MITSUBISHI FTO 2003 1.G Owners Handbook
Manufacturer: MITSUBISHI, Model Year: 2003, Model line: FTO, Model: MITSUBISHI FTO 2003 1.GPages: 72, PDF Size: 4.64 MB
Page 31 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0431
Warning lights
1. Exhaust warning light.
2. Oil pressure warning light.
3. Battery warning light.
4. Engine system warning light
5. Turn signal lights.
6. Washer reservoir tank warning light.
7. Door open warning light.
8. Brake / hand brake warning light.
9. High beam indicator light
10. Seat belt reminder light.
11. Low fuel warning light.
Page 32 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0432
Turn signal indicator. – when the indicator lever is operated
for a left or right turn, the appropriate light will be illuminated, it
will flash along with the outside lights. Pushing the hazard-warning
switch will cause both the turn indicators on the instrument panel
and all the outside lights to flash.
High beam indicator light. – This will be illuminated when
the main lights are switched to high beam.
Exhaust warning light. – If this comes on then the exhaust is
overheating. Stop the car as soon as possible, make sure there is
nothing flammable (grass, paper etc) under the vehicle. Wait approx
15 minutes before restarting, if the light has gone out continue on
your journey. If the light comes back on stop the vehicle again and
wait longer, also have the exhaust checked.
Oil pressure warning light. – This will normally come, on
when the ignition is turned on, but should go out after a few seconds.
Battery warning light. – This will normally come, on when the
ignition is turned on, but should go out after a few seconds. If it
stays on or comes on whilst you are driving, stop the car and have it
checked by an auto electrician.
Engine system. – if this comes on, it indicates a problem with the
engine or electrical system, have the engine / electric’s checked.
Washer reservoir tank warning light. – This will come on
when the water level in the washer bottle is low.
Door open warning light. – This will come on when a door is
open or not closed properly.
Brake / hand brake warning light. – This has 3 functions:-
1. Will be illuminated when the handbrake is on.
2. When the brake fluid is low.
3. When the brake pads need replacing.
Seat belt reminder light. – This will be illuminated until the
driver puts their seat belt on.
Low fuel warning light. – This will come on when the fuel
level is down to about 8 litres.
Page 33 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0433
Light switch
Redo photo
Ft0-40-1a
- Off.
- Parking lights.
- Driving lights.
Ft0-40-1b
Change from main beam to low beam.
Ft0-41-1a
Position 1 – indicator on.
Position 2 – hold for indicator.
Page 34 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0434
Wiper switch
Front wiper
Fto-41-1b
O = off
- - - = intermittent (fixed time)
I = normal speed
II = fast speed
Fto-41-1c
O = off
- - - = intermittent (variable time)
I = normal speed
II = fast speed
Fto-42-1a
O = off
- - - = intermittent (variable time)
I = normal speed
II = fast speed
Fto-42-1b
By turning this switch, you can control
the delay on the intermittent.
Page 35 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0435
Fto-42-1c
By turning this switch, you can control
the delay on the intermittent.
Wash / wipe control.
Fto-43-1a
Operates wash / wipe.
Rear screen wiper.
Fto-43-1b
O = off
- - - = Intermittent.
I = normal speed.
Page 36 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0436
Fto-43-1c
Rear screen washer control.
Other switches
Hazard switch
Hazard warning light switch. This turns
ON / OFF the hazard warning lights. The
turn signal indicator light will operate on
the instrument panel. The ignition does
not need to be on for this operation.
Windscreen de-mist
The switch indicated is for the
windscreen de-mister. When it is
operating, there is a small indicator on
the display panel.
Page 37 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0437
Fog / park light
Fto-44-1c
Fog light switch? / Park lights?. When
this is depressed the front fog lights and
the rear lights will be illuminated.
Redo photo
Ignition switch
Ft0-46-1a
Ignition switch.
Ft0-46-1b
When the key is in this position, the
steering is locked and the key can be
removed.
Ft0-46-1c
When the key is in this position, the
accessories i.e. radio / CD can be used.
Page 38 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0438
Park brake
Fto-47-1a
Lift up to activate park brake. Press
button in, to release the brake.
Fto-47-1b
Always leave the gear selection in
Neutral or Park, when the park brake is
applied.
Fto-48-1a
Recommended speeds / gears for
running in.
Redo photo
Page 39 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0439
Ft0-50-1a
The button indicated must be depressed
and the foot brake applied, before the
gear lever can be moved.
Fto-50-1b
FTO-51-1
Gear selection indicator.
Add pages 52/53/54/55/56
Fto-52-1aPark.
Reverse.
Neutral.
Drive.
Page 40 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0440
Ft0-53-1a
53-1b
53-1c
54-1a
