Charge Overview
Quick Charge (if so equipped)
Quick Charging is based on accessing a public charging station that is CHAdeMO certified. Note that in under 30 minutes of
charging you will reach a maximum of 80% of a full charge as shown in your Energy Level Gauge.
1) Fully apply the parking brake and place the selector lever in the P - (Park) position.
2) Turn off the headlights and turn the key to the Lock position.
3) Pull the quick charging lid opener at the bottom left of the driver’s seat on the floor to open the quick charging lid at the
rear driver’s side of the vehicle.
4) Remove the key and lock the vehicle.
5) The fuel door will be open. Press the tab to open the inner lid providing access to the charge port.
6) Open the cap on the regular charge connector and make sure there is no foreign matter such as dust or dirt on the end of
the connector.
7) Connect the quick charge connector to your Mitsubishi i according to the manual of the quick charger you are using.
8) Make sure the charging indicator on the Mitsubishi i’s instrument cluster is illuminated.
9) In order to protect the life of the battery, charging is complete at 80% of a full charge.
10) Remove the connector according to the manual of the quick charger you are using.
11) Close the inner lid and the quick charging door.
12) Place the quick charger back on its unit.
CHARGING YOUR MITSUBISHI i
Access to Level 1/Level 2
Charging
Level 2 ChargingQuick Charging

10AUDIO SYSTEM
1) FM (FM1/FM2) indicator
2) Radio (AM/FM selection) button
3) Memory (Memory selection) button
4) Power
5) Scan button
6) Seek (Up/Down) buttons
7) CD button
8) Clock button
9) Seek ∧ button
10) Seek ∨ button
How to connect a USB memory device or an iPod®
The USB connector is used to play music or charge an audio device.
1) Park your vehicle in a safe place and turn the electric motor switch to the LOCK
position.
2) Open the USB terminal input cover (A) in the floor console.
3) Connect a commercially available USB connector cable to the USB memory device
or connect a genuine Apple Inc. Dock connector to your terminal and to your iPod®.
How to set the clock
1) Press and hold the clock button 8 and the clock display flashes.
2) Press the SEEK button 9 or 10 to adjust the “hours” digit. If you keep pressing the button, fast-forward begins.
3) When the “hours” digit is adjusted, press the clock button to flash the “minutes” digit. Press the SEEK button to adjust the
“minutes” digit. If you keep pressing the button, fast-forward begins.
4) When the time is set, press the clock button to stop the clock display from flashing.
4
1
6
8
29
10
7
53

11
Making a call by using the telephone number:
1. Press A button and Say “Dial.”
2. The voice guide says “Number please.”
3. Say the telephone number “XXX•••••••.”
4. The voice guide says “Dialing .”
Making a call using a phonebook:
1. Press A button and Say “Call.”
2. After the voice guide says “Name please.”
Say the name you want to call “XXX•••••••.”
3. If there is only 1 match, the voice guide says “Calling ” and then the system will dial the telephone number.
Receiving calls:
1. If an incoming phone call is received while the ignition switch is in the “ACC” or “ON” position, with the audio system
OFF, the audio system automatically turns ON.
2. Press B button.
Hanging up a call:
1. Press C button.
To import a devices phonebook:
1. Press A button and Say “Phonebook.” Vehicle must be parked.
2. The voice guide will say “Select one of the following: new entry, edit number, edit name, list names, delete, erase all, or
import contact.” Say “Import contact.”
3. The voice guide will say “Would you like to import a single entry or all contact?” Say “All contacts.”
4. The voice guide will say “Importing the contact list from the mobile phonebook. This may take several minutes to
complete. Would you like to continue?” Answer “Yes.”
5. When the import is complete, the voice guide will say “Import complete.”
Bluetooth® Operation with FUSE Hands-free Link System™
(if so equipped)
If you are having difficulties operating your phone or connecting to the system, please call
Mitsubishi Handsfree at (888) 702-4100.
A
B
C
SPEECH button:Change to voice recognition
PICK-UP button:Answer an incoming call
HANG-UP buttonEnd a call or voice recognition
A
B
C

12MITSUBISHI MiEV REMOTE
Effectively using your Mitsubishi MiEV Remote
1) Pre-activate the climate control – you can use the controller to set the climate inside the vehicle while the vehicle is plugged in. The
vehicle cabin’s temperature will be comfortable while utilizing the power from the outlet rather than from the main drive battery.
2) Timed battery charging – you can set a timer to take advantage of lower energy rates by having your Mitsubishi i programmed to
charge during those off peak hours.
3) Battery level information – you can view your Mitsubishi i’s charge level on your MiEV Remote without being in your vehicle.
4) To maximize the range of the MiEV Remote, extend the antenna to its full height. When
unobstructed, the range is up to 300 feet.
Your Mitsubishi MiEV Remote includes the following functions:
1) Power/communication button – when briefly pushed, settings are communicated to the
Mitsubishi i. When pushed longer than a second, the controller is turned on or off.
2) Mode button – scrolls to Charging Time, AC, Heater, and Defroster by just pressing the mode
button
3) Manual charge button – turns charging on or off, bypassing preset timers.
4) Scrolling buttons – scrolls the display items.
5) Communication signal – blinks when communicating with the vehicle and when errors occur.
6) Charging indicator – lights up during charging and blinks if charging cable is not connected
during charging attempt.
7) ERROR indicator – blinks if there is an operation or communication error.
8) Battery indicator – shows remaining charge of main drive battery. Blinks if battery has less than
20% charge.
9) Timer indicator – shows whether the timer is on or off.
10) Program timing indicator – shows the amount of time left until timer charging is complete based on the program
time set.
11) Climate control settings – displays modes currently active.
6
1
8
2
11
3
5
7
9
10
4

13
Press (within 1 second) totransmit the setting data
Press toSelect On timer setting
Press toSet the waiting time0h -19.5h
ON Timer
Press toSelect Off timer setting
OFF Timer
Press toSet the charging time0.5h -19.5h-h (Full charge)
Press(within 1 second) totransmit the setting data
Press toSelect RemoteClimate Controlsetting
Remote
Climate Control
Press toSelect the A/C mode1.COOL2.HEAT3.DEFROSTER4.A/C OFF
Press(within 1 second) totransmit the setting data
Press
Blinking
Manual
Charging
Press(within 1 second) to transmit the setting data
Hold down more than 1 second to turn on the MiEV Remote
Hold down more than 3 seconds to turn off, Remote will also turn off after 30 seconds of inactivity.
To set the Manual charging,Cancelling theTimer ChargingRemote Climate Control
How to Set the MiEV Remote

14NAVIGATION SYSTEM
1 Press the [MENU] key to display.
2 Touch [Point of Interest].
6Touch [All POIs]
3 Input the “State” and “City”
7 Input the POI name
4 Touch [All Categories]
8 Touch [Set]
5 Touch the category of the desired POI and category type to select.
Point of Interest (POI) Name
6
4
2
Way Points – Once you have set a destination, you can enter additional stops along the way called Way Points. For details on how to set Way Points refer to your Navigation Owner’s Manual.
Saving Addresses - To save an address, first enter the address into the system. Then touch [Address Book] and confirm location to be stored. Touch [Set to Address Book] to complete.

15NAVIGATION SYSTEM
1 Press the [MENU] key to display2 Touch [Address/Intersection]
7 Touch [List] to select a street from the list
4 Input the “State” and “City” name
8 Touch House # or intersection
6Input the street name
3 Touch the “State” and “City” button
9 Touch [Set]
5 Touch [All Streets]
5
8
8
2 3
3
Searching for a Location by Address / Location
Way Points – Once you have set a
destination, you can enter additional stops
along the way called Way Points. For
details on how to set Way Points refer to
your Navigation Owner’s Manual.
Saving Addresses - To save an
address, first enter the address into
the system. Then touch [Address
Book] and confirm location to be
stored. Touch [Set to Address
Book] to complete.See Navigation Manual for additional instructions.

16
Q: Will my battery’s capacity decrease over time?
A: The capacity of the lithium-ion battery used as the main drive lithium-ion battery on your Mitsubishi i, like other commonly used lithium-
ion batteries, will decrease according to time and usage. This type of decrease in battery capacity is normal, and is not indicative of
any defect or failure in your main drive lithium-ion battery.
Q:Can I charge when it is raining or stormy?
A: To reduce the risk of electric shock, connect only to a properly grounded and waterproofed outlet. Never connect or disconnect the
plug with a wet hand.
Q:How can I tow my car?
A: Do not tow this vehicle with rear wheels on the ground at any time. Please see additional information in your Owner’s Manual.
Q:What do I do if I need to store my Mitsubishi i for a long period of time?
A: Do not disconnect the battery or any of the i’s cables. Make sure the battery’s Energy Level Gauge shows 2-4 bars and make sure all
lights are turned off. Do not leave the battery charged with more than 4 bars as this may severely decrease the main drive battery’s
overall lifespan. Check the battery residual every 3 months and if you see any discharge, please charge to 2-4 bars. Try to avoid storage
in a hot or cold environment.
Q:Where can I find charging stations?
A: You can find charging stations near you by logging on to the US Department of Energy’s Website at www.afdc.energy.gov.
Q:Why does my Mitsubishi i Energy Level show bars but the engine won’t start?
A: Even though your main drive battery displays a charge, your 12 volt battery may be drained and in need of charging. Your 12 volt
battery provides the power to start up the main battery.
Q:What does this light mean?
A: The Tire Pressure Monitoring System gives you information to help maintain your tire pressure. Please note that changes in the
outside temperature may decrease tire pressure causing the TPMS light to turn on. If the TPMS light remains illuminated, check
your tire pressure.
Q:What do I do if I need Roadside Assistance?
A: For Roadside Assistance, call 1-888-648-7820.
Q:Where do I get my Mitsubishi i serviced?
A: Only Mitsubishi i authorized dealers are factory trained to service your vehicle.
YOU MIGHT BE THINKING…

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE \:POCKET BELOW:
\f. Pre\bDelivery Inspection F orm (Customer C opy)
2. T riple Diamond Delivery Checklist ( Customer Copy)
3. S alesperson or K ey Dealership C ontact’s Business Card
17
Q: What do I do if I get\u a at tire?
A: The tire repair kit is stored under the rear seat cushion. To access the tire repair kit\f pull forward the seat stoppers under the r\.ear seat
cushion. \bift up the seat cushion and pull it forward. Next remove the wing nuts\f remove the cover and lift out the tire repair kit. Once
you have accessed the tire repair kit\f refer to the Mitsubishi i \.Owner’s Manual for instructions.
Warning – do not us\.e the tire sealant repair kit if any of these situations occur:
