MPI – Troubleshooting13-23
Terminal
No.Normal condition Check condition (Engine condition) Check item
21Fan motor relay (LOW)Fan not operating (coolant temperature: 90C or
below)Battery voltage
Fan at low speed (coolant temperature: 90 – 100C)0 – 3 V
22A/C relayEngine: Idling
A/C switch: OFF to ON (Compressor is being
driven.)Battery voltage, or 6 V
or more instanta-
neously to 0 – 3 V
33Alternator G terminalEngine: Warm, idle (radiator fan: OFF)
Headlamp: OFF to ON
Brake lamp: OFF to ON
Rear defogger switch: OFF to ONVoltage rises by 0.2 –
3.5 V.
36Engine warning lampIgnition switch: OFF → ON0 – 3 V → Battery
voltage (After several
seconds have
elapsed)
37Power steering fluid
pressure switchEngine: Idling after
warming upWhen steering wheel is
stationaryBattery voltage
When steering wheel is
turned0 – 3 V
38Control relayIgnition switch: OFFBattery voltage
Ignition switch: ON0 – 3 V
39Fuel pump relay No.2While engine is idling, suddenly depress the
accelerator pedal.Momentarily rises
slightly from 0 to 3 V.
40Exhaust temperature
warning lampIgnition switch: OFF to ON0 – 3 V to battery
voltage (After several
seconds have
elapsed)
41Alternator FR terminalEngine: Warm, idle (radiator fan: OFF)
Headlamp: OFF to ON
Brake lamp: OFF to ON
Rear defogger switch: OFF to ONVoltage drops by 0.2 –
3.5 V.
45A/C switchEngine: Idle speedTurn the A/C switch OFF0 – 3 V
Turn the A/C switch ON
(A/C compressor is oper-
ating)Battery voltage
60Oxygen sensor heater
(Evolution V only)
Engine: Idling0 – 3 V
(Evolution-V only)
Engine speed: 5,000 r/minBattery voltage
71Ignition switch-STEngine: Cranking8 V or more

CLUTCH –
Service Specifications /
Lubricants / On-vehicle Service21-2
SERVICE SPECIFICATIONS
ItemsStandard value
Clutch pedal height mm162.5 – 165.5
Clutch pedal clevis pin play mm1 – 3
Clutch pedal free play mm6 – 13
Distance between the clutch pedal and the toeboard when the clutch is disengaged mm70 or more
LUBRICANTS
ItemsSpecified lubricantsQuantity
Clutch fluidMITSUBISHI genuine brake fluid “DIA-QUEEN
BRAKE FLUID SUPER 4”As required
Push rod assemblyRubber grease
Boot
Release cylinder push rodMOLYKOT BR-2 PUS
ON-VEHICLE SERVICE
1. CLUTCH PEDAL INSPECTION AND
ADJUSTMENT
(1) Turn up the carpet, etc. under the clutch pedal.
(2) Measure the clutch pedal height.
Standard value (A): 162.5 – 165.5 mm
(3) If the height of the clutch pedal is outside the standard
value, loosen the lock nut and adjust the pedal height
to the standard value using the adjusting bolt.
Clutch pedal height
A
Setting nutAdjusting bolt
Locking
nut
13 {1.3}
6 {0.6}

CLUTCH – On-vehicle Service21-3
(4) Measure the clutch pedal play.
Standard value (B): 1 – 3 mm
(5) If the clutch pedal play is not within the standard value,
loosen the setting nut and move the push rod to adjust.
Caution
Do not push in the master cylinder push rod at this
time.
(6) After completing the adjustments, confirm that the clutch
pedal free play (measured at the face of the pedal pad)
and the distance between the clutch pedal (the face of
the pedal pad) and the toeboard when the clutch is
disengaged are within the standard value ranges.
Standard value (C): 6 – 13 mm
Standard value (D): 70 mm or more
(7) If the clutch pedal free play and the distance between
the clutch pedal and the toeboard when the clutch is
disengaged do not agree with the standard values, it
is probably the result of either air in the hydraulic system
or a faulty master cylinder or clutch. Bleed the air, or
disassemble and inspect the master cylinder, release
cylinder or clutch.
(8) Turn back the carpet, etc.
2. BLEEDING
Specified fluid:
MITSUBISHI genuine brake fluid “DIA-QUEEN BRAKE
FLUID SUPER 4”
Caution
Use the specified brake fluid. Avoid using a mixture of
the specified fluid and other fluid.
Clutch pedal clevis pin play
B
Clutch pedal free
playDistance between the
clutch pedal and the
toeboard when the
clutch is disengaged
CD

CLUTCH – Clutch Control21-6
CLUTCH MASTER CYLINDER
DISASSEMBLY AND REASSEMBLY
6 7
4
1
3
Piston repair kitClutch fluid:
DIA-QUEEN BRAKE
FLUID SUPER 4
Grease: Rubber grease
5
2
21422 8
3
Unit: Nm {kgf
m}
13 {1.3}
Disassembly steps
1. Piston stopper ring
2. Piston assembly
3. Push rod assembly
4. Boot
5. Reservoir cap
6. Spring pin
7. Reservoir tank
8. Clutch master cylinder bodyCaution
Do not disassemble piston assembly.

REAR SUSPENSION – Rear Suspension Assembly34-4
REAR SUSPENSION ASSEMBLY
REMOVAL AND INSTALLATION
Pre-removal Operation
(1) Center Exhaust Pipe Removal
(Refer to GROUP 15.)
(2) Trunk Room Side Trim Removal
(3) AYC Fluid Draining
(Refer to GROUP 27 – On-vehicle Service.)Post-installation Operation
(1) AYC Fluid Refilling and Bleeding
(Refer to GROUP 27 – On-vehicle Service.)
(2) Center Exhaust Pipe Installation
(Refer to GROUP 15.)
(3) AYC Operation Check
(4) Parking Brake Cable Stroke Check
(Refer to GROUP 36 – On-vehicle Service.)
(5) Wheel Alignment Check and Adjustment
(Refer to P.34-3.)
1
34
5
6
7 9 10
1112
1314
15 1617
Unit: Nm {kgf
m}
44 {4.5}
108 – 127 {11.0 – 13.0}
54 {5.5}
88 {9.0}
93 {9.5}*88 {9.0}
158 2
15
29 – 34
{3.0 – 3.5}
25 {2.6}34 {3.5}25 {2.5}
69
{7.0} Toe control bar
EVOLUTION-V RS
137 – 156 {14.0 – 16.0}*59 – 68 {6.0 – 7.0}*
Removal steps
1. Fuel filler cap
2. Bolt
3. Filler neck protector
4. Cap
5. Shock absorber mounting nut
A6. Brake caliper assembly
7. Rear speed sensor AYC>
8. Brake disc
9. Parking brake cable end (Refer to
GROUP 36.)
10. AYC fluid line connection with AYC>BB11. Propeller shaft connection
12. Upper arm mounting bolt
13. Trailing arm mounting bolt
14. Toe control arm mounting bolt
CA15. Crossmember mounting bolt
16. Differential support assembly
mounting bolt
17. Rear suspension assembly
Caution
The parts marked with * should be first temporarily
tightened, then torqued to specification with the
vehicle on the ground in unloaded condition.

BASIC BRAKE SYSTEM – Master Cylinder and Brake Booster35A-5
MASTER CYLINDER AND BRAKE BOOSTER

REMOVAL AND INSTALLATION
Pre-removal Operation

Brake Fluid Draining

Air Intake Hose RemovalPost-installation Operation

Brake Fluid Supplying

Brake Line Bleeding

Brake Pedal Adjustment (Refer to P.35A-2.)

Air Intake Hose Installation
15–18 Nm 15 Nm
Sealant: 3M ATD Part No.
8661 or equivalent
6
7 3
14
2
8
5
4
14 Nm
5 9
1
10 Nm
Removal steps
1. Brake pipe connection
2. Brake fluid level sensor connector
3. Master cylinder assembly
B
Clearance adjustment between brake
booster push rod and primary piston
A4. Vacuum hose
(With built-in check valve)5. Fitting
6. Snap pin
7. Clevis pin assembly
8. Brake booster
9. Sealer

BASIC BRAKE SYSTEM – Master Cylinder and Brake Booster35A-7
MASTER CYLINDER
DISASSEMBLY AND REASSEMBLY
Master cylinder kit
11
14
1312
141315 1
4 2
3
6
8
9 5
7
10
12
15
13
14Brake fluid: DOT3 or DOT4
11
Disassembly steps
1. Reservoir cap assembly
2. Reservoir cap
3. Diaphragm
4. Filter
5. Brake fluid level sensor
6. Float
7. Reservoir stopper bolt8. Reservoir tank
9. Reservoir seal
A10. Piston stopper bolt
11. Gasket
B12. Piston stopper ring
13. Primary piston assembly
14. Secondary piston assembly
15. Master cylinder body
