Mercury Mercury Cougar 1997 s Owner's Guide

18 % [IS13001( BC )03/96]Door Ajar Light (If equipped)
[IS13101( BC )03/96]
This light tells you when any door is not
completely shut. It glows when the key is in the
ON position.
[IS13201( BC )03/96]
one inch art:0010126-C
The door ajar light
%*
[IS13250( BC )04/96]
Engine Oil Pressure Light
[IS13300( BC )05/96]
This light indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. The light
should come on every time your ignition key is
turned to ON or START, and should go out
when the engine starts. If the light stays on or
turns on while the engine is running, you have
lost oil pressure andcontinued operation will
cause severe engine damage.
[IS13350( BC )05/96]
one inch art:0010532-A
The engine oil pressure light
*
[IS13400( BC )05/96]
If you lose engine oil pressure:
*
[IS13450( BC )04/96]
1. Pull off the road as soon as safely possible.
*
[IS13500( BC )05/96]
2. Shut off the engine immediately. If you do
not stop the engine as soon as safely
possible, severe engine damage could result.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

19 [IS13550( BC )04/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, seeEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your vehicle should be on level
ground.
[IS13600( BC )03/96]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the light is on, regardless of the oil level.
Contact your nearest dealer for service as
soon as possible.
*
[IS13700( BC )03/96]
For more information about adding oil, see
Adding engine oilin theMaintenance and Care
chapter of this guide.
%*
[IS13750( BC )04/96]
Low Fuel Light
[IS13800( BC )04/96]
This light comes on when your fuel gauge
indicates approximately 1/8 to 1/16 of a tank.
Your vehicle must be turned to ON for this light
to come on. This light will either flicker or glow
steadily.
[IS13850( BC )04/96]
one inch art:0000116-C
The low fuel light
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

20 % [IS13900( BC )04/96]Washer Fluid Low Light
*
[IS13950( BC )04/96]
This light comes on if the reservoir is less than a
quarter full when you turn on the windshield
washers.
[IS14000( BC )05/96]
one inch art:0000118-B
The washer fluid low light
%*
[IS14200( ALL)03/96]
Fuel Gauge
[IS14300( BC )04/96]
one third page art:0011340-B
The fuel gauge
[IS14600( ALL)12/95]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON. For proper fuel gauge
indication after adding fuel, turn the ignition
switch OFF while refueling the vehicle.
[IS14700( ALL)12/95]
The fuel gauge indicator may vary slightly when
the vehicle is in motion. The most accurate
reading is obtained with the vehicle on level
ground.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

21
*
[IS14800( ALL)01/96]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
%*
[IS15700( ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS15800( ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS15905( BCGV)04/96]
The pointer moves from the C (cold) mark into
the normal band as your engine coolant warms
up. Under normal driving conditions, the pointer
should stay in the normal band. It is acceptable
for the pointer to fluctuate within the noprmal
band under normal driving conditions, and
under certain driving conditions such as, heavy
stop and go traffic, or driving up hills in hot
weather, for the pointer to indicate at the top of
the normal band.
[IS16005( BCGV)04/96]
If, under any circumstances, the pointer moves
above the normal band, the engine is
overheating and continued operation may cause
engine damage.
% [IS16200( BC )04/96]
one third page art:0011144-D
The engine coolant temperature gauge
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

22
*
[IS16400( ALL)03/96]
If your engine overheats:
*
[IS16500( ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS16600( ALL)01/96]
2. Turn off the engine.
*
[IS16700( ALL)03/96]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[IS16800( ALL)03/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[IS16900( ALL)03/96]
If the coolant continues to overheat, have the
coolant system serviced.
%*
[IS18100( ALL)03/96]
Speedometer
[IS18200( BC )04/96]
one third page art:0011341-B
The speedometer
*
[IS18350( ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS18900( ALL)03/96]
Odometer
*
[IS19000( ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

23 %
*
[IS20400( ALL)01/96]
Trip Odometer
*
[IS20500( ALL)04/96]
If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply
set the trip odometer to zero by pressing the
reset control firmly when beginning the distance
you wish to measure.
[IS20600( ALL)04/96]
Since the trip odometer displays distance
independent of the odometer it will not always
advance to the next mile (kilometer) at the same
time as the odometer.
%*
[IS20700(MBC )03/96]
Tachometer
[IS20800( BC )04/96]
one third page art:0011342-B
The tachometer
*
[IS21000(MBC )01/96]
The tachometer displays the approximate engine
revolutions per minute (rpm), or how fast the
engine is running.
*
[IS21200( BC )01/96]
You can drive your vehicle at most rpm points
on the tachometer but you must stay out of the
red zone.
[IS21300( BC )01/96]
Regardless of the type of transmission in your
vehicle, if you drive with the tachometer pointer
in the red zone, you may damage the engine.
File:03rcisc.ex
Update:Fri Jun 7 13:56:06 1996

25
Electronic Sound Systems
% [AS01100( BC )10/95]
full page art:0060658-A
Compact Disc Radio
File:04rcasc.ex
Update:Thu May 30 10:24:18 1996

26
%*
[AS01105( BC )10/95]
Compact Disc Radio
*
[AS01175( BC )10/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
[AS01200( BC )10/95]
Using the Controls on Your New Compact
Disc Radio
*
[AS01300( BC )10/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS01400( BC )03/96]
How to turn the radio on and off
*
[AS01500( BC )10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01600( BC )03/96]
How to adjust the volume
*
[AS01700( BC )03/96]
Press the (R/S) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01800( BC )02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS01900( BC )03/96]
Selecting the AM or FM frequency band
*
[AS02000( BC )10/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:04rcasc.ex
Update:Thu May 30 10:24:18 1996

27 %
*
[AS02100( BC )03/96]
How to tune radio stations
*
[AS02200( BC )10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS02300( BC )10/95]
q
Using the ªSCAN/TUNEº button to manually
tune
*
[AS02400( BC )04/96]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
top
aor bottom
bhalf of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button. While you are
manually tuning, the display will show a
blinking ªMº.
*
[AS02500( BC )03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
File:04rcasc.ex
Update:Thu May 30 10:24:18 1996

28
*
[AS02600( BC )04/96]
q
Using the ªSEEKº function
*
[AS02700( BC )04/96]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the top
a
half of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the bottom
bhalf of the button to
select the next listenable station down the
frequency band. By pressing and holding the
button, listenable stations can be passed over
to reach the desired station.
*
[AS02800( BC )02/96]
q
Using the ªSCAN/TUNEº button to scan
radio stations
*
[AS02900( BC )04/96]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the top
ahalf of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately five
seconds. Pushing the bottom
bhalf of the
ªSEEKº button will begin the scan mode
down the frequency band, again stopping on
each listenable station for approximately five
seconds.
*
[AS03000( BC )03/96]
To stop the scan mode on the presently
sampled station, press the ªSCAN/TUNEº
button again.
*
[AS03200( BC )02/96]
q
Setting the Station Memory Preset buttons
*
[AS03300( BC )10/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
