MOTORCRAFT PART NUMBERS
Component 4.6L SOHC V8 engine
Air filter element FA-1668
Fuel filter FG-986B
Battery-standard BXT-65±650
Battery-heavy duty BXT-65±750
Oil filter FL-820-S
PCV valve EV-98
Spark plugs* AWSF-32P
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
REFILL CAPACITIES
Fluid Ford Part Name Capacity
Engine oil (includes
filter change)Motorcraft SAE 5W-20
Super Premium Motor
Oil4.7L (5.0 quarts)
Brake fluid
1Fill to line on reservoir
Power steering fluid Motorcraft MERCONt
AT FFill to line on reservoir
Transmission fluid
2Motorcraft MERCONtV
AT F13.1L (13.9 quarts)3
Engine coolant4Motorcraft Premium
Engine Coolant
(green-colored) or
Motorcraft Premium
Gold Engine Coolant
(yellow-colored)15.0L (15.8 quarts)
Fuel tank N/A 71.9L (19.0 gallons)
Rear axle lubricant
5Motorcraft SAE 80W-90
Premium Rear Axle
Lubricant1.8L (3.75 pints)
Windshield washer
fluidUltra-Clear Windshield
Washer ConcentrateFill to line on reservoir
1Use only brake fluids certified to meet Ford specifications. Refer to
Lubricant Specificationsin this chapter. DOT 3 fluid is recommended.
Capacities and specifications
216

Seat belts (see Safety
restraints) ..................................102
Seats ............................................98
child safety seats ....................122
cleaning ...................................215
SecuriLock passive anti-theft
system ....................................90±92
Servicing your vehicle ..............168
Spark plugs,
specifications .............216, 219±220
Specification chart,
lubricants ...........................218±219
Speed control ..............................69
Speedometer ...............................18
Starting your vehicle..129±130, 132
jump starting ..........................162
Steering
speed sensitive .......................138
Steering wheel
controls ......................................73
tilting .........................................67
T
Tires ...........................157, 190±192
changing ..........................157±158
checking the pressure ............192
replacing ..................................193
rotating ....................................192
snow tires and chains ............194
tire grades ...............................191
treadwear ................................191
Towing .......................................145
recreational towing .................147
trailer towing ..........................145
wrecker ....................................167
Traction control ..................65, 136off light ......................................14
Traction-lok rear axle ...............143
Transmission .............................139
fluid, checking and adding
(automatic) .............................183
fluid, refill capacities ..............216
lubricant specifications ..218±219
Trip odometer .............................20
Trunk ...........................................96
remote release ....................81, 87
Turn signal ............................12, 65
V
Vehicle dimensions ...................220
Vehicle Identification Number
(VIN) ..........................................221
Vehicle loading ..........................143
Ventilating your vehicle ...........133
W
Warning chimes ...........................16
Warning lights (see Lights) .........8
Washer fluid ..............................175
Water, Driving through .............148
Windows
power .........................................81
Windshield washer fluid and
wipers
checking and adding fluid .....175
checking and cleaning ............189
operation ...................................66
replacing wiper blades ...........189
Wrecker towing .........................167
Index
239
