Kick Down
When the accelerator is pressed down
quickly, the transmission will “kick
down” to a lower gear. This will give an
instant power response which is useful
when overtaking or entering a major
road or motorway.
55-1a
Tip-Tronic gear selection.
56-1a.
The selected gear is shown as indicated
by the arrow.
Hand brake operation
56-1b
lift the hand brake to apply, push in the
button to release the brake.
Page 42 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0442
Adjustable items
Steering wheel adjustment
Fto-57-1a
Push lever located under the steering
wheel down, move the steering wheel to
the desired position and firmly pull the
lever up to lock.
Interior mirror adjustment
Fto-57-1b
The mirror can be dipped (so you are not
dazzled by the lights from a following
vehicle) by moving the small lever
forward or backward.
Door mirrors
Fto-57-1c
On basic model. The small joystick will
adjust the drivers door mirror.
Page 43 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0443
Fto-57-1d
On the next model, the switch can be
moved so you can adjust both door
mirrors.
Door mirror parking
Fto-58-1a
The door mirrors can be folded in to
allow for easier parking.
Fto-58-1b
To fold the mirrors in, depress #1 button.
To unfold the mirrors, depress #2 button.
ABS
Anti Lock Brakes
Page 44 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0444
Traction Control operation
Fto-060-1a
To turn the TCL on / off, use the switch
located next to the mirror adjustment
switch.
Fto-060-1b
Fto-060-1c
When the Traction Control on, the
indicator light on the instrument panel is
illuminated.
Interior bits
Fto-062-1a
The sun-visor can be unclipped and
moved to the side position.
Redo photo
Page 45 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0445
Fto-062-1b
Document / sunglasses holder.
Fto-062-1c
Cigarette ashtray. Lift to open.
Fto-062-1d
Pull to remove so you can empty the
ashtray.
Fto-062-1e
Cigarette lighter, push in to use.
Page 46 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0446
Passenger interior lights.
Fto-063-1a
Fto-063-1b
Clock
64-1a
Page 47 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0447
Storage space
Coin holder
064 1b
Redo photo
Glove box
1c
Center console
1d
Page 48 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0448
Storage in boot
65-1a
Redo photo
Climate control
Fto-68-1a
Fto-68-1b
Page 49 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0449
Fto-68-1c
Redo photo
Fto-69-1a
Page 50 of 72
Downloaded from www.Manualslib.com manuals search engine Owners Handbook
Copyright © Tarkus Services (2003)
www.angelfire.com/emo/ftoAll rights reserved
26-Aug-0450
Climate controls
Fto-70-1a
1. On switch.
2. Rear screen de-mist switch.
3. Air flow.
4. Fan speed control.
5. Air condition control.
6. Exterior temperature switch.
7. Off switch.
8. Indicator screen.
9. Air flow direction.
10. Front screen de-mist switch.
Fto-70-1b
Fan speed indicator.
Redo photo
Fto-071-1a
`
