Climate controls
Fto-70-1a
1. On switch.
2. Rear screen de-mist switch.
3. Air flow.
4. Fan speed control.
5. Air condition control.
6. Exterior temperature switch.
7. Off switch.
8. Indicator screen.
9. Air flow direction.
10. Front screen de-mist switch.
Fto-70-1b
Fan speed indicator.
Redo photo
Fto-071-1a
`

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0451
Rear demister switch
Front demister switch
Air flow indicator

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0453 temperature automatically to 25.0°C (AUTO).
Operating the system as an automatic air conditioning
1. Auto button and temperature set dial.
2. Front windscreen demister.
3. Outside air / recirculate.
4. Fan speed control.
5. Air condition control.
6. Set temperature / outside temperature control.
7. Off button.
8. Display screen.
9. Air flow control.
10. Rear windscreen demister control.
In normal conditions, use the system in AUTO mode and follow these procedures:
1. Press the “AUTO” button. The indicator will illuminate and the outlet port (except ? and ?),
interior/exterior air select and blower speed and ON/OFF of air conditioner will be controlled
automatically. The air conditioning compressor operation will change to (insert picture) (constant
air conditioning operation).
2. Turn the “TEMP” dial to set the desired temperature. The temperature can be set within a range
of 17.0°C to 32.0°C. the temperature will increase as the dial is turned in a clockwise direction.
Note: 1 If the outside air temperature drops below 0°C an alarm will sound, and the outside air
temperature is automatically displayed for a while.
Note: 2 When the vehicle is stopping or in some cases when the outside air temperature is likely to
be influenced by the engine compartment, or the sunshine reflected by the road surface, the
displayed temperature may be higher than the actual temperature.
Note: 3 Press the * button according to the need. Ever time the button is pressed, the mode
changes from ECO * to * to stop; and simultaneous with this, the display indicator changes
as well.
