Page 14 of 248
Traction ControlYactive (if equipped)
Illuminates when the Traction
Controlysystem is active. It will be
lit for a minimum of four seconds or
for the duration of the Traction
Controlyevent.
For more information, refer to theDrivingchapter.
Air suspension (if equipped)
²Standard instrument cluster
²Optional instrument cluster
Illuminates when the air suspension
switch is turned OFF, the load limit
is exceeded or the air suspension
system requires servicing.
Low fuel (if equipped)
Illuminates when the fuel level in
the fuel tank is at, or near, empty
(refer toFuel gaugein this chapter
for more information).
O/D off
²Standard instrument cluster
²Optional instrument cluster
Illuminates when the overdrive
function has been turned OFF using
the Transmission Control Switch
(TCS). If the light does not come on
or the light flashes steadily, have
your vehicle serviced as soon as
possible, damage to the transmission could occur.
TRAC
CNTL
AIR
SUSP
CHECK
TRUNK AJAR LTR/100 kmAIR SUSPENSION
OVERDRIVE OFFDOOR
AJAR
LOW
WASHER
FLUID
km
MILES
/GAL
LOW
FUEL
O/D
OFF
CHECK
TRUNK AJAR LTR/100 kmAIR SUSPENSION
OVERDRIVE OFFDOOR
AJAR
LOW
WASHER
FLUID
km
MILES
/GAL
Instrument Cluster
14
Page 157 of 248
²do not allow the static water level to rise above the bottom edge of
the rear bumper.
²do not allow waves to break higher than 15 cm (6 inches) above the
bottom edge of the rear bumper.
Exceeding these limits may allow water to enter critical vehicle
components, adversely affecting driveability, emissions, reliability and
causing internal transmission damage.
Replace the rear axle lubricant any time the axle has been submerged in
water. Rear axle lubricant quantities are not to be checked or changed
unless a leak is suspected or repair required.
Disconnect the wiring to the trailer before backing the trailer into the
water. Reconnect the wiring to the trailer after the trailer is removed
from the water.
RECREATIONAL TOWING (ALL WHEELS ON THE GROUND)
Follow these guidelines for your specific powertrain combination to tow
your vehicle with all four wheels on the ground (such as behind a
recreational vehicle).
These guidelines are designed to ensure that your transmission is not
damaged due to insufficient lubrication.
All Rear Wheel Drive (RWD) vehicles
This applies to all cars and 4x2 trucks/sport utilities with rear wheel
drive capability.
An example of recreational towing is towing your vehicle behind a
motorhome. The following recreational towing guidelines are designed to
ensure that your transmission is not damaged.
²Place the transmission in N (Neutral).
²Maximum speed is 56 km/h (35 mph).
²Maximum distance is 80 km (50 miles).
If a distance of 80 km (50 miles) or a speed of 56 km/h (35 mph) must
be exceeded, you must disconnect the driveshaft. Ford recommends the
driveshaft be removed/installed only by a qualified technician. See your
local dealer for driveshaft removal/installation.
Improper removal/installation of the driveshaft can cause
transmission fluid loss, damage to the driveshaft and internal
transmission components.
Driving
157
Page 222 of 248
TRANSMISSION FLUID
Checking automatic transmission fluid (if equipped)
Refer to your scheduled maintenance guide for scheduled intervals for
fluid checks and changes. Your transmission does not consume fluid.
However, the fluid level should be checked if the transmission is not
working properly, i.e., if the transmission slips or shifts slowly or if you
notice some sign of fluid leakage.
Automatic transmission fluid expands when warmed. To obtain an
accurate fluid check, drive the vehicle until it is at normal operating
temperature (approximately 30 km [20 miles]). If your vehicle has been
operated for an extended period at high speeds, in city traffic during hot
weather or pulling a trailer, the vehicle should be turned off for about 30
minutes to allow fluid to cool before checking.
1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating
temperature.
2. Park the vehicle on a level surface and engage the parking brake.
3. With the parking brake engaged and your foot on the brake pedal,
start the engine and move the gearshift lever through all of the gear
ranges. Allow sufficient time for each gear to engage.
4. Latch the gearshift lever in P (Park) and leave the engine running.
5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If
necessary, refer toIdentifying components in the engine compartment
in this chapter for the location of the dipstick.
6. Install the dipstick making sure it is fully seated in the filler tube.
7. Remove the dipstick and inspect the fluid level. The fluid should be in
the designated area for normal operating temperature or ambient
temperature.
Low fluid level
Do not drive the vehicle if the fluid
level is at the bottom of the dipstick
and the ambient temperature is
above 10ÉC (50ÉF).
DON’T ADD
Maintenance and Specifications
222
Page 223 of 248
Correct fluid level
The transmission fluid should be checked at normal operating
temperature 66ÉC-77ÉC (150ÉF-170ÉF) on a level surface. The normal
operating temperature can be reached after approximately 30 km (20
miles) of driving.
You can check the fluid without driving if the ambient temperature is
above 10ÉC (50ÉF). However, if fluid is added at this time, an overfill
condition could result when the vehicle reaches normal operating
temperature.
The transmission fluid should be in
this range if at normal operating
temperature (66ÉC-77ÉC
[150ÉF-170ÉF]).
The transmission fluid should be in
this range if at ambient temperature
(10ÉC-35ÉC [50ÉF-95ÉF]).
High fluid level
Fluid levels above the safe range
may result in transmission failure.
An overfill condition of transmission
fluid may cause shift and/or
engagement concerns and/or
possible damage.
High fluid levels can be caused by
an overheating condition.
Adjusting automatic transmission fluid levels
Before adding any fluid, make sure the correct type is used. The type of
fluid used is normally indicated on the dipstick and also in the
Lubricant specificationssection in this chapter.
DON’T ADD
DON’T ADD
DON’T ADD
Maintenance and Specifications
223
Page 240 of 248
A
Air bag supplemental restraint
system ........................................125
and child safety seats ............127
description ..............................125
disposal ....................................129
driver air bag ..........................127
indicator light ...................13, 129
operation .................................127
passenger air bag ...................127
Air cleaner filter ...............224, 230
Air conditioning ..........................53
manual heating and air
conditioning system .................50
Air suspension ...........................147
description ..............................147
warning light .............................14
Antifreeze (see Engine
coolant) .....................................203
Anti-lock brake system
(see Brakes) ..............................143
Automatic transmission
driving an automatic
overdrive .................................149
fluid, adding ............................222
fluid, checking ........................222
fluid, refill capacities ..............230
fluid, specification ..................233
Auxiliary power point ...........70, 91
Axle
lubricant specifications ..232±233
refill capacities ........................230
traction lok ..............................152
B
Battery .......................................200
acid, treating emergencies .....200charging system
warning light .............................13
jumping a disabled battery ....171
maintenance-free ....................200
replacement, specifications ...230
servicing ..................................200
voltage gauge ............................19
Belt minder ...............................120
Brakes ........................................142
anti-lock ...................................143
anti-lock brake system
(ABS) warning light .........12, 144
brake warning light ..................12
fluid, checking and adding ....221
fluid, refill capacities ..............230
fluid, specifications .........232±233
lubricant specifications ..232±233
pedals (see Power adjustable
foot pedals) ...............................74
shift interlock ..........................148
Break-in period .............................6
C
Capacities for refilling fluids ....230
Cassette tape player ...................35
CD changer .................................45
Certification Label ....................235
Child safety restraints ..............130
child safety belts ....................130
Child safety seats ......................131
attaching with tether straps ..136
in front seat ............................133
in rear seat ......................133, 135
Cleaning your vehicle
engine compartment ..............189
exterior ....................................192
instrument cluster lens ..........191
Index
240
Page 241 of 248
instrument panel ....................191
interior .....................................191
plastic parts ............................190
safety belts ..............................192
washing ....................................187
waxing .....................................187
wheels ......................................188
windows ..................................192
wiper blades ............................190
Clock ......................................32, 70
Compass, electronic ....................73
calibration .................................74
set zone adjustment .................73
Console ........................................91
Controls
power seat .......................108, 110
steering column ........................79
Coolant
checking and adding ..............203
coolant temperature light ........13
refill capacities ................206, 230
specifications ..................232±233
Cruise control
(see Speed control) ....................75
Customer Assistance ................158
Ford accessories for your
vehicle .....................................193
Ford Extended Service
Plan ..........................................179
Getting assistance outside the
U.S. and Canada .....................183
Getting roadside assistance ...158
Getting the service you
need .........................................177
Ordering additional owner's
literature .................................184
The Dispute Settlement
Board .......................................180Utilizing the
Mediation/Arbitration
Program ...................................183
D
Daytime running lamps
(see Lamps) ................................60
Defrost
rear window ..............................58
Dipstick
automatic transmission
fluid ..........................................222
engine oil .................................197
Doors
lubricant specifications ..........232
Driving under special
conditions
through water .........................152
E
Electronic message center .........84
Emergencies, roadside
jump-starting ..........................171
Emission control system ..........218
Engine ................................233±234
check engine/service
engine soon light ......................11
cleaning ...................................189
coolant .....................................203
fail-safe coolant ......................207
idle speed control ...................200
lubrication
specifications ..................232±233
refill capacities ........................230
service points ..........................196
starting after a collision .........160
Engine block heater .................141
Index
241
Page 245 of 248
SecuriLock passive anti-theft
system ........................102±103, 105
Servicing your vehicle ..............194
Spark plugs,
specifications .............230, 233±234
Specification chart,
lubricants ...........................232±233
Speed control ..............................75
Speedometer ...............................21
Starting your vehicle .......138±139,
141
jump starting ..........................171
Steering
speed sensitive .......................147
Steering wheel
controls ..........................69, 75, 79
tilting .........................................69
T
Tires ...........................166, 225±227
changing ..........................166±167
checking the pressure ............227
replacing ..................................228
rotating ....................................227
snow tires and chains ............229
tire grades ...............................226
treadwear ................................226
Towing .......................................154
recreational towing .................157
trailer towing ..........................154
wrecker ....................................176
Traction control ........................145
active light ................................14
Traction-lok rear axle ...............152Transmission .............................148
fluid, checking and adding
(automatic) .............................222
fluid, refill capacities ..............230
lubricant specifications ..232±233
Trip odometer .............................22
Trunk ...........................................93
remote release ....................90, 96
Turn signal ............................15, 61
V
Vehicle dimensions ...................234
Vehicle Identification Number
(VIN) ..........................................235
Vehicle loading ..........................153
Ventilating your vehicle ...........142
W
Warning chimes ...........................16
Warning lights (see Lights) .......10
Washer fluid ..............................197
Water, Driving through .............152
Windows
power .........................................70
Windshield washer fluid and
wipers
checking and adding fluid .....197
checking and cleaning ..............68
operation ...................................68
replacing wiper blades .............68
Wrecker towing .........................176
Index
245
