hook MITSUBISHI LANCER 2006 Workshop Manual

AC212035AC
Spring balance
Approximately
40 mm Pull
ON-V
EHICLE SER VICE
PA R K ING B RAKES36-4
2.Hook a spring bala n ce onto th e ce ntre of the
p a rking brake lever grip and p u ll it with a force of
10 0
− 150 N in a directio n perpe ndicula r to the
ha
ndle .
3. Drive the veh i cle at a const ant speed o f 35 − 50
km/h
for 100
metre
s
.
4. Release the p a rking brake an d let th e bra k es cool
fo r 5
− 10 minutes.
5.Repe at the proce dure in ste p s 2 to 4, four or five
times.
PARKING BRAKE SW ITCH CHECK
M13610033 0038 1
1.Remove the rea r con s ole assembly (Re f er to
GROUP 52A, Rea r Floo r Co nsole
P.52A-10).
2.Remove the fro n t se at assembly (RH). (Re f er to
GROUP 52A, Fr ont Seat
P.5 2 A - 26).
AC304746AB
3.Check f o r co ntinu i ty between t he p a rking bra k e
switch terminal and th e swit ch mounting bo lt.
When parking brake lever is pulledLess than 2 Ω
When parking brake lever is
releasedOpen circuit

FENDER
BODY42-7
REMOVAL SERVICE POINT
<> SIDE TURN-SIGNAL LAMP
REMOVAL
AC005980AC005980
Front of vehicleSide turn-signal lamp
MB990784
AB
Use sp ecial to ol orn a men t remover (MB9907 84) to
prize out th
e t ab from the fender , and re move the
side
turn
− signal lamp .
INSTALLA T ION SER VICE POINT
>>A<< SIDE TURN-SIGNAL LAMP
INST
ALLA TION
AC005719
Fender panel Hook
Claw
Fender panel
: Front of vehicle
AE
En gage t he claw with t he fend er p anel, and inst all
the side tu
rn-signal lamp.

FUEL FILLER LID
BODY42-8
FUEL FILLER LID
REMOVAL AND INSTALLATIONM1421002500277
Pre-removal and Post-installation Operation
•Rear Seat Removal and Installation (Refer to GROUP
52A, Rear Seat
P.52A-30.)
•Front Scuff Plate (Driver's Seat Side), Rear Scuff Plate
(Driver's Side), Centre Pillar Lower Trim (Driver's Side),
Quarter Trim (Driver's Side) Removal and Installation
(Refer to GROUP 52A, Trims
P.52A-13.)
18M0109 W0570AQ
AC005996
AC005973
3
5 4
3
2
1
5.0 ± 1.0 N·m
AC
Fuel filler lid height and clearance
adjustment
Removal steps
1.Fuel filler lid panel assembly
2.Clip
3.Fuel filler lid hook assembly
4.Fuel filler lid lock release cable
5.Fuel filler lid lock release handle
Removal steps (Continued)

AC301208
7
AC

Rear seatback
hook (RH)
AC212111
7
AC

Rear
speaker
(RH)
AC212112AC
8Rear wiper motor
AC301744AB
9
Heat protector
AC301743AB
10
Rocker cover
AC300437
1112
,
1112
AD
Relay box
AC301745
13
AB
Air cleaner
assembly
AC301750AB
14
SRS-ECU
EARTH
COMPONENT LOCA TIONS70-18

AC300436AC
15
SRS-ECU
AC208871AC
Junction block16
AC301210
17
AC

Rear seatback
hook (LH)
AC300440
17
AC
Rear
speaker
(LH)

INSPECTION CONN ECT O R AND SP ARE CONNEC T OR
COMPONENT LOCATIONS70-19
IN SPECTION CONNECT OR AND SP ARE CONNECT OR
M17010002 0034 3
NameSymbolNameSymbol
Diagnosis connectorESpare connector (for front fog lamp
relay)A
Engine speed detection connectorASpare connector (for front fog lamp
switch)C
Spare connector (for front fog lamp)BSpare connector (for audio)D
AC301758ACB
ADC
E
