Mercury Sable 1996 Owner's Manuals

134 [FV07751(ALL)02/95]
one third page art:0001000-ARemote entry transmitter
%*
[FV07801(ALL)02/95]
Unlocking the doors with the remote entry
system
*
[FV07851(ALL)02/95]
To unlock the driver's door, press the UNLOCK
button.
*
[FV07901(ALL)02/95]
To unlock the other doors and liftgate, press the
UNLOCK button a second time, within five
seconds after the first UNLOCK.
[FV07910(ALL)04/95]
To open the trunk (sedan), press the TRUNK
button.
[FV07920(ALL)04/95]
To unlock the liftgate (wagon), press the TRUNK
button. To open the liftgate, you must press the
liftgate release located above the license plate.
*
[FV07951(ALL)02/95]
Locking the doors with the remote entry
system
*
[FV08001(ALL)02/95]
To lock all the doors and liftgate, press the
LOCK button. This will also arm the factory
installed Anti-Theft system.
[FV08051(ALL)04/95]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. If all doors and the liftgate
are completely closed, the doors and liftgate will
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

135
lock again, the horn will chirp and the external
lamps will flash. If a door or the liftgate is open
or ajar, the horn will give two short chirps
warning you that a door or the liftgate is open.
%*
[FV08100(ALL)02/95]
Remote entry personal alarm
*
[FV08151(ALL)02/95]
If you wish to activate the remote entry system
personal alarm, press the PANIC button. This
will honk the horn and flash the lights for
approximately 2 minutes 45 seconds. You can
turn it off by pressing the PANIC button again
from the transmitter or by turning the ignition
to the ON or ACCESSORY position.
*
[FV08200(ALL)02/95]
When you use the remote entry UNLOCK or
PANIC buttons, the illuminated entry system
turns on the vehicle's interior lights for 25
seconds. You can turn these lights off with the
remote entry LOCK button or by turning the
ignition to the ON or ACCESSORY position.
[FV08251(ALL)04/95]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
%*
[FV08300(ALL)04/95]
Arming and Disarming the Alarm System
with Remote Entry
*
[FV08351(ALL)04/95]
Your Remote Entry System will automatically
arm the factory installed Anti-Theft System when
the doors are locked, and automatically disarm it
when the doors are unlocked. The remote will
also reset the anti-theft alarm (when the driver's
door is unlocked or the PANIC button is pressed
on a programmed remote entry transmitter) if it
was triggered.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

136
*
[FV08400(ALL)04/95]
The remote entry system may not arm and
disarm non-factory installed anti-theft systems.
%*
[FV08451(ALL)02/95]
Replacing the batteries
*
[FV08500(ALL)02/95]
The remote entry transmitter is powered by two
coin type three-volt lithium 2016
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
*
[FV08551(ALL)02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV08600(ALL)02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
[FV08651(ALL)02/95]
quarter page art:0020790-A
Replacing the batteries
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

137 %
*
[FV08700(ALL)02/95]
Replacing lost transmitters
*
[FV08751(ALL)02/95]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
*
[FV08800(ALL)02/95]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
[FV08851(ALL)04/95]
Illuminated Entry System
*
[FV08900(ALL)04/95]
This system will provide illumination of the
vehicle's interior courtesy lamps when either
outside front door handle is pulled or when the
remote entry system is used to unlock the door
or sound the personal alarm. The system will
automatically turn off after approximately 25
seconds or when the ignition is turned to the
START or ACC position.
*
[FV08951(ALL)02/95]
NOTE: The inside lights will not turn off if
you have turned them on with the
dimmer thumbwheel or if any door is
open.
[FV09551(ALL)04/95]
Perimeter Anti-Theft System (If equipped)
*
[FV09600(ALL)04/95]
When armed, this system helps protect your
vehicle against break-ins or theft.
%*
[FV09651(ALL)04/95]
When an unauthorized entry occurs, the system
triggers and will:
*
[FV09700(ALL)02/95]
q
flash the headlamps, parking lamps, and theft
indicator lamp
*
[FV09751(ALL)04/95]
q
chirp the horn
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

138 [FV09801(ALL)04/95]Arming the system
*
[FV09851(ALL)04/95]
The system is ready to arm any time the ignition
switch is turned OFF and the alarm is not
triggered or sounding. Any of the following
events will prearm the anti-theft system:
[FV09900(ALL)04/95]
q
Pressing the remote entry transmitter LOCK
button to lock the doors (with the doors open
or closed).
[FV09951(ALL)04/95]
q
Pressing the 7/8 and 9/10 buttons on the
Keyless Entry Keypad at the same time to
lock the doors (with the doors open or
closed).
*
[FV10001(ALL)04/95]
q
Opening a door and pressing the power door
lock button to lock the doors.
[FV10050(ALL)04/95]
q
Turning the driver's or front passenger's door
key to the LOCK position to centrally lock all
doors (with the doors open or closed).
*
[FV10100(ALL)04/95]
If a door or the liftgate is open, the anti-theft
system is prearmed and waiting for all doors to
close. The THEFT indicator in the instrument
panel will light continuously while the system is
prearmed.
*
[FV10201(ALL)04/95]
Once all doors and the liftgate are closed, if any
were open, the system will begin a 30 second
countdown to become armed. The 30 second
countdown allows people who may still be in
the vehicle time to exit without triggering the
alarm. The THEFT indicator will glow steadily
until the system is armed. When the system is
armed, the THEFT indicator will begin to flash
with short flashes every 2 seconds until the
system is triggered or disarmed.
*
[FV10251(ALL)02/95]
Remember, all doors and the liftgate must be
fully closed for the anti-theft system to arm. If a
door or the liftgate has been left open or ajar,
and you press the remote entry transmitter twice
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

139
to confirm the doors are locked, two short horn
chirps will warn you that the anti-theft system is
not arming.
*
[FV10301(ALL)04/95]
The anti-theft system is designed to work with
the factory installed remote entry system. It may
not work with other remote entry systems.
*
[FV10351(ALL)02/95]
When you get a single horn chirp by pressing
the LOCK button twice within 5 seconds on
your remote entry transmitter, you can be
assured that all doors are locked and the
anti-theft system is arming.
[FV10400(ALL)04/95]
Disarming the system
*
[FV10451(ALL)04/95]
An armed or triggered system can be disarmed
if you:
*
[FV10501(ALL)04/95]
q
Unlock the doors by pressing the remote
entry transmitter UNLOCK button.
*
[FV10551(ALL)04/95]
q
Unlock the doors by entering the unlock code
on the keyless entry keypad.
*
[FV10601(ALL)02/95]
q
Unlock any door or the liftgate with a key.
*
[FV10651(ALL)02/95]
q
Turn ignition to the ON or ACC position.
*
[FV10700(ALL)04/95]
q
Pressing the remote entry PANIC button will
disarm the anti-theft system only when the
anti-theft alarm is triggered and sounding.
*
[FV10751(ALL)02/95]
When unlocking the vehicle with a key, turn the
key all the way to the end of its travel or the
system may not disarm.
[FV10800(ALL)04/95]
NOTE: the flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

140 [FV10802(ALL)04/95]Coded Key Anti-Theft System
[FV10804(ALL)08/95]
If your vehicle is equipped with the coded key
anti-theft system, you can only use an
electronically coded key to start the vehicle.
During each vehicle start, the coded key is
ªreadº by the anti-theft system. If the key's ID
code matches that in the anti-theft system, the
vehicle is enabled to start. If the key's ID code
does not match the anti-theft system, or if no
coded key is detected, then the vehicle is not
able to start. Your vehicle will need to be taken
to the dealership for re-initializaiton if either of
the following situations occur:
[FV10805(ALL)07/95]
q
Both supplied keys are lost or stolen.
[FV10807(ALL)07/95]
q
Only one key has been lost, but you want to
ensure the ªlostº key will not start the
vehicle. In this case, bring the remaining
key(s) to the dealer for re-programming.
[FV10808(ALL)04/95]
THEFT indicator
[FV10810(ALL)04/95]
The anti-theft indicator (THEFT) in the
instrument cluster will light for 2 seconds and
then go out when the ignition is turned to the
ON or START position. If it does not light or if
it flashes, have the system serviced by your
dealer or a qualified technician.
[FV10812(ALL)04/95]
Programming additional keys
[FV10814(ALL)04/95]
Two electronically coded keys were supplied
with your vehicle. Additional keys can be
purchased as spares, up to a total of 16 keys. To
program a new key, use a coded key and the
following procedure:
[FV10816(ALL)04/95]
1. With the coded key in the ignition, turn the
ignition from the ON to the OFF position.
[FV10820(ALL)04/95]
2. Within 15 seconds, insert the new electronic
key in the ignition and turn it to ON or
START. The key must have the correct
mechanical cut.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

141 [FV10825(ALL)04/95]
If the key has been coded, the anti-theft
indicator will come on for two seconds. The key
can then be used to start the vehicle. Repeat
until all spare keys have been coded.
[FV10828(ALL)04/95]
If the key coding failed, the anti-theft indicator
will flash and the vehicle cannot be started with
the new key. Coding failure can be caused by
the following:
[FV10830(ALL)04/95]
q
The new key was not inserted within 15
seconds, or
[FV10832(ALL)04/95]
q
16 keys have already been programmed, or
[FV10835(ALL)04/95]
q
The key does not have an electronic code.
[FV10838(ALL)04/95]
Try the coding procedure again. If it fails again,
see your dealer or a qualified technician.
%
*
[FV10850(ALL)02/95]
Windows
%*
[FV10900(ALL)02/95]
Using the Power Windows
*
[FV10950(ALL)02/95]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates all
four windows.
[FV11001(ALL)02/95]
The power windows only operate when the
ignition key is in the ON or ACC position or
when the ignition has been turned from the ON
to the OFF position and/or the key has been
removed and no front doors on the vehicle have
been opened.
[FV11050(ALL)02/95]
The power window controls are illuminated.
*
[FV11100(ALL)02/95]
RWARNING
Do not let children play with the
power windows. They may seriously
hurt themselves.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

142 [FV11150(ALL)04/95]
one third page art:0000417-DThe master controls on the driver's door
%*
[FV11201(ALL)08/95]
Your vehicle is equipped with a ªone touch
downº feature. This feature allows the driver to
fully open the driver's window by firmly
pressing the switch and then releasing. The ªone
touch downº feature can be stopped by pressing
the up or down switch again.
[FV11250(ALL)02/95]
one third page art:0000418-D
The window controls on the passenger's door
[FV11270(ALL)03/95]
Accessory Delay
[FV11290(ALL)04/95]
The power windows and moon roof (if
equipped) can be operated for 45 seconds after
the ignition has been turned to the OFF position
if the front doors have not been opened.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

143
%*
[FV11301(ALL)02/95]
Moon Roof (If equipped)
[FV11351(ALL)03/95]
You can use the moon roof in your vehicle in
two ways. Move it back to open the glass panel,
or you can move it up to ventilate the vehicle.
[FV11400(ALL)02/95]
The moon roof will only operate when the
ignition is in the ON or ACC position or when
the key has been removed from the ignition and
no doors have been opened.
[FV11451(ALL)02/95]
one third page art:0000419-D
The map lamps and the switches for the moon roof
[FV11500(ALL)02/95]
The roof console SLIDE switch is used to open
and close the moon roof.
[FV11550(ALL)04/95]
Press the AUTO portion of the switch and the
roof will fully open automatically. Press the
switch again during the opening cycle and the
roof will stop at that location.
[FV11600(ALL)04/95]
To close the moon roof, press and hold the front
portion of the switch. At the fully closed
position, the motor automatically turns off.
[FV11850(ALL)02/95]
The roof console TILT switch is used to tilt the
moon roof.
[FV11900(ALL)04/95]
To tilt the moon roof into vent position from the
closed position, press the UP portion of the
switch.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995
