Diagrams MITSUBISHI LANCER IX 2006 Service Manual

80-1
GROUP 80
CONFIGURATION
DIAGRAMS
CONTENTS
OVERALL CONFIGURATION DIAGRAM
OVERALL WIRING DIAGRAM
. . . . . . . . . . . . . . . . . . . . . 80-2
OVERALL WIRING DIAGRAM
. . . . . . . . . . . . . . . . . . . . 80-3
OVERALL WIRING DIAGRAM
. . . . . . . . . . . . . . . . . . . . 80-4
OVERALL WIRING DIAGRAM
. . . . . . . . . . . . . . . . . . . . 80-5
ENGINE COMPARTMENT
ENGINE COMPARTMENT . . . . . . . 80-6
ENGINE COMPARTMENT . . . . . . 80-8
ENGINE AND TRANSMISSION
ENGINE AND TRANSMISSION
<4G1-MPI (LHD)> . . . . . . . . . . . . . . . . . . . . 80-10
ENGINE AND TRANSMISSION
<4G1-MPI (RHD)> . . . . . . . . . . . . . . . . . . . 80-14
ENGINE AND TRANSMISSION
<4G6-MPI (LHD)> . . . . . . . . . . . . . . . . . . . . 80-18
ENGINE AND TRANSMISSION
<4G6-MPI (RHD)> . . . . . . . . . . . . . . . . . . . 80-22
DASH PANEL
DASH PANEL . . . . . . . . . . . . . . . . . 80-26
DASH PANEL . . . . . . . . . . . . . . . . . 80-32
FLOOR AND ROOF
FLOOR AND ROOF . . . . 80-38
FLOOR AND ROOF . . . . 80-40
FLOOR AND ROOF . . . . 80-42
FLOOR AND ROOF . . . 80-44
DOOR
DOOR . . . . . . . . . . . . . . . . . . . . . . . 80-46
DOOR . . . . . . . . . . . . . . . . . . . . . . . 80-48
TRUNK (LUGGAGE COMPARTMENT)
TRUNK (LUGGAGE COMPARTMENT)
. . . . . . . . . . . . . . . . . . . . . 80-50
TRUNK (LUGGAGE COMPARTMENT)
. . . . . . . . . . . . . . . . . . . . . 80-51
TAILGATE
TAILGATE . . . . . . . . . . . 80-52
TAILGATE . . . . . . . . . . . 80-53

OVERALL CONFIGURATION DIAGRAM
CONFIGURATION DIAGRAMS80-2
OVERALL CONFIGURATION DIAGRAM
OVERALL WIRING DIAGRAM M1801000101261
AC301175AB
Front wiring
harness (RH) Control wiring
harness Instrument panel
wiring harness Roof wiring
harnessFloor wiring
harness (RH)
Battery wiring
harness Front wiring
harness (LH) Front door
wiring harness
Floor wiring
harness (LH) Fuel wiring
harnessRear door
wiring harness
Front bumper
wiring harness
Rear bumper
wiring harness
*
*
NO
TE: .
1.This illu stration shows o n ly major wirin g harne sses.
2.*: also eq uipp ed at t he rig h t side.

OVERALL CONFIGURATION DIAGRAM
CONFIGURATION DIAGRAMS80-3
OVERALL WIRING DIAGRAM
M1801000101272
AC301176AB
Front wiring
harness (RH) Control wiring
harness Instrument panel
wiring harness Roof wiring
harnessFloor wiring
harness (RH)
Battery wiring
harness Front wiring
harness (LH) Front door
wiring harness
Floor wiring
harness (LH) Fuel wiring
harnessRear door
wiring harness
Front bumper
wiring harness
Rear bumper
wiring harness
*
*
NO
TE: .
1.This illu stration shows o n ly major wirin g harne sses.
2.*: also eq uipp ed at t he rig h t side.

OVERALL CONFIGURATION DIAGRAM
CONFIGURATION DIAGRAMS80-4
OVERALL WIRING DIAGRAM
M1801000101283
AC301177AB
Front wiring
harness (RH)Control wiring
harness Instrument panel
wiring harness Roof wiring
harnessFloor wiring
harness (RH)
Battery wiring
harness Front wiring
harness (LH) Front door
wiring harness
Floor wiring
harness (LH) Fuel wiring
harnessRear door
wiring harness
Front bumper
wiring harness
Rear bumper
wiring harness
*
*
Tailgate wiring
harness
NO
TE: .
1.This illu stration shows o n ly major wirin g harne sses.
2.*: also eq uipp ed at t he rig h t side.

OVERALL CONFIGURATION DIAGRAM
CONFIGURATION DIAGRAMS80-5
OVERALL WIRING DIAGRAM
M1801000101294
AC301178AB
Front wiring
harness (RH)Control wiring
harness Instrument panel
wiring harness Roof wiring
harnessFloor wiring
harness (RH)
Battery wiring
harness Front wiring
harness (LH) Front door
wiring harness
Floor wiring
harness (LH) Fuel wiring
harnessRear door
wiring harness
Front bumper
wiring harness
Rear bumper
wiring harness
*
*
Tailgate wiring
harness
NO
TE: .
1.This illu stration shows o n ly major wirin g harne sses.
2.*: also eq uipp ed at t he rig h t side.

ENGINE COMPARTMENT
CONFIGURATION DIAGRAMS80-6
ENGINE COMPARTMENT
ENGINE COMPARTMENT M1801000302440
AC301123
Front wiring
harness (RH)
A-01
A-32
A-31
A-29
A-28
A-27
A-26
A-25 A-23
A-24 A-22
AC
1
Front bumper
wiring harness
Connector colour
code
B : Black
BR : Brown
G : Green
GR : Grey
L : Blue
None : Milk white
O : Orange
R : Red
V : Violet
Y : Yellow
Connector
symbol
A
A-01(2-GR)Side turn signal lamp (RH)
A-02(2-GR)Side turn signal lamp (LH)
A-03(2-B)Wheel speed sensor (Front: LH)
A-04X(4)Front fog lamp relay or spare connector
(for front fog lamp)
A-05X(4)Horn relay
A-09X(4)Fan control relay
A-10X(11)Front-ECU
A-11X(11)Front-ECU
A-12(2-B)Front wiring harness (LH) and control
wiring harness combination
A-13(12-B)Front wiring harness (LH) and control
wiring harness combination
A-14(3-B)Headlamp (LH)
A-15(6-B)Front combination lamp (LH)
A-16(2)Front turn signal lamp (LH)

ENGINE COMPARTMENT
CONFIGURATION DIAGRAMS80-8
ENGINE COMPARTMENT
M1801000302451
AC301126
Front wiring
harness (RH)
A-01
A-32
A-31
A-29 A-30
A-27
A-26
A-25 A-23
A-24 A-22
AC
1
Front bumper
wiring harness
Connector colour
code
B : Black
BR : Brown
G : Green
GR : Grey
L : Blue
None : Milk white
O : Orange
R : Red
V : Violet
Y : Yellow
Connector
symbol
A
A-01(2-GR)Side turn signal lamp (RH)
A-02(2-GR)Side turn signal lamp (LH)
A-03(2-B)Wheel speed sensor (Front: LH)
A-04X(4)Front fog lamp relay or spare connector
(for front fog lamp)
A-05X(4)Horn relay
A-09X(4)Fan control relay
A-10X(11)Front-ECU
A-11X(11)Front-ECU
A-12(2-B)Front wiring harness (LH) and control
wiring harness combination
A-14(3-B)Headlamp (LH)
A-15(6-B)Front combination lamp (LH)
A-16(2)Front turn signal lamp (LH)
A-17(2-B)Front fog lamp (LH)
