Engine oil pressure gauge
This shows the engine oil pressure
in the system. Sufficient pressure
exists as long as the needle
remains in the normal range (the
area between the ªHº and ªLº).
If the gauge indicates low
pressure, switch off the engine
immediately. Check the oil level.
Add oil if needed (refer to
Checking and adding engine oil
in theMaintenance and care
chapter). If the oil level is correct,
have your vehicle checked at your
dealership or by a qualified
technician.
Fuel gauge
Displays approximately how much
fuel is in the fuel tank (when the
key is in the ON position). The
fuel gauge may vary slightly when
the vehicle is in motion. The
ignition should be in the OFF
position while the vehicle is being
refueled. When the gauge first
indicates empty, there is a small
amount of reserve fuel in the tank.
When refueling the vehicle from
empty indication, the amount of
fuel that can be added will be less
than the advertised capacity due to
the reserve fuel.
The FUEL DOOR icon and arrow
indicates which side of the vehicle
the fuel filler door is located.
H
L
EF
Instrumentation
15

Press the control for rear washer
fluid operation.
OVERHEAD CONSOLE
(IF EQUIPPED)
The appearance of your vehicle's
overhead console will vary
according to your option package.
All overhead consoles show the
outside temperature and compass
display.
Storage compartment
(if equipped)
Press the OPEN control to open
the storage compartment. The
door will open slightly and can be
moved to full open.
Installing a garage door opener
(if equipped)
The storage compartment can be
converted to accommodate a
variety of aftermarket garage door
openers:
PUSH
OFFR.WIPE
HI
MODELAMP
LAMP
OPEN
Controls and features
33

The moon roof has a sliding shade
that can be manually opened or
closed when the glass panel is
shut. To close the shade, pull it
toward the front of the vehicle.
Do not let children play
with the moon roof. They
may seriously hurt themselves.
Electronic compass/temperature
display
A compass and outside
temperature display are contained
in the overhead console.
The compass and temperature
display can be turned off and on
by pressing the MODE control on
the overhead console. The vehicle
heading is displayed as one of N,
NE, E, SE, S, SW, W and NW.
Outside air temperature
The temperature can be displayed
in Centigrade or Fahrenheit by
pressing the MODE control.
If the outside temperature falls
below 3.3ÉC (38ÉF), the display
will alternate from ªICEº to the
outside temperature at a two
second rate for one minute.
LAMPMODELAMP
9 VAR
Controls and features
35

2. Press and hold the MODE
control until VAR appears in the
display, then release. The display
should show the current zone
number.
3. Press the MODE control until
the desired zone number appears.
The display will flash and then
return to normal operation. The
zone is now updated.
Compass calibration adjustment
Perform this adjustment in an
open area free from steel
structures and high voltage lines:
²Press and hold the MODE
control until CAL appears in the
display (approximately eight
seconds) and release.
²Drive the vehicle slowly (less
than 5 km/h [3 mph]) in circles
until CAL indicator turns off in
about 2±3 complete circles.
AUTOLAMP DELAY SYSTEM
(IF EQUIPPED)
The autolamp sets the headlamps
to turn on and off automatically.
The autolamp may be set to:
²turn on the lamps automatically
at night
²turn off the lamps automatically
during daylight
²keep the lamps on for up to
three minutes after the key is
turned to OFF
LAMPMODELAMP
9 VAR
LAMPMODELAMP
CAL
Controls and features
37

P (Park)
Always come to a complete stop
before shifting into P (Park). Make
sure the gearshift is securely
latched in P (Park).
R (Reverse)
With the gearshift in R (Reverse),
the vehicle will move backward.
Always come to a complete stop
before shifting into and out of R
(Reverse).
N (Neutral)
With the gearshift in N (Neutral),
the vehicle can be started and is
free to roll. Hold the brake pedal
down while in this gear.
(Overdrive)
The normal driving position for the
best fuel economy. Transmission
operates in gears one through four.
(Overdrive) can be deactivated
by pressing the transmission
control switch on the end of the
gearshift lever.
The transmission control indicator
light (TCIL) will illuminate on the
instrument cluster.
Drive± Not shown on the display.
Activate by pressing theO/D
ON/OFF
O/ D
OFF
Driving
106

R (Reverse)
With the gearshift in R (Reverse),
the vehicle will move backward.
Always come to a complete stop
before shifting into and out of R
(Reverse).
N (Neutral)
With the gearshift in N (Neutral),
the vehicle can be started and is
free to roll. Hold the brake pedal
down while in this gear.
(Overdrive)
The normal driving position for the
best fuel economy. Transmission
operates in gears one through five.
(Overdrive) can be deactivated
by pressing the transmission
control switch on the end of the
gearshift lever.
The transmission control indicator
light (TCIL) will illuminate on the
instrument cluster.
Drive± Not shown on the display.
Activate by pressing the
transmission control switch on the
end of the gearshift lever with the
gearshift in the
position. The
TCIL will illuminate on the
instrument cluster. Transmission
operates in gears one through four.
(Drive) provides more engine
O/D
ON/OFF
O/ D
OFF
Driving
109

improving fuel economy ........134
octane rating ...........................185
quality ......................................186
safety information relating to
automotive fuels .....................183
Fuel gauge ...................................15
Fuel pump shut-off switch .......135
Fuse panels
instrument panel ....................138
power distribution box ...........141
Fuses ...................................136,137
Gauges, Mechanical ....................12
engine coolant temperature
gauge .........................................13
Hazard flashers .........................135
Head restraints ......................62,65
Headlamps ...................................16
daytime running lights .............16
flashing ......................................17
high beam .................................17
Heating ........................................18
High beams
indicator light .............................9
Hood
release lever ............................156
Instrument panel
lighting up panel and interior..17
Jump-starting your
vehicle .................................149,151
attaching cables ......................150
disconnecting cables ..............151
Keyless entry system
autolock .....................................50
keypad .......................................52
locking and unlocking doors ....54
programming entry code ....53,54
Keys
key in ignition chime ...............12
Liftgate ........................................43
Lights, warning and indicator
air bag ..........................................8
anti-lock brakes (ABS) ..............9anti-theft ...................................10
brake ............................................9
charging system ........................10
check engine ............................6,7
cruise indicator .........................11
door ajar ....................................10
fuel reset .....................................8
overdrive off ..............................11
safety belt ...................................8
turn signal indicator ...................9
Load limits
trailer towing ..........................125
Lubricant specifications ...........207
Luggage rack .............................133
Mirrors
cleaning ...................................203
side view mirrors (power) .......41
Moon roof ....................................34
Motorcraft parts ........................204
Odometer .....................................13
Off road driving, 4-wheel
drive ....................................114,119
Overhead console
compass/temperature display ..33
storage compartment ...............33
Panic alarm feature, remote
entry system ................................47
Parking brake ............................102
Power door locks ........................40
Power steering
fluid, checking and adding ....167
Radio (see Electronic sound
systems) ......................................25
Rear window
washer .......................................32
Recreational towing, all wheels
on the ground ...........................133
Refill capacities for fluids ........204
Relays ........................................136
Remote entry system .................46
illuminated entry ......................49
locking/unlocking doors ......46,47
