Page 8 of 305
5
*
[II03210( ALL)05/96]
You may purchase Ford ESP from any
participating Ford Motor Company dealer. There
are several Ford ESP plans available in various
time-and-mileage combinations. Each plan can be
tailored to fit your own driving needs, including
reimbursement benefits for towing and rental.
(In Hawaii, rules vary. See your dealer for
details.)
*
[II03240( ALL)05/96]
When you buy Ford ESP, you receive
peace-of-mind protection throughout the United
States and Canada, provided by a network of
more than 5,100 participating Ford Motor
Company dealers.
*
[II03270( ALL)05/96]
NOTE: Repairs performed outside the United
States and Canada are not eligible for
ESP coverage.
*
[II03310( ALL)05/96]
This information is subject to change. Ask your
dealer for complete details about Ford ESP
coverage.
File:02rciig.ex
Update:Tue Jun 11 13:52:18 1996
Page 48 of 305
46
%*
[AS10319( GV)03/96]
Luxury Audio System
*
[AS10320( GV)03/96]
Using the Controls on Your New Radio
*
[AS10330( GV)03/96]
How to turn the radio on and off
*
[AS10340( GV)03/96]
Press the ªVOL/PUSH ONº knob to turn the
radio on. Press again to turn it off.
*
[AS10351( GV)03/96]
How to adjust the volume
[AS10352( GV)06/95]
Turn the ªVOL/PUSH ONº knob to the right to
increase the volume and to the left to decrease
the volume.
*
[AS10354( GV)03/96]
Selecting the AM or FM frequency band
[AS10355( GV)03/96]
Push the ªAM/FMº button to select the desired
frequency band. Pushing the ªAM/FMº button
causes the frequency band to switch from ªAMº
to ªFM1º to ªFM2º to ªAMº, changing one band
to the next each time the button is pressed.
These functions are used with the station
memory buttons described underHow to tune
radio stations.
%*
[AS10356( GV)03/96]
How to tune radio stations
*
[AS10357( GV)03/96]
There are four ways for you to tune in a
particular station. You can use the ªTUNEº,
ªSEEKº, ªSCANº or memory buttons.
*
[AS10358( GV)03/96]
q
Using the ªTUNEº function
[AS10359( GV)03/95]
You can change the frequency up or down
one increment at a time by pressing and
releasing either the left
bor right
aside of
the ªTUNEº button. To change frequencies
quickly, press and hold down either the right
or left side of the ªTUNEº button.
*
[AS10360( GV)03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996
Page 54 of 305
52
*
[AS10430( GV)01/95]
To stop the scan mode on the presently
sampled tape selection, press the ªSCANº
button or the ªTAPEº button.
*
[AS10435( GV)08/95]
q
How to change the side of the tape being
played
*
[AS10440( GV)01/95]
The alternate side of the tape can be selected
by pressing the ªSIDE 1-2º button.
*
[AS10445( GV)08/95]
How to eject the tape
*
[AS10450( GV)03/95]
To stop the tape and eject the cassette, press the
ªEJECTº button. The tape will eject only when
in the tape mode. The cassettecannotbe ejected
when the radio is playing an ªAMº or ªFMº
station. The system will revert to radio mode
when the cassette is ejected.
*
[AS10455( GV)02/96]
Using the DolbyHB noise reduction feature
*
[AS10460( GV)09/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS10465( GV)07/95]
Push thekbutton to activate. When
activated, the light above thekbutton will be
illuminated.
*
[AS10470( GV)08/95]
Tape error messages
*
[AS10475( GV)08/95]
Your cassette tape player is equipped to
diagnose certain problems you may experience.
Error codes are as follows:
*
[AS10480( GV)01/95]
TD E1 Ð Radio tries to change sides of tape 3
times in a 10 second span. Push ªEJECTº and
try another tape. If problem persists, refer
problem to qualified personnel for service.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996
Page 58 of 305
56 %
*
[AS56600( GV)03/96]
How to tune radio stations
*
[AS56650( GV)10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS56660( GV)03/96]
q
Using the ªTUNEº function
*
[AS56700( GV)03/96]
You can change the frequency up or down
one increment at a time by pressing and
releasing either the left
bor right
aside of
the ªTUNEº button.
*
[AS56750( GV)03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS56800( GV)04/96]
q
Using the ªSEEKº function
*
[AS56850( GV)05/96]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the right
a
side of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the left
bside of the button to select
the next listenable station down the
frequency band. By holding the button down,
listenable stations can be passed over to reach
the desired station.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996
Page 62 of 305
60
*
[AS58400( GV)01/95]
At the end of the tape, the direction
automatically reverses and plays the other
side of the tape.
*
[AS58450( GV)08/95]
q
Rewinding the tape
*
[AS58500( GV)01/95]
To rewind the tape, press the ªREWº button.
The radio will begin playing until rewind is
manually stopped (by pushing the ªTAPEº
button) or the beginning of the tape is
reached.
*
[AS58550( GV)08/95]
q
Using the ªSEEKº function with your cassette
tape player
*
[AS58600( GV)03/96]
While in the tape mode, push the right
a
side of the ªSEEKº button to seek forward to
the next selection on the tape. Push the left
bside to seek the previous tape selection.
*
[AS58650( GV)08/95]
q
Using the ªSCANº function with your
cassette tape player
*
[AS58700( GV)01/95]
Press the ªSCANº button to begin the
forward scan mode on the tape currently
playing, stopping on each tape selection for
approximately an eight-second sampling
(display indicates ªSCº).
*
[AS58800( GV)01/95]
To stop the scan mode on the presently
sampled tape selection, press ªSCANº a
second time.
*
[AS58850( GV)08/95]
q
How to change the side of the tape being
played
*
[AS58900( GV)01/95]
The alternate side of the tape can be selected
by pressing the ªSIDE 1-2º button.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996
Page 65 of 305
63
*
[AS61400( ALL)08/95]
2. Terrain
*
[AS61500( ALL)08/95]
The terrain (hilly, mountainous, tall buildings) of
the area over which the signal travels may
prevent the FM signal from being noise-free.
*
[AS61700( ALL)08/95]
If there is a building or large structure between
the antenna and station, some of the signal
ªbendsº around the building, but certain spots
receive almost no signal. Moving out of the
ªshadowº of the structure will allow the station
to return to normal.
*
[AS61800( ALL)08/95]
When the radio waves are reflected off objects or
structures, the reflected signal cancels the normal
signal, causing the antenna to pick up noise and
distortion. Cancellation effects are most
prominent in metropolitan areas, but also can
become quite severe in hilly terrain and
depressed roadways.
*
[AS61900( ALL)08/95]
To minimize these conditions, a stereo/mono
blend circuit has been incorporated into this
system. This feature automatically switches a
weak stereo signal to a clearer monaural signal,
which improves the quality of reception.
*
[AS62000( ALL)08/95]
Several sources of static are normal conditions
on AM frequencies. These can be caused by
power lines, electric fences, traffic lights and
thunderstorms.
*
[AS62100( ALL)08/95]
Another reception phenomenon isStrong Signal
Capture and Overload. This can occur when
listening to a weak station and when passing
another broadcast tower. The close station may
capture the more distant station, although the
displayed frequency does not change. While
passing the tower, the station may switch back
and forth a few times before returning to the
original station.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996
Page 72 of 305
71
*
[CF09400( GV)12/95]
To change the temperature in the display
window, select any temperature between65ÊF
(18ÊC) and 85ÊF (29ÊC)using the BLUE (cooler)
or RED (warmer) buttons. The Electronic
Automatic Temperature Control will do the rest.
*
[CF09500( GV)12/95]
If you want continuous maximum cooling, push
the BLUE button until60ÊF (16ÊC) isshown in
the display window. Your EATC will cool at
maximum and disregard the60ÊF (16ÊC)setting
until you select a warmer temperature with the
RED button. If you want continuous maximum
heating, push the RED button until90ÊF (32ÊC)
is shown in the display window. Your EATC
will provide maximum heat regardless of the
90ÊF (32ÊC)setting until you select a cooler
temperature with the BLUE button.
[CF09600( GV)12/95]
one third page art:0011300-B*
[CF09700( GV)01/96]
The display window tells you how the system is
operating. It will indicate the selected
temperature and the operating function you
have chosen; AUTO or one of the six manual
overrides. It will also indicate manual
(thumbwheel) control of the fan speed with the
Hsymbol. The display window with all possible
displays and their positions are shown here.
Normally not all are shown at the same time but
are included here to familiarize you with the
names and symbols.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996
Page 73 of 305
72
*
[CF09800( GV)01/96]
Automatic operation
*
[CF09900( GV)01/96]
Push the AUTOMATIC button and select the
desired temperature. The selected temperature
and AUTO will be shown in the display
window. The EATC will automatically heat or
cool to achieve the set temperature. Under
normal conditions, your EATC will need no
additional attention.
[CF10000( GV)12/95]
quarter page art:0011301-C*
[CF10100( GV)12/95]
When in AUTOMATIC and weather conditions
require heat, air will be sent to the floor. But, a
feature is included in your EATC to prevent
blowing cold air to the floor if the engine
coolant is not warm enough to allow heating.
For a short time the fan will be at low speed
and air directed to the windshield. In 3-1/2
minutes or less, the fan speed will start to
increase and the airflow will change to the floor
area.
*
[CF10200( GV)12/95]
If unusual conditions exist (i.e., window fogging,
etc.), the six manual override buttons allow you
to select special air discharge locations. A
thumbwheel allows you to adjust the fan speed
to suit your needs.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996
Page 75 of 305
74without an E/M Button, the temperature display
can also be changed to ÊF or ÊC using the MAX
A/C and DEFrost override buttons.
[CF10900( GV)12/95]
one third page art:0011303-E*
[CF11000( GV)05/96]
To change the temperature display to ÊF or ÊC,
press and hold the MAX A/C and DEF Buttons
at the same time for 3/4 second. The display
will change. If you continue to press the two
buttons, the display will continuously switch
between ÊF and ÊC. If the temperature display
does not agree with the speedometer on vehicles
with an E/M button, pressing the E/M button
will make them agree.
*
[CF11100( GV)01/96]
Fan speed and thumbwheel
*
[CF11200( GV)12/95]
Your EATC automatically adjusts the fan speed
to the existing conditions. You must push
AUTOMATIC for automatic fan speed operation.
To control the fan speed yourself, use the
thumbwheel which will cancel the automatic fan
speed control. The thumbwheel is located at the
extreme right side of the EATC control panel. It
is a vertical control marked with a fan symbol.
Rotate up for HI and down for LO speeds.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996
Page 101 of 305
100
*
[CF38700( ALL)01/96]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not block
your vision. If you cannot see through the
mirror, it could result in a collision,
injuring yourself and others.
%*
[CF39100( GV)05/96]
Automatic Dimming Inside Rearview
Mirror (If equipped)
[CF39200( GV)12/95]
quarter page art:0010037-C
The automatic non-glare mirror
*
[CF39300( GV)01/96]
The electronic day/night mirror will change
from the normal state to the non-glare state
when bright lights (glare) reach the mirror. This
mirror functions at night, and has a limited
function at dusk or dawn. From the non-glare
state, the mirror will return to the normal state
after a short delay. The delay starts when the
glare goes away. The delay prevents excessive
changing of the mirror as traffic moves behind
and around the vehicle, or on rolling hills and
curves.
[CF39400( GV)12/95]
To turn the mirror on, push the ON/OFF
switch, located on the bottom of the mirror, to
latch it in the ON position. The switch will
illuminate and the mirror will be in the
automatic dimming mode. To turn the switch
illumination and automatic dimming feature off,
push the ON/OFF switch again.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996
