MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual

Interior lights 5-184 Features and controls
5
The accessory can be operated when the igni- tion switch is in any position.To use a “plug-in” type accessory, open the cover, then insert the plug in the socket.
N00525300487
N00525801287
The dome light can be turned on by sliding the dome light switch.
Type 3 Type 1Type 2
Interior lights 1- Cargo room light
P.5-186
2- Dome light (Rear)(if so equipped)
 P.5-185
3- Dome light (Front)/Reading lights
 P.5-184
Dome light (Front)/Reading lights Dome light (Front)
1- (DOOR) The dome light comes on when any door or the rear hatch is opened. When all the doors and the rear hatch are closed, the dome light goes off after approximately 30 seconds. However, the light goes off immediately if:
BK0200700US.book
184 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Interior lights
Features and controls 5-185
5
N00553800070
Regardless of the dome light switch position, when you press the lens, the light on the side that is pressed illuminates; when you pressthe lens again, the light goes off.
N00525401502
The dome light can be turned on by sliding the dome light switch.
 The doors and the rear hatch are closed while the ignition switch is in the “ON” position.  The driver’s door is closed after all the other doors and the rear hatch are closed while the lock knob of the driver’s door is in the lock position.  The doors and the rear hatch are closed and the power door lock switch is used to lock the doors.  The keyless entry system remote con- trol transmitter is used to lock the doors and the rear hatch.  In vehicles equipped with the F.A.S.T.-key, the doors and the rear hatch are locked using the F.A.S.T.- key.NOTE
 When the engine is started using the key while the doors and rear hatch are closed, ifyou remove the key, the dome light will illu- minate for approximately 30 seconds before going off.  When the engine is started using the F.A.S.T.-key while the doors and rear hatch are closed, if the ignition switch is moved to the “LOCK” position, the dome light willilluminate for approximately 30 seconds before going off.  The time until the light goes off can be adjusted. See your authorized Mitsubishi Motors dealer for details.
2- (OFF) The dome light goes off.
Reading lights Dome light (Rear)
(if so equipped)
1- (ON) The dome light comes on.2- (
)
The dome light comes on when any door or the rear hatch is opened. When all the doors and the rear hatch are closed, the dome light goes off after approximately 30 seconds. However, the light goes off immediately if:  The doors and the rear hatch are closed while the ignition switch is in the “ON” position.  The driver’s door is closed after all the other doors and the rear hatch are closed while the lock knob of the driver’s door is in the lock posi- tion.
BK0200700US.book
185 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Interior lights 5-186 Features and controls
5
N00526200063
N00526301478
If any of the interior lights are left on with the ignition switch in the “LOCK” position, the lights go off automatically after about 30minutes. The lights come on again if the ignition switch is turned to the “ON” or “ACC” posi-tion, any door or the rear hatch is opened andclosed, or the keyless entry system or F.A.S.T.-key is operated.
 The door and the rear hatch are closed and the power door lock switch is used to lock the doors.  The keyless entry system remote control transmitter is used to lock the doors and the rear hatch.  In vehicles equipped with the F.A.S.T.-key, the doors and the rear hatch are locked using the F. A . S . T. - k e y.
NOTE
 When the engine is started using the key while the doors and the rear hatch are closed,if you remove the key, the dome light will illuminate for approximately 30 seconds before going off.  When the engine is started using the F.A.S.T.-key while the doors and the rearhatch are closed, if the ignition switch is moved to the “LOCK” position, the dome light will illuminate for approximately 30seconds before going off.  The time until the light goes off can be adjusted. See your au
thorized Mitsubishi
Motors dealer for details.3- (OFF) The dome light goes off.
Cargo room light
1- (ON) The light illuminates regardless of whether the rear hatch is open or closed. 2- The light illuminates when the rear hatch is opend, and goes off when the rear hatch is closed. 3- (OFF) The light remains off regardless of whether the rear hatch is open or closed.
Interior light auto-cutout func- tion (dome light and other lights)
NOTE
 The interior light auto-cutout function can be deactivated. The time until the lights auto-matically go off can be adjusted. See your authorized Mitsubishi Motors dealer for details.
BK0200700US.book
186 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Storage spaces
Features and controls 5-187
5
N00526400498
N00551500246
To open the glove compartment, pull the lever (A).
There is a card holder on the inside of the glove compartment.
Storage spaces
CAUTION Never leave lighters, carbonated drink cans, or spectacles in the cabin when parking the vehicle in hot sunshine. The cabin will become extremely hot, so lighters and otherflammable items may catch fire and unopened drink cans (including beer cans) may rupture. The heat may also deform orcrack plastic spectacle parts. Keep the lids of stor
age spaces closed while
driving the vehicle. A lid or the contents of a storage space could otherwise cause injuries during a sudden stop.NOTE
 Do not leave valuables in any storage space when leaving the vehicle.
1- Cargo floor boxes (if so equipped)
 P.5-189
2- Floor console box
P.5-188
3- Front console tray (if so equipped)
 P.5-188
4- Front console boxes (if so equipped)
 P.5-188
5- Glove compartment
P.5-187
Glove compartment
WA R N I N GAn open glove compartment door can cause a serious injury or death to the front passenger in an accident, even if the pas- senger is wearing his/her seat belt. Alwayskeep the glove compartment door closed when driving. NOTE
 The USB input terminal (if so equipped) is located in the glove compartment. For details, refer to “USB input terminal” on page 5-180.
Card holder
BK0200700US.book
187 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Storage spaces 5-188 Features and controls
5
N00547800017
The front console tray is on the front console part.
N00546401097
To open, push the lid.
N00551600175
To open the floor console box, lift the rightrelease lever (A) and raise the lid.
NOTE
 Up to 2 cards will fit in the card holder.
Front console tray
(if so equipped)
CAUTIONDo not use the front c
onsole tray as an ash-
tray. This could cause a fire.
Front console boxes
(if so equipped)
Upper box

Lower box

CAUTION Do not use the front console boxes as an ash- tray. This could cause a fire.
Floor console box
BK0200700US.book
188 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cup holder
Features and controls 5-189
5
The tissue holder (A) is located on the under- side of the floor console box lid.
N00552300023
The boxes for storing articles are locatedinside the luggage compartment. To use the boxes, raise the lids (A).
N00527300351
The cup holder is located the middle of the floor console. The cup holder is designed for holding cups or drink-cans securely.
To use the cup holder, open up the lid.
Tissue holder
Cargo floor boxes
(if so equipped)
Cup holder For the front seat
Ty p e 1 Ty p e 2
BK0200700US.book
189 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Bottle holder 5-190 Features and controls
5
N00537000162
This cup holder is located
in the rear seat arm
rest (A). Pull the rear arm rest down to use the cupholder.
N00502800049
There are bottle holders located on both sides of the front seats.
N00528200070
CAUTION Do not drink beverages while driving your vehicle. This is distracting and could cause an acci- dent.
For the rear seat
Bottle holder
CAUTION Do not drink beverages while driving your vehicle. This is distracting and could cause an accident. Vibration and shaking while driving may cause beverages to spill. Be very careful, as spilling hot beverages could cause burns.NOTE
 Make sure all lids are tightly closed when storing beverages that are in plastic bottles, etc.  Some beverages may not be stored, depend- ing on the size and shape of the plastic bot-tles, etc.
Rear shelf panel
WA R N I N G To avoid obstructing your rearward view, never place anything on the rear shelfpanel. In the event of sudden braking or an accident, objects placed on the rear shelf panel could strike occupants causinginjury.
BK0200700US.book
190 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Dual height adjustable cargo
floor board (if so equipped) Features and controls 5-191
5
1. Insert the concave portion (A) on the underside of the rear shelf panel into the inside protruding portion (B) on bothsides of the luggage compartment.
2. Hang the strap (C) of the rear shelf panel on the hook (D).
Follow this procedure in reverse to remove.
N00562400027
To increase the capacity of the luggage com- partment, the board can be lowered.
1. Raise the rear part of the board.
To install
WA R N I N G Lightly push the rear shelf panel to make sure that the concave portion (A) is setfirmly in the protruding portion (B) on both sides of the luggage compartment. Unsecured rear shelf panel can strikeoccupants causing injury in the event of sudden braking or an accident.
To remove Dual height adjustable cargo floor board
(if so
equipped)
CAUTION The exhaust pipe remains hot for a while after stopping the engine, so be sure not to touch it.
 Do not stand behind the exhaust pipe when loading and unloading luggage. The heat from the exhaust could cause burns. Handle the board with care so as to not injure your fingers and your hands.NOTE
 Before handling the board, remove any lug- gage from the luggage compartment.  When loading heavy luggage, the board must be set in the lower position to avoid damage to the board.CAUTION
BK0200700US.book
191 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Assist grip 5-192 Features and controls
5
2. Pull the board towa
rd you until the front
part is lowered. 3. Push the board in all the way with the front part lowered, then set the board into place. 4. Make sure the board is set firmly in place. 5. Follow this procedure in reverse to return the board to its original position.
N00559000029
These grips are to support the body by hand while seated in the vehicle.
N00553600124
There is a coat hook on the rear seat assistgrip of the driver’s side.Assist grip
CAUTION Do not use the assist grips when getting into or out of the vehicle. The assist grips could detach and cause an accident.
Coat hook
WA R N I N G Do not put a hanger or any heavy or pointed object on the coat hook. If the cur- tain airbag was activated, any such item could be propelled away with great forceand could prevent the curtain airbag from inflating correctly. Hang clothes directly on the coat hook (without using a hanger).Make sure there are no heavy or sharp objects in the pockets of clothes that you hang on the coat hook.
BK0200700US.book
192 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

6
