Starting Your Villager
59
*
[ST04500(ALL)01/93]
RWARNING
Do not leave children, unreliable adults, or pets alone in
your vehicle. They could accidentally injure themselves
or others through inadvertent operation of the vehicle.
Further, on hot, sunny days, temperatures in a closed
vehicle could quickly become high enough to cause
severe and possibly fatal injuries to people as well as
animals.
%*
[ST04600(ALL)03/95]
Fuel-Injected Engines
*
[ST04700(ALL)03/95]
When starting a fuel-injected engine,the most important thing
to remember is to avoid pressing down on the accelerator
before or during starting. Only use the accelerator when you
have problems getting your vehicle started. SeeStarting Your
Enginein this chapter for details about when to use the
accelerator while you start your vehicle.
[ST04750(ALL)02/95]
Starting Your Vehicle
%*
[ST04800(ALL)05/94]
Preparing to Start Your Vehicle
*
[ST04900(ALL)05/95]
RWARNING
Do not start your vehicle in a closed garage or other
enclosed area. Never sit in a stopped vehicle for more
than a short period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding Against Exhaust
Fumesin this chapter for more instructions.
*
[ST04950(ALL)01/93]
Before you start your vehicle, always:
*
[ST05000(ALL)01/93]1.
Make sure you and all your passengers buckle your safety
belts. SeeSafety beltsin the Index for more details.
*
[ST05100(ALL)03/95]2.
Make sure the headlamps and other accessories are turned
off when starting.
File:04vxstn.ex
Update:Mon Jun 3 08:20:06 1996
Page 78 of 396
Warning Lights and Gauges
77
*
[LG06400(ALL)01/95]
High Beam Light
*
[LG06500(ALL)03/95]
This light comes on when the headlamps are turned to high
beam or when you flash the lights.
[LG06600(ALL)09/93]
6 pica art:0040065-A
High beam light
*
[LG06700(ALL)03/95]
ªHeadlamps Onº Alert Chime
[LG06800(ALL)01/93]
This chime will sound if you open the door while the
headlamps or parking lamps are on.
*
[LG06850(ALL)10/93]
Gauges
*
[LG06900(ALL)01/95]
Fuel Gauge
[LG07000(ALL)07/93]
The fuel gauge displays approximately how much fuel you have
in the fuel tank. The fuel gauge indicator may vary slightly
while the vehicle is in motion. This is the result of fuel
movement within the tank. An accurate reading may be
obtained when the vehicle is on smooth, level ground.
[LG07100(ALL)09/93]
7-1/2 pica art:0040056-A
Fuel gauge
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996
Page 91 of 396
Instrument Panel Controls
91
[IP01400(ALL)01/93]
The controls for the climate control systems, headlamps, clock,
radio, rear window washer and wiper, hazard flasher, power
switch, and speed control are all on the instrument panel.
*
[IP01500(ALL)01/93]
Climate Control Systems
[IP01600(ALL)04/95]
13-1/2 pica
art:0040301-A
Climate control system panel
[IP01700(ALL)01/93]
Function Selector Buttons
[IP01800(ALL)01/93]
There are six function selector buttons: OFF, Mix, Defrost, Panel,
Panel/Floor, and Floor. When you press a function selector
button, the indicator light on the button will illuminate. If your
vehicle is equipped with a rear passenger compartment climate
control system, the instrument panel will also include a rear seat
function selector lever.
[IP01900(ALL)04/94]
n
The OFF button shuts off the air supply to all outlets and
stops all fan operations. Use this setting when driving
through an area where outside air is unpleasant or dusty.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 113 of 396
Instrument Panel Controls
113
[IP11800(ALL)06/95]
13-1/2 pica
art:0040078-D
Hazard flasher switch location
[IP12100(ALL)01/93]
Interior and Exterior Lights
*
[IP12200(ALL)01/94]
To turn on the headlamps, parking lamps, marker lamps, tail
lamps and instrument panel lights, use the headlamp control
knob, to the left of the instrument cluster.
*
[IP12300(ALL)01/93]1.
Turn the headlamp knob to the first position to turn on the
parking lamps, tail lamps, license plate lamps, marker lamps
and instrument panel lights.
*
[IP12400(ALL)05/95]2.
Turn the headlamp knob to the second position to turn on
the headlamps in addition to the parking lamps, tail lamps,
license plate lamps, marker lamps and instrument panel
lights.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 114 of 396
114
[IP12500(ALL)09/93]
13-1/2 pica art:0040074-E
The headlamp control knob
[IP12600(ALL)01/93]
A chime will sound if any of the exterior lamps are on when
the driver's door is opened.
%*
[IP12625(ALL)05/95]
Cleaning the Exterior Lamps
*
[IP12650(ALL)05/95]
Do not use dry paper towel, chemical solvents or abrasive
cleaners to clean the lamps, as these may cause scratches or
crack the lamps.
%*
[IP12700(ALL)01/93]
Daytime Running Light (DRL) System
(Canadian vehicles only)
*
[IP12800(ALL)03/95]
The Daytime Running Light (DRL) system turns the high beam
headlamps on, with a reduced light output, when:
*
[IP12900(ALL)01/93]
n
the vehicle is ªrunningº
*
[IP13000(ALL)01/93]
n
the vehicle has a fully released parking brake
*
[IP13100(ALL)01/93]
n
the headlamp system is in the OFF position
*
[IP13200(ALL)01/93]
NOTE: You may notice that the lights flicker when the engine
is turned on or off. This is a normal condition.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 115 of 396
Instrument Panel Controls
115
*
[IP13300(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system will not
illuminate the tail lamps and parking lamps. Turn on
your headlamps at dusk. Failure to do so may result in a
collision.
*
[IP13400(ALL)01/93]
Lighting Up the Instrument Panel
[IP13500(ALL)01/93]
The instrument panel lights can be turned on by turning the
headlamp control knob to either the first or second position.
You can brighten or dim the instrument panel lights with the
DIM switch. The DIM switch is located near the headlamp
controls.
[IP13600(ALL)01/93]
Pushing and holding the right side of the switch will continue
to brighten the lights until the maximum brightness is reached.
Release the switch to maintain the desired brightness. The DIM
feature works similarly to dim the instrument panel lights when
the left side of the switch is pushed.
[IP13700(ALL)06/94]
7-1/2 pica art:0040076-B
The instrument panel brightness control
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 116 of 396
116
[IP13800(ALL)09/93]
Autolamp On/Off Delay System (If equipped)
*
[IP13900(ALL)02/95]
The autolamp sets the headlamps to turn on and off
automatically. You can use the autolamp to:
*
[IP14000(ALL)09/93]
n
turn on the headlamps automatically at night
*
[IP14100(ALL)09/93]
n
turn off the headlamps automatically during daylight
[IP14200(ALL)01/93]
n
keep the headlamps on for approximately three minutes after
you turn the key to OFF.
*
[IP14300(ALL)01/95]
To set the autolamp:
[IP14400(ALL)02/94]1.
Make sure the headlamp control knob is in the OFF position.
If the knob for the headlamps is on, the autolamp system is
canceled.
[IP14500(ALL)04/94]2.
Turn the ignition key to ON to start your vehicle.
[IP14600(ALL)01/93]3.
Use the autolamp thumbwheel to activate the autolamp
feature. It is located to the left of the instrument cluster. The
white mark indicates the approximate center of the
thumbwheel.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 117 of 396
Instrument Panel Controls
117
[IP14700(ALL)09/93]
13-1/2 pica
art:0040077-B
Autolamp thumbwheel location
[IP14800(ALL)01/93]4.
Move the thumbwheel all the way to the right. The
autolamp will automatically turn the lamps on and off.
[IP14900(ALL)01/93]
NOTE: Be sure that you do not put anything on top of the
photodiode located in the top right side of the
instrument panel speaker grille. The photodiode
controls the autolamp; if it is covered, the photodiode
reacts as if it is nighttime, and the headlamps will be
illuminated.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 118 of 396
118
[IP15000(ALL)09/93]
13-1/2 pica
art:0040081-B
Autolamp photodiode location
[IP15100(ALL)01/93]
To turn the autolamp off, move the thumbwheel all the way to
the left.
[IP15200(ALL)04/95]
You can set the autolamp so the headlamps stay on for
approximately three minutes after you turn off your ignition.
The farther the thumbwheel is moved to the right, the longer
the headlamps stay on.
[IP15300(ALL)01/93]
The chime will sound when the autolamp system turns the
headlamps on and the driver's door is open.
[IP15400(ALL)01/93]
Interior Lamps
[IP15500(ALL)07/93]
The front dome lamp is located overhead between the driver
and front passenger seats. However, if your vehicle is equipped
with a power sun roof, the dome lamp is located behind the
driver's seat.
[IP15600(ALL)01/93]
The rear dome lamp is located overhead near the rear seating
positions.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996
Page 122 of 396
123
Steering Column Controls
*
[SC00900(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
*
[SC01000(ALL)01/93]
Turn Signal Lever
*
[SC01100(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC01200(ALL)01/93]
n
operate the turn signals.
*
[SC01300(ALL)01/93]
n
turn the headlamps to high beam.
*
[SC01400(ALL)01/93]
n
flash the headlamps.
*
[SC01500(ALL)01/93]
n
turn the windshield wipers and washer on/off.
*
[SC01600(ALL)01/95]
Turn Signals
[SC01700(ALL)02/95]
Move the lever up to signal a right turn. Move it down to
signal a left turn. The corresponding indicator light in the
instrument cluster will flash.
*
[SC01900(ALL)11/93]
7-1/2 pica art:0040085-D
The turn signal lever
[SC02000(ALL)02/95]
If the turn signal stays on after you turn, move the lever back
to the center (off) position.
[SC02100(ALL)02/95]
For lane changes, move the lever far enough to signal but not to
latch. The lever will return to the off position when you release
it.
File:07vxscn.ex
