wheel bolts MITSUBISHI iMiEV 2015 Owner's Manual (in English)

Replacement of light bulbs 9-24 Vehicle care and maintenance
9
2. Remove the socket and bulb assembly together by turning it counterclockwise. 3. Pull the bulb out of the socket.4. To install the bulb, perform the removal steps in reverse.
N00943401407
1. To create enough work space, turn the steering wheel all the way in the same direction to the side
you wish to replace.
2. Remove the clip (A) and bolts (B), then lift the cover (C).
NOTE
 When installing the light assembly, push in the end facing the front
of the vehicle first.
* : Front of the vehicle
Front turn signal lights/Front fog lights/Daytime running lights
BK0209800US.book 24 ページ ２０１４年１月１４日　火曜日　午前９時２６分
