engine MITSUBISHI LANCER EVOLUTION VI 1999 Workshop Manual

– Dash Panel WIRING HARNESS
CONFIGURATION DIAGRAMS
Interior relay box
C-9
B-21 (2) Stop lamp switch
B-22 (16-B) Diagnosis connector
B-24 (26-Y) ABS-ECU
B-25 (22-Y) ABS-ECU
B-26 (2-B) Diode (for ABS circuit)
B-27 (4) Engine control relay
B-28 (4) Fuel pump relay
B-30 (14) Radio or spare connector for radio
B-31 (1) Glass antenna amplifier
B-32 (19-B) J/C (5)
B-33 (2) Blower motor matic air conditioner>B-34 (4) Blower high speed relay fully automatic air conditioner>
B-35 (22) Body harness and front door harness
(passenger’s side) combination
B-36 (2) Inside and outside air change-over
damper motor automatic air conditioner>
B-37 (4) Power transistor automatic air conditioner> or resistor
conditioner>

– Dash Panel WIRING HARNESS
CONFIGURATION DIAGRAMS
Interior relay box
NOTE
The connectors with framed
number are newly introduced.
C-11
B-59 (26-Y) Engine-ECU
B-60 (16-Y) Engine-ECU
B-61 (12-Y) Engine-ECU
B-62 (22-Y) Engine-ECU
B-63 (2) Blower motor manual air conditioner>
B-64 (13) Control harness and body harness
combinationB-65 (16-B) Control harness and body harness
combination
B-94 (13) Control harness and body harness
combination
B-95 (26) AYC-ECU
B-96 (16) AYC-ECU
B-99 (12) Diagnosis connector

SINGLE PART INSTALLATION POSITION – ECU / SensorC-17
ECU
B21A066
SENSOR
NameSymbolNameSymbol
Acceleration sensor (lateral) AYC>IKnock sensorB
Acceleration sensor (longitudinal) with ABS and AYC>IOutside air temperature sensor fully automatic air conditioner>F
Air flow sensorDO2 sensorE
Camshaft position sensorGSteering angle sensor (lateral) AYC>H
Crank angle sensorAThrottle position sensorC
Engine coolant temperature sensorG
B21A066

SINGLE PART INSTALLATION POSITION – Sensor
A
Crank angle sensor
B
Knock sensor
C
Throttle position
sensor
D
Air flow sensor
E
O2 sensor
F
Outside air
temperature sensor
G
Engine coolant
temperature sensor
Camshaft position
sensor
H
Steering angle sensor
I
Acceleration
sensor
(longitudinal)
Acceleration sensor
(lateral)
C-18

Inspection Connector / Fusible Link and
Fuse SINGLE PART
INSTALLATION POSITION –C-20
INSPECTION CONNECTOR
Engine speed
check connector
Fuel pump
check connector
FUSIBLE LINK AND FUSE
(vehicles without ABS)>
Fusible link
(vehicles with ABS)>
Fusible link

CIRCUIT DIAGRAM – Centralized JunctionC-23
CIRCUIT DIAGRAM
CENTRALIZED JUNCTION
CENTRALIZED RELAY
Connector No.NameConnector No.Name
A-82XRadiator fan motor relay (LO)A-113XCondenser fan motor relay (LO)
A-112XRadiator fan motor relay (HI)A-114XCondenser fan motor relay (HI)
Relay box in engine compartment
(A/C relay box)
