ECU MITSUBISHI LANCER IX 2006 User Guide

AIR CLEANER
INTAKE AND EXHAUST15-3
AIR CLEANER
REMOVAL AND INSTALLATIONM1151002100486
CAUTION
Parts marked by * are made of recycled-paper mixed plastic material, so observe the following pre-
cautions.
•Avoid any shock or load to these parts when removing and installing them.
•When installing, securely set the air cleaner cover clamp to the air cleaner body.
NOTE: Parts marked by * are made of recycled-paper mixed plastic material. Dispose of according to state
and local laws.
AC303618
4.0 ± 1.0 N·m
4.0 ± 1.0 N·m
10*
9* 4
1* 5
11
12 ± 1 N·m 9.0 ± 1.0 N·m
9.0 ± 1.0 N·m
AB
12 ± 1 N·m
Clamp
8*
3*
<4G1>

CHARGING SYSTEM
ENGINE ELECTRICAL16-2
CHARGING SYSTEM
GENERAL INFORMATIONM1161000100522
The charging system uses the alternator output to
keep the battery charged at a constant level under
various electrical loads.
OPERATION
AKX00183
VoltageTime
Approximately
14.4 V
AC
Rota tion of the excited fi eld coil gene rates AC volt-
age in the sta t or .
This alternatin g cur r ent is rectified throu gh diodes to
DC volt
age h a ving a waveform sh own in t he illustra
-
tion.
The average outpu t volt a ge flu c tua t es slightly with
the alternato
r load con d ition.
When the ign i tion switch is t u rned on, current flows in
the field coil and initial e
x cit a tion of the field coil
occurs.
When the st ator coil beg ins to gen erate p o wer af ter
the eng
ine is st a r ted, th e fie l d coil is excited by th e
output
curren t of th e st ator coil.
The alternator outpu t volt a ge rises as th e fie l d cur-
rent increa ses and it falls a s the field cu rrent
decre
ases. Whe n the b a ttery volt a ge (alternato r "S"
terminal volt
ag e) reaches a regulated volt ag e of
approximately 14.4
V , the field current is cut o f f.
When th
e batte ry volt age drop s be low the regulated
volt
ag e, the volt ag e regulator re gulat es th e outp u t
volt
ag e to a const ant level by contro lling the field cur
-
rent.
In addition, when th e fie l d current is const a n t, the
altern
ator ou tput volt age rise s as the e ngine spe ed
increase
s .
SYSTEM DIAGRAM
AK400308
Alternator
B
Stator coil
Engine-ECU or
Engine-A/T-ECU
G
SL
FR
<4G1>
Voltage regulator Charge warning lightIgnition switch
Battery
Field coil
+
–
AB
AL TERNA T O R SPECIFICA T IONS
Item4G14G6
Ty p eBattery voltage sensing
Rated output V/A12/8012/110
Voltage regulatorElectronic built-in type

CHARGING SYSTEM
ENGINE ELECTRICAL16-5
OUTPUT CURRENT TEST
M1161001000368
AK203362
Alternator
Ammeter
(clamp-type)
Voltmeter
Battery
Inition switch
Engine-ECU
or
Engine-A/T-ECU
Load
B FR
L
S
G
+
AH
–
Charging indicator
Brake warning light
This test determine s whethe r the a l terna t or outp u t
curren
t is normal.
1.Befo re the t e st, always be sure t o che c k the
fo llowi ng.
•Alternator inst allatio n
•Battery (Refer to GROUP 54 A − Battery − On-vehi-
cle Serv ice P.54A-5).
NOTE: The battery sh ould be sligh t ly discharg ed.
The
load neede d by a fully-charge d batte ry is
in
sufficient for an accurat e test.
•Drive belt tension
(Ref er to GROUP 1 1 A − On-vehicle Service <4G1>
P.11A-7 or GROUP 1 1 C − On-vehicle Se rvice
<4G6> P.11C-7.)
•Fusible link
• Abnormal noise from the altern ator while the
eng
ine is ru nning .
2.T u rn the ignition switch to the "LOCK" (OFF)
po sit i on.
3.Disco nnect the ne gative ba ttery cable.
CAUTION
Never use clips but tighten bolts and nuts to con-
nect the line. Otherwise loose connections (e.g.
using clips) will lead to a serious accident
because of high current.
4. Connect a clamp-type DC test ammeter with a
range of 0
− 120 A to the alternator "B" terminal
output wire.
NOTE: The way of disconnecting the alternator
output wire and of connecting the ammeter is pos
-
sibly not found the problem that the output current
is dropping due to the insufficient connection
between terminal "B" and the output wire.
5. Connect a voltmeter with a range of 0 − 20 V
between the alternator "B" terminal and the earth
[Connect the (+) lead of the voltmeter to the "B"
terminal, and then con nect the (-) lead of the
voltmeter to the earth].
6. Connect the negative battery cable.
7. Connect a tachometer or the M.U.T.-II/III (Refer to GROUP 11A
− On-vehicle Service − Idle speed
check <4G1>
P.11A-11 or GROUP 11C −
On-vehicle Service − Idle speed check <4G6>
P.11C-11).
8. Leave the hood open.

CHARGING SYSTEM
ENGINE ELECTRICAL16-7
REGULATED VOLTAGE TEST
M1161001100860
AK300727AC
BatteryIgnition switch
Engine-ECU
Engine-A/T-ECU Ammeter (clamp-type)
Load
Blue
MB991519
Voltmeter (digital-type)Red
Yellow BlackAlternator
B
FR
L
S
G
This test determine s whethe r the volt age regulator
correctly con
t rolling t he alternato r outpu t volt a ge.
1.Always b e su re to check the following b e fore th e
te st.
•Alternator inst allatio n
•Check that the b a ttery inst a lled in th e ve hicle is
fully charg
ed.
(Refer to GROUP 54A − Battery − On-vehicle Service −
Charging
P.54A - 4).
•Drive belt tension
(Ref er to GROUP 1 1 A − On-vehicle Service <4G1>
P.11A-7 or GROUP 1 1 C − On-vehicle Se rvice
<4G6> P.11C-7.)
•Fusible link
•Abnormal noise from the a l tern ator while the
eng
ine is ru nning
2.T u rn the ignition switch to the "LOCK" (OFF)
po sit i on.
3.Disco nnect the ne gative ba ttery cable.
4.Use the special tool Alternat or test harne ss
(MB99151 9) to connect a d i git a l voltmet e r
be tween the alte rnator "S" te rmin al an d earth
[Con nect the (+) lead o f the voltmeter t o the "S"
terminal, and then con nect the (-) lead of the
voltmeter to a secure earth or to the battery (-)
te rmin al].
5.Conn ect a clamp-t y pe DC test ammete r with a
ran ge of 0
− 120 A to the alte rnator "B" te rmin al
ou
tput wire
.
NOTE: The way of d i sconnectin g the a l terna t or
o
u
tput wire an d o f conn ecting the ammete r is pos
-
sibl y no t fo und th e p r oblem th at t he outp u t cur r ent
is dro
ppin g due t o the insu fficient conne ction
b
e tween te rmin al "B" an d the o u tput wire.
6.Reconne ct the negat ive battery ca ble.
7.Conn ect a t a chometer or th e M.U.T . -II/III (Refe r to
GROUP 1 1 A
− On-veh icle Service − Idle speed
check <4G1>
P.11A - 11 or GROUP 1 1 C −
On-vehicle Service − Idle speed check <4G6>
P.11C-11).
8. T u rn the ignition switch to the "ON" position an d
ch ec k t h at th e rea d i n g on t h e vo lt me te r i s eq u a l t o
th e batte ry volt age.
NOTE: If the volt a ge is 0 V , the cause is proba bly
a
n
open circuit in th e wire or fusible link betwee n
th
e alt
e
rnator "S" t e rminal a nd the battery (+) ter
-
minal.
9.T u rn all lamp s and accessorie s of f.
10.St a r t the en gine .
11 . I ncre ase t he eng ine speed to 2,5 00 r/min.
12.Read the va lue disp layed on the voltmeter when
th e alt e rnator output curren t alte rnator b e comes
1 0 A or le ss.
13.If the volt age re adin g conf orms t o the va lue in the
volt age regulation , then the volt age re gula t or is
o perating normally .

IGNITION SYSTEM
ENGINE ELECTRICAL16-30
IGNITION SYSTEM
GENERAL INFORMATIONM1163000100294
This system is equipped with two ignition coils (A and
B) with built-in power transistors for the No. 1 and
No. 4 cylinders and the No. 2 and No. 3 cylinders
respectively.
Interruption of the primary current flowing in the pri-
mary side of ignition coil A generates a high voltage
in the secondary side of ignition coil A. The high volt
-
age thus generated is applied to the spark plugs of
No. 1 and No. 4 cylinders to generate sparks. At the
time that the sparks are generated at both spark
plugs, if one cylinder is at the compression stroke,
the other cylinder is at the exhaust stroke, so that
ignition of the compressed air/fuel mixture occurs
only for the cylinder which is at the compression
stroke.
In the same way, when the primary current flowing in
ignition coil B is interrupted, the high voltage thus
generated is applied to the spark plugs of No. 2 and
No. 3 cylinders.
The engine-ECU or engine-A/T-ECU
turns the two power transistors inside the ignition
coils alternately on and off. This causes the primary
currents in the ignition coils to be alternately inter
-
rupted and allowed to flow to fire the cylinders in the
order 1-3-4-2.
The engine-ECU or engine-A/T-ECU
determines which ignition coil should be controlled
by means of the signals from the camshaft position
sensor which is incorporated in the camshaft and
from the crank angle sensor which is incorporated in
the crankshaft. It also detects the crankshaft position
in order to provide ignition at the most appropriate
timing in response to the engine operation condi
-
tions. It also detects the crankshaft position in order
to provide ignition at the most appropriate timing in
response to the engine operation conditions.
When the engine is cold or operated at high alti-
tudes, the ignition timing is slightly advanced to pro-
vide optimum performance.
When the automatic transmission shifts gears, the
ignition timing is also retarded in order to reduce out
-
put torque, thereby alleviating shifting shocks.
SYSTEM DIAGRAM
AK101074
Air flow sensor
<4G6> MAP sensor <4G1>
Intake air temperatur
sensor
Engine coolant
temperature sensor
Camshaft position
sensor
Crank angle sensor
Barometric pressure
sonsor <4G6>
Detonatoin sensor
Ignition switch-ST Engine-A/T-
ECU Engine-ECU

Ignition coil B
Cylinder No. 23 4
AG
1
Spark plug Ignition coil A
Ignition
switch
Battery

IGNITION SYSTEM
ENGINE ELECTRICAL16-42
REMOVAL AND INSTALLATION <4G6>
M1163003500440
Pre-removal and Post-installation Operation
•Valve Timing Belt Removal and Installation (Refer to
GROUP 11C P.11C-35).
AC301612
8.8 ± 1.0 N·m
8
8.8 ± 1.0 N·m
9
1
22 ± 4 N·m
4
2
3
49 ± 9 N·m49 ± 9 N·m5
22 ± 4 N·m
3.0 ± 0.5 N·m
6
7
AC
Removal steps
1.Power steering pressure switch
connector
2.A/C compressor connector
3.A/C compressor connector clamp
<>4.Power steering oil pump assembly
5.Power steering oil pump bracket
6.Rocker cover centre cover
7.Engine crank angle sensor
connector
8.Engine crank angle sensor
9.Crank angle sensor connector
bracket
REMOV A L SER VICE POINT
<> POWE R STEERING OIL PUMP
ASSEMBL
Y REMOV A L
Remove the p o wer st eering oil pump assembly from
the bra
cke t with th e hose att a ched.
NOTE: Place the remo ved power st eering oil pump
assembly in a place where it will not be a hindrance
wh
en removing an d inst a lling an d secure it with a
cord or wire.

EMISSION CONTROL
ENGINE AND EMISSION CONTROL17-8
VACUUM HOSE INSTALLATION
M1173007200107
1. When connecting the vacuum hoses, they should
be securely inserted onto the nipples.
2. Connect the hoses correctly, using the vacuum hose piping diagram as a guide.
CRANKCASE EMISSION CONTROL
SYSTEM
GENERAL INFORM ATION (CRANKCASE
EMISSION CONTROL SYSTEM)
M1173005000237
The crankcase emission control system prevents
blow-by gases from escaping inside the crankcase
into the atmosphere.
Fresh air is sent from the air cleaner into the crank-
case through the breather hose.
The air becomes mixed wi th the blow-by gases
inside the crankcase.
The blow-by gas inside the crankcase is drawn into
the intake manifold through the positive crankcase
ventilation (PCV) valve.
The PCV valve lifts the plunger according to the
intake manifold vacuum so as to regulate the flow of
blow-by gas properly.
In other words, the blow-by gas flow is regulated dur-
ing low load engine operation to maintain engine sta-
bility, while the flow is increased during high load
operation to improve the ventilation performance.
SYSTEM DIAGRAM
AK204365
Air cleaner
Air
Ventilation hose Breather hose
PCV valve
AB

EMISSION CONTROL
ENGINE AND EMISSION CONTROL17-10
SYSTEM DIAGRAM
AK204367AC
Throttle body
Canister
From
fuel
tank
OFF
ON Purge
control
solenoid
valve
Control
relay
Battery Engine-ECU <4G1-M/T, 4G6>,
Engine-A/T-ECU <4G1-A/T>
Air flow sensor <4G6>Engine coolant
temperature sensor
Intake air
temperature sensor
Barometric pressure
sensor <4G6>
Manifold absolute pressure
(MAP) sensor <4G1>
COMPONENT LOCA
TION (EV A PORA TIVE
EMISSION CONTROL SYSTEM)
M1173 0075 0021 6
AK300769
<4G1>
AB
Purge control
solenoid valve
AK300770
<4G6>
AB
Purge control
solenoid valve
PURGE CONTROL SYSTEM CHECK
M1173 0014 0029 9
AK300771
<4G1>
AB
Plug
Vacuum hose
AK300772
<4G6>
AB
Plug
Vacuum hose
1.Disco nnect the vacu um h o se (re d str i pe) fro m
th rottle body and conne ct it to a h and vacu um
pu m p .

EMISSION CONTROL
ENGINE AND EMISSION CONTROL17-13
SYSTEM DIAGRAM
AK300775
Manifold absolute
pressure (MAP) sensor
Engine-ECU ,
Engine-A/T-ECU
Engine coolant
temperature sensor
Crank angle sensor
EGR
control
solenoid
valve
EGR valve OFF
ON Control
relay
Battery
AB
<4G1>

AK302349AB
<4G6>EGR
control
Solenoid
valve
EGR valve OFF
ON
Control
relay
Battery Engine-ECU
Barometric pressure
sensor
Air flow sensor
Engine coolant
temperature sensor
Crank angle sensor
EMISSION CONTROL
ENGINE AND E M ISSION CON T ROL17-14
COMPONENT LOCATION (EGR SYSTEM)
M1173 0076 0022 4
AK300776
<4G1>
AB
EGR control
solenoid valve
AK300778
<4G6>
AB
EGR control
solenoid valve
AK300777
<4G1>
AB
EGR valve
AK300779AB
<4G6>
EGR valve
