screen is a wind protection
device for driving with the soft top open.
The wind screen is stored on the inside of
the trunk lid.
1Wind screen
2Release
!
Always remove the soft top linkage covers
(
page 202) before closing the soft top.
You could otherwise damage the covers or the
linkages.
!
Before pulling the soft top down, make sure
that the handle is in the release position. Other-
wise, the locking mechanism could be damaged
when closing the soft top.
!
Do not pull on the wind screen to close the
trunk lid. Otherwise, the wind screen or the trim
panel could be damaged.

202 Controls in detailOpen air
Press on releases2 in direction of the
arrow and pull wind screen1 out
upwards.
Installing
1Mounting
2Recess

Insert mountings1 into recesses2.
The mountings must audibly engage.

Make sure the mountings are properly
engaged.Removing
You can close the soft top without remov-
ing the wind screen.
1Release

Press on releases1 in direction of the
arrow and pull the wind screen out
upwards.

Store the wind screen back into the
trunk lid.
Linkage covers
The covers are located in a bag that is lo-
cated in the trunk.
Take out bag in direction of arrow.
!
Always remove the soft top linkage covers
before closing the soft top. You could otherwise
damage the covers or the linkages.

203 Controls in detail
Open air
Installing
The following describes the installation of
the driver’s side cover. The installation of
the passenger-side cover is identical but
mirror-inverted.
1Cover
2Tab
3Bodywork
4Sealing

Open the trunk lid.

Fit tabs2 of cover1 between
sealing4 and bodywork3.5Lock
6Holder
7Slot

Press down on lock5 and turn it
clockwise by 90°.

Hold the lock in this position and insert
holder6 into slot7.

Press down on the cover and turn the
lock counter-clockwise by 90°.
Warning!
G
Do not use damaged covers. Damaged
covers could come loose while driving and
hit other road users.!
Do not use damaged covers. Damaged
covers could come loose while driving and
damage the vehicle.


204 Controls in detailOpen airThe cover is properly locked when the
white markings face each other.Removing
1Lock
2Cover

Open the trunk lid.

Press down on lock1 and turn it
clockwise by 90°.

Lift cover2 slightly and pull it out in
direction of the arrow.

Repeat the above steps for the passen-
ger-side cover.

Store both covers into the bag and put
the bag in the trunk.
Warning!
G
Covers that are not properly locked, could
come loose while driving and hit other road
users.
Therefore, make sure that the covers are
properly locked.


205 Controls in detail
Driving systems
Driving systems
The driving system of your vehicle is
described on the following pages:

Cruise control, with which the vehicle
can maintain a preset speed
For information on the BAS, ABS and ESP
®,
see “Driving safety systems” (
page 82).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set or resume the
cruise control at any speed over 20 mph
(30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 30).
Warning!
G
The Cruise control is a convenience system
designed to assist the driver during vehicle
operation. The driver is and must always
remain responsible for the vehicle’s speed
and for safe brake operation.
Only use the cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of the cruise control can be dan-
gerous on winding roads or in heavy traf-
fic because conditions do not allow safe
driving at a steady speed.


The use of the cruise control can be dan-
gerous on slippery roads. Rapid changes
in tire traction can result in wheel spin
and loss of control.


Deactivate the cruise control when
driving in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.

206 Controls in detailDriving systems1Sets current or higher speed
2Sets current or lower speed
3Cancels the cruise control
4Resumes at last set speed
Setting current speed
Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 the cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
The cruise control is activated.
Canceling the cruise control
There are several ways to cancel the cruise
control:

Step on the brake pedal.
The cruise control is canceled. The last
speed set is stored for later use.
or

Briefly push the cruise control lever to
position3.
The cruise control is canceled. The last
speed set is stored for later use.The cruise control is automatically can-
celled, when


the vehicle speed is below 20 mph
(30 km/h)


ESP
® is in operation or switched off
with the ESP
® switch (
page 87)


you move the gear selector lever to
neutral positionN while driving
i
On uphill or downhill grades, the cruise
control may not be able to maintain the set
speed. Once the grade eases, the set speed will
be resumed.
!
However, the gear selector lever should not
be moved to neutral positionN while driving, ex-
cept to coast when the vehicle is in danger of
skidding (e.g. on icy roads).
i
Depressing the accelerator pedal does not
deactivate the cruise control. After brief acceler-
ation (e.g. for passing), the cruise control will re-
sume the last speed set.
The last stored speed is canceled when you turn
off the engine.

207 Controls in detail
Driving systems
Setting a higher speed
Lift the cruise control lever to
position1 and hold it up until the de-
sired speed is reached.

Release the cruise control lever.
The new speed is set.Setting a lower speed

Depress the cruise control lever to
position2 and hold it down until the
desired speed is reached.

Release the cruise control lever.
The new speed is set.
Warning!
G
If you increase the set vehicle speed, keep in
mind that it may take a brief moment until
the vehicle has made the necessary adjust-
ments.
Increase the set vehicle speed to a value
that the prevailing road conditions and legal
speed limits permit. Otherwise, sudden and
unexpected acceleration of the vehicle
could cause an accident and/or serious in-
jury to you and others.
i
Depressing the accelerator pedal does not
deactivate the cruise control. After brief acceler-
ation (e.g. for passing), the cruise control will
resume the last speed set.Warning!
G
If you decrease the set vehicle speed, keep
in mind that it may take a brief moment until
the vehicle has made the necessary adjust-
ments.
Decrease the set vehicle speed to a value
that the prevailing road conditions and legal
speed limits permit. Otherwise, sudden and
unexpected acceleration of the vehicle
could cause an accident and/or serious in-
jury to you and others.
i
When you use the cruise control lever to de-
celerate, the transmission will automatically
downshift if the engine’s braking power does not
brake the vehicle sufficiently.

208 Controls in detailDriving systemsFine adjustment in 1 mph
(Canada: 1 km/h) increments
Faster
Briefly tip the cruise control lever in
direction of arrow1.
Slower

Briefly tip the cruise control lever in
direction of arrow2.Setting to last stored speed
(“Resume” function)

Briefly push the cruise control lever to
position4.
The cruise control resumes the last set
speed.

Remove your foot from the accelerator
pedal.Warning!
G
The speed stored in memory should only be
set again if prevailing road conditions per-
mit. Possible acceleration or deceleration
differences arising from returning to preset
speed could cause an accident and/or
serious injury to you and/or others.

209 Controls in detail
Useful features
Useful features
Map pocket in passenger footwell
Storage compartments Storage compartment under armrest
1Release button
2Armrest

Press release button1.
The armrest2 opens automatically.
Warning!
G
Do not place heavy or fragile objects, or ob-
jects having sharp edges in the map pocket.
In an accident, during hard braking or sud-
den maneuvers, they could be thrown
around inside the vehicle, and cause injury
to vehicle occupants.i
Canada only: The compact guide is located
in the map pocket.
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk. Do not pile lug-
gage or cargo higher than the seat backs.
Do not place anything on the shelf below the
rear window.
Parcel nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.

210 Controls in detailUseful featuresStorage compartment between
the backrests
1Release button
2Cover
Press release button1.
Cover2 opens automatically.
The Bluetooth
® interface (
page 213)
is installed in the cover of the storage
compartment.
Parcel net in trunk
There is a net available in the trunk to
secure loads:
Pull the trunk floor net from the trunk
back wall towards the front over the
luggage.

Hang the hooks of the net on the eyes
on the trunk floor.
Ashtray and cigarette lighter
The ashtray and the cigarette lighter are lo-
cated in the storage compartment under
the armrest.
1Cigarette lighter
2Ashtray insert
