Introductory Information
5
[IN04575(ALL)05/96]
When you purchase Ford ESP, you receive peace-of-mind
protection throughout the United States and Canada, provided
by a network of more than 5,100 participating Ford Motor
Company dealers.
[IN04600(ALL)05/96]
NOTE: Repairs performed outside the United States and
Canada are not eligible for ESP coverage.
[IN04700(ALL)05/96]
This information is subject to change. Ask your dealer for
complete details about Ford ESP coverage.
[IN05500(ALL)01/93]
Break-In Period for Your Villager
[IN05600(ALL)02/95]
Your new vehicle will go through an adjustment or break-in
period during the first 1,000 miles (1,600 km) of driving. During
the break-in period, you need to pay careful attention to how
you drive your vehicle.
[IN05700(ALL)01/93]
n
Change your speed often as you drive.Do not drive at one
speed for a long time.
%*
[IN05800(ALL)01/95]
n
Use only the type of engine oil that Ford recommends.See
Engine oil recommendationsin the Index. Do not use special
ªbreak-inº oils.
%*
[IN05900(ALL)01/95]
n
Avoid sudden stops.Because your vehicle has new brake
linings, you should take these steps:
*
[IN06000(ALL)01/95]
Ð Watch traffic carefully so that you can anticipate when to stop.
*
[IN06100(ALL)01/95]
Ð Begin braking well in advance.
*
[IN06200(ALL)01/95]
Ð Apply the brakes gradually.
[IN06300(ALL)05/93]
The break-in period for new brake linings lasts for 100 miles
(160 km) of city driving or 1,000 miles (1,600 km) of highway
driving.
File:02vxinn.ex
Update:Mon Jun 3 08:15:32 1996

Warning Lights and Gauges
73
*
[LG02700(ALL)01/95]
Charging System Light
*
[LG02800(ALL)03/95]
This light, shown as a battery symbol on your cluster, indicates
that your battery is not being charged and that you need to
have the electrical system checked.
[LG02900(ALL)09/93]
6 pica art:0040054-A
Charging system light
[LG03000(ALL)01/93]
This light comes on every time you turn your ignition key to
the ON or START position. The light should go off when the
engine starts and the alternator begins to charge.
*
[LG03100(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
%*
[LG03200(ALL)02/95]
Engine Oil Pressure Warning Light
[LG03300(ALL)04/94]
The oil pressure light is represented by an oil can symbol. It
indicates the engine's oil pressure, not oil level. However, if
your engine's oil level is low, it could affect the oil pressure.
The oil can symbol will flash if the oil pressure drops below the
normal operating level. When you turn the key to the ON
position, the light will illuminate.
[LG03400(ALL)09/93]
6 pica art:0040060-A
Oil pressure light
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

74
[LG03500(ALL)04/94]
The light should turn off after a few seconds. If the light stays
on or illuminates when the engine is running Ð you have lost
oil pressure and continued operation will cause severe engine
damage.
[LG03550(ALL)02/95]
If you lose engine oil pressure:
[LG03600(ALL)02/95]1.
Pull off the road as soon as safely possible.
*
[LG03700(ALL)03/95]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
[LG03800(ALL)04/94]3.
Check the oil level following the instructions on checking
and adding engine oil in this owner guide. (SeeEngine oilin
the index.) Make sure your vehicle is on level ground.
[LG03900(ALL)01/93]4.
If the level is low, add as much oil as necessary before you
drive your vehicle again. Do not drive your vehicle if the oil
pressure light is on, even if the oil level is correct. For more
information about adding oil, seeEngine oil, checking and
addingin the Index.
%*
[LG04000(ALL)01/93]
Door Ajar Warning Light
*
[LG04100(ALL)08/94]
If the ignition switch is in the ON position and any door or the
liftgate is not completely closed, the light will illuminate.
[LG04200(ALL)09/93]
6 pica art:0040061-B
Door ajar warning light
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

255
Roadside Emergencies
[RE00700(ALL)03/94]
Jump-Starting Your Battery
*
[RE00800(ALL)01/93]
Your vehicle's battery may discharge if you leave the lights or
any electrical equipment on after you turn the engine off. If this
happens, you may be able to jump-start from a booster battery
to start your vehicle.
*
[RE00900(ALL)02/95]
RWARNING
The gases around the battery can explode if exposed to
flames, sparks, or lit cigarettes. An explosion could result
in injury or vehicle damage.
*
[RE01000(ALL)02/95]
RWARNING
To protect yourself when charging a battery, always
shield your face and eyes. Make sure that you can
breathe fresh air.
%*
[RE01100(ALL)05/95]
RWARNING
Applying too much pressure on the ends when lifting a
battery could cause acid to spill. Lift the battery with a
carrier or with your hands on the opposite corners.
%*
[RE01200(ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns skin, eyes,
and clothing.
*
[RE01210(ALL)06/95]
If the acid touches someone's skin, eyes, or clothing,
immediately flush the area with water for at least 15 minutes. If
someone swallows the acid, have him or her drink lots of milk
or water first, then Milk of Magnesia, a beaten egg, or vegetable
oil. Call a doctor immediately.
File:12vxren.ex
Update:Tue Jun 4 11:42:14 1996

300
*
[SV04400(ALL)01/93]
To close the hood:
*
[SV04500(ALL)01/93]1.
Remove the prop rod from the slotted hole in the hood.
Place the rod in its retaining clip and close the hood with
enough force to make it latch. Be sure to oil the hood latch
every six months to maintain smooth operation.
*
[SV04600(ALL)01/93]2.
Try to lift the hood after closing it to be sure it is securely
latched.
%*
[SV04700(ALL)04/95]
Engine Compartment
[SV04800(ALL)04/94]
Your vehicle has a 3.0 liter EFI, V-6 engine. The following
illustration will show a diagram of your engine and where you
can find items that you should service regularly.
[SV04900(ALL)04/95]
fourteen pica
chart:0040238-BFile:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

310
%*
[SV14600(ALL)02/95]
Engine Oil Recommendations
*
[SV14750(ALL)02/96]
We recommend using Motorcraft oil or an equivalent oil
meeting Ford Specification WSS-M2C153-F and displaying the
American Petroleum Institute CERTIFICATION MARK on the
front of the container.
*
[SV14850(ALL)03/95]
one third page
art:0060021-E
The API Certification Mark
*
[SV15000(ALL)01/95]
Neveruse:
*
[SV15100(ALL)01/95]
n
ªNon-Detergentº oils
*
[SV15200(ALL)04/95]
n
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV15300(ALL)01/95]
n
Additional engine oil additives, oil treatments or engine
treatments
%*
[SV15400(ALL)03/95]
Engine oils with an SAE 5W-30viscosity arePREFERREDfor
your vehicle. They provide the best engine performance, fuel
economy and engine protection for all climates down to-15ÊF
(-25ÊC).
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

Servicing Your Villager
311
[SV15500(ALL)02/94]
10-1/2 pica
art:0040196-B
Selecting the right viscosity for your climate
%*
[SV15575(ALL)03/95]
Synthetic engine oils which are CERTIFIED and of the preferred
viscosity may be used in your engine. The engine oil and oil
filter must still be changed according to the maintenance
schedule.
%*
[SV15600(ALL)01/95]
Checking and Adding Engine Oil
*
[SV15700(ALL)03/95]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[SV15800(ALL)03/95]
Checking the engine oil level:
*
[SV15900(ALL)02/95]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
[SV16000(ALL)07/95]2.
Set the parking brake fully and make sure that the gearshift
is securely latched in P (Park).
*
[SV16100(ALL)02/95]3.
Open the hood. Protect yourself from engine heat.
*
[SV16200(ALL)03/95]4.
Locate the engine oil dipstick (highlighted in yellow) and
carefully pull it out of the engine.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

312
*
[SV16300(ALL)01/95]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
[SV16400(ALL)05/93]
7-1/2 pica art:0040218-A
Engine oil dipstick
[SV16500(ALL)05/94]6.
Carefully pull the dipstick out again. If the oil level is below
the ªLº line, add engine oil as necessary. If the oil level is
beyond the letter ªH,º engine damage or high oil
consumption may occur and some oil must be removed from
the engine.
*
[SV16600(ALL)01/95]7.
Put the dipstick back in and make sure it is fully seated.
%*
[SV16650(ALL)03/95]
Adding engine oil
*
[SV16700(ALL)01/95]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[SV16800(ALL)03/95]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

Index
385
A
ABS warning light (see Anti-lock brake system)...... 70
Accessory position on the ignition............. 57
Additives, engine oil.................. 310
Air bag supplemental restraint system
and child safety seats............... 25,32
description.................... 23,26
driver air bag................... 23,26
indicator light..................... 71
operation....................... 26
passenger air bag................... 26
proper seating.................... 24
service and information labels............. 26
tone generator.................... 30
wearing safety belts.................. 24
Air cleaner filter, location............... 300
Antenna, radio (see Electronic sound system). . . 121, 205, 226
Antifreeze (see Engine coolant)............. 314
Anti-lock brake system (ABS)
description..................... 234
noise........................ 235
see also Brake.................... 234
warning light..................... 70
Anti-theft lug nuts and key............... 267
Appeals (see Dispute settlement board)......... 278
Assistance (see Customer assistance)........... 275
Audio system (see Electronic sound system)....... 205
File:vxixn.ex
Update:Fri Jun 7 09:28:47 1996

389
Index
Coolant (see Engine coolant)
checking and adding................ 314
drain and flush................... 318
preparing for storage................ 370
specifications.................... 368
temperature gauge................ 78,82
warnings...................... 314
Cooling fan...................... 296
Cruise control (see Speed control)............ 128
Customer Assistance Centre, Ford of Canada....... 282
D
Dashboard (see Instrument panel)............. 89
Daytime running light system............. 114
Defrost, windshield................... 91
Dipstick
automatic transaxle fluid............... 331
engine oil..................... 311
power steering fluid................. 335
Disabled vehicle (see Towing).............. 273
Dispute Settlement Board................ 278
Doors
door ajar warning light................ 74
lubricant specifications................ 368
Driving under special conditions
bad weather.................... 240
heavy load..................... 241
high speed..................... 240
high water..................... 241
slippery roads................... 240
tips for safe driving................. 239
towing a trailer................... 242
File:vxixn.ex
Update:Fri Jun 7 09:28:47 1996
