MITSUBISHI LANCER EVOLUTION VI 1999 Workshop Manual

MPI – Troubleshooting13-9
Code No. 13 Intake air temperature sensor systemProbable cause
Range of Check

Ignition switch: ON

Excluding 60 seconds after the ignition switch is turned to ON or immediately
after the engine starts.
Set conditions

Sensor output voltage is 4.6 V or more (corresponding to an intake air temperature
of –45C or less) for 4 seconds.
or

Sensor output voltage is 0.2V or less (corresponding to an intake air temperature
of 125C or more) for 4 seconds.
Malfunction of the intake air temperature sensor

Improper connector contact, open or short-circuited
harness wire of the intake air temperature sensor circuit

Malfunction of the engine-ECU
Check the intake air temperature
sensor. (Refer to P.13-32.)*NG
OK
Measure at the air flow sensor con-
nector A-25.

Disconnect the connector, and
measure at the harness side.

Voltage between 6 and earth
(Ignition switch: ON)
OK:4.5–4.9 V

Continuity between 5 and earth
OK:ContinuityNGCheck the following connector:
B-62NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between
the engine-ECU and the intake air
temperature sensor connector.NG
Repair
OK
Replace the engine-ECU. OK
Check the following connector:
A-25NG
Repair
OK
Check trouble symptom.NGReplace the engine-ECU.
Replace the air flow sensor.
NOTE
*: Refer to Workshop Manual for LANCER EVOLUTION-IV and EVOLUTION-V (Pub. No. S9806CNCP9).
Code No. 14 Throttle position sensor system
Probable cause
Range of Check

Ignition switch: ON

Excluding 60 seconds after the ignition switch is turned to ON or immediately
after the engine starts.
Set conditions

The sensor output voltage is 0.2 V or less for 4 seconds.
Malfunction of the throttle position sensor

Improper connector contact, open or short-circuited
harness wire of the throttle position sensor circuit

Improper “ON” state of idle position switch

Short circuit of the idle position switch signal line

Malfunction of the engine-ECU
MUT-II Data list
26 Idle position switch system
OK:With the throttle valve at the
idle position: ON
With the throttle valve slight-
ly open: OFFNGCheck the idle position switch system.
(Refer to P.13-38, INSPECTION PRO-
CEDURE 26.)
OK
Check the throttle position sensor.NG
Replace
OK
Measure at the throttle position sensor
connector A-16.

Disconnect the connector, and
measure at the harness side.

Voltage between 1 and earth
(Ignition switch: ON)
OK:4.8–5.2 V

Continuity between 4 and earth
OK:ContinuityNGCheck the following connector:
B-62NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between the
engine-ECU and the throttle position
sensor connector.NG
Repair
OK
Replace the engine-ECU. OK
Check the throttle position sensor out-
put circuit. (Refer to P.13-55, INSPEC-
TION PROCEDURE 49.)

MPI – Troubleshooting13-10
Code No. 21 Engine coolant temperature sensor systemProbable cause
Range of Check

Ignition switch: ON

Excluding 60 seconds after the ignition switch is turned to ON or immediately
after the engine starts.
Set conditions

Sensor output voltage is 4.6 V or more (corresponding to an engine coolant
temperature of –45C or less) for 4 seconds.
or

Sensor output voltage is 0.1 V or less (corresponding to an engine coolant
temperature of 140C or more) for 4 seconds.
Malfunction of the engine coolant temperature sensor

Improper connector contact, open or short-circuited
harness wire of the engine coolant temperature sensor
circuit

Malfunction of the engine-ECU
Range of Check

Ignition switch: ON

Engine speed is approx. 50 r/min or more
Set conditions

The sensor output voltage increases from 1.6 V or less (corresponding to an
engine coolant temperature of 40C or more) to 1.6 V or more (corresponding
to an engine coolant temperature of 40C or less).

After this, the sensor output voltage is 1.6 V or more for 5 minutes.
Check the engine coolant temperature
sensor. (Refer to P.13-32.)*NG
Replace
OK
Measure at the engine coolant temper-
ature sensor connector A-38.

Disconnect the connector, and
measure at the harness side.

Voltage between 1 and earth
(Ignition switch: ON)
OK:4.5–4.9 V

Continuity between 2 and earth
OK:ContinuityNGCheck the following connector:
B-62NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between the
engine-ECU and the engine coolant
temperature sensor connector.NG
Repair
OK
Replace the engine-ECU.
Check the following connector:
A-38OKCheck trouble symptom.
NG
Replace the engine-ECU.
NG
RepairOK
NOTE
*: Refer to Workshop Manual for LANCER EVOLUTION-IV and EVOLUTION-V (Pub. No. S9806CNCP9).

MPI – Troubleshooting13-11
Code No. 22 Crank angle sensor systemProbable cause
Range of Check

Engine is cranking.
Set conditions

Sensor output voltage does not change for 4 seconds (no pulse signal input.)
Malfunction of the crank angle sensor

Improper connector contact, open or short-circuited
harness wire of the crank angle sensor

Malfunction of the engine-ECU
Measure at the crank angle sensor connector A-51.

Connect the connector. (Use the test harness: MD998478.)

Voltage between 2 (black clip) and earth (Engine: cranking)
OK:0.4–4.0 V

Voltage between 2 (black clip) and earth (Engine: idling)
OK:1.5–2.5 V
NGOKReplace the engine-ECU.
Measure at the crank angle sensor connector A-51.

Disconnect the connector, and measure at the harness side.
1. Voltage between 3 and earth (Ignition switch: ON)
OK:System voltage
2. Voltage between 2 and earth (Ignition switch: ON)
OK:4.8–5.2 V
3. Continuity between 1 and earth
OK:Continuity
OK
Check the following con-
nector: A-51NG
Repair
OK
Check trouble symptom.
NG
Replace the crank angle sensor.1. NG
Check the harness wire between the crank angle sensor and the
control relay connector, and repair if necessary.
2. NGCheck the following con-
nector: B-62NG
Repair
OK3. NG
Check trouble symptom.
NG
Check the harness wire
between the engine-ECU
and the crank angle sensor
connector.NG
Repair
OK
Replace the engine-ECU.
Check the harness wire between the crank angle sensor and the
earth, and repair if necessary.

MPI – Troubleshooting13-12
Code No. 23 Camshaft position sensor systemProbable cause
Range of Check

Ignition switch: ON

Engine speed is approx. 50 r/min or more.
Set conditions

Sensor output voltage does not change for 4 seconds (no pulse signal input.)
Malfunction of the camshaft position sensor

Improper connector contact, open or short-circuited
harness wire of the camshaft position sensor circuit

Malfunction of the engine-ECU
Measure at the camshaft position sensor connector A-97.

Connect the connector.

Voltage between 2 and earth (Engine: cranking)
OK:0.4–3.0 V

Voltage between 2 and earth (Engine: idling)
OK:0.5–2.0 VOKReplace the engine-ECU.
NG
Measure at the camshaft position sensor connector A-97.

Disconnect the connector, and measure at the harness side.
1. Voltage between 3 and earth (Ignition switch: ON)
OK:System voltage
2. Voltage between 2 and earth (Ignition switch: ON)
OK:4.8–5.2 V
3. Continuity between 1 and earth
OK:Continuity1. NGCheck the harness wire between the camshaft position sensor
and the control relay connector, and repair if necessary.
2. NGCheck the following con-
nector: B-62NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire
between the engine-ECU
and the camshaft position
sensor connector.NG
Repair
OK
Replace the engine-ECU. 3. NG
Check the harness wire between the camshaft position sensor
and the earth, and repair if necessary.
OK
Check the following con-
nector: A-97NG
Repair
OK
Check trouble symptom.
NG
Replace the camshaft position sensor.

MPI – Troubleshooting13-13
Code No. 24 Vehicles speed sensor systemProbable cause
Range of check

Ignition switch: ON

Excluding 60 seconds after the ignition switch is turned to ON or immediately
after the engine starts.

Idle position switch: OFF

Engine speed is 3,000 r/min or more.

Driving under high engine load conditions.
Set conditions

Sensor output voltage does not change for 4 seconds (no pulse signal input).
Malfunction of the vehicle speed sensor

Improper connector contact, open or short-circuited
harness wire of the vehicle speed sensor circuit

Malfunction of the engine-ECU
OK
Check the ignition switch. (Refer to GROUP 54 – Ignition Switch.)
2. NG
OK
Replace the engine-ECU.
3. NG
OK
Replace the engine-ECU.
NG
Check the harness wire
between the engine-ECU
and the vehicle speed
sensor connector.NG
Repair
OK
Check trouble symptom.
OK
Check the following
connectors:
A-19, B-62NG
Repair
NG
Check the harness wire
between the engine-ECU
and the vehicle speed
sensor connector.NG
Repair
OK
Check trouble symptom.
Check the following
connector: B-62NG
Repair
NG
Check the harness wire
between the vehicle
speed sensor and ignition
switch connector.NG
Repair
OK
Check trouble symptom.
OK
Measure at the vehicle speed sensor connector A-19.

Disconnect the connector, and measure at the harness
side.
1. Voltage between 1 and earth (Ignition switch: ON)
OK:System voltage
2. Voltage between 3 and earth (Ignition switch: ON)
OK:4.8 – 5.2 V
3. Continuity between 2 and earth
OK:Continuity1. NGCheck the following
connectors:
B-64, B-74, B-76NG
Repair
Check the vehicle speed sensor. (Refer to GROUP 54 – Combina-
tion Meters.)NG
Replace
Check the harness wire between the vehicle speed sensor and
the earth, and repair if necessary.

MPI – Troubleshooting13-14
Code No. 25 Barometric pressure sensor systemProbable cause
Range of Check

Ignition switch: ON

Excluding 60 seconds after the ignition switch is turned to ON or immediately
after the engine starts.
Set conditions

Sensor output voltage is 4.5 V or more (corresponding to a barometric pressure
of 114 kPa or more) for 4 seconds.
or

Sensor output voltage is 0.2 V or less (corresponding to a barometric pressure
of 5.33 kPa or less) for 4 seconds.
Malfunction of the barometric pressure sensor

Improper connector contact, open or short-circuited
harness wire of the barometric pressure sensor circuit

Malfunction of the engine-ECU
Measure at the air flow sensor con-
nector A-25.

Connect the connector. (Use
the test harness: MB991709)

Voltage between 2 and earth
(Ignition switch: ON)
OK:3.7–4.3 V (Altitude: 0 m)
3.2–3.8V (Altitude:
1,200 m)NGMeasure at the air flow sensor con-
nector A-25.

Disconnect the connector, and
measure at the harness side.

Voltage between 1 and earth
(Ignition switch: ON)
OK:4.8–5.2 V

Continuity between 5 and earth
OK:ContinuityNGCheck the following connector:
B-62NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between
the engine-ECU and the baromet-
ric pressure sensor connector.NG
Repair
OK
Replace the engine-ECU.
OK
Check the following connector:
A-25NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between
the engine-ECU and the baromet-
ric pressure sensor connector.NG
Repair
OK
Replace the air flow sensor.
OK
Measure at the engine-ECU con-
nector B-62.

Connect the connector.

Voltage between 85 and earth
(Ignition switch: ON)
OK:3.7–4.3 V (Altitude: 0 m)
3.2–3.8V (Altitude:
1,200 m)NGCheck the harness wire between
the engine-ECU and the baromet-
ric pressure sensor connector, and
repair if necessary.
Check the following connector:
A-25, B-62
OK
Check trouble symptom.
NG
Replace the engine-ECU.NG
Repair OK

MPI – Troubleshooting13-15
Code No. 31 Detonation sensor systemProbable cause
Range of Check

Ignition switch: ON

Excluding 60 seconds after the ignition switch is turned to ON or immediately
after the engine starts.

Engine speed is approx. 5,000 r/min or more

Set conditions

The change in the detonation sensor output voltage (detonation sensor peak voltage
at each 1/2 revolution of the crankshaft) is less than 0.06 V for 200 times in
succession.
Malfunction of the detonation sensor

Improper connector contact, open or short-circuited
harness wire of the detonation sensor circuit

Malfunction of the engine-ECU
Measure at the detonation sensor con-
nector A-96.

Disconnect the connector and
measure at the harness side.

Continuity between 2 and earth
OK:ContinuityOKCheck the following connector:
B-62NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between the
engine-ECU and the detonation sensor
connector.OKReplace the detonation sensor.
Check trouble symptom.
NG
Replace the engine-ECU.
NG
Repair
NG
Check the harness wire between the
detonation sensor and earth, and repair
if necessary.
Code No. 41 Injector systemProbable cause
Range of Check

Engine speed is approx. 50–1,000 r/min

The throttle position sensor output voltage is 1.15 V or less.

Actuator test by MUT-II is not carried out.
Set conditions

Surge voltage of injector coil is not detected for 4 seconds.
Malfunction of the injector

Improper connector contact, open or short-circuited
harness wire of the injector circuit

Malfunction of the engine-ECU
OK
Check trouble symptom.NGCheck the harness wire between the
resistor and the injector connector, and
repair if necessary.
Check the injector control circuit.
(Refer to P.13-55, INSPECTION PRO-
CEDURE 50.)OK
OK
Measure at the injector connectors
A-53, A-54, A-55, A-56

Disconnect the connector, and
measure at the harness side.

Voltage between 1 and earth
(Ignition switch: ON)
OK:System voltageNGCheck the following connector:
A-125NG
Repair
OK
Measure at the resistor connector
A-125.

Disconnect the connector, and
measure at the harness side.

Voltage between 3 and earth
(Ignition switch: ON)
OK:System voltageNGCheck the harness wire between the
control relay and the resistor connector,
and repair if necessary.
Check the injector. (Refer to P.13-34.)*
Check the resistor. (Refer to P.13-34.)*NG
Replace
NOTE
*: Refer to Workshop Manual for LANCER EVOLUTION-IV and EVOLUTION-V (Pub. No. S9806CNCP9).

MPI – Troubleshooting13-16
Code No. 44 Ignition coil and power transistor unit systemProbable cause
Range of Check

Engine speed is approx. 50–4,000 r/min

Engine is not cranking.
Set conditions

Abnormal rotation due to misfire is detected by crank angle sensor (Either one
of coils fails).
Malfunction of the ignition coil

Improper connector contact, open or short-circuited
harness wire of the ignition primary circuit

Malfunction of the engine-ECU
OK
OK
Check trouble symptom.
Measure at the ignition coil connectors
A-110, A-111

Disconnect the connector, and
measure at the harness.
1. Voltage between 1 and earth
(Ignition switch: ON)
OK: System voltage
2. Voltage between 3 and earth
(Engine: Cranking)
OK: 0.5–4.0 V
3. Continuity between the 2 and earth
OK: Continuity1. NGCheck the following connectors:
B-65, B-76OKCheck trouble symptom.
NG
Check the harness wire between the
ignition coil and ignition switch connec-
tor, and repair if necessary.
2. NGCheck the following connector: B-59NG
Repair
NG
Check the harness wire between the
engine-ECU and ignition coil connector.OKReplace the engine-ECU.
NG
Repair
3. NG
Check the harness wire between the
ignition coil connector and earth, and
repair if necessary.
Check the following connectors:
A-110, A-111NG
Repair
Check trouble symptom.
NG
Check the following items.

Check the spark plugs, spark plug
cables.

Check the compression pressure.
NG
Repair
Check the ignition coil. (Refer to
GROUP 16 – IGNITION SYSTEM.)NG
Replace
OK
OK

MPI – Troubleshooting13-17
Code No. 64 Alternator FR terminal systemProbable cause
Range of Check

Engine speed is approx. 50 r/min or more
Set Conditions

The input voltage from the alternator FR terminal is higher than 4.5 V for 20 seconds.
Open circuit in alternator FR terminal circuit

Malfunction of the engine-ECU
Measure at the alternator connector A-05.

Connect the connector. (Use the test harness: MB991519.)

Voltage between 4 (blue clip) and earth
(Engine: Idling)
(Radiator fan: Stopped)
(Headlamp: OFF → ON)
(Brake lamp: OFF → ON)
(Rear window defogger switch: OFF → ON)
OK:Voltage drops 0.2 to 3.5 VOKReplace the engine-ECU.
NG
Measure at the alternator connector A-05.

Disconnect the connector, and measure at the harness side.

Voltage between 4 and earth
(Ignition switch: ON)
OK:4.8 – 5.2 VNGCheck the following
connectors: B-60, A-88NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire
between the engine-ECU
and the alternator con-
nector.NG
Repair
OK
Replace the engine-ECU.
OK
Check the following connector: A-05NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between the engine-ECU and the alternator
connector.NG
Repair
OK
Replace the alternator.

MPI – Troubleshooting13-18
INSPECTION CHART FOR TROUBLE SYMPTOMS
Trouble symptomInspection
procedure
No.Reference page
Communication
with MUT-IIis
Communication with all systems is impossible.113-20
with MUT-II is
impossible.
Communication with engine-ECU only is impossible.213-20
Engine warning
lamp and
related parts
The engine warning lamp does not illuminate right after the
ignition switch is turned to the ON position.313-21
related partsThe engine warning lamp remains illuminating and never goes
out.413-21
StartingNo initial combustion (starting impossible)513-22
Initial combustion but no complete combustion
(starting impossible)613-23
Long time to start (improper starting)713-24
Idling stability
(Improper idling)
Unstable idling (Rough idling, hunting)813-25
(Improper idling)
Idling speed is high. (Improper idling speed)913-26
Idling speed is low. (Improper idling speed)1013-27
Idling stability
(Engine stalls)
When the engine is cold, it stalls at idling. (Die out)1113-28
(Engine stalls)
When the engine is hot, it stalls at idling. (Die out)1213-29
The engine stalls when starting the car. (Pass out)1313-30
The engine stalls when decelerating.1413-30
DrivingHesitation, sag or stumble1513-31
The feeling of impact or vibration when accelerating1613-31
The feeling of impact or vibration when decelerating1713-32
Poor acceleration1813-32
Surge1913-33
Knocking2013-33
Dieseling2113-33
Too high CO and HC concentration when idling2213-34
Low alternator output voltage (approx. 12.3 V)2313-35
