Page 20 of 496
Quick index
5
Metallic squeal when you press the
brake pedal while driving.“Brake pad wear alarm”
The brake pads are worn down to the serviceable limit.
Have the brake pads replaced at an authorized Mitsubishi Motors dealer or a
repair facility of your choice.P.3-82
Tone when the ignition key is turned to
the “ON” position.“Seat belt reminder buzzer”
When the ignition key is turned to the “ON” position, the tone will sound for
about 6 seconds. If the driver’s seat belt remains unfastened 1 minute later, the
tone will sound intermittently (12 times) when the vehicle is driven. If the
driver’s seat belt subsequently remains unfastened while the vehicle is being
driven, the tone will sound as a warning each time the vehicle stops and starts.
When the driver’s seat belt is fastened, the tone will stop.P.2-18
Tone when the vehicle is moving at
more than 5 mph (8 km/h).“Door-ajar warning buzzer”
Door or rear hatch (ECLIPSE) is not properly shut.
If you shut the door or rear hatch (ECLIPSE), the tone will stop.P. 3 - 1 1 6
When the headlights have flashed for
three minutes, the horn will sound inter-
mittently for three minutes.“Theft-alarm system”
The theft-alarm system is operating. To stop the alarm, use the keyless-entry
transmitter to lock or unlock the doors or rear hatch (ECLIPSE) or the trunk
lid (ECLIPSE SPYDER).
Alternatively, turn the ignition key to the “ON” position.P.3-22
Sound
Do this
Ref. page
BK0098300US.book 5 ページ 2008年12月8日 月曜日 午前11時37分
Page 174 of 496
Features and controls
3-79
3
When pulling away from a standstill on a slippery road,
push the selector lever forward to the + (SHIFT UP) posi-
tion. This causes the transaxle to select 2nd gear, which is
better for safe driving on slippery roads. Push the selector
lever to the - (SHIFT DOWN) side to shift back to 1st
gear.
Move the selector lever gently between the manual and
main gates and between positions in the manual gate.
Excessive force could damage the selector lever.
Operation of the automatic transaxle
N00514500186
CAUTION
!Before selecting a gear with the engine running and
the vehicle stationary, fully depress the brake pedal
to prevent the vehicle from creeping.
The vehicle will begin to move as soon as the gear is
engaged, especially when the engine speed is high, at
fast idle or with the air conditioning operating, the
brakes should only be released when you are ready
to drive away.Depress the brake pedal with the right foot at all
times.
Using the left foot could cause driver movement
delay in case of an emergency.To prevent sudden acceleration, never run the
engine at high rpms when shifting from the “P”
(PARK) or “N” (NEUTRAL) position.Operating the accelerator pedal while the other foot
is resting on the brake pedal will affect braking effi-
ciency and may cause premature wear of brake
pads.
Do not rev the engine with the brake pedal pressed.
This can damage the transaxle.
BK0098300US.book 79 ページ 2008年12月8日 月曜日 午前11時37分
Page 176 of 496
Features and controls
3-81
3 Service brake
N00517500187
Brake pedalOveruse of the brake can cause poor brake response and pre-
mature wear of the brake pads.
When driving down a long or steep hill, use engine braking by
shifting the transaxle into a lower gear (manual transaxle) or a
lower gear of the sports mode (automatic transaxle).
Power brakes
N00517600247
Your vehicle is equipped with power brakes for more braking
force with minimal brake pedal effort.
Your brakes are designed to operate at full capacity, even if the
power assist is lost.
If the power assist is lost, the effort needed to press the brake
pedal is greater.
If you should loose the power assist for some reason, the
brakes will still work.
If the power brake unit or either of the two brake hydraulic sys-
tems stops working properly, the rest of the brake system will
still work, but the vehicle will not slow down as quickly.
You will know this has happened if you find you need to
depress the brake pedal down further, or harder when slowing
down or stopping, or if the brake warning light comes on.
WA R N I N G
!Do not leave any objects near the brake pedal or let
a floor mat slide under it; doing so could prevent the
full pedal stroke that would be necessary in an emer-
gency. Make sure that the pedal can be operated
freely at all times. Make sure the floor mat is
securely held in place.
CAUTION
!It is important not to drive the vehicle with your foot
resting on the brake pedal when braking is not
required. This practice can result in very high brake
temperatures, premature pad wear, and possible
damage to the brakes.
WA R N I N G
!Never coast downhill with the engine OFF. Keep the
engine running whenever your vehicle is in motion.
If you turn off the engine while driving, the power
brake booster will stop working and your brakes
will not work as well.If the power assist is lost or if either brake hydraulic
system stops working properly, take your vehicle to
an authorized Mitsubishi Motors dealer or a repair
facility of your choice immediately.
BK0098300US.book 81 ページ 2008年12月8日 月曜日 午前11時37分
Page 177 of 496
3-82 Features and controls
3
Brake pad wear alarm
N00532500087
The disc brakes have an alarm that makes a metallic squeal
when the brake pads have worn down enough to need service.
If you hear this sound, have the brake pads replaced at an
authorized Mitsubishi Motors dealer or a repair facility of your
choice.
Anti-lock braking system
N00517900224
The anti-lock braking system helps prevent the wheels from
locking up when braking. This helps you keep control of your
vehicle and its direction. Driving hints When using the anti-lock brakes (sudden braking), steer-
ing is slightly different from normal driving conditions.
Use the steering wheel carefully.
Always keep a safe distance from the vehicle in front of
you. Even if your vehicle is equipped with the anti-lock
braking system, leave a greater braking distance when:
• Driving on gravel or snow-covered roads.
• Driving on uneven road surfaces.
Operation of anti-lock braking system is not restricted to
situations where brakes are applied suddenly. This system
may also prevent the wheels from locking when you drive
over manholes, steel roadwork plates, road markings, or
any uneven road surface.
When the anti-lock braking system is in use, you may feel
the brake pedal vibrating and hear a unique sound. You
may also feel as if the pedal resists being pressed.
In this situation, simply hold the brake pedal down
firmly. Do not pump the brake, which will result in
reduced braking performance.
WA R N I N G
!Driving with worn brake pads will make it harder to
stop, and can cause an accident.
BK0098300US.book 82 ページ 2008年12月8日 月曜日 午前11時37分
Page 392 of 496
For emergencies
6-23
6
On wet roads On snowy or icy roads
When driving on a road covered with snow or ice, use
snow tires. Tire chains cannot be used on your vehicle.
There may be state or local regulations about using snow
tires. Always check the regulations in your local area
before using them. Refer to the section entitled “Snow
tires” on page 7-28 and “Tire chains” on page 7-29.
Drive slowly. Do not make sudden starts or stops, sharp
turns, or slam on the brakes.
Pressing the brake pedal when driving on snowy or icy
roads can make your tires slip and skid. When a skid
occurs, take your foot off the accelerator. Steer gently into
the skid. As your vehicle is equipped with an anti-lock
braking system (ABS), brake by pressing the brake pedal
firmly and keep it depressed.
Allow extra distance between your vehicle and the vehicle
in front of you, and avoid sudden braking.
CAUTION
!Avoid flooded roads. Water is often deeper than it
looks, and you could be seriously hurt by driving
into flood water. When driving in rain, on water-covered roads, or
through a car wash, water could get into the brake
discs and make them fail temporarily. In such cases,
lightly press the brake pedal to see if they are work-
ing properly. If they are not, press the pedal lightly
several times while driving to dry the brake pads,
then check them again. When driving in rain, a layer of water may form
between the tires and the road surface (aquaplan-
ing). This loosens your tires’ grip on the road, mak-
ing it difficult to steer or brake properly. When
driving on a wet road:
• Drive your vehicle at a safe speed.
• Do not drive on worn tires.
• Always keep the tires at the correct inflation pres-
sures.
BK0098300US.book 23 ページ 2008年12月8日 月曜日 午前11時37分
Page 408 of 496
Vehicle care and maintenance
7-15
7 Brake fluid/Clutch fluid
(if so equipped)
N00938700229
The brake fluid and the clutch fluid share the reservoir tank.To check the fluid levelThe fluid level must be between the “MAX” and “MIN” marks
on the reservoir.
The fluid level is monitored by a float. When the brake fluid
level falls below the “MIN” mark, the brake fluid warning
lamp lights up.
The fluid level falls slightly with wear of the brake pads, but
this does not indicate any abnormality.
The fluid in the master cylinder should be checked when doing
other work under the engine hood. The brake system should
also be checked for leaks at the same time.If the fluid level falls markedly in a short length of time, it indi-
cates leaks from the brake system.
If this occurs, have the vehicle checked by an authorized Mit-
subishi Motors dealer or a repair facility of your choice.
Fluid typeUse the brake fluid conforming to DOT 3 or DOT 4. The reser-
voir cap must be tightly sealed to keep dirt and water out.
CAUTION
!Do not let any petroleum-based fluid touch, mix
with, or get into the brake fluid. This will damage
the seals.Be careful when handling brake fluid. It can damage
painted surfaces.Use only the listed brake fluid. Different brands of
brake fluid have different additives, and these can
cause a chemical reaction. Do not mix brands of
brake fluid.Keep the reservoir tank cap closed to keep the brake
fluid from evaporating.
BK0098300US.book 15 ページ 2008年12月8日 月曜日 午前11時37分
Page 426 of 496
Vehicle care and maintenance
7-33
7
Evaporative emission control system (except
evaporative emission canister)
N00941400116
If the fuel-vapor vent line is clogged or damaged, the fuel-
vapor mixture will escape, polluting the air.
Have the system checked at an authorized Mitsubishi Motors
dealer at the mileage specified in the “WARRANTY AND
MAINTENANCE MANUAL”.
General maintenance
N00941500159
The next pages list the maintenance service recommended by
Mitsubishi Motors Corporation. In addition to the general
maintenance that needs to be performed at the times listed,
there are other parts which do not usually need regular mainte-
nance.
But, if any of these parts stops working properly, your vehicle
performance could suffer. Have these items checked if you
notice a problem with them.
See your authorized Mitsubishi Motors dealer for assistance, if
you have any questions.Disc brake pads
N00941600020
Good brakes are essential to safe driving. Check the brake pads
for wear. For good braking performance, replace the brake pads
with the same type pads as the originals.Brake hoses
N00941700047
Brake hoses and tubing should be checked for:
Severe surface cracking, scuffing or worn spots. If the
fabric casing of the hose is showing through any cracks or
worn spots in the rubber hose cover, the hose should be
replaced. The brakes can fail if the hose wears through.
Improper installation may cause twisting, or wheel, tire or
chassis interference.
BK0098300US.book 33 ページ 2008年12月8日 月曜日 午前11時37分
Page 487 of 496
Alphabetical index
2Hose 7-33
Parking brake 3-54
Parking brake lever stroke 7-30
Pedal 3-81
Pedal free play 7-30
Power brakes 3-81
Service brake 3-81
Warning light 3-113
Break-in recommendations 3-2
Bulb capacity 7-47
C
California Perchlorate Materials Requirements 1-9
Capacities 9-10
Cargo area light 3-176
Bulb capacity 7-50
Replacement 7-69
Cargo loads 4-12
Catalytic converter 7-3
Certification label 9-5
Charging system warning light 3-115
Child restraints 2-24
Cleaning
Inside of your vehicle 7-72
Outside of your vehicle 7-73
Clutch
Fluid 7-15
Pedal free play 7-29
Coat hooks 3-181Coin holder 3-178
Combination headlights and dimmer switch 3-127
Consumer information 8-2
Convertible top 3-31
,7-77
Coolant (engine) 7-10,9-10
Cruise control 3-91
Indicator 3-92
Cup holder 3-179
D
Defogger (rear window) 3-137
Dimensions 9-6
Dimmer (high/low beam change) 3-129
Disc brake pads 7-33
Dome light
Bulb capacity 7-50
Replacement 7-68
Switch 3-175
Dome light/Reading lights
Bulb capacity 7-50
Replacement 7-68
Switch 3-171
,3-173
Door-ajar warning buzzer 3-116
Doors
Lock 3-13
Power door locks 3-15
Drive belt 7-34
Driving during cold weather 4-5
Driving, alcohol and drugs 4-2
BK0098300US.book 2 ページ 2008年12月8日 月曜日 午前11時37分
