Maintenance and care
186Checking wiper blades
Check the wiper blades on your
vehicle for roughness by running
the tips of your fingers over the
edge of the blade.
Traces of grease, silicone and fuel
prevent wiper blades from
functioning properly. We
recommend Ford cleaning
solutions or equivalent to clean
wiper blades.
Change the wiper blades on your
vehicle at least once a year.
Cabin air filter replacement
In your climate control system, you
have a filter that cleans the air
before it enters the interior of the
vehicle. This filter should be
replaced at the intervals in the
“Scheduled Maintenance Guide“.
To replace the cabin air filter:
1. Unscrew the nut in the base of
each windshield wiper arm.
Remove the windshield wiper arms.
31MMCen 24.6.99 15:31 Uhr Seite 186

223
Capacities and specifications
* Refer to Vehicle Emission Control Information (VECI) decal for spark plug and gap specifications.
** If a spark plug is removed for examination, it must be reinstalled in the same cylinder.
If a spark plug needs to be replaced, use only spark plugs with the service part number suffix
letter “FE” as shown on the engine decal.
Motorcraft parts
Component
Spark plug*
Air filter
Passenger compartment
air filter
Fuel filter
Oil filter
Battery
PCV valve
Crankcase ventilation
filter2.0 litre engine
AZFS-22F # 1+2**
AZFS-22FE# 3+4
FA-1612
FP4
FG-800A
FL-2005
BXT-40R
EV-224
FA-1621
2.5 litre engine
AWSF-32F
FA-1613
FP4
FG-800A
FL-820
BXT-40R
EV-152
—
Part number
32MCSen 24.6.99 15:34 Uhr Seite 223

Capacities and specifications
224
* Total capacity
** with automatic transaxle
Engine oil
- with filter
- without
Manual transaxle 1.9 l (2.0 qts)
Automatic transaxle
with oil cooler
Power steering
Cooling system with heating
Windshield washer fluid
Fuel tank
Braking system4.25 l (4.5 qts)
3.75 l (4.0 qts)
8.5 l (9.0 qts.)
6.6 l (7.0 qts)*
7.1 l (7.5 qts)**
Fill to MAX mark
Fill to top of reservoir
58.5 l (15.4 gallons)
Fill to MAX mark5.5 l (5.8 qts)
5.0 l (5.3 qts)
9.6 l (10.2 qts)
9.5 l (10.0 qts)*
9.7 l (10.2 qts)**
Capacities2.0 litre
engine2.5 litre
engine
32MCSen 24.6.99 15:34 Uhr Seite 224

243
Index
CPage
Cleaning your vehicle
engine compartment . . . . . . . .219
exterior lamps . . . . . . . . . . . . .220
fabric . . . . . . . . . . . . . . . . . . . .221
instrument panel . . . . . . . . . . .221
plastic exterior parts . . . . . . . .220
safety belts . . . . . . . . . . . . . . .222
wheels . . . . . . . . . . . . . . . . . . .218
wiper blades . . . . . . . . . . . . . .220
Climate control system
air conditioning . . . . . . . . . . . . .29
controlling airflow . . . . . . . . . . .26
defrosting . . . . . . . . . . . . . . . . . .38
temperature . . . . . . . . . . . . . . . .27
vents . . . . . . . . . . . . . . . . . . . . . .26
Clock . . . . . . . . . . . . . . . . . . . . . .45
Clutch
operation . . . . . . . . . . . . . . . . .127
recommended shift speeds . . .128
Cold engine starting . . . . . . . . .114
Controls
instrument panel . . . . . . . . . . . .20
power seats . . . . . . . . . . . . . . . .75
steering column . . . . . . . . . . . . .55
Customer assistance . . . . . . . . .229
D
Daytime running lights . . . . . . . .23
Defects, reporting . . . . . . . . . . .241
Defrost
rear window . . . . . . . . . . . . . . . .24
windshield . . . . . . . . . . . . . . . . .32
Dipstick, engine oil . . . . . . . . . .167
Door mounted controls . . . . . . . .64
Driving under special conditions
heavy load . . . . . . . . . . . . . . . .133
towing a trailer . . . . . . . . . . . .134
E
Electrical system
fuses . . . . . . . . . . . . . . . . . . . . .143EPage
Emergencies, roadside
fuel pump shut-off switch . . . .141
jump starting . . . . . . . . . . . . . .154
towing . . . . . . . . . . . . . . . . . . .160
Emergency brake (see Parking
brake)
Emission control system . . . . . .202
Engine
check engine warning light . . . .12
fuel pump shut-off switch . . . .141
lubricant specifications . . . . . .225
preparing to start . . . . . . . . . .111
refill capacities . . . . . . . . . . . .224
starting . . . . . . . . . . . . . . . . . . .114
Engine block heater . . . . . . . . .115
Engine coolant
checking and adding . . . . . . . .174
disposal . . . . . . . . . . . . . . . . . .178
low coolant warning light . . . . .11
refilll capacities . . . . . . . . . . . .224
specifications . . . . . . . . . . . . . .225
Engine fan . . . . . . . . . . . . . . . . .163
Engine oil
changing oil and filter . . . . . . .170
checking and adding . . . . . . . .169
dipstick . . . . . . . . . .167, 168, 169
disposal . . . . . . . . . . . . . . . . . .171
engine oil pressure
warning light . . . . . . . . . . . . . . .18
filter specifications . . . . . . . . .223
refill capacities . . . . . . . . . . . .224
specifications . . . . . . . . . . . . . .225
Exhaust fumes . . . . . . . . . .110, 202
F
Fan (see Engine fan)
Flasher, hazard . . . . . . . . . .56, 141
Flashing the lights . . . . . . . . . . . .57
Floor mats . . . . . . . . . . . . . . . . . .67
Fluid refill capacities . . . . . . . . .224
Foglamps . . . . . . . . . . . . . . .23, 208
4MInden 24.6.99 15:41 Uhr Seite 243

Index
245 LPage
Lamps
bulb replacement specification
chart . . . . . . . . . . . . . . . . . . . . .212
daytime running light system . .23
flashing the lamps . . . . . . . . . . .57
foglamps . . . . . . . . . . . . . .23, 208
hazard flashers . . . . . . . . .56, 141
headlamps . . . . . . . . . . . . . . . . .22
high beams . . . . . . . . . . . . . . . . .57
high-mounted brake lamp . . . .210
instrument panel, dimming . . .25
interior lamps . . . . . . . . . . . . . .62
reading lamps . . . . . . . . . . . . . .62
replacing bulbs . . . . . . . . . . . .206
rear lamps . . . . . . . . . . . . . . . .209
Lights, warning and indicator
air bag . . . . . . . . . . . . . . . . . . . .15
anti-lock brakes (ABS) . . . . . . .17
brake . . . . . . . . . . . . . . . . . . . . .16
charging system . . . . . . . . . . . . .9
check engine . . . . . . . . . . . . . . .12
engine oil pressure . . . . . . . . . .18
high beam . . . . . . . . . . . . . . . . . .9
low coolant . . . . . . . . . . . . . . . .11
low fuel . . . . . . . . . . . . . . . . . . .15
overdrive off . . . . . . . . . . . . . . .11
safety belt . . . . . . . . . . . . . . . . . .9
testing the warning lights . . . . .19
turn signal indicator . . . . . . . . . .8
Load limits . . . . . . . . . . . . . . . . .130
Lubricant specifications . . . . . .225
Luggage compartment . . . . . . . .66
M
Maintenance (see Servicing)
Manual transaxle
backing up (reverse) . . . . . . . .129
clutch . . . . . . . . . . . . . . . . . . . .127
fluid, capacity . . . . . . . . . . . . .224
shift speeds . . . . . . . . . . . . . . .128MPage
Mileage, calculating fuel
economy . . . . . . . . . . . . . . . . . . .201
Mirrors
side view mirrors (power) . . . .25
Motorcraft parts . . . . . . . . . . . .223
N
National Highway Traffic Safety
Administration . . . . . . . . . . . . . .241
O
Octane rating . . . . . . . . . . . . . . .199
Odometer . . . . . . . . . . . . . . . . . . .20
Oil (see Engine oil)
Oil filter . . . . . . . . . . . . . . .170, 223
On-board diagnostic
(OBD II) system . . . . . . . . . . . .205
Overdrive . . . . . . . . . . . . . . .11, 124
Overhead controls . . . . . . . . . . . .62
P
Panel dimmer control . . . . . . . . .25
Panic alarm, remote entry sytem 69
Parking brake . . . . . . . . . . . . . .118
Parts (see Motorcraft parts) . . .223
Passenger compartment
air filter (see Cabin air filter)
Passive Anti-Theft
System (PATS) . . . . . . . . . . . . . .71
Power distribution box
(see Fuses)
Power door locks . . . . . . . . . . . . .64
Power features
mirrors . . . . . . . . . . . . . . . . . . . .25
seats . . . . . . . . . . . . . . . . . . . . . .75
sunroof . . . . . . . . . . . . . . . . . . . .63
windows . . . . . . . . . . . . . . . . . . .64
Power steering
fluid, checking and adding . . .178
fluid, refill capacity . . . . . . . . .224
fluid, specification . . . . . . . . . .225
4MInden 24.6.99 15:41 Uhr Seite 245
