WORKSHOP MANUAL
FOREWORD
This Workshop Manual contains procedures for
service mechanics, including removal, disassembly,
inspection, adjustment, reassembly and
installation. Figures taken from registration
documents are given in metric units only. All other
figures are given in SI units with metric units in
brackets. Use the following manuals in combination
with this manual as required.
TECHNICAL INFORMATION MANUAL
N9806CNCP9
All information, illustrations and product
descriptions contained in this manual are current
as at the time of publication. We, however, reserve
the right to make changes at any time without prior
notice or obligation.
July 1998
EVOLUTION-IV
EVOLUTION-V

REAR AXLE – Troubleshooting 27-14
Code No. 52: Longitudinal acceleration sensor systemProbable cause
This code is output when the longitudinal acceleration exceeds a predetermined value
while the vehicle is running with both ABS and brakes being inactive.
Defective longitudinal acceleration sensor

Defective harness or connector

Defective AYC-ECU
NG
Check and repair the harness between
longitudinal acceleration sensor and
AYC-ECU.
OK
Check the trouble symptom.
NG
Replace AYC-ECU.
OK
Check the trouble symptom.
OK
Check the following connector:
B-95NG
Repair
OK
Measure at B-95 AYC-ECU connector.

Connector connected

Ignition switch: ON

Voltage across 3 and body ground
OK:2.4 V to 2.6 V (where vehicle
in horizontal position)NGCheck the following connectors:
B-95, B-52, D-20
Check the acceleration sensor.
(Refer to P.27-52.)NG
Replace
NG
Repair
Code No. 61: Stop lamp switch systemProbable cause
This code is output under either of the following conditions:

Stop lamp switch remains ON for 15 min. or more.

There is an open-circuit in the harness between AYC-ECU and stop lamp switch.
Defective stop lamp switch

Defective harness or connector

Defective AYC-ECU
NG
Replace AYC-ECU.
OK
Check the trouble symptom.
OK
Check the following connector:
B-95NG
Repair
OK
Measure at the B-95 AYC-ECU con-
nector.

Disconnect the connector and
measure at the harness side.

Voltage across 11 and body ground

Brake pedal not depressed.
OK:1 V or lessNGCheck and repair the harness between
AYC-ECU and stop lamp switch.
Check the stop lamp switch.NG
Replace

BASIC BRAKE SYSTEM 35A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ANTI-LOCK BRAKING SYSTEM (ABS) 35B. . . . . . . . . . . . . . . . . . . . . .
35-1
SERVICE BRAKES
CONTENTS

BASIC BRAKE SYSTEM – General / On-vehicle Service35A-2
GENERAL
OUTLINE OF CHANGE

The service procedures for left-hand drive vehicles have been established as described below.

The service procedures for the front and rear disc brakes have been changed since they had been
replaced by a different type.
ON-VEHICLE SERVICE
BRAKE PEDAL CHECK AND ADJUSTMENT

1. Turn up the carpet, etc under the brake pedal.
2. Measure the brake pedal height as illustrated. If the brake
pedal height is not within the standard value, follow the
procedure below.
Standard value: 163.5 –166.5 mm
(1) Disconnect the stop lamp switch connector.
(2) Adjust the brake pedal height by turning the operating
rod with pliers (with the operating rod lock nut
loosened), until the correct brake pedal height is
obtained.
(3) Secure by tightening the lock nut of the operating
rod.
(4) Push the stop lamp switch in the direction of the
pedal stroke until it stops. (The switch will slide if
it is pushed firmly.)
(5) Lift up the pedal until the operating rod is fully
extended, and then slide the stop lamp switch back
to the required position. Adjust the position of the
switch by turning it until the distance shown in the
illustration is correct.
(6) Connect the connector of the stop lamp switch.
(7) Check that the stop lamp is not illuminated with the
brake pedal unpressed.
3. With the engine stopped, depress the brake pedal two
or three times. After eliminating the vacuum in the power
brake booster, press the pedal down by hand, and confirm
that the amount of movement before resistance is met
(the free play) is within the standard value range.
Standard value: 3 – 8 mmOperating
rod
Operating
rod lock nutStop lamp
switch
Pedal down
Pedal up
Lock nut
Lock nut
Outer case
0.5 – 1.0 mm

36-1
PARKING
BRAKES
CONTENTS
SERVICE SPECIFICATIONS 2. . . . . . . . . . . . . .
LUBRICANTS 2. . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 2. . . . . . . . . . . . . . . . . . . . . . . . ON-VEHICLE SERVICE 3. . . . . . . . . . . . . . . . . .
1. Parking Brake Lever Stroke Check and
Adjustment 3. . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Lining Running-in 4. . . . . . . . . . . . . . . . . . . . . .
PARKING BRAKE CABLE 5. . . . . . . . . . . . . . .
PARKING BRAKE DRUM 7. . . . . . . . . . . . . . . .

PARKING BRAKE – On-vehicle Service36-3
ON-VEHICLE SERVICE
1. PARKING BRAKE LEVER STROKE CHECK
AND ADJUSTMENT
1-1 STROKE CHECK
Standard value: 5 – 7 notches
[Operating force of approx. 196 N {20 kgf}]
1-2 STROKE ADJUSTMENT
If the parking brake lever stroke is not the standard value,
adjust as described below.
(1) Loosen the adjusting nut at the floor console to release
the cable.
(2) Remove the adjustment hole plug, and then use a flat-tip
(–) screwdriver to turn the adjuster in the direction of
the arrow (the direction which expands the shoe) until
the disc cannot be rotated by both hands.
Return the adjuster five notches in the direction opposite
to the direction of the arrow. (Reference: shoe clearance
on one side 0.19 mm)
(3) Turn the adjusting nut to adjust the parking brake lever
stroke to the standard value. After adjusting, check that
there is no space between the adjusting nut and the
parking brake lever.
Check also that the adjusting nut is firmly held by the
nut holder.
Caution
If the parking brake lever stroke is below the standard
value and the braking is too firm, the rear brakes
may drag.
(4) After adjusting the parking brake lever stroke, jack up
the rear of the vehicle. Release the parking brake and
turn the rear wheels to check that the rear brakes are
not dragging.
Nut
holder
Adjusting nut
Rear floor console
Adjuster

PARKING BRAKE – On-vehicle Service36-4
2. LINING RUNNING-IN
Carry out running-in by the following procedure when replacing
the parking brake linings or the rear brake disc rotors, or
when brake performance is insufficient.
Caution
Carry out running-in in a place with good visibility, and
pay careful attention to safety.
(1) Adjust the parking brake stroke to the specified value.
Standard value: 5 – 7 notches
[Operating force of approx. 196 N {20 kgf}]
(2) Hook a spring balance onto the center of the parking
brake lever grip and pull it with a force of 98 – 147 N
{10 – 15 kgf} in a direction perpendicular to the handle.
(3) Drive the vehicle at a constant speed of 35 – 50 km/h
for 100 metres.
(4) Release the parking brake and let the brakes cool for
5 – 10 minutes.
(5) Repeat the procedure in steps (2) to (4) 4 – 5 times.
Pull
Spring
balance
Approx.
40 mm

EXTERIOR – Mark 51-15
MARK
REMOVAL AND INSTALLATION
3
2 1
A1. EVOLUTION-V mark (side)
A2. brembo mark
A3. EVOLUTION-V mark (rear)NOTE
The mark “brembo” represents an Italian disc brake
maker, whose disc brakes are used both in front and rear
on EVOLUTION-V.
INSTALLATION SERVICE POINT
AMARK INSTALLATION
Installation positions
The dimension up to the cutout in decal (A in fig.) is the same as the dimension from the mounting
reference line (A’ in fig.). Use this dimension as a guideline to determine the mounting position. (A =
A’)
1. EVOLUTION-V MARK (SIDE)
Body press lineApplication tape edge
Rear door garnish edge line
Rear door opening line 176 mm
