ENGINE – Water Pump and Water Hose11-35
REMOVAL AND INSTALLATION
1
2
3 4
567 8
9 11
12
13
1415 16
14 Nm 22 Nm11 Nm 24 Nm24 Nm
29 Nm 13 Nm
10
13 Nm
Removal steps
1. Water hose
2. Water hose
3. Water hose
4. Water hose
E5. Water temperature sensor
D6. Water temperature gauge unit
7. Water inlet fitting
8. ThermostatC9. Water outlet fitting
B10. Thermostat housing
A11. O-ring
A12. Water inlet pipe
A13. O-ring
14. Water pump
15. Water pump gasket
16. Knock sensor

ENGINE – Water Pump and Water Hose11-36
INSTALLATION SERVICE POINTS
AWATER PIPE / O-RING INSTALLATION
Wet the O-ring (with water) to facilitate assembly.
Caution
Keep the O-ring free of oil or grease.
BTHERMOSTAT HOUSING INSTALLATION
Apply 3 mm diameter of form-in-place gasket (FIPG) to the
location shown in the illustration.
Specified sealant:
Mitsubishi Genuine Part No. MD970389 or equivalent
CWATER OUTLET FITTING INSTALLATION
Apply 3 mm diameter of form-in-place gasket (FIPG) to the
location shown in the illustration.
Specified sealant:
Mitsubishi Genuine Part No. MD970389 or equivalent
DSEALANT APPLICATION TO ENGINE COOLANT
TEMPERATURE GAUGE UNIT
(1) When reusing the gauge unit, clean its thread.
(2) Apply the specified sealant to the thread.
Specified sealant:
3M
TM AAD Part No. 8672 or equivalent
ESEALANT APPLICATION TO ENGINE COOLANT
TEMPERATURE SENSOR
(1) When reusing the sensor, clean its thread.
(2) Apply the specified sealant to the thread.
Specified sealant:
3M
TM AAD Part No. 8731 or equivalent
6EN0594
Water pipe
O-ring
9EN0092
9EN0091

ENGINE – Rocker Arms and Camshaft11-37
ROCKER ARMS AND CAMSHAFT
REMOVAL AND INSTALLATION
1 2 3
4
5 6
78
9
1011
121314
15
16
1718
11 Nm9 Nm 10 Nm
13 Nm 21 Nm
20 Nm
Apply engine oil to all
moving parts before
installation.
Removal steps
1. Cam position sensor
2. O-ring
3. Cam position sensor support cover
4. Cam position sensor support
gasket
F5. Cam position sensing cylinder
E6. Cam position sensor support
D7. Camshaft oil seal
C8. Camshaft bearing cap rear right
C9. Camshaft bearing cap rear leftC10. Camshaft bearing cap front
C11. Camshaft bearing cap No. 5
C12. Camshaft bearing cap No. 2
C13. Camshaft bearing cap No. 3
C14. Camshaft bearing cap No. 4
B15. Camshaft
16. Rocker arm
A17. Lash adjuster
18. Oil delivery body

ENGINE – Rocker Arms and Camshaft11-38
INSTALLATION SERVICE POINTS
ALASH ADJUSTER INSTALLATION
Caution
If the lash adjuster is re-used, clean the lash adjuster.
Fit the lash adjuster onto rocker arm without allowing diesel
fuel to spill out.
BCAMSHAFT INSTALLATION
(1) Apply engine oil to the journals and cams of the camshafts.
Install the camshafts on the cylinder head.
Use care not to confuse the intake camshaft with the
exhaust one. The intake camshaft has a slit on its rear
end for driving the crankshaft position sensor.
(2) Install the crankshaft sprocket B or spacer and flange
to one end of the crankshaft, and turn the crankshaft
until the timing marks are lined up, setting No. 1 cylinder
to the TDC.
(3) Set the camshafts so that their dowel pins are positioned
at top.
CBEARING CAP INSTALLATION
(1) According to the identification mark stamped on the top
of each bearing cap, install the caps to the cylinder head.
Only “L” or “R” is stamped on front bearing cap. Cap
No. is stamped on No. 2 to No. 5 bearing caps. Rear
bearing cap has no stamping.
I: For intake camshaft side
E: For exhaust camshaft side
(2) Tighten the bearing caps in the order shown two to three
times by torquing progressively.
Tighten to the specification in the final sequence.
(3) Check to ensure that the rocker arm is positioned correctly
on the lash adjuster and valve stem end.
Camshaft sprocket side
Slit
Intake side
camshaft
Dowel pin
Cam number
Symbol identifying
intake or exhaust
Timing belt side

ENGINE – Rocker Arms and Camshaft11-39
DCAMSHAFT OIL SEAL INSTALLATION
(1) Apply engine oil to lib area of the oil seal and the front
end outside diameter of the camshaft.
(2) Using special tool install the camshaft oil seals.
ECAMSHAFT POSITION SENSOR SUPPORT
INSTALLATION
Apply 3 mm diameter of form-in-place gasket (FIPG) to the
location shown in the illustration.
Specified sealant:
Mitsubishi Genuine Part No. MD970389 or equivalent
FCAMSHAFT POSITION SENSING CYLINDER
INSTALLATION
(1) Set the No. 1 cylinder to the compression top dead center
position (so that dowel pin of the exhaust camshaft is
at the top).
(2) Install the camshaft position sensing cylinder so that the
white paint mark is facing in the direction shown in the
illustration.
INSPECTION
CAMSHAFT
Measure the cam height.
ItemStandard value mmLimit mm
Intake35.7935.29
Exhaust35.4934.99
ROCKER ARM
(1) Check the roller surface. If any dents, damage or seizure
is evident, replace the rocker arm.
(2) Check rotation of the roller. If it does not rotate smoothly
or if looseness is evident, replace the rocker arm.
(3) Check the inside diameter. If damage or seizure is evident,
replace the rocker arm.
MD998713
Camshaft
position
sensorPaint mark
Roller
Tip

ENGINE – Throttle Body11-73
THROTTLE BODY
DISASSEMBLY AND REASSEMBLY
1
2
34
5 6
73.5 Nm
3.5 Nm
Disassembly steps
AA1. Throttle position sensor (with built-
in closed throttle position switch)
2. Idle speed control body assembly
3. O-ring
B4. Throttle body
5. Fixed SAS
6. Speed adjusting screw
8. O-ringNOTE
1. The fixed SAS and the speed adjusting screw are
correctly adjusted at the factory and should not be
removed.
2. If the fixed SAS should happen to have been
removed, carry out fixed SAS adjustment.
3. If the speed adjusting screw should happen to have
been removed, carry out speed adjusting screw
adjustment.

ENGINE – Throttle Body11-74
DISASSEMBLY SERVICE POINTS
ATHROTTLE POSITION SENSOR AND IDLE AIR
CONTROL MOTOR REMOVAL
(1) Do not disassemble the sensor and motor.
(2) Do not immerse solvent to clean the sensor and motor.
Clean then with shop towel.
BTHROTTLE BODY REMOVAL
(1) Do not remove the throttle body.
(2) Check if the vacuum port or passage is clogged. Use
compressed air to clean the vacuum passage.
REASSEMBLY SERVICE POINT
ATHROTTLE POSITION SENSOR INSTALLATION
(1) Install the throttle position sensor to the throttle body
as shown in the diagram.
(2) Turn throttle position sensor 90° clockwise to set it, and
tighten screws.
(3) Check the continuity between terminal No. 3 (Idle throttle
position switch) and No. 4 (Earth).
Throttle valve conditionContinuity
Fully closedConductive
Fully openNo conductive
If there is no continuity with the throttle valve fully closed,
turn the throttle position sensor counterclockwise, and
then check again.
Throttle position sensor
Earth TPS power supply
TPS outputIdle position switch

MPI – General13-3
MPI System Diagram
1 Injector
2 ISC servo
3 Fuel pressure control valve
4 Waste gate solenoid valve
5 Secondary air control solenoid valve

Control relay

Fuel pump relay

A/C relay

Ignition coil

Exhaust temperature warning lamp

Engine warning lamp

Diagnosis output

Alternator G terminal

Fan motor relay

Tachometer

Fuel pump relay No.2 1 Oxygen sensor
2 Air flow sensor
3 Intake air temperature sensor
4 Throttle position sensor
5 Idle switch
6 Camshaft position sensor
7 Crank angle sensor
8 Barometric pressure sensor
9 High temperature sensor
10 Engine coolant temperature sensor
11 Detonation sensor

Power supply voltage

Ignition switch-IG

Ignition switch-ST

Vehicle speed sensor

A/C switch

Power steering fluid pressure switch

Alternator FR signalEngine ECU
1 Oxygen sensor
2 Air flow sensor3
Intake air tem-
perature sensor
4,
5
6 Camshaft position
sensor
7 Crank angle sensor 8 Barometric
pressure sensor
9 High temperature
sensor 10 Coolant temperature sensor
11 Detonation sensor1 Injector 2 ISC servo
3 Fuel pressure
control valve
4 Waste gate
solenoid valve 5 Secondary air
control solenoid
valveCanister
Check valveFrom
fuel
tank
Throttle position
sensor (with a
built-in
idle
switch)
Secondary
air valve
AirTo fuel
tankFuel
pressure
regulatorFrom
fuel
pump
Waste gate
actuator
Catalytic converter

MPI – Service Specifications / Sealant13-4
SERVICE SPECIFICATIONS
ItemsSpecifications
Basic ignition timing BTDC5 ± 3
Basic idle speed rpm850 ± 50
Throttle position sensor adjusting voltage mV400 – 1,000
Throttle position sensor resistance kΩ3.5 – 6.5
ISC servo coil resistance (at 20C) Ω28 – 33
Intake air temperature sensor resistance kΩAt 20C2.3 – 3.0
At 80C0.30 – 0.42
Coolant temperature sensor resistance kΩAt 20C2.1 – 2.7
At 80C0.26 – 0.36
Fuel pressure kPaWhen vacuum hose is connected230
When vacuum hose is disconnected289 – 309
Injector coil resistance Ω2 – 3
Amount of injector fuel leak drop/min1 or less
Oxygen sensor output voltage V0.6 – 1.0
Fuel pressure control valve coil resistance (at 20C) Ω28 – 36
SEALANT
ItemSpecified sealantRemark
Engine coolant temperature sensor
threaded portion3M Nut Locking Part No.4171 or equivalentDrying sealant

MPI – Troubleshooting13-6
TROUBLESHOOTING
DIAGNOSIS TROUBLESHOOTING FLOW
Refer to GROUP 00 – How to Use Troubleshooting/Inspection
Service Points.
DIAGNOSIS FUNCTION
ENGINE WARNING LAMP (CHECK ENGINE LAMP)
If an abnormality occurs in any of the following items related
to the Multipoint Fuel Injection (MPI) system, the engine
warning lamp will illuminate.
If the lamp remains illuminated or if the lamp illuminates while
the engine is running, check the diagnosis code output.
Engine warning lamp inspection items
Engine-ECU
Air flow sensor
Intake air temperature sensor
Throttle position sensor
Engine coolant temperature sensor
Crank angle sensor
Camshaft position sensor
Barometric pressure sensor
Detonation sensor
Injector
Ignition coil, power transister unit
METHOD OF READING AND ERASING DIAGNOSIS
CODES
Refer to GROUP 00 – How to Use Troubleshooting/Inspection
Service Points.
INSPECTION USING MUT-II DATA LIST AND
ACTUATOR TESTING
1. Carry out inspection by connecting the MUT-II.
If there is an abnormality, check and repair the chassis
harnesses and components.
2. After repairing, check that the abnormal input and output
have returned to normal as a result of the repairs.
3. Erase the diagnosis code memory.
4. Remove the MUT-II and carry out a road test to confirm
that the problem has disappeared.
Engine warning lamp
(check engine lamp)
