ENGINE – Throttle Body11-74
DISASSEMBLY SERVICE POINTS
ATHROTTLE POSITION SENSOR AND IDLE AIR
CONTROL MOTOR REMOVAL
(1) Do not disassemble the sensor and motor.
(2) Do not immerse solvent to clean the sensor and motor.
Clean then with shop towel.
BTHROTTLE BODY REMOVAL
(1) Do not remove the throttle body.
(2) Check if the vacuum port or passage is clogged. Use
compressed air to clean the vacuum passage.
REASSEMBLY SERVICE POINT
ATHROTTLE POSITION SENSOR INSTALLATION
(1) Install the throttle position sensor to the throttle body
as shown in the diagram.
(2) Turn throttle position sensor 90° clockwise to set it, and
tighten screws.
(3) Check the continuity between terminal No. 3 (Idle throttle
position switch) and No. 4 (Earth).
Throttle valve conditionContinuity
Fully closedConductive
Fully openNo conductive
If there is no continuity with the throttle valve fully closed,
turn the throttle position sensor counterclockwise, and
then check again.
Throttle position sensor
Earth TPS power supply
TPS outputIdle position switch

ENGINE – Turbocharger11-75
TURBOCHARGER
DISASSEMBLY AND REASSEMBLY
1 2 3
4567
8
11 Nm
Disassembly steps
F
Inspection of turbocharger waste gate
actuator operation
1. Snap pin
2. Waste gate actuator
E3. CouplingD4. Turbine housing
AC5. Snap ring
BB6. Turbine wheel assembly
7. Compressor cover
A8. O-ring

ENGINE – Turbocharger11-76
DISASSEMBLY SERVICE POINTS
ASNAP RING REMOVAL
Lay the unit with the compressor cover side facing down
and using snap ring pliers, remove the compressor cover
attaching snap ring.
Caution
When removing the snap ring, hold it with fingers to
prevent it from springing away.
BTURBINE WHEEL ASSEMBLY REMOVAL
Remove the turbine wheel assembly, striking the
circumference of the compressor cover with a plastic hammer.
The turbine wheel assembly may be a little hard to remove
due to an O-ring put on the outer circumference.
CLEANING
(1) Use a clean cleaning oil commercially available. Do not
use corrosive cleaning oils as they could damage to some
parts.
(2) Use a plastic scraper or hard brush to clean aluminum
parts.
REASSEMBLY SERVICE POINTS
AO-RING INSTALLATION
Apply a light coat of engine oil to a new O-ring and fit in
the turbine wheel assembly groove.
Caution
When installing the O-ring, use care not to damage it.
A damaged O-ring causes oil leaks.
BTURBINE WHEEL ASSEMBLY
(1) Apply a light coat of engine oil to the periphery of the
O-ring.
(2) Install the turbine wheel assembly to the compressor cover
in relation to the dowel pin.
Caution
Use care not to damage the blades of turbine wheel
and compressor wheel.
Snap ring
Turbine
wheel
assembly
O-ring
Dowel pin hole
Dowel pin

ENGINE – Turbocharger11-77
CSNAP RING INSTALLATION
Lay the assembly with the compressor cover facing down
and fit the snap ring.
Caution
Fit the snap ring with its chamfered side facing up.
DTURBINE HOUSING INSTALLATION
Install the turbine housing in relation to the dowel pin.
Caution
Use care not to damage the blades of turbine wheel.
ECOUPLING INSTALLATION
Install the coupling and tighten to the specified torque.
FWASTE GATE ACTUATOR OPERATION CHECK
Using a tester, apply a pressure of approx. 100.0 kPa to
the actuator and make sure that the rod moves.
Caution
Do not apply a pressure of more than 113.3 kPa to the
actuator. Otherwise, diaphragm may be damaged. Never
attempt to adjust the waste gate valve.
INSPECTION
TURBINE HOUSING
(1) Check the housing for traces of contact with the turbine
wheel, cracks due to overheating, pitching, deformation
and other damage. Replace with a new turbine housing
if cracked.
(2) Operate the waste gate valve lever manually to check
that the gate can be operated and closed smoothly.
Compressor
cover
Turbine wheel
assembly
Chamfered
edge
Snap ring
Dowel pin
Dowel pin hole
Coupling
Traces of contact

ENGINE – Turbocharger11-78
COMPRESSOR COVER
Check the compressor cover for traces of contact with the
compressor wheel and other damage.
TURBINE WHEEL ASSEMBLY
(1) Check the turbine and compressor wheel blades for bend,
burr, damage, corrosion and traces of contact on the
back side and replace if defective.
(2) Check the oil passage of the turbine wheel assembly
for deposit and clogging.
(3) In the case of water cooled type, check also the water
passage for deposit and clogging.
(4) Check the turbine wheel and compressor wheel for light
and smooth turning.Oil passage
Turbine wheel
Compressor
wheelWater passage

ENGINE – Alternator11-79
ALTERNATOR
DISASSEMBLY AND REASSEMBLY
1
234
5
6
7
8910
11 12
1314
Disassembly steps
A1. Front bracket assembly
B2. Alternator pulley
B3. Rotor
4. Rear bearing
5. Bearing retainer
6. Front bearing
7. Front bracketC8. Stator
9. Plate
CA10. Regulator assembly
11. Brush
12. Slinger
13. Rectifier
14. Rear bracket

ENGINE – Alternator11-80
DISASSEMBLY SERVICE POINTS
AFRONT BRACKET ASSEMBLY REMOVAL
Insert a flat tip screwdrivers or the like in the clearance between
the front bracket assembly and stator core, to pry open and
separate the stator and front bracket.
Caution
Do not insert the screwdriver too far, or the stator coil
gets damaged.
BALTERNATOR PULLEY REMOVAL
Face pulley side upward, fix the rotor with a work bench
and remove the pulley.
Caution
Use care not to damage the rotor.
CSTATOR / REGULATOR ASSEMBLY REMOVAL
(1) Unsolder the stator with a soldering iron (180 to 250
W). Complete this work within four seconds not to transfer
heat to the diode.
(2) When removing rectifier from the regulator assembly,
remove the soldered sections to rectifier.
Caution
1. Use care to make sure that the heat of the soldering
iron is not transmitted to the diodes for a long
period.
2. Use care that no undue force is exerted to the
lead wires of the diodes.
REASSEMBLY SERVICE POINTS
AREGULATOR ASSEMBLY INSTALLATION
After installing the regulator assembly, insert a wire into the
hole provided on the rear bracket while pressing in the brush
to fix the brush.
NOTE
The brush is fixed when a wire is inserted, making rotor
installation easier.
Soldered
Rear bracket
Brush
WireWire

ENGINE – Alternator11-81
BROTOR INSTALLATION
After installing the rotor, remove the wire used to fix the brush.
INSPECTION
ROTOR CHECK
(1) Check the continuity between the rotor coil slip rings,
and replace the rotor if the resistance value is not at
the standard value.
Standard value: 3 – 5 Ω
(2) Check the continuity between the slip ring and core, and
if there is continuity, replace the rotor.
STATOR CHECK
(1) Check the continuity between the coil leads, and if there
is continuity, replace the stator.
(2) Check the continuity between the coil and core, and if
there is continuity, replace the stator.
Wire

ENGINE – Alternator11-82
RECTIFIERS CHECK
(1) Inspect the (+) heat sink by checking the continuity
between the (+) heat sink and stator coil lead wire
connection terminal using a tester probe.
If there is a continuity at both, the diode is short circuited,
so replace the rectifier.
(2) Inspect the (–) heat sink by checking the continuity
between the (–) heat sink and stator coil lead wire
connection terminal using a tester probe.
If there is a continuity at both, the diode is short circuited,
so replace the rectifier.
(3) Check the diode trio by connecting an ohmmeter to both
ends of each diode and check the continuity of the three
diodes.
If there is a continuity at both ends, or if there is no
continuity, the diode is damaged so replace the recitifier.
BRUSH CHECK
(1) Measure the length of the brush protrusion shown in the
illustration, and replace the brush if the measured value
is below the limit value.
Limit: 2 mm or less
(2) The brush can be removed if the solder of the brush
lead wire is removed.
(3) When installing a new brush, insert the brush into the
holder as shown in the illustration, and then solder the
lead wires.
Protrusion
length
Soldered

ENGINE – Starter Motor11-83
STARTER MOTOR
DISASSEMBLY AND REASSEMBLY
1 23
4 5
6
789
10 1112 13 14
15
16 17
18 19
202122
23
Disassembly steps
1. Cover
2. Screw
A3. Magnetic switch
4. Screw
5. Through
6. Rear bracket
7. Brush holder
8. Brush
9. Rear bearing
B10. Armature
11. Yoke assembly
B12. Ball13. Packing A
14. Packing B
15. Plate
16. Planetary gear
17. Lever
CA18. Snap ring
CA19. Stop ring
20. Overrunning clutch
21. Internal gear
22. Planetary gear holder
23. Front bracket
