DIAGNOSTIC TROUBLE CODE PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-53
STEP 5. Recheck for diagnostic trouble code.
Check again if the DTC is set.
(1) Turn the ignition switch to the "ON" position.
(2) Check if the DTC is set.
(3) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the DTC set?
YES : Replace the ETACS-ECU. On completion, verify that
the DTC is not reset.
NO : A poor connection, open circuit or other intermittent
malfunction is present in the CAN bus lines between
the multi center display and the ETACS-ECU (Refer
to GROUP 00, How to Cope with Intermittent
Malfunction P.00-14).
DTC 021 (U1128): Failure Information on Combination Meter.
If DTC 021 (U1128) is set in the ETACS-ECU,
always diagnose the CAN main bus line.
Whenever the ECU is replaced, ensure that the
communication circuit is normal.
The combination meter- related DTC may be set
when DTC 021 (U1128) is set. (For details refer
to GROUP 00, Affiliated DTC Reference Table
P.00-17.) Diagnose the combination meter first
when the combination meter- related DTC is set.
.
TROUBLE JUDGMENT
The ETACS-ECU receives combination
meter-related signal from the combination meter via
the CAN bus lines. If a fail-safe related data is con-
tained in the signal from the combination meter,
DTC 021 (U1128) will be stored.
.
TECHNICAL DESCRIPTION (COMMENT)
Current trouble
The wiring harness wire or connectors may have
loose, corroded, or damage terminals, or termi-
nals pushed back in the connector, the Engine-
ECU, the combination meter or the ETACS-ECU
may be defective.
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80

INPUT SIGNAL PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-429
INSPECTION PROCEDURE M-8: Sunroof Switch: ETACS-ECU does not receive any signal from the
up, open or close/down switch.
.
CIRCUIT OPERATION
The ETACS-ECU receives a signal through the sun-
roof motor assembly via the SWS communication
line from the sunroof switch, and sends a signal to
the data link connector.
.
TECHNICAL DESCRIPTION (COMMENT)
If the SWS communication line between the sunroof
motor assembly and the ETACS-ECU is defective,
the ETACS-ECU cannot identify the input signal from
the sunroof switch even if the sunroof is normal.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The sunroof motor assembly may be defective
The ETACS-ECU may be defective

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-54
DTC U1073: Bus Off
If DTC U1073 is set in the A/C-ECU, diagnose the
CAN main bus line.
Whenever the ECU is replaced, ensure that the
communication circuit is normal.
.
TROUBLE JUDGMENT
DTC U1073 will be stored when the A/C-ECU ceases
CAN communication (bus off) and then resumes the
communication when the ignition switch is turned to
the "LOCK" (OFF) position.
.
TECHNICAL DESCRIPTION (COMMENT)
The wiring harness wire or connectors may have
loose, corroded, or damage terminals, or terminals
pushed back in the connector, or the A/C-ECU may
be defective.
.
TROUBLESHOOTING HINTS
Defective connector(s) or wiring harness
Malfunction of the A/C-ECU.
Refer to component locations GROUP-70
Refer to configuration diagrams GROUP-80
Refer to circuit diagrams GROUP-90
DIAGNOSIS
Required Special Tools:
MB991223: Harness Set
: Diagnostic Tool (MUT-III Sub Assembly)
MB991824: V.C.I.
MB991827: USB Cable
MB991910: Main Harness A
STEP 1. Using diagnostic tool , diagnose the CAN bus line.
To prevent damage to diagnostic tool (MUT-III), always turn
the ignition switch to the "LOCK" (OFF) position before
connecting or disconnecting diagnostic tool (MUT-III).
(1) Connect diagnostic tool to the data link connector.
(2) Turn the ignition switch to the "ON" position.
(3) Diagnose the CAN bus line.
(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the CAN bus line found to be normal?
YES : Go to Step 2.
NO : Repair the CAN bus lines (Refer to GROUP 54C,
precautions on how to repair the can bus lines
P.54C-5).

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-64
DTC U1120: Failure Information on Electronic control unit (Related to Engine)
If DTC U1120 is set in the A/C-ECU, diagnose the
CAN main bus line.
Whenever the ECU is replaced, ensure that the
communication circuit is normal.
The engine control system- related DTC may be
set when DTC U1120 is set. (For details refer to
GROUP 00, Intersystem Affiliated DTC Reference
Ta b l e P.00-17.) Diagnose the engine control sys-
tem first when the engine control system- related
DTC is set.
.
TROUBLE JUDGMENT
The A/C-ECU receives engine control sys-
tem-related signal from the Electronic control unit by
the CAN bus lines. If a fail-safe related data is con-
tained in the signal from the Electronic control unit,
DTC U1120 will be stored.
.
TECHNICAL DESCRIPTION (COMMENT)
Current trouble
The wiring harness wire or connectors may have
loose, corroded, or damage terminals, or termi-
nals pushed back in the connector, the Electronic
control unit, or the A/C-ECU may be defective.Past trouble
If DTC U1120 is stored as a past trouble, carry
out diagnosis with particular emphasis on wiring
and connector(s) in the CAN bus line between
the A/C-ECU and the Electronic control unit, and
the power supply system to the Electronic control
unit. If the connectors and wiring are normal, and
obviously the ECU is the cause of the trouble,
replace the ECU. If in doubt, do not replace the
ECU.
NOTE: For a past trouble, you cannot find it by
the diagnostic tool CAN bus diagnostics even if
there is a failure in CAN bus lines. In this case,
refer to GROUP 00, How to Use Troubleshoot-
ing/Inspection Service Points
How to Cope with
Intermittent Malfunctions P.00-14.) and check the
CAN bus lines. You can narrow down the possi-
ble cause of the trouble by referring to the DTC,
which is set regarding the CAN communica-
tion-linked ECUs (Refer to GROUP 54C
Expla-
nation about the diagnostic tool CAN bus
diagnostics P.54C-6).
.
TROUBLESHOOTING HINTS
Malfunction of the A/C-ECU.
Malfunction of the Electronic control unit.
Refer to component locations GROUP-70
Refer to configuration diagrams GROUP-80
Refer to circuit diagrams GROUP-90
DIAGNOSIS
Required Special Tool:
: Diagnostic Tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A (Vehicles with CAN
communication system)

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-104
INSPECTION PROCEDURE 7: The A/C Indicator Flashes.
.
TECHNICAL DESCRIPTION (COMMENT)
If the A/C indicator flashes, inadequate refrigerant
quantity, the ambient air temperature sensor circuit
or the A/C pressure sensor circuit is suspected.
.
TROUBLESHOOTING HINTS
Malfunction of the A/C pressure sensor
Malfunction of the ambient air temperature sen-
sor
Malfunction of the A/C-ECU
Refer to component locations GROUP-70
Refer to configuration diagrams GROUP-80
Refer to circuit diagrams GROUP-90
DIAGNOSIS
Required Special Tools:
MB991223: Test Harness Set
: Scan Tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A (Vehicles with CAN
communication system)
STEP 1. Using scan tool , read the diagnostic trouble code.
Check if an A/C-ECU DTC is set.
(1) Connect scan tool to the data link connector.
(2) Turn the ignition switch to the "ON" position.
(3) Check if the DTC is set.
(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the check result satisfactory?
YES : Go to Step 2.
NO : Refer to DIAGNOSTIC TROUBLE CODE CHART
P.55-9.
