General overview
Dashboard
1. Passenger air bag cover
2. Climate control screen
3. Analogue clock
4. Heated rear screen switch
5. Ammeter
6. Emergency hazard switch
7. Electric antenna switch
8. Windscreen wiper switch
9. Instrument panel10. Fog light switch
11. Indicator / light switch
12. Traction control switch
13. Exterior mirror control
14. Radio
15. Gear lever
16. Handbrake
17. Drivers air bag cover
18. Ignition switch

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0415
To lock the door from inside the vehicle,
push the door-lock lever forward. To
unlock pull the lever backward. If the
drivers handle is used, the door will
automatically open if previously locked.
Page 15?
Keyless entry
To lock the door with the remote, press
the red button. To unlock the door, press
the white button, the indicator light will
illuminate during both operations.
To change the battery in the remote,
remove the small screw and pries open
the case carefully. Be careful that you do
not damage the seal.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0428
The SRS cannot be turned off.
Redo photo
Do not place objects or stickers onto the
steering wheel or passenger side air bag
egress panel.
Do not fit rear facing child restraint seats
in the front passenger seat. If the air bag
is deployed in an accident, the child seat
will be pushed backwards.
When the ignition is turned on, the SRS
indicator will be illuminated for approx 7
seconds then go out. If it stays on or fails
to come on at all, contact your dealer.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0431
Warning lights
1. Exhaust warning light.
2. Oil pressure warning light.
3. Battery warning light.
4. Engine system warning light
5. Turn signal lights.
6. Washer reservoir tank warning light.
7. Door open warning light.
8. Brake / hand brake warning light.
9. High beam indicator light
10. Seat belt reminder light.
11. Low fuel warning light.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0432
Turn signal indicator. – when the indicator lever is operated
for a left or right turn, the appropriate light will be illuminated, it
will flash along with the outside lights. Pushing the hazard-warning
switch will cause both the turn indicators on the instrument panel
and all the outside lights to flash.
High beam indicator light. – This will be illuminated when
the main lights are switched to high beam.
Exhaust warning light. – If this comes on then the exhaust is
overheating. Stop the car as soon as possible, make sure there is
nothing flammable (grass, paper etc) under the vehicle. Wait approx
15 minutes before restarting, if the light has gone out continue on
your journey. If the light comes back on stop the vehicle again and
wait longer, also have the exhaust checked.
Oil pressure warning light. – This will normally come, on
when the ignition is turned on, but should go out after a few seconds.
Battery warning light. – This will normally come, on when the
ignition is turned on, but should go out after a few seconds. If it
stays on or comes on whilst you are driving, stop the car and have it
checked by an auto electrician.
Engine system. – if this comes on, it indicates a problem with the
engine or electrical system, have the engine / electric’s checked.
Washer reservoir tank warning light. – This will come on
when the water level in the washer bottle is low.
Door open warning light. – This will come on when a door is
open or not closed properly.
Brake / hand brake warning light. – This has 3 functions:-
1. Will be illuminated when the handbrake is on.
2. When the brake fluid is low.
3. When the brake pads need replacing.
Seat belt reminder light. – This will be illuminated until the
driver puts their seat belt on.
Low fuel warning light. – This will come on when the fuel
level is down to about 8 litres.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0433
Light switch
Redo photo
Ft0-40-1a
- Off.
- Parking lights.
- Driving lights.
Ft0-40-1b
Change from main beam to low beam.
Ft0-41-1a
Position 1 – indicator on.
Position 2 – hold for indicator.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0436
Fto-43-1c
Rear screen washer control.
Other switches
Hazard switch
Hazard warning light switch. This turns
ON / OFF the hazard warning lights. The
turn signal indicator light will operate on
the instrument panel. The ignition does
not need to be on for this operation.
Windscreen de-mist
The switch indicated is for the
windscreen de-mister. When it is
operating, there is a small indicator on
the display panel.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0439
Ft0-50-1a
The button indicated must be depressed
and the foot brake applied, before the
gear lever can be moved.
Fto-50-1b
FTO-51-1
Gear selection indicator.
Add pages 52/53/54/55/56
Fto-52-1aPark.
Reverse.
Neutral.
Drive.

Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0444
Traction Control operation
Fto-060-1a
To turn the TCL on / off, use the switch
located next to the mirror adjustment
switch.
Fto-060-1b
Fto-060-1c
When the Traction Control on, the
indicator light on the instrument panel is
illuminated.
Interior bits
Fto-062-1a
The sun-visor can be unclipped and
moved to the side position.
Redo photo
