194
*
[DR05100(ALL)01/95]
R (Reverse)
*
[DR05200(ALL)02/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[DR05250(ALL)01/95]
N (Neutral)
*
[DR05275(ALL)01/95]
With the gearshift in the N (Neutral) position,
the vehicle can be started and is free to roll.
Hold the brake pedal down while in this
position.
*
[DR05300(ALL)01/95]
Driving
%*
[DR05400(ALL)04/95]
When to usej(Overdrive)
[DR05500(ALL)04/95]
j(Overdrive) is the usual driving position for
an automatic overdrive transaxle. It works the
same way D (Drive) works, automatically
upshifting or downshifting as the vehicle speeds
or slows.
[DR05600(ALL)04/95]
However,j(Overdrive) also shifts into a fourth
gear Ð an overdrive gear Ð when your vehicle
cruises at a consistent speed for any length of
time. This fourth gear will increase your fuel
economy when you travel at cruising speeds.
*
[DR05800(ALL)03/93]
When to use D (Drive)
[DR06000(ALL)04/95]
D (Drive) eliminates the excessive shifting
between third and fourth gears that your vehicle
sometimes does when you are traveling through
hilly terrain inj(Overdrive). It also provides
more engine braking thanj(Overdrive) for
descending hills or city driving.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

195
*
[DR06100(ALL)04/95]
When to use 1 (First)
*
[DR06200(ALL)11/94]
Use 1 (First) when added engine braking is
desired when descending steep hills.
*
[DR06220(ALL)11/94]
The automatic transaxle will shift to the proper
gear to ascend any grade without any need to
shift to 1 (First).
[DR06300(ALL)04/95]
Do not go faster than 38 mph (61 km/h) in this
gear. You can upshift from 1 (First) to D (Drive)
or from 1 (First) toj(Overdrive) at any speed.
*
[DR06400(ALL)01/95]
P (Park)
*
[DR06500(ALL)11/94]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transaxle and prevents the front wheels from
rotating.
*
[DR06600(ALL)01/95]
RWARNING
Do not use the P (Park) position in
place of the parking brake. Always
set the parking brake fully and make
sure that the gearshift is securely
latched in P (Park).
*
[DR06625(ALL)03/95]
Always turn off the ignition
whenever you leave your vehicle. Do
not leave your vehicle unattended
while the engine is running.
*
[DR06650(ALL)01/95]
If you do not take these precautions,
your vehicle may move unexpectedly
and injure someone.
[DR06700(ALL)11/94]
You can tell a column-mounted gearshift is
securely latched in P (Park) if you cannot move
it without pulling it toward you and rotating it
downward.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

196
[DR06705(ALL)04/95]
Driving with an Automatic
Overdrive Transaxle (Column or
Console Gearshift with O/D OFF
Switch)
[DR06710(ALL)02/95]
Your automatic overdrive transaxle provides
fully automatic operation in either D (Overdrive)
or with the O/D OFF Switch depressed. Driving
with the shift selector in D (Overdrive) gives the
best fuel economy for normal driving conditions.
For manual control, start in 1 (First) and then
shift manually.
*
[DR06730(ALL)01/95]
Putting Your Vehicle in Gear
[DR06735(ALL)04/95]
You must push in the thumb button to move the
console-mounted gearshift to the position you
choose.
[DR06740(ALL)02/95]
To move the gearshift out of P (Park), the
ignition must be turned from the locked position
to either the OFF or the ON position.
*
[DR06745(ALL)03/95]
To operate:
*
[DR06750(ALL)01/95]
1. Start the engine.
*
[DR06755(ALL)01/95]
2. Depress and hold the brake pedal.
*
[DR06760(ALL)01/95]
3. Move the gearshift lever out of P (Park).
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

197 %
*
[DR06765(ALL)04/95]
Your vehicle is equipped with a Brake Shift
Interlock safety feature. This feature prevents the
gearshift from being moved from the P (Park)
position until the brake pedal is depressed. This
feature is active when the ignition is in the ON
position. If the gearshift lever CANNOT be
moved from P (Park) with the brake pedal
depressed:
*
[DR06770(ALL)01/95]
1. Turn the engine off and remove the ignition
key.
[DR06775(ALL)11/94]
2. Reinsert the ignition key and turn clockwise
to the first position (OFF).
[DR06780(ALL)11/94]
3. Depress the brake pedal, move the gearshift
lever to N (Neutral) and start the engine.
*
[DR06783(ALL)03/95]
RWARNING
If you need to shift out of P (Park)
by using the alternate procedure
described above, it is possible that a
fuse has blown and that your
brakelamps may also not be
functional. Please refer to the chapter
titledServicing Your Vehiclein this
Owner Guide for instructions on
checking and replacing fuses. DO
NOT DRIVE YOUR VEHICLE
UNTIL YOU VERIFY THAT THE
BRAKELAMPS ARE WORKING.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

198 [DR06785(ALL)04/95]Using the gearshift
*
[DR06787(ALL)04/95]
If your gearshift is on the column, you can use
any of the following positions:
[DR06788(ALL)04/95]
half page art:0001435-A
The column-mounted gearshift
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

199 [DR06789(ALL)04/95]
If your gearshift is on the console, you can use
any of the following positions:
[DR06790(ALL)04/95]
half page art:0001028-D
The console-mounted gearshift
*
[DR06791(ALL)04/95]
The console-mounted gearshift will lock when
you turn the key to the LOCK position. When
the gearshift is in any position except P (Park),
the ignition key cannot be turned to LOCK or
removed from the steering column. TO
REMOVE THE KEY, the gearshift levermustbe
in P (Park).
*
[DR06793(ALL)11/94]
Once the gearshift is secure in the desired
position, release the brake pedal and use the
accelerator as necessary.
*
[DR06795(ALL)01/95]
R (Reverse)
*
[DR06800(ALL)02/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

200
*
[DR06802(ALL)01/95]
N (Neutral)
*
[DR06804(ALL)01/95]
With the gearshift in the N (Neutral) position,
the vehicle can be started and is free to roll.
Hold the brake pedal down while in this
position.
*
[DR06805(ALL)01/95]
Driving
%*
[DR06825(ALL)01/95]
When to use D (Overdrive)
[DR06830(ALL)11/94]
D (Overdrive) is the usual driving position for
an automatic overdrive transaxle. It
automatically upshifts or downshifts as the
vehicle speeds or slows.
[DR06835(ALL)11/94]
However, D (Overdrive) also shifts into a fourth
gear Ð an overdrive gear Ð when your vehicle
cruises at a consistent speed for any length of
time. This fourth gear will increase your fuel
economy when you travel at cruising speeds.
[DR07025(ALL)04/95]
When to use D (O/D OFF)
[DR07050(ALL)04/95]
You will notice that there is only one drive
position on your gearshift indicator (instead of
Drive and Overdrive). However, you will find a
switch labeled O/D located on the gearshift
lever. Push in the switch and the O/D OFF light
in the instrument cluster will illuminate. With
the O/D OFF light illuminated, the transaxle
will operate in first, second and third gears and
will not shift into fourth gear. Operating in D
(O/D OFF) eliminates the excessive shifting
between third and fourth gears that your vehicle
sometimes does when you are traveling through
hilly terrain in D (Overdrive). It also provides
more engine braking than D (Overdrive) for
descending hills or city driving.
[DR07075(ALL)04/95]
To return the transaxle to the normal Overdrive
operation, press the O/D OFF switch again. Use
this switch to select Overdrive or D (O/D OFF)
whenever you drive your vehicle.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

201 [DR08050(ALL)11/94]
NOTE: If the O/D OFF indicator light is
flashing on and off repeatedly when
the vehicle is started or does not come
on when the O/D OFF switch is
pushed, it means that there is a
transaxle electronic system malfunction.
You should contact your dealer as soon
as possible or damage to the transaxle
could occur.
*
[DR08075(ALL)02/95]
The transaxle will be in the ªoverdrive onº
mode when the vehicle is started even if the
O/D OFF mode was selected when the vehicle
was last shut off.
*
[DR09025(ALL)01/95]
When to use 2 (Second)
[DR09050(ALL)11/94]
Use Second for start-up on slippery roads or to
give you more engine braking to slow your
vehicle on downgrades.
*
[DR09075(ALL)04/95]
When to use 1 (First)
*
[DR10025(ALL)11/94]
Use 1 (First) when added engine braking is
desired when descending steep hills.
*
[DR10050(ALL)11/94]
The automatic transaxle will shift to the proper
gear to ascend any grade without any need to
shift to 1 (First).
[DR10075(ALL)11/94]
Do not go faster than 38 mph (61 km/h) in this
gear. You can upshift from 1 (First) to D
(Overdrive) at any speed.
*
[DR10125(ALL)01/95]
P (Park)
*
[DR10150(ALL)11/94]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transaxle and prevents the front wheels from
rotating.
[DR10160(ALL)04/95]
If your vehicle has a console mounted gearshift,
the gearshift indicator in the cluster is
illuminated in P (Park) only when the gearshift
button is released.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

202
*
[DR10175(ALL)01/95]
RWARNING
Do not use the P (Park) position in
place of the parking brake. Always
set the parking brake fully and make
sure that the gearshift is securely
latched in P (Park).
*
[DR10225(ALL)03/95]
Always turn off the ignition
whenever you leave your vehicle. Do
not leave your vehicle unattended
while the engine is running.
*
[DR10250(ALL)01/95]
If you do not take these precautions,
your vehicle may move unexpectedly
and injure someone.
[DR10275(ALL)11/94]
You can tell a console-mounted gearshift is
securely latched in P (Park) if you cannot move
it without pushing in the thumb button.
*
[DR15600(ALL)01/95]
Steering Your Vehicle
%*
[DR15800(ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
[DR15970(ALL)11/94]
Your vehicle has variable-assist steering. This
system provides light power steering efforts for
parking and heavier power steering efforts for
highway driving. If you notice that the power
steering effort does not change according to the
speed you are traveling, or if the power steering
system is not working, have the system checked.
%*
[DR16100(ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

203
*
[DR16150(ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
*
[DR16200(ALL)03/95]
Brakes
%*
[DR16300(ALL)01/95]
Applying the Brakes
[DR16450(ALL)05/94]
Your vehicle may have four-wheel power
anti-lock disc brakes which adjust automatically
through everyday use.
[DR16500(ALL)11/94]
Some models have power front disc brakes and
rear drum brakes which automatically adjust as
the brake pads and linings wear down.
[DR16700(ALL)04/95]
If your vehicle does not have anti-lock brakes,
apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[DR16800(ALL)02/95]
If your vehicle does not have anti-lock brakes,
extreme braking can make the wheels lock and
slide, causing you to lose control of the steering.
If the wheels lock, release the brake pedal and
repeat the ªsqueezeº technique.
*
[DR16900(ALL)08/95]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[DR17000(ALL)03/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995
