138 %
*
[FV18500( BCGV)05/95]
Using the Power Seats (If equipped)
[FV18700( GV)10/94]
If your vehicle has power seats, you can adjust
them in several directions. The controls are
located on the driver and passenger door trim
panels or on the side of the driver's seat.
[FV18810( GV)10/94]
one third page art:0011313-A
The power seat controls on the driver's seat Ð Base models
*
[FV18850( ALL)05/95]
RWARNING
Do not pile cargo higher than the
seatbacks to avoid injuring people in a
collision or sudden stop.
% [FV18920( GV)10/90]
Power Seat Recliner/Lumbar Option
[FV18960( GV)10/90]
The arrows on the power seat control panel
indicate the direction the seat or seatback will
move. To adjust the seat or seatback move the
control knob in the desired direction.
[FV18980( GV)03/94]
The power lumbar switch controls the inflation
of the lumbar support pad in the seatback. To
inflate the lumbar pad, push the forward portion
of the switch. To deflate the pad, press the rear
portion of the switch.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

139 [FV18990( GV)05/95]
one third page art:0010686-B
The power lumbar switch
%*
[FV20500( ALL)04/95]
Cleaning the Seats
*
[FV20600( ALL)05/95]
Leather and vinyl
*
[FV20650( ALL)05/95]
For routine cleaning, wipe the surface with a
soft, damp cloth. For more thorough cleaning,
wipe the surface with a leather and vinyl cleaner
or a mild soap.
%*
[FV20700( ALL)04/95]
Fabric
*
[FV20750( ALL)04/95]
Remove dust and loose dirt with a whisk broom
or a vacuum cleaner. Remove fresh spots
immediately. Follow the directions that come
with the cleaner.
*
[FV20775( ALL)04/95]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

140
%*
[FV20800( ALL)01/95]
Mirrors
*
[FV20850( ALL)03/95]
You can adjust your rearview mirror in any
direction. The special swivel bracket lets you
move the mirror up or down and from side to
side.
[FV21000( ALL)03/95]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not block
your vision. If you cannot see through the
mirror, it could result in a collision,
injuring yourself and others.
%*
[FV21500( GV)01/95]
Automatic Dimming Inside Rearview
Mirror (If equipped)
[FV22620( GV)10/94]
quarter page art:0010037-C
The automatic non-glare mirror
*
[FV22630( GV)01/95]
The electronic day/night mirror will change
from the normal state to the non-glare state
when bright lights (glare) reach the mirror. This
mirror functions at night, and has a limited
function at dusk or dawn. From the non-glare
state, the mirror will return to the normal state
after a short delay. The delay starts when the
glare goes away. The delay prevents excessive
changing of the mirror as traffic moves behind
and around the vehicle, or on rolling hills and
curves.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

141 [FV22650( GV)10/94]
To turn the mirror on, push the ON/OFF
switch, located on the bottom of the mirror, to
latch it in the ON position. The switch will
illuminate and the mirror will be in the
automatic dimming mode. To turn the switch
illumination and automatic dimming feature off,
push the ON/OFF switch again.
*
[FV22660( GV)01/95]
The electronic mirror measures the brightness of
the light coming in from the rear of the vehicle.
It automatically makes a correction in the glare
state. The mirror may be turned off in either the
normal or non-glare position.
[FV22685( GV)03/95]
There are two light sensors (photocells) in this
mirror. The sensor that detects rear glare is
located inside a window in the center of the
mirror. The second light sensor which
determines outside light level is located on the
backside of the mirror case.
*
[FV22690( GV)01/95]
One important safety feature is that the mirror
automatically returns to the normal position
whenever the vehicle is placed in R (Reverse)
(when the mirror is in the ON position). This
feature ensures a bright clear view in the mirror
when backing up.
% [FV24100( BCGV)07/93]
Adjusting the Dual Electric Remote
Control Mirrors
[FV24150( GV)11/90]
Your vehicle is equipped with electric remote
control side view mirrors; the switch for
controlling their operation is a control knob in
the armrest.
%*
[FV24400( ALL)01/95]
Do not clean the housing or glass of any mirror
with harsh abrasives, fuel or other
petroleum-based cleaning products.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

142 [FV24450( GV)03/94]
one third page art:0010273-CThe mirror controls on the driver's left armrest
*
[FV24700( ALL)04/95]
To adjust the side mirrors:
*
[FV24800( ALL)01/95]
1. Find the control switch in the driver's door
panel.
*
[FV24900( ALL)02/95]
2. Select the right or left mirror by moving the
selector switch to R or L.
[FV25000( ALL)06/93]
3. Move the knob in the direction of the arrows
for the direction you want to move the
mirror.
*
[FV25100( ALL)01/95]
4. Return the selector switch to the middle
position to keep the mirror in place.
%*
[FV25200( GV)03/95]
Heated Mirror Feature
*
[FV25300( GV)03/95]
Both mirrors are heated whenever the Electric
Rear Window Defroster is turned on. Do not
remove ice from the mirrors with a scraper or
you could damage them. If the outside mirror
glass is frozen in place, do not attempt to
readjust or move the mirror glass or damage
may result.
[FV28700( ALL)01/89]
The Right Side Convex Mirror
[FV28800( ALL)03/90]
The side view mirror on the right is a convex
mirror. This mirror gives you a wider view of
the lanes on your right and behind you.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

143
*
[FV28900( ALL)05/95]
RWARNING
The side view mirror on the right makes
objects appear smaller and farther away
than they actually are.
%
*
[FV28950( ALL)01/95]
Sun Visors
*
[FV28955( G )03/95]
Using the Sun Visors
[FV28960( G )03/95]
Your vehicle has special sun visors. Besides the
regular sun visor, you may have a second sun
visor. By using both the regular sun visor and
the second visor, you shield the sun from both
the front and the side of the vehicle at the same
time.
*
[FV28970( G )03/95]
To block the sun, move the main visor sideways
and flip the second visor down.
[FV28975( G )03/95]
one third page art:0010753-A
The sun visors
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

144 %
*
[FV29100( ALL)05/94]
Turning on the Mirror Light on the Sun
Visors (If equipped)
[FV29300( ALL)06/93]
To turn on the visor mirror light, lift the mirror
cover.
[FV29900( GV)10/90]
one third page art:0010278-B
The mirror on the sun visor
%*
[FV32626( GV)03/95]
Ashtray and Cupholder
[FV32650( GV)10/94]
Your vehicle is equipped with an
ashtray/cupholder mounted to the lower center
of the instrument panel.
*
[FV32675( GV)01/95]
To open the ashtray, pull out the bottom edge of
the drawer until it stops.
*
[FV32701( GV)01/95]
To close, remove cup(s) and push drawer
forward until closed.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

145
%*
[FV32725(M GV)03/95]
Power Point Electrical Outlet
[FV32760( GV)03/95]
The power point outlet is located on the
instrument panel to the right of the ashtray. This
outlet should be used for optional electrical
accessories.
[FV32785( GV)05/95]
NOTE: Do not attempt to plug the cigarette
lighter into the power point outlet.
Damage could occur. Do not plug
optional electrical accessories into the
cigarette lighter. Electrical system
damage could occur.
[FV32815( GV)05/95]
half page art:0011352-A
Power point electrical outlet
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

146
%*
[FV32875( ALL)01/95]
Storage Compartments
*
[FV32900(M GV)01/95]
Your vehicle may have several small storage
compartments:
[FV33000( BCGV)11/94]
q
a glove compartment that locks. Use the
round key to lock and unlock it.
*
[FV33100( BCGV)01/95]
q
two map pockets on the panels of the front
doors.
*
[FV33210( G )01/95]
q
two map pockets on the back of the front
seats.
*
[FV33300( ALL)05/95]
RWARNING
Do not put objects on the ledge between
the back seat and the rear window, as
they can become dangerous projectiles and
injure someone.
%
*
[FV33400( ALL)01/95]
Trunk
*
[FV33500( ALL)01/95]
Opening the Trunk Manually
[FV34200( GV)05/94]
The trunk in your vehicle gives you plenty of
room for storage Ð 20.6 cubic feet (.58 cubic
meters).
%*
[FV34600( ALL)03/95]
To open and close the trunk from the outside:
[FV34950( BCGV)03/95]
1. Insert the key into the lock on the trunk.
[FV35100( ALL)11/90]
2. Turn the key to the right until the trunk
opens.
[FV35300( ALL)11/90]
3. Remove the key before you close and lock
the lid.
[FV35450( ALL)06/93]
4. Shut the trunk lid completely.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

147 % [FV36200( ALL)03/95]
Using the Remote Control for the
Trunk (If equipped)
[FV36550( GV)12/91]
You can use the remote control on the driver's
door to unlock and open the trunk unless you
lock the button with the main key. The valet key
equipped with your vehicle can only open the
doors and start the engine.
[FV36800( GV)05/95]
one third page art:0010670-C
The remote control for the trunk
