illuminates when the parking
brake is activated, brake fluid level
is low, or break system requires
service.
illuminates when the
headlamp high beams are on.
ABSilluminates when the anti-lock
brake system requires service.
illuminates when the ignition
key is turned to ON and the safety
belt is not buckled. The light will
remain illuminated for one to two
minutes or until the safety belt is
buckled.
SPEED
CONTilluminates when the engine
is running and speed control is
turned on.
!P
BRAKE
ABS
0ABS
- +
P RND21
UNLEADED
FUEL ONLY
RPM x 1000
12345
6
- +
H
H
L L
ANTI-
THEFT
CHECK
ENGINE
O/D
OFF
SPEED
CONT
H
C
F
E
!P
DOOR
AJAR
BRAKE0
20
1030405060
70
80
90
110
120000000
oooo
100

20406080100
120
140
160
180
MPH km/h
SPEED
CONT
Instrumentation
9

Do not drive your vehicle
until you verify that the
brakelamps are working.
If your vehicle gets stuck in the
mud or snow it may be rocked out
of the spot. To rock the vehicle
out, shift between forward and
reverse gears in a steady rhythm.
Press lightly on the accelerator in
each gear. Do not rock the vehicle
for more than a few minutes,
because it could damage the
vehicle.
Do not spin the wheels at
over 55 km/h (35 mph).
The tires may fail and injure a
passenger or bystander.
ALL-WHEEL DRIVE (AWD)
SYSTEM (IF EQUIPPED)
Your vehicle is equipped with a
full-time All-Wheel Drive (AWD)
transfer case. Power is constantly
supplied to all four wheels through
a transfer case. The AWD system is
full-time and has no external
controls.
The AWD transfer case utilizes a
viscous clutch that distributes
torque to the front and rear
differentials (approximately 35%
front and 65% rear). The viscous
clutch is filled with a high viscosity
fluid; seeLubricant specifications
for more information.
All utility-type and AWD vehicles
have special design and equipment
Driving
102

that could damage drive
components.
If the transmission and transfer
case are submerged in water, their
fluids should be checked and
changed, if necessary.
All rear axle lubricants must be
replaced every 160,000 km
(100,000 miles) or if the axle has
been submerged in water.
Otherwise, check the lubrication of
the rear axle according to the
intervals in theService Guide.
Driving on hill or slope terrain
When driving on a hill, avoid
driving crosswise or turning on
steep slopes. You could lose
traction and slip sideways. Drive
straight up, straight down or avoid
the hill completely. Know the
conditions on the other side of a
hill before driving over the crest.
When climbing a steep hill, start in
a lower gear rather than
downshifting to a lower gear from
a higher gear once the ascent has
started. This reduces strain on the
engine and the possibility of
stalling.
When descending a steep hill avoid
sudden braking. Rapid pumping of
the brake pedal will help slow the
vehicle and still maintain steering
control.
When speed control is on and you
are driving uphill, your vehicle
speed may drop considerably,
especially if you are carrying a
Driving
105

IDENTIFYING COMPONENTS IN
THE ENGINE COMPARTMENT
V1Engine coolant recovery
reservoir
V2Windshield washer reservoir
V3Engine oil filler tube
V4Automatic transmission dipstick
V5Brake master cylinder
V6Power distribution box
V7Battery
V8Radiator cap
V9Power steering fluid reservoir
V10Engine oil dipstick
V11Ignition coil packs
V12Air cleaner
3
4
5
6
2
1
1211
108
79
5.0L
V8
Maintenance and care
139

Adding engine oil
If the fluid level is below the MIN
line, add engine oil. Add engine oil
through the oil filler cap and use a
funnel to pour oil into the opening.
Make sure you use a certified
engine oil of the preferred
viscosity.
Recheck the oil level. Make sure
that the oil level is not above the
MAX line on the dipstick.
Continuous contact with
USED motor oil has
caused cancer in laboratory rats.
Ford production and aftermarket
(Motorcraft) oil filters are designed
for added engine protection and
long life. If a replacement oil filter
is used that does not meet Ford
material and design specifications,
startup engine noises or knock
may be experienced.
It is recommended you use the
appropriate Motorcraft oil filter (or
another brand meeting Ford
specifications) for your engine
application.
CHECKING AND ADDING
BRAKE FLUID
Brake fluid should be checked and
refilled as needed at least once
each year.
Maintenance and care
142

1. Clean the reservoir cap before
removal to prevent dirt or water
from entering the reservoir.
2. Visually inspect the fluid level.
3. If necessary, add brake fluid
until the level reaches within 1/89
of the MAX line on the reservoir.
²Do not exceed MAX.
Use only a DOT 3 brake fluid
certified to meet Ford specification
ESA-M6C25-A. Refer toLubricant
specifications.
Brake fluid is toxic.
If you use brake fluid that
is not DOT 3, you will
cause permanent damage.
Do not let the reservoir in
the master cylinder run
dry. This may cause the brakes
to fail.
MAX
Maintenance and care
143

Your vehicle does not use up
transmission fluid. However, it is
recommended that you check the
transmission fluid at least twice a
year. The fluid level should be
checked if the transmission is not
working properly, i.e., the
transmission slips or shifts slowly
or if you notice some sign of fluid
leakage.
It is preferable to check the
transmission fluid level at normal
operating temperature, after
approximately 32 km (20 miles) of
driving. However, if necessary, you
can check the fluid level without
driving to obtain a normal
operating temperature if the
outside temperature is above 10ÉC
(50ÉF).
If the vehicle has been operated
for an extended period at high
speeds, in city traffic during hot
weather or pulling a trailer, the
vehicle should be turned off for
about 30 minutes to allow the fluid
to cool before checking.
1. Park the vehicle on a level
surface.
2. Start the engine and move the
gearshift lever through all of the
gear ranges. Allow sufficient time
for each gear to change.
3. Latch the gearshift lever in
P(Park), set the parking brake and
leave the engine running.
4. Remove the dipstick, wiping it
clean with a clean, dry rag.
5. Install the dipstick.
P R N D 2 1
Maintenance and care
150

MOTORCRAFT PART NUMBERS
Component Motorcraft part number
Spark plug
1AWSF-32EE*
Air filter FA-1641
Fuel filter FG-872
Oil filter FL-1A
Battery BXT-65-650 or BXT-65-850 (optional)
P.C.V. valve EV-152
1Refer to Vehicle Emission Control Information Decal for spark plug and
gap specifications.
*If any spark plug needs to be removed for examination, each spark plug
removed must be reinstalled in the same cylinder. Cylinders 1-4 have an
ªEGº suffix. Cylinders 5-8 have an ªEº suffix. If any spark plug needs to
be replaced, use only spark plugs with the service part number suffix
letters ªEEº as shown on the engine decal.
REFILL CAPACITIES
Fluid Component Capacity
Brake fluid Brake master
cylinderFill to line in
reservoir
1
Engine coolant Engine coolant
recovery reservoir
and radiator13.5 L (12.8 qts.)
Engine oil 5.0 L (302 c.i.d.) 4.7 L (5.0 qts.)
2
Fuel 4-door 79.5 L (21.0 gal)
Front axle Dana 35 front axle 1.7 L (3.5 pts.)
1
Power steering fluid Power steering fluid
reservoirFill to line in
reservoir1
Rear axle Ford conventional
and Traction Lok 8.82.6 L (5.5 pts.)1
Capacities and specifications
185

LUBRICANT SPECIFICATIONS
ComponentFord part
nameFord part
numberFord
specification
Windshield
washer
reservoirUltra-Clear
Windshield
Washer
ConcentrateC9AZ-
19550-AA or
BAESR-M17P5-A
Body hinges,
latches, door
striker plates
and rotors, seat
tracks, door
checks and
tracks, hood
latch, auxiliary
latch, and fuel
filler door and
springMulti-Purpose
GreaseD0AZ-19584-AA
or
D7AZ-19584-AAESB-M1C93-A
or
ESB-M1C159-A
Steering
column,
U-joints, clutch
linkage pivots,
parking brake
linkage pivots
and clevises
and
transmission
control linkage
pivotsPremium
Long-Life
GreaseXG-1C or K ESA-M1C75-B
Brake master
cylinderHigh
Performance
DOT 3 Brake
FluidC6AZ-19542-AA
or BAESA-M6C25-A
Capacities and specifications
187

Air bag supplemental restraint
system ............71,74,75,76,77,82,87
and child safety
seats .......................74,76,77,82,87
description ................................73
indicator light ...........................74
Air cleaner filter
replacing ..................................156
All Wheel Drive .........................102
Anti-theft system ........................56
arming the system ....................56
disarming a triggered system ..57
disarming an untriggered
system .......................................57
Audio system (see Electronic
sound system) .............................16
Autolamp system (see
Headlamps) .................................33
Automatic transmission ..............98
fluid, adding ............................149
Battery .......................................153
battery saver .............................58
how to service ........................153
Brake fluid
checking and adding ..............142
Brakelamp
bulb replacement ....................174
Brakes ..........................................97
adjustment ................................96
anti-lock .....................................96
anti-lock brake system (ABS)
warning light .............................97
parking ......................................97
Break-in period .............................3
Bulbs, replacing
specifications ..........................179
Cargo area shade ...................46,47
Cargo cover ............................46,47
Childproof locks ..........................39
Chime ...........................................11
headlamps on ............................12
key-in-ignition ...........................11safety belt ............................11,69
Cleaning your vehicle
built-in child seat ...................184
engine compartment ..............183
exterior ....................................182
instrument panel ....................182
plastic parts ............................182
safety belts ..............................184
washing ....................................181
wheels ......................................182
wiper blades ............................183
Climate control
system ...........................17,18,19,21
air conditioning .........................21
heating .......................................21
Compass, electronic
calibration .................................30
set zone adjustment .................30
Compass/temperature display ...29
Console, description ...................42
Controls
instrument panel ......................13
steering column ........................22
Daytime running light system ...14
Defects, reporting .....................192
Defrost
rear window ..............................15
Driving under special
conditions
towing a trailer .......................114
Electronic sound system ............16
Emission control system ..........168
Engine .................................139,189
Engine block heater ...................93
Engine coolant
checking and adding ..............145
checking hoses .......................148
Engine coolant temperature
gauge ..............................................7
Engine oil
checking and adding .......140,142
Exhaust fumes ............................94
Index
193
