spare wheel Mercury Villager 1997 Owner's Manuals

232
*
[GF15000(ALL)01/96]
n
GVWR (Gross Vehicle Weight Rating)
*
[GF15100(ALL)01/96]
n
GAWR (Gross Axle Weight Rating)
*
[GF15200(ALL)01/96]
n
GCWR (Gross Combined Weight Rating)
*
[GF15300(ALL)01/96]
Base Curb Weight
*
[GF15400(ALL)01/96]
The base curb weight is the weight of the vehicle including fuel,
coolants, lubricants, emergency tools and spare wheel and tire.
It also includes any equipment that is standard. It does not
include passengers, cargo or optional equipment installed by
factory, dealer, aftermarket supplier or customer.
*
[GF15500(ALL)01/96]
Payload
*
[GF15600(ALL)01/96]
Maximum payload is the combined, maximum allowable weight
of cargo, occupants and optional equipment that the vehicle is
designed to carry. It is the Gross Vehicle Weight Rating minus
the base curb weight.
*
[GF15700(ALL)01/96]
Gross Vehicle Weight (GVW)
*
[GF15800(ALL)01/96]
The Gross Vehicle Weight (GVW) is the total weight of the
passengers, cargo and all equipment.
*
[GF15900(ALL)01/96]
It is important to remember that GVW is not a limit or a
specification, but actual weight. If an owner loads up the vehicle
and weighs it, that's the GVW at that moment. If the owner
adds on more of a load and weighs it again, that becomes the
GVW.
%*
[GF16000(ALL)01/96]
Gross Vehicle Weight Rating (GVWR)
[GF16100(ALL)01/96]
To avoid overloading your vehicle, never exceed the specified
Gross Vehicle Weight Rating for your Villager. The GVWR is
the maximumallowableweight of the vehicle when fully
loaded including passengers, cargo and all equipment.
File:09vxgfn.ex
Update:Thu May 30 09:54:10 1996

256
%*
[ER00500(ALL)01/96]
Changing a Flat Tire
*
[ER00505(ALL)02/96]
If you get a flat tire while you are driving, do not apply the
brake heavily. Instead, gradually decrease the speed. Hold the
steering wheel firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off the ignition, set
the parking brake, and turn on the hazard flashers.
%*
[ER00510(ALL)02/96]
The Temporary Spare Tire
*
[ER00515(ALL)01/96]
Your vehicle has a temporary spare tire (unless you ordered the
optional full-size spare tire). This spare tire is smaller than a
regular tire and is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon as you can. This
spare tire is marked with the words TEMPORARY USE ONLY
so that you can easily identify it.
*
[ER00520(ALL)02/96]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle, possibly injuring
yourself or others.
*
[ER00525(ALL)01/96]
When you drive with the temporary spare tire, DO NOT:
*
[ER00530(ALL)01/96]
n
exceed 50 mph (80 km/h) under any circumstances
*
[ER00535(ALL)01/96]
n
load your vehicle so that it is heavier than the maximum
vehicle load rating listed on the tire decal
*
[ER00540(ALL)01/96]
n
tow a trailer
*
[ER00545(ALL)01/96]
n
use tire chains
*
[ER00550(ALL)01/96]
n
try to repair the temporary spare tire or remove it from its
wheel
*
[ER00555(ALL)01/96]
n
use the wheel for any other type of vehicle
File:10vxern.ex
Update:Thu May 30 09:55:50 1996

258
*
[ER00590(ALL)05/96]2.
Find the lug wrench in the tool kit located behind the jack in
the right cargo area side panel.
*
[ER00595(ALL)01/96]3.
Fit the hex-shaped end of the lug wrench over the hex nut
in the floor of the cargo area. Turn counterclockwise until
the cable extends far enough to lower the spare tire to the
ground.
*
[ER00600(ALL)01/96]
10-1/2 pica
art:0040172-B
The spare tire in the lowered position
*
[ER00605(ALL)01/96]4.
Continue to turn the hex nut counterclockwise until the
spare tire retainer can be seen for removal.
*
[ER00610(ALL)01/96]5.
Remove the retainer from the center of the wheel. It may be
necessary to lift one end of the tire to disengage the retainer.
File:10vxern.ex
Update:Thu May 30 09:55:50 1996

Roadside Emergencies
259
*
[ER00615(ALL)01/96]
10-1/2 pica
art:0040173-B
Removing the spare tire retainer
*
[ER00620(ALL)01/96]
Stowing the spare tire
[ER00625(ALL)05/96]1.
To raise the tire to the stowed position, lay the tire on the
ground with the inboard side facing up. Install the retainer
through the wheel center and slide the tire under the vehicle.
Fit the hex-shaped end of the lug wrench over the hex nut
in the floor of the cargo area. Turn the lug wrench clockwise
until the tire is raised to its original position underneath the
vehicle.
[ER00630(ALL)01/96]
NOTE: The lug wrench ratchets when the tire is raised to the
stowed position. It will not allow you to over-tighten.
*
[ER00635(ALL)01/96]2.
Check for proper seating against the underbody supports
and retighten if necessary.
*
[ER00640(ALL)01/96]
RWARNING
Make sure the spare tire and jacking equipment are
stowed and secured in the proper storage location.
File:10vxern.ex
Update:Thu May 30 09:55:50 1996

260
%*
[ER00645(ALL)03/96]
Preparing to Change the Tire
*
[ER00650(ALL)01/96]
You should only raise your vehicle with a jack properly placed
at the front or rear jacking points.
*
[ER00655(ALL)05/96]1.
Make sure that your vehicle will not move or roll and that
the tires and jack are on a level, solid surface. Put the
gearshift lever in P (Park). Set the parking brake and block
the wheel Ð in both directions Ð that is diagonally opposite
the tire that you are changing.
*
[ER00660(ALL)01/96]
RWARNING
When one of the front wheels is off the ground, the
transaxle alone will not prevent the vehicle from moving
or slipping off the jack, even if the vehicle is in P (Park).
*
[ER00665(ALL)01/96]
RWARNING
To prevent the vehicle from moving when you change a
tire, be sure the parking brake is set, then block (in both
directions) the wheel that is diagonally opposite (other
side and end of the vehicle) to the tire being changed.
*
[ER00670(ALL)03/96]
RWARNING
If the vehicle slips off the jack, you or someone else
could be seriously injured.
[ER00675(ALL)05/96]2.
Get out the spare tire and jack. See previous section for
instructions on spare tire removal. The jack is located in the
rear storage compartment in the right door panel of the
cargo area. You will have to unfasten the jack before
removing it as shown in the illustration. The jack handle is
in the tool kit located behind the jack.
File:10vxern.ex
Update:Thu May 30 09:55:50 1996

Roadside Emergencies
267
*
[ER00775(ALL)01/96]7.
Turn the lug nut wrench (attached to the jack handle)
clockwise to raise the vehicle off the ground.
*
[ER00780(ALL)01/96]8.
Remove the wheel lug nuts with the lug nut wrench.
*
[ER00785(ALL)01/96]9.
Remove the flat tire and replace it with the spare tire.
*
[ER00790(ALL)01/96]10.
Place the wheel lug nuts on the spare tire. Use the lug nut
wrench to screw the lug nuts snug against the wheel, but do
not tighten fully.
*
[ER00795(ALL)01/96]11.
Lower the vehicle by turning the jack handle
counterclockwise.
*
[ER00800(ALL)01/96]12.
Use the wheel lug wrench to tighten lug nuts in the
appropriate sequence. Re-check for complete tightness.
%*
[ER00805(ALL)01/96]
7-1/2 pica art:0040176-A
Lug nut tightening sequence
[ER00810(ALL)01/96]
The lug nuts should be tightened to 72-87 ft-lb (98-118 N%m).
File:10vxern.ex
Update:Thu May 30 09:55:50 1996

268
*
[ER00815(ALL)01/96]
RWARNING
Never use wheels or lug nuts different than the original
equipment as this could damage the wheel or mounting
system. This damage could allow the wheels to come off
while the vehicle is being driven.
*
[ER00820(ALL)01/96]13.
Replace the wheel cover by pressing it into place. If you
have the standard wheel covers, you must align the notch in
the wheel cover with the tire's valve stem and align the
recess in the back of the wheel cover with one of the lug
nuts. If you have the optional aluminum wheel, press the
center wheel cap into place after matching up the design of
the wheel cap to the wheel.
[ER00825(ALL)01/96]14.
Make sure the jack is securely fastened. When you replace
the jack in the jack storage compartment, place the base
against the square-shaped fastening bracket and open the
jack slightly so that the jack is snug against the fastening
brackets.
*
[ER00830(ALL)01/96]15.
Store the flat tire under the vehicle just as you would store
the spare tire. Refer to the section onStowing the Spare Tire
in this chapter.
File:10vxern.ex
Update:Thu May 30 09:55:50 1996

Maintenance and Care
303
*
[MC24700(ALL)01/96]
Inspect the tire sidewalls for cuts, bruises and other damage. If
you suspect internal damage to the tire, have it removed and
checked. You may need to repair or replace it.
%*
[MC24800(ALL)01/96
]
Tire Rotation
*
[MC24900(ALL)01/96]
Because your vehicle's front and rear tires perform different
jobs, they often wear differently. To make sure your tires wear
evenly and last longer, rotate them as indicated in the following
diagram.
*
[MC25000(ALL)03/96]
In situations where the tires differ from front to rear
(snow/traction), simply rotate using a side to side pattern.
[MC25100(ALL)01/96]
10-1/2 pica
art:0040199-B
Rotating the tires
[MC25200(ALL)01/96]
After each rotation, adjust individual tire pressure as specified
on the Tire Pressure Decal. Tighten wheel lug nuts to the
required torque specification and retighten again after 500 miles
(800 km).
*
[MC25300(ALL)01/96]
If your vehicle has the optional full-size spare tire, you may
rotate the spare tire into the rotation pattern.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

304
[MC25400(ALL)01/96]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle.
[MC25500(ALL)01/96]
If your vehicle has aluminum wheels, you may remove the
spare tire from the wheel and remount it on an aluminum
wheel to rotate the spare tire into your vehicle's rotation
pattern.
%*
[MC25600(ALL)01/96
]
Replacing the Tires
*
[MC25700(ALL)01/96]
Replace tires that show wear bands. When your tire shows a
wear band, it has only 1/16 of an inch (1.59 mm) of tread left.
*
[MC25800(ALL)01/96]
7-1/2 pica art:0040200-A
A worn-out tire
*
[MC25900(ALL)02/96]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread.
*
[MC26000(ALL)03/96]
Your wheels and tires are match-mounted for improved ride.
Before you begin to repair a tire, mark the wheel and tire so
that they are properly aligned when remounted. This will
ensure that the tires will continue to give you the same ride
level.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

401
Index
Tires
changing...................... 256
checking the pressure................ 301
cleaning...................... 334
inspection and maintenance............. 301
replacing...................... 304
rotating...................... 303
snow tires and chains................ 307
spare tire...................... 257
storing your vehicle................. 339
tire grades..................... 304
treadwear...................304, 306
wear bands..................... 304
wheel and tire matching............... 305
Towing a trailer (see Trailer towing).......... 230
Towing your vehicle
using wheel dollies................. 274
with a tow truck.................. 274
Trailer towing
tips........................ 238
trailer brakes.................... 237
trailer lamps.................... 237
Transaxle
automatic operation................. 224
fluid, checking and adding (automatic)........ 295
lubricant specifications................ 343
Transaxle control switch................ 226
Trip odometer...................... 20
Turn signal
indicator lights.................... 87
lever......................... 87
File:vxixn.ex
Update:Fri Jun 14 07:38:49 1996
