spark plugs replace MITSUBISHI ECLIPSE 2010 4.G Owners Manual

7-32 Vehicle care and maintenance
7
NOTE
To meet government regulations and promote cleaner air,
your vehicle is equipped with an onboard diagnostic sys-
tem (OBD). The engine electronic control module that
controls OBD functions stores various data (especially
about the exhaust emissions). This data will be erased if
the battery cable is disconnected, which could make a
rapid diagnosis difficult. Do not disconnect the battery
cable when the engine malfunction indicator (“SERVICE
ENGINE SOON” or “Check engine light”) is on.Spark plugs
N00940900039
Spark plugs must fire properly for good engine performance
and emission-control.
Do not reuse them by cleaning or regapping. Change them at
the mileage listed in the “WARRANTY AND MAINTE-
NANCE MANUAL”.
Your vehicle may be equipped with iridium tipped spark plugs,
which are identified by marks on the ceramic. They do not
require replacement as frequently as the conventional type
spare plug and will last much longer.NOTE
Use the spark plugs listed under “Engine specifications”
on page 9-8 or plugs that are exactly the same. Other
plugs could cause engine damage, performance problems
or radio noise.
Fuel hoses
N00941000037
Check the hose surfaces for any heat and mechanical damage,
hard and brittle rubber, cracking, tears, cuts and abrasions. Pay
special attention to the hoses closest to high heat sources such
as the exhaust manifold. Check all the hose connections, such
as clamps and couplings, to make sure they are secure and that
there are no leaks. If you see any wear or damage, replace the
hoses immediately.Fuel system (tank, pipe line and connection, and
fuel tank filler cap)
N00941300085
Check these regularly for damage or leaks in the fuel lines and
connections. Check the fuel tank filler cap for damage or loose-
ness. Pay special attention to the fuel lines closest to high heat
sources such as the exhaust manifold.
WA R N I N G
!
If you see a fuel leak or if you smell fuel, do not run
the engine. Any spark (including from the ignition),
flame or smoking material could cause an explosion
or fire. Call an authorized Mitsubishi Motors dealer
or a repair facility of your choice for assistance.
BK0098300US.book 32 ページ ２００８年１２月８日　月曜日　午前１１時３７分

Alphabetical index
6AM/FM electronically tuned radio with CD autochanger-
Type 2 5-39
AM/FM electronically tuned radio with CD player-Type 1 5-
26
AM/FM/Satellite electronically tuned radio with CD au-
tochanger-Type 3 5-39
General information about your radio 5-76
Reading lights on a inside rearview mirror
Bulb capacity 7-50
,7-51
Replacement 7-69
Switch 3-174
Rear combination lights 7-59
Rear hatch 3-16
Rear seat 2-11
Rear shelf panel 3-180
Rear side-marker light
Bulb capacity 7-49
Rear side-marker lights
Replacement 7-59
Rear turn signal light
Bulb capacity 7-49
Rear turn signal lights
Replacement 7-59
Rear window defogger switch 3-137
Rear-view camera 3-104
Rearview mirror
Inside 3-56
Outside 3-59
Refrigerant (air conditioning) 9-10Replacement of light bulbs 7-47
Replacing tires and wheels 7-25
Reporting Safety Defects 8-3
S
Safe driving techniques 4-4
Seat 2-2
Front seats 2-4
Heated seats 2-10
Rear seat 2-11
Seats and restraint systems 2-3
Seat belt 2-13
Adjustable seat belt shoulder anchor 2-19
Child restraints 2-24
Driver’s seat belt reminder/warning light 2-18
Front passenger seat belt warning light 2-19
Maintenance and inspection 2-35
Pre-tensioner 2-22
Seat belt extender 2-21
Seat belt use during pregnancy 2-22
Seat belt guide 2-20
Seat belts
Seat belt guide 2-20
Service brake 3-81
Service precautions 7-2
Skid control function 3-86
Snow tires 7-28
Spark plugs 7-32
Speedometer 3-107
