54-2
ON-VEHICLE SERVICE 27. . . . . . . . . . . . . . . .
COMBINATION METERS 30. . . . . . . . . . . . . . .
HEADLAMP 32. . . . . . . . . . . . . . . . . . . . . . . .
SERVICE SPECIFICATIONS 32. . . . . . . . . . . .
SPECIAL TOOLS 32. . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING 33. . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 34. . . . . . . . . . . . . . . .
HEADLAMP AND FRONT TURN-SIGNAL
LAMP* 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FRONT FOG LAMP 39. . . . . . . . . . . . . . . .
SERVICE SPECIFICATIONS 39. . . . . . . . . . . .
ON-VEHICLE SERVICE 39. . . . . . . . . . . . . . . .
FOG LAMP 41. . . . . . . . . . . . . . . . . . . . . . . . . . .
REAR COMBINATION LAMP* 42. . . . . . .
TROUBLESHOOTING 42. . . . . . . . . . . . . . . . . .
REAR COMBINATION LAMP* 42. . . . . . . . . .
SIDE TURN-SIGNAL LAMP 43. . . . . . . . .
SPECIAL TOOL 43. . . . . . . . . . . . . . . . . . . . . . . SIDE TURN-SIGNAL LAMP 43. . . . . . . . . . . .
HAZARD WARNING LAMP
SWITCH, CLOCK 44. . . . . . . . . . . . . . . . . . .
SPECIAL TOOL 44. . . . . . . . . . . . . . . . . . . . . . .
HAZARD WARNING LAMP SWITCH 44. . . .
RADIO AND TAPE PLAYER 45. . . . . . . .
TROUBLESHOOTING 45. . . . . . . . . . . . . . . . . .
RADIO AND TAPE PLAYER 47. . . . . . . . . . . .
SPEAKER 47. . . . . . . . . . . . . . . . . . . . . . . . .
ANTENNA 48. . . . . . . . . . . . . . . . . . . . . . . . .
POLE ANTENNA 48. . . . . . . . . . . . . . . . . . . . . .
REAR WINDOW ANTENNA AND GLASS
DIVERSITY ANTENNA 49. . . . . . . . . . . . . . . . .
REAR WINDOW DEFOGGER 50. . . . . . .
TROUBLESHOOTING AUTOMATIC A/C> 50. . . . . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 50. . . . . . . . . . . . . . . .
REAR WINDOW DEFOGGER SWITCH
51. . .

CHASSIS ELECTRICAL – Antenna54-49
REMOVAL SERVICE POINT
AANTENNA ASSEMBLY REMOVAL
To facilitate the installation work of the antenna assembly,
perform the following before removing the feeder cable:
1. Tie a cord to the end of the feeder cable.
2. Pull out the antenna assembly until the end of the drain
pipe can be seen.
3. Pass the cord through the hole in the end of the drain
pipe and wrap it with vinyl tape.
Caution
Wrap it securely so that the cord will not come off.
4. Pull out the antenna assembly little by little to remove
it.
REAR WINDOW ANTENNA AND GLASS DIVERSITY ANTENNA
REMOVAL AND INSTALLATION
12
Removal steps

Glove box

Front pillar trim (LH), center pillar trim
(LH), rear pillar trim (LH)
Assist grip
1. Radio and tape player
A2. Antenna assembly
Feeder cable
Cord
Cord
Tape
Hole

CHASSIS ELECTRICAL – Antenna / Rear Window Defogger54-50
REMOVAL SERVICE POINT
AANTENNA AMPLIFIER ASSEMBLY REMOVAL
Take off the left-hand edge of the hand lining and undo the
clips of the antenna amplifier assembly.
REAR WINDOW DEFOGGER
TROUBLESHOOTING WITH AUTOMATIC A/C>
Refer to GROUP 55.
ON-VEHICLE SERVICE
PRINTED-HEATER CHECK
1. Run engine at 2,000 r/min. Check heater element with
battery at full.
2. Turn ON rear window defogger switch. Measure heater
element voltage with circuit tester at rear window glass
centre A.
Condition is good if it indicates about 6V.
3. If 12 V is indicated at A, there is a break in the negative
terminals from A.
Move test bar slowly to negative terminal to detect where
voltage changes suddenly (0V).
4. If 0 V is indicated at A, there is a break in the positive
terminals from A. Defect where the voltage changes
suddenly (12 V) in the same method described above.
DEFOGGER RELAY CONTINUITY CHECK
Battery voltageTerminal No.Battery voltage1325
Power is not supplied
Power is supplied
Normal characteristic curve
Voltage
A (Centre point)
approx. 6 V
Positive
terminal
Printed heater lineNegative
terminal
Abnormal characteristic curve
Voltage
Open-circuit
point
Positive
terminal
Printed heater lineNegative
terminal
Junction block
Defogger relay

CHASSIS ELECTRICAL – Rear Window Defogger
ILL
IND
ILL
54-51
REAR WINDOW DEFOGGER SWITCH

REMOVAL AND INSTALLATION
Refer to GROUP – Heater Control Assembly.
INSPECTION
DEFOGGER SWITCH CONTINUITY CHECK
Switch
iti
Terminal No.
position12–34–6
OFF
ON
OFF ←→ON
