MITSUBISHI L200 2011 (in English) Repair Manual

WARNINGlChildren who are not buckled up can
strike other people in the vehicle in an ac-
cident.
l A child should never be left unattended
in your vehicle. When you leave the vehi-
cle, take the child with you.
Seat and seat belts
2-15
2

Suitability for various ISOFIX positionsE00411400269Mass groupSize classFixtureVehicle ISOFIX positionsFront passengerRear outboardRear centreCarrycotFISO/L1XXXGISO/L2XXX XXX0- Up to 10 kgEISO/R1XXX XXX0+- Up to 13 kgEISO/R1XIL*2XDISO/R2XXXCISO/R3XXX XXXI-9 to 18 kgDISO/R2XXXCISO/R3XXXBISO/F2XIUFXB1ISO/F2XXIUF, IL* 1XAISO/F3XIUFX XXXII-15 to 25 kg XXXIII-22 to 36 kg XXXKey of letters to be inserted in the table above:
l
IUF- Suitable for ISOFIX forward child restraints systems of universal category approved for use in the mass group.
l IL- Suitable for particular ISOFIX child restraint systems given in the following list (MITSUBISHI MOTORS genuine parts).
l X- ISOFIX position not suitable for ISOFIX child restraint systems in this mass group and/or this size class.
Seat and seat belts
2-16
2

IL (Genuine part information) Genuine part No.ECE No.*1MZ313045E1-04301133*2MZ314393 (Child restraint system),
MZ314394 (ISOFIX base)E1-04301146
NOTE
l MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Seat and seat belts
2-17
2

Suitability for various seating positionsE00406800874Single cab (Separate seat)
Mass group
Seating positionFront passengerActivated airbagDeactivated airbag*10- Up to 10 kgXU0+- Up to 13 kgXU, L*2I-9 to 18 kgUF, L* 3
, L* 4U, L* 3
, L* 4II-15 to 25 kgUF, L* 5U, L*5III-22 to 36 kgUF, L* 5U, L*5
*1
: With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch.
Key of letters to be inserted in the table above:
l U- Suitable for “universal” category restraints approved for use in this mass group.
l UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group.
l L- Suitable for particular child restraints in the following list (MITSUBISHI MOTORS genuine parts).
l X- Seat position not suitable for children in this mass group.
L (Genuine part information) Genuine parts No.ECE No.*2MZ312807E1-04301146*3MZ314451E1-04301203*4MZ313045E1-04301133*5MZ314250E1-04301169
Seat and seat belts
2-18
2

CAUTIONlWhen installing a child restraint system, prevent the head restraint from touching the child restraint system by removing it or adjusting its height.
NOTE
l There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0-Up to 10 kg”.

MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Single cab (Bench seat)
Mass group
Seating positionFront passengerFront centreActivated airbagDeactivated airbag* 10- Up to 10 kgXUX0+- Up to 13 kgXU, L*2XI-9 to 18 kgUF, L* 3
, L* 4U, L* 3
, L* 4XII-15 to 25 kgUF, L* 5U, L*5XIII-22 to 36 kgUF, L* 5U, L*5X
*1
: With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch.
Key of letters to be inserted in the table above:
l U- Suitable for “universal” category restraints approved for use in this mass group.
l UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group.
l L- Suitable for particular child restraints in the following list (MITSUBISHI MOTORS genuine parts).
l X- Seat position not suitable for children in this mass group.
Seat and seat belts
2-19
2

L (Genuine part information) Genuine parts No.ECE No.*2MZ312807E1-04301146*3MZ314451E1-04301203*4MZ313045E1-04301133*5MZ314250E1-04301169CAUTIONl
When installing a child restraint system, prevent the head restraint from touching the child restraint system by removing it or adjusting its height.
NOTE
l There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0-Up to 10 kg”.

MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Club cab
Mass group
Seating positionFront passengerRear outboardActivated airbagDeactivated airbag* 10- Up to 10 kgXUX0+- Up to 13 kgXU, L*2L*2I-9 to 18 kgUF, L* 3
, L* 4U, L* 3
, L* 4L*3
, L* 4II-15 to 25 kgUF, L* 5U, L*5XIII-22 to 36 kgUF, L* 5U, L*5X
*
1
: With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch.
Seat and seat belts
2-20
2

Key of letters to be inserted in the table above:l U- Suitable for “universal” category restraints approved for use in this mass group.
l UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group.
l L- Suitable for particular child restraints in the following list (MITSUBISHI MOTORS genuine parts).
l X- Seat position not suitable for children in this mass group.L (Genuine part information) Genuine parts No.ECE No.*2MZ312807E1-04301146*3MZ314451E1-04301203*4MZ313045E1-04301133*5MZ314250E1-04301169CAUTIONl
When installing a child restraint system, prevent the head restraint from touching the child restraint system by removing it or adjusting its height.
NOTE
l There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0-Up to 10 kg”.

MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Seat and seat belts
2-21
2

Double cab
Mass group
Seating positionFront passengerRear outboardRear centreActivated airbagDeactivated airbag*10- Up to 10 kgXUUX0+- Up to 13 kgXU, L*2U, L*2XI-9 to 18 kgUF, L* 3
, L* 4U, L* 3
, L* 4U, L* 3
, L* 4L*4II-15 to 25 kgUF, L* 5U, L*5U, L*5L*5III-22 to 36 kgUF, L* 5U, L*5U, L*5L*5
*1
: With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch.
Key of letters to be inserted in the table above:
l U- Suitable for “universal” category restraints approved for use in this mass group.
l UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group.
l L- Suitable for particular child restraints in the following list (MITSUBISHI MOTORS genuine parts).
l X- Seat position not suitable for children in this mass group.
L (Genuine part information) Genuine parts No.ECE No.*2MZ312807E1-04301146*3MZ314451E1-04301203*4MZ313045E1-04301133*5MZ314250E1-04301169CAUTIONl
When installing a child restraint system, prevent the head restraint from touching the child restraint system by removing it or adjusting its height.
Seat and seat belts
2-22
2

NOTEl There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0-Up to 10 kg”.

MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Seat and seat belts
2-23
2

Child restraint anchorage points (Dou-
ble cab)* E00406900354
Anchorage locations
There are 2 child restraint anchorage points on the
floor, located behind the rear seat. These are for se-
curing a child restraint system tether strap to each
of the 2 rear seating positions in your vehicle.
*: Rear of the vehicle
CAUTIONl The anchorages are only applicable for
child restraints fitted in the rear seat.Tether anchorage strap installationWARNINGl Child restraint anchorages are designed
to withstand only those loads imposed by
correctly fitted child restraints. Under no
circumstances are they to be used for
adult seat belts, harnesses, or for attach-
ing other items or equipment to the vehicle.
1. Remove the head restraint from the location
in which you wish to install a child restraint.
2. Drop the child restraint’s tether strap (A)
down the back of the rear seatback.
3. Tip the armrest forward. Open the fastener
(B) that is located in the space where the arm-
rest was stowed.
4. Put your hand in the opening of the fastener,
attach the tether strap’s hook (C) to the tether
anchorage (D), and securely tighten the teth-
er strap.
